Formax Atlas C102 User manual

Atlas C102
Auto-Feed High-Speed Creaser
OPERATOR MANUAL
Second Edition
12/2019

Page 2 CREASING
INDEX
THE STACKER ASSEMBLY
Setting the Height Adjustable Stacker unit 28
Setting the Optional Stacker unit 30
PERFORATING
Equipment, spares 31
Setting the perforating blade position 32
THE BLADE ASSEMBLY
Setting the blade pressure 34
REPLACING CREASING BLADE SETS
Installing crease blade sets 35
Spares 37
CROSS PERFORATING KIT 38
TROUBLE SHOOTING 39
DISPATCH KIT 47
ACCESSORIES & OPTIONS 48
RECOMMENDED SPARES 49
FUSE POSITIONS AND RATINGS 51
PRODUCT RECYCLING & DISPOSAL 52
INTRODUCTION
The Atlas C102 Creaser PAGE 3
SAFETY Do’s & Don’ts 4
THE ATLAS C102 CREASER
Labeled Picture 6
THE CONTROLS
The switch panel 7
Features on the switch panel 7
QUICK START GUIDE 8
SCREEN CALIBRATION 19
OPERATING THE MACHINE
Setting the machine 20
Setting up a job 24
Loading & saving 25
Paper jamming 27
Page 3
SYSTEM
INTRODUCTION
AutoCreaser Pro 33A
AutoCreaser Pro 33A
The blade and anvil are mechanically controlled over their entire length
and can be adjusted to accommodate various weights of media.
IMPORTANT
The operating environment should be controlled to a temperature between
16° C and 27° C Maximum.
Specification
Feeding System ................................................Bottom suction feed
Max. Sheet Size ................................................900mm x 330mm (27.5” x 12.6”)
Min. Sheet Size (in automatic mode)................. 210mm x 140mm (8.5” x 5.5”)
Max. Paper Thickness .......................................0.4mm (varies according to hardness,
type of fold, and substrate)
Max. No. Creases per Sheet ............................ 16
Min. Distance Between Creases ....................... 0.1mm
Max. No. Stored Programes ............................. Unlimited
Min. Crease Distance from Leading Edge ........ 2.5mm
Min. Crease Distance from Tail Edge ................35mm
In Hand Feed Mode up to 2499.9mm to Last Crease can be Programmed.
Speed per Hour (A4 in half)...............................8500
Speed per Hour (A5 in half)...............................11000
Dimensions ....................................................... L: 1450mm H: 1224mm W: 522mm
L: (57”) H: (48.2”) W: (20.5”)
Weight ............................................................... 140 kg (+50 kg packing)
Power Requirement .......................................... 1 phase 230V 50Hz
1 phase 220V 60Hz
Sound Power Level ........................................... 78.0 dB(A)
*As part of our continued product improvement plan, specifications and information
published in this manual are subject to change without notice.
All specifications are dependant on application, type of stock, temperature, RH and print
engine used.
Specifications quoted were measured on uncoated and un-printed stock. E & OE.

