Forest LEAN-TO LOG STORE User manual

20mm
REMINDER
Always pre-drill before
screwing.
IMPORTANT
Assembly requires 2+
adults.
Tape Measure Drill & 2-3mm
Drill Bits
Pozidrive
Screwdriver
Hand Saw Fit For Purpose
Ladder
Hammer
4 x 60mm Screws
QTY: 25
4 x 50mm Screws
QTY: 20
3.5 x 25mm Screws
QTY: 8
4 x 40mm Screws
QTY: 6
Felt Tacks
QTY: 30
Mending Plate
QTY: 2
5 x 90mm Screws
QTY: 12
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
EU Authorised Representative: Authorised Representative Service, 77 Camden Street Lower Dublin, D02 XE80, Ireland
Missing something or need more information?
Call our aftersales team on
0333 321 3142
Visit our website for spare instructions and
more information
www.forestgarden.co.uk
LEAN-TO LOG STORE
INSTRUCTIONS
ISSUE: 0123
We recommend using the following
tools (not supplied):
FIXING PACK CONTAINS:
FIXING PACK CODE: LTLSMFP
Using the hand saw, cut the middle Cover Strip(s)
down by 20mm. Re-attach the middle Cover Strips(s)
back to their original place.
Whilst attaching the roof, the lean-to log store can now
be assembled. Detach the middle Cover Strip(s) from
the side you are attaching your log store.
1
CHECK AND TIGHTEN ALL THE FIXINGS APPLIED TO THIS PRODUCT ON A REGULAR BASIS.
PLEASE KEEP PLASTIC BAGS AND SMALL PARTS AWAY FROM CHILDREN
Making British gardens great

936mm
936mm
25MM
SCREWS
60MM
SCREWS
60MM
SCREWS
90MM
SCREWS
90MM
SCREWS
60MM
SCREWS
3 4
Turn the Floors upside down and connect them together
using the mending plates. Position the Floor next to
the shed. (7x5 & 8x6 have 2 x oors)
Position and attach the Left Hand Side Panel to the
Floor. Ensure the panel is ush to the edge of the Floor
and placed underneath the shed’s roof batten.
5
LEFT HAND SIDE PANEL
Position the Floor next to the shed. This will now be
able to t underneath the cut Cover Strip(s) as shown
above. (6x4 only has 1 x oor)
Secure the Posts to the oor bearers using 90mm
screws. Secure the panels to the posts using 60mm
screws. Ensure the Posts are ush to the Floor and panel
as shown above. (6x4 only has 2 x posts)
Position and attach the Right Hand Side Panel to the
Floor. Ensure the panel is ush to the edge of the Floor
and placed underneath the shed’s roof batten.
Secure the Posts to the oor bearers using 90mm
screws. Secure the panels to the posts using 60mm
screws. Ensure the Posts are ush and positioned using
the measurement provided. (7x5 & 8x6 have 3 x posts)
POST
6x4 ONLY
2
FLOOR
7x5 & 8x6 ONLY
FLOOR
RIGHT HAND SIDE PANEL
6x4 ONLY 7x5 & 8x6 ONLY

60MM
SCREWS
50MM
SCREWS 90MM SCREWS
60MM
SCREWS 50MM
SCREWS 60MM
SCREWS
60MM
SCREWS
6
7
Position the Roof. Ensure the Roof is butt up to the
shed’s roof and the Posts sit inside the framework.
If you have 3 x Posts, ensure the central Post is up
against the middle batten attached to the Roof.
Secure the Roof to the shed’s roof batten. Please take
precautions when entering the log store to prevent
any head injuries.
Secure the side panels to the shed. Ensure to screw
through the overlap board, into the shed’s framework
using 60mm screws. The 8x6 side panel’s need to be
screwed into the shed at an angle using 90mm screws.
8
9
Position and secure the Side Braces. Secure 1 x Side
Brace to a side panel and Post as shown above.
ROOF ROOF
SIDE BRACE
Position and secure the Middle Brace if you have 3 x
Posts, to the roof batten and Post as shown above.
7x5 & 8x6 ONLY
7x5 & 8x6 ONLY
MIDDLE BRACE

