FORESIGHT GCQuad User manual

USER GUIDE

THANK YOU FOR CHOOSING THE GCQUAD
We listened to what you wanted - and created the most
accurate, versatile and game-enhancing ball and club
analysis solution available today.
The GCQuad is designed to deliver years of trusted,
reliable performance. From range practice to full
immersion simulation, whether for education or
entertainment, the GCQuad will truly change your game.
This user manual will help you better understand the
proper set-up, operation, and care of your GCQuad.
Please read it carefully and refer to it should an issue arise
during use. If you need more assistance, please contact
our customer service team for prompt, personal attention.
WELCOME TO THE REVOLUTION

INCLUDED
WITH YOUR
GCQUAD
PERFORMANCE
PACKAGE GCQuad
Quadrascopic System
Power Adapter/Cable
Input 100-240VAC/50-60 Hz
Output 15VDC/2.4 Amps
GCQuad
Lithium Battery
Club Marker
Dispenser
Reflective
Alignment Stick
USB Type-C
Cable
TABLE OF
CONTENTS FEATURE OVERVIEW
GETTING STARTED
SYSTEM OPTIONS
BALL PLACEMENT & HITTING
APPLYING CLUB MARKER
TARGET ALIGNMENT
CONNECTING THE DEVICEe
BATTERY CARE
STORAGE & MAINTENANCE
SAFETY
01
05
07
15
17
25
27
28
31
32

FEATURE
OVERVIEW
FRONT
12
POWER BUTTON
Turns device on/off
LCD DISPLAY
Displays ball placement graphic,
ball and club data, and system
options menu
Displays ball
4 TRACKING CAMERAS
High speed cameras used for ball
placement and tracking
urns device on/off
BACK
CARRYING HANDLE
POWER LED INDICATOR
Indicates whether the GCQuad is
receiving power through the power
adapter
POWER PORT
Connector for the power adapter
(included) to recharge the battery
or to operate on external power
USB TYPE-C PORT
Connector for USB Type-C cable
(included) to connect to external
PC (optional)
ETHERNET PORT
Connector for Ethernet cable (not
included) to connect to network or
external PC (optional)

#00000
LCD DISPLAY
DISPLAY BACKLIGHT
Illuminates the display for better
viewing in low light situations
BACK KEY
Return to previous screen
OK KEY
Used to access Main Menu
and select system options
LEFT HANDED TRACKING
Switches GCQuad to left handed
tracking mode, indicated by the
blinking LED
POWER BUTTON
Turns device on/off
CURSOR KEYS
Used to toggle between ball/club
data and navigate system options
RIGHT HANDED TRACKING
Switches GCQuad to right handed
tracking mode, indicated by the
blinking LED
SERIAL NUMBER LABEL
Indicates product serial number
and MAC address
BATTERY RELEASE LEVERS
Used to release removable
battery from the GCQuad
Displays ball
KICKSTAND
Deployed to provide stability on
uneven surfaces
BATTERY
Removable lithium-ion power
pack
34