Page 2 CREASING
INDEX
THE STACKER ASSEMBLY
Setting the Height Adjustable Stacker unit 28
Setting the Optional Stacker unit 30
PERFORATING
Equipment, spares 31
Setting the perforating blade position 32
THE BLADE ASSEMBLY
Setting the blade pressure 34
REPLACING CREASING BLADE SETS
Installing crease blade sets 35
Spares 37
CROSS PERFORATING KIT 38
TROUBLE SHOOTING 39
DISPATCH KIT 47
ACCESSORIES & OPTIONS 48
RECOMMENDED SPARES 49
FUSE POSITIONS AND RATINGS 51
PRODUCT RECYCLING & DISPOSAL 52
INTRODUCTION
The Morgana AutoCreaser Pro 33A PAGE 3
SAFETY Do’s & Don’ts 4
THE AUTOCREASER PRO 33A
Labeled Picture 6
THE CONTROLS
The switch panel 7
Features on the switch panel 7
QUICK START GUIDE 8
SCREEN CALIBRATION 19
OPERATING THE MACHINE
Setting the machine 20
Setting up a job 24
Loading & saving 25
Paper jamming 27
Page 3
SYSTEM
INTRODUCTION
Atlas C102 Creaser
The Atlas C102 is a fully automatic suction feeding creasing system
designed for use with both conventional litho and digital printers.
The feed on the Atlas C102 can also be manually operated for use
with heavy stock, very small or very large sheets, embossed or even irregular
sheets.
The crease is programmed from the leading edge of the sheet using the
controls on the front panel.
The blade and anvil are mechanically controlled over their entire length
and can be adjusted to accommodate various weights of media.
IMPORTANT
The operating environment should be controlled to a temperature between
16° C and 27° C Maximum.
Specification
Feeding System ................................................Bottom suction feed
Max. Sheet Size ................................................900mm x 330mm (27.5” x 12.6”)
Min. Sheet Size (in automatic mode)................. 210mm x 140mm (8.5” x 5.5”)
Max. Paper Thickness .......................................0.4mm (varies according to hardness,
type of fold, and substrate)
Max. No. Creases per Sheet ............................ 16
Min. Distance Between Creases .......................0.1mm
Max. No. Stored Programs ............................. Unlimited
Min. Crease Distance from Leading Edge ........ 2.5mm
Min. Crease Distance from Tail Edge ................35mm
In Hand Feed Mode up to 2499.9mm to Last Crease can be Programmed.
Speed per Hour (A4 in half)...............................8500
Speed per Hour (A5 in half)...............................11000
Dimensions ....................................................... L: 1450mm H: 1224mm W: 522mm
L: (57”) H: (48.2”) W: (20.5”)
Weight ...............................................................140 kg (+50 kg packing)
Power Requirement .......................................... 1 phase 230V 50Hz
1 phase 220V 60Hz
Sound Power Level ........................................... 78.0 dB(A)
*As part of our continued product improvement plan, specifications and information
published in this manual are subject to change without notice.
All specifications are dependent on application, type of stock, temperature, RH and print
engine used.
Specifications quoted were measured on uncoated and un-printed stock. E & OE.

Page 4 CREASING
Safety Do’s & Don’ts
Safety Do’s & Don’ts
REGLES DE SECURITE : « A FAIRE » ET « A NE PAS FAIRE »
Do - read this operator manual fully before operating the machine.
Lire ce mode d'emploi avant d'utiliser la machine.
Do - operate with the designated AC current only. Use an exclusive outlet, as
overloading may cause fire or an electric shock.
Respecter l'alimentation électrique indiquée. Brancher sur une prise séparée
car une surcharge peut entraîner un incendie ou un choc électrique.
Do - install the power cord out of the way to avoid a tripping hazard.
Installer le cordon d'alimentation de manière à ne pas pouvoir
trébucher par dessus.
Do - make sure that the mains inlet connector is always easily accessible.
Ménager un accès libre à la prise de courant.
Do - Fit the yellow outrigger feet, (supplied in the Dispatch Kit), to the front and back
of the machine as shown on Page 6; to comply with safety regulations.
Fixer les pieds stabilisateurs jaune, (fourni dans le kit d'expédition), à l'avant et
l'arrière de la machine comme indiqué sur la page 6; pour se conformer aux
règlements de sécurité.
Do not - install the machine in an unstable place such that it tilts or shakes.
Ne pas installer la machine sur une surface non plane, afin d'éviter
qu'elle ne penche ou ne vibre.
Do not - unplug the plug or unplug the power cord from the outlet with a wet hand,
this can cause an electric shock.
Ne pas installer la machine sur une surface non plane, afin d'éviter
qu'elle ne penche ou ne vibre.
Do not - unscrew and remove any covers from the machine, as it can cause an
electric shock or injury.
Ne démonter et enlever aucun carter de la machine, par crainte de décharge
électrique ou de blessure.
Do not - place receptacles containing liquids on any surface.
Ne pas placer de récipient contenant un liquide sur la machine.
Do not - adjust any part of the machine whilst rollers are running
N'effectuer aucun réglage pendant que les rouleaux fonctionnent.
Do not - operate the machine with loose or trailing clothing or loose hair.
Ne pas porter de vêtements flottants et rassembler les cheveux longs
lors de l'utilisation de la machine.
Do not - under any circumstances adjust the paper gate when the machine is
switched on.
En aucune circonstance, régler le séparateur de papier lorsque la
machine est branchée.
Page 5
SYSTEM
Warning Labels
Do - be aware of any finger traps and rotating parts when operating
the machine.
Attention au risque de se coincer les doigts, et aux pièces en
mouvement lors du fonctionnement de la machine.
Do - read this operator manual fully before operating the machine.
Lire ce mode d’emploi avant d’utiliser la machine.
Do not - operate the machine with loose or trailing clothing.
Ne pas porter de vêtements flottants lors de l'utilisation de la machine
Do not - operate the machine with loose hair.
Rassembler les cheveux longs lors de l'utilisation de la machine.
Do - be aware of any finger traps and rotating parts when operating
the machine.
Attention au risque de se coincer les doigts, et aux pièces en
mouvement lors du fonctionnement de la machine.
Do - be aware of sharp points and blades.
Attention aux éléments tranchants et aux couteaux.
Do - be aware of rotating rollers.
Attention aux rouleaux en fonctionnement
Do - be aware of low current anti-static shock.
Attention aux faibles chocs d'électricité statique
AutoCreaser Pro 33A