50mm
50MM
SCREWS 50MM SCREWS
Cut-Resistant
Gloves
Protective Glasses Protective Boots Protective Mask Working At
Height
HEALTH & SAFETY
THE ROOF OF THIS LOG STORE IS NOT A LOAD BEARING STRUCTURE
PLEASE MIND YOUR HEAD WHEN CONSTRUCTING AND USING YOUR LOG STORE
We strongly recommend that PPE (Personal Protective Equipment) is used throughout your build to ensure you are
protected from any potential health and safety risks. Do not exempt yourself from wearing PPE.
Fix the Roof to the side Posts as shown above.
Follow the main assembly instructions to begin felting
your shed, and then continue down to felt your log
store. Use a measuring tape to measure out 3/4 equal
lengths & cut with a sharp knife. Hammer the tacks into
the felt at 150mm intervals.
Position and secure the Fascia’s to the log store once
the sheds Fascia’s have been attached.
12
Fix the Roof to the central Post as shown above.
7x5 & 8x6 ONLY
10
11
FASCIA

TREATED TIMBER CONTAINING A BIOCIDAL PRODUCT
CONTROL OF WOOD DESTROYING ORGANISMS
Active Ingredients - Propiconazole, Tebuconazole, IPBC, Permethrine, Benzyl-C12-16-Alkyldimethyl Chlorides. (Dip Treated)
Basic Copper Carbonate, DDA Carbonate, DDA Chloride. (Pressure Treated)
Wear gloves when handling. Avoid inhalation of sawdust. Do not use in contact with drinking water or food. Do not use for animal
bedding or in sh ponds. Dispose of treated wood responsibly.
Use the labelled components to help identify the part code and description.
CHECK YOU HAVE ALL YOUR PARTS PRIOR TO ASSEMBLY.
(The parts do not have codes on them. They are listed below should you need to order one.)
Timber is a natural material of which will shrink and swell as a result of varying moisture content.
Assembly of damaged parts may be deemed to be acceptance and this may affect the remedies you are entitled to. If the product is not constructed
in accordance with the instructions, or is altered in anyway (e.g. painted), the manufacturer cannot be held liable for any resulting damage.
The components provided may be heavy. Please lift with caution and with a minimum of 2 people.
G HA B C D E F I
J K L
Label Part Code Description No.
ALTKMFL1802PT Floor 600x1802mm 1
DLTKLHSIDEPT Left Hand Side Panel 600x1543mm 1
ELTKRHSIDEPT Right Hand Side Panel 600x1543mm 1
F75751343AI63PT Post 75x75x1343mm 2
G64LTKRF Roof 742x1858mm 1
J45280500AII32PT Side Brace 45x28x500mm 2
LP38120751PT Fascia 38x12x751mm 2
Label Part Code Description No.
BLTKMFL1049PT Floor 600x1049mm 2
DLTKLHSIDEPT Left Hand Side Panel 600x1543mm 1
ELTKRHSIDEPT Right Hand Side Panel 600x1543mm 1
F75751343AI63PT Post 75x75x1343mm 3
H75LTKRFV2 Roof 736x2153mm 1
J45280500AII32PT Side Brace 45x28x500mm 2
K45450500AII32PT Middle Brace 45x45x500mm 1
MP59120740PT Fascia 59x12x740mm 2
Label Part Code Description No.
CLTKMFL1168PT Floor 600x1168mm 2
DLTKLHSIDEPT Left Hand Side Panel 600x1543mm 1
ELTKRHSIDEPT Right Hand Side Panel 600x1543mm 1
F75751343AI63PT Post 75x75x1343mm 3
I86LTKRF Roof 742x2392mm 1
J45280500AII32PT Side Brace 45x28x500mm 2
K45450500AII32PT Middle Brace 45x45x500mm 1