Page 4 CREASING
Safety Do’s & Don’ts
Safety Do’s & Don’ts
REGLES DE SECURITE : « A FAIRE » ET « A NE PAS FAIRE »
Do - read this operator manual fully before operating the machine.
Lire ce mode d'emploi avant d'utiliser la machine.
Do - operate with the designated AC current only. Use an exclusive outlet, as
overloading may cause fire or an electric shock.
Respecter l'alimentation électrique indiquée. Brancher sur une prise séparée
car une surcharge peut entraîner un incendie ou un choc électrique.
Do - install the power cord out of the way to avoid a tripping hazard.
Installer le cordon d'alimentation de manière à ne pas pouvoir
trébucher par dessus.
Do - make sure that the mains inlet connector is always easily accessible.
Ménager un accès libre à la prise de courant.
Do - Fit the yellow outrigger feet, (supplied in the Dispatch Kit), to the front and back
of the machine as shown on Page 6; to comply with safety regulations.
Fixer les pieds stabilisateurs jaune, (fourni dans le kit d'expédition), à l'avant et
l'arrière de la machine comme indiqué sur la page 6; pour se conformer aux
règlements de sécurité.
Do not - install the machine in an unstable place such that it tilts or shakes.
Ne pas installer la machine sur une surface non plane, afin d'éviter
qu'elle ne penche ou ne vibre.
Do not - unplug the plug or unplug the power cord from the outlet with a wet hand,
this can cause an electric shock.
Ne pas installer la machine sur une surface non plane, afin d'éviter
qu'elle ne penche ou ne vibre.
Do not - unscrew and remove any covers from the machine, as it can cause an
electric shock or injury.
Ne démonter et enlever aucun carter de la machine, par crainte de décharge
électrique ou de blessure.
Do not - place receptacles containing liquids on any surface.
Ne pas placer de récipient contenant un liquide sur la machine.
Do not - adjust any part of the machine whilst rollers are running
N'effectuer aucun réglage pendant que les rouleaux fonctionnent.
Do not - operate the machine with loose or trailing clothing or loose hair.
Ne pas porter de vêtements flottants et rassembler les cheveux longs
lors de l'utilisation de la machine.
Do not - under any circumstances adjust the paper gate when the machine is
switched on.
En aucune circonstance, régler le séparateur de papier lorsque la
machine est branchée.
Page 5
SYSTEM
Warning Labels
Do - be aware of any finger traps and rotating parts when operating
the machine.
Attention au risque de se coincer les doigts, et aux pièces en
mouvement lors du fonctionnement de la machine.
Do - read this operator manual fully before operating the machine.
Lire ce mode d’emploi avant d’utiliser la machine.
Do not - operate the machine with loose or trailing clothing.
Ne pas porter de vêtements flottants lors de l'utilisation de la machine
Do not - operate the machine with loose hair.
Rassembler les cheveux longs lors de l'utilisation de la machine.
Do - be aware of any finger traps and rotating parts when operating
the machine.
Attention au risque de se coincer les doigts, et aux pièces en
mouvement lors du fonctionnement de la machine.
Do - be aware of sharp points and blades.
Attention aux éléments tranchants et aux couteaux.
Do - be aware of rotating rollers.
Attention aux rouleaux en fonctionnement
Do - be aware of low current anti-static shock.
Attention aux faibles chocs d'électricité statique

Page 6 CREASING
DOCUMENT CREASING MACHINE
Key to photograph below
1 Roller tilt handle 6 Air separation knob 11 Paper Gate
2 Height Adj. Stacker Assy. 7 Adjustable side lay 12 Exit Guard
3 Suction slot knob 8 Back stop 13 Switch Panel
4 Touchscreen 9 Fixed side lay 14 Fuses
5 Air distribution knob 10 Roller tilt knob 15 Outrigger Foot
16 Vacuum bleed knob
13
14
17
9
10
11
12
4
1
2
3
5
67
8
15
Atlas C102
16
17 Loading Table Extension
Page 7
SYSTEM
THE CONTROLS
THE SWITCH PANEL
System Switch
Compressor Switch
Emergency Stop Switch
The Switch Panel houses the Compressor switch, System switch, and an
industry standard Emergency Stop switch which will stop all power going to
the machine when activated.
AutoCreaser Pro 33A
Features on the Switch Panel
System switch
When activated the system switch will operate the motors in order to begin the
creasing sequence.
Compressor switch
Allows the operator to switch off the compressor unit in order to utilise the machine
to manually feed sheets.