MP59120740PT Fascia 59x12x740mm 2
Contact our aftersales team with your product code if you are missing your felt.
6x4 Lean-To Log Store (OPA46LTKM)
7x5 Lean-To Log Store (OPA57LTKM)
8x6 Lean-To Log Store (OPA68LTKM)
Contact our aftersales team with your product code if you are missing your felt.
Contact our aftersales team with your product code if you are missing your felt.
Label Part Code Description No.
ALTKMFL1802PT Floor 600x1802mm 1
DLTKLHSIDEPT Left Hand Side Panel 600x1543mm 1
ELTKRHSIDEPT Right Hand Side Panel 600x1543mm 1
F75751343AI63PT Post 75x75x1343mm 2
G64LTKRF Roof 742x1858mm 1
J45280500AII32PT Side Brace 45x28x500mm 2
LP38120751PT Fascia 38x12x751mm 2
Label Part Code Description No.
BLTKMFL1049PT Floor 600x1049mm 2
DLTKLHSIDEPT Left Hand Side Panel 600x1543mm 1
ELTKRHSIDEPT Right Hand Side Panel 600x1543mm 1
F75751343AI63PT Post 75x75x1343mm 3
H75LTKRFV2 Roof 736x2153mm 1
J45280500AII32PT Side Brace 45x28x500mm 2
K45450500AII32PT Middle Brace 45x45x500mm 1
MP59120740PT Fascia 59x12x740mm 2
Label Part Code Description No.
CLTKMFL1168PT Floor 600x1168mm 2
DLTKLHSIDEPT Left Hand Side Panel 600x1543mm 1
ELTKRHSIDEPT Right Hand Side Panel 600x1543mm 1
F75751343AI63PT Post 75x75x1343mm 3
I86LTKRF Roof 742x2392mm 1
J45280500AII32PT Side Brace 45x28x500mm 2
K45450500AII32PT Middle Brace 45x45x500mm 1
MP59120740PT Fascia 59x12x740mm 2
Contact our aftersales team with your product code if you are missing your felt.
6x4 Lean-To Log Store (OPA46LTKM)
7x5 Lean-To Log Store (OPA57LTKM)
8x6 Lean-To Log Store (OPA68LTKM)
Contact our aftersales team with your product code if you are missing your felt.
Contact our aftersales team with your product code if you are missing your felt.
Label Part Code Description No.
ALTKMFL1802PT Floor 600x1802mm 1
DLTKLHSIDEPT Left Hand Side Panel 600x1543mm 1
ELTKRHSIDEPT Right Hand Side Panel 600x1543mm 1
F75751343AI63PT Post 75x75x1343mm 2
G64LTKRF Roof 742x1858mm 1
J45280500AII32PT Side Brace 45x28x500mm 2
LP38120751PT Fascia 38x12x751mm 2
Label Part Code Description No.
BLTKMFL1049PT Floor 600x1049mm 2
DLTKLHSIDEPT Left Hand Side Panel 600x1543mm 1
ELTKRHSIDEPT Right Hand Side Panel 600x1543mm 1
F75751343AI63PT Post 75x75x1343mm 3
H75LTKRFV2 Roof 736x2153mm 1
J45280500AII32PT Side Brace 45x28x500mm 2
K45450500AII32PT Middle Brace 45x45x500mm 1
MP59120740PT Fascia 59x12x740mm 2
Label Part Code Description No.
CLTKMFL1168PT Floor 600x1168mm 2
DLTKLHSIDEPT Left Hand Side Panel 600x1543mm 1
ELTKRHSIDEPT Right Hand Side Panel 600x1543mm 1
F75751343AI63PT Post 75x75x1343mm 3
I86LTKRF Roof 742x2392mm 1
J45280500AII32PT Side Brace 45x28x500mm 2
K45450500AII32PT Middle Brace 45x45x500mm 1
MP59120740PT Fascia 59x12x740mm 2
Contact our aftersales team with your product code if you are missing your felt.
6x4 Lean-To Log Store (OPA46LTKM)
7x5 Lean-To Log Store (OPA57LTKM)
8x6 Lean-To Log Store (OPA68LTKM)
Contact our aftersales team with your product code if you are missing your felt.
Contact our aftersales team with your product code if you are missing your felt.
M