Page 6 CREASING
DOCUMENT CREASING MACHINE
Key to photograph below
1 Roller tilt handle 6 Air separation knob 11 Paper Gate
2 Height Adj. Stacker Assy. 7 Adjustable side lay 12 Exit Guard
3 Suction slot knob 8 Back stop 13 Switch Panel
4 Touchscreen 9 Fixed side lay 14 Fuses
5 Air distribution knob 10 Roller tilt knob 15 Outrigger Foot
16 Vacuum bleed knob 17 Loading Table Extension
13
14
17
9
10
11
12
4
1
2
3
5
67
8
15
AutoCreaser Pro 33A
16
Page 7
SYSTEM
THE CONTROLS
THE SWITCH PANEL
System Switch
Compressor Switch
Emergency Stop Switch
The Switch Panel houses the Compressor switch, System switch, and an
industry standard Emergency Stop switch which will stop all power going to
the machine when activated.
Features on the Switch Panel
System switch
When activated the system switch will operate the motors in order to begin the
creasing sequence.
Compressor switch
Allows the operator to switch off the compressor unit in order to utilise the machine
to manually feed sheets.

Page 8 CREASING
Quick Start Guide
Setting the machine to operate in automatic sheet feed mode
1. Set the gap between the paper gate and the vacuum roller to approximately twice
the thickness of the stock to be creased.
2. Place the stock to be creased onto the loading table against the fixed side lay.
3. Release the clamps on the adjustable side lay and slide up to the paper stack
allowing a gap of approximately 0.5mm (1/64 inch) between the paper and the side
lay.
4. Position the backstop and slide it up to the paper stack, also allowing a gap (as
stated in the above step).
5. Turn the Emergency Stop button clockwise to switch the power on. After the
system start up procedure the touch screen will be displayed as shown below.
WARNING:-
Wait at least 10 seconds, after making any selection on the Touchscreen
panel, before switching the machine OFF. Failure to do so could result in the
data storage being corrupted, and the machine not operating.
IMPORTANT.
If you have not been trained to operate this machine, we strongly advise that you select
the red cross icon.
We recommend that you either seek training or ask a trained operator to run the machine
for you.
Select the green check icon only if you have been trained to operate this machine.

Page 8 CREASING
Quick Start Guide
Setting the machine to operate in automatic sheet feed mode
1. Set the gap between the paper gate and the vacuum roller to approximately twice
the thickness of the stock to be creased.
2. Place the stock to be creased onto the loading table against the fixed side lay.
3. Release the clamps on the adjustable side lay and slide up to the paper stack
allowing a gap of approximately 0.5mm (1/64 inch) between the paper and the side
lay.
4. Position the backstop and slide it up to the paper stack, also allowing a gap (as
stated in the above step).
5. Turn the Emergency Stop button clockwise to switch the power on. After the
system start up procedure the touch screen will be displayed as shown below.
WARNING:-
Wait at least 10 seconds, after making any selection on the Touchscreen
panel, before switching the machine OFF. Failure to do so could result in the
data storage being corrupted, and the machine not operating.
IMPORTANT.
If you have not been trained to operate this machine, we strongly advise that you select
the red cross icon.
We recommend that you either seek training or ask a trained operator to run the machine
for you.
Select the green tick icon only if you have been trained to operate this machine.
If you have not been trained to operate this machine and you select the green tick icon,
Morgana Systems Ltd accept no responsibility for personal injury, damage to the
machine or damage to materials being processed by the machine.
Page 9
SYSTEM
Quick Start Guide
The touch screen is laid out into 3 main areas as shown below:
Settings Pages.
Paper Settings Page.
Status of
machine &
data entry
area. Also
used for
quick links
to setting
pages.
Tabs to enable switching between setting
pages
-
choose either Paper
Settings,
Crease Setting, Store or Tools
Setting
page
Batch Button - Image
is identical to that
shown in the status
area. On selection the
status area is replaced
with a calculator for
inputting new values.
Batches of any
numerical value.
Fold Selection - For quick setting of crease positions on standard size sheets.
Highlighted fold is type currently selected, other folds may be selected.
Currently selected fold is shown in the status area.
Page Length - On
selection the status
area is replaced with
a calculator for
inputting new values.
Min Length = 190mm
Vacuum Suck -
There
are two selections
available - 1 short
suck & 2 continuous
for stream feeding.
Highlighted number is
type currently
selected. The status
area also shows
currently selected
suck.
Arrows may be
selected to increase
or decrease the page
size in 0.1mm
increments
Toggle between, Delay between batches
and stop after batch
Current Job Name

Page 10 CREASING
Crease settings Pages.
To get to the crease setting page click the lower tab or from
the status area.
If you have selected a predefined standard crease type from the paper settings
page the crease positions will be set for you. These positions can be fine tuned
by ± 0.1 mm increments by pressing side arrow buttons for each crease.
Press to remove all
creases – you will be
asked to confirm
deletion.
Cross box for deletion of crease.
On deletion of crease following
creases will move up by one
place. You will be asked to
confirm deletion of the crease.
Crease position - On selection
the status area is replaced with
a calculator for inputting new
values.
Plus box for inserting
additional creases. On
selection following
creases will move down
by one place a
maximum number of 6
creases can be seen at
any one time further
creases can be
accessed by use of the
scroll bar.
Arrows may be selected
to increase or decrease
the crease position
in 0.1mm increments
Crease on/off selector
green is on & red is off.
This is also indicated in
the status area.
Number of creases – if
more than 6 creases are
added a scroll bar will
appear to enable
viewing of all creases
Additional creases
added – scroll bar
appears for more than
six creases.
Quick Start Guide
Page 11
SYSTEM
AutoCreaser Pro 33A
Creasing turned off -
Greyed out areas are
unselectable. Status
area will show
creasing is off with
red icon
Quick Start Guide

Page 10 CREASING
Crease settings Pages.
To get to the crease setting page click the lower tab or from
the status area.
If you have selected a predefined standard crease type from the paper settings
page the crease positions will be set for you. These positions can be fine tuned
by ± 0.1 mm increments by pressing side arrow buttons for each crease.
Press to remove all
creases – you will be
asked to confirm
deletion.
Cross box for deletion of crease.
On deletion of crease following
creases will move up by one
place. You will be asked to
confirm deletion of the crease.
Crease position - On selection
the status area is replaced with
a calculator for inputting new
values.
Plus box for inserting
additional creases. On
selection following
creases will move down
by one place a
maximum number of 6
creases can be seen at
any one time further
creases can be
accessed by use of the
scroll bar.
Arrows may be selected
to increase or decrease
the crease position
in 0.1mm increments
Crease on/off selector
green is on & red is off.
This is also indicated in
the status area.
Number of creases – if
more than 6 creases are
added a scroll bar will
appear to enable
viewing of all creases
Additional creases
added – scroll bar
appears for more than
six creases.
Quick Start Guide
Page 11
SYSTEM
Creasing turned off -
Greyed out areas are
unselectable. Status
area will show
creasing is off with
red icon
Quick Start Guide

Page 12 CREASING
Run Job
System Switch Not On
Push System Switch down to start the machine.
The machine running screen will appear.
Click to start machine with
settings currently shown -
you will receive a
notification if system
switch is not on. Press
again to stop Job
Click to stop machine
Quick Start Guide
Page 13
SYSTEM
AutoCreaser Pro 33A
Cover Crease Mode.
1. Select the Paper Settings Tab.
2. Enter the Paper Length and then select the Cover Crease button.
3. Select the Crease Settings Tab.
4. Enter the Spine Width dimension. If necessary, adjust the Spine Offset from the
centre of the sheet.
5. Select the arrow button to set the hinge Dimension.
Cover Crease button
Paper Length
Spine Offset Spine Width
Arrow Button Hinge Distance
Quick Start Guide

Page 12 CREASING
Run Job
System Switch Not On
Push System Switch down to start the machine.
The machine running screen will appear.
Click to start machine with
settings currently shown -
you will receive a
notification if system
switch is not on. Press
again to stop Job
Click to stop machine
Quick Start Guide
Page 13
SYSTEM
Cover Crease Mode.
1. Select the Paper Settings Tab.
2. Enter the Paper Length and then select the Cover Crease button.
3. Select the Crease Settings Tab.
4. Enter the Spine Width dimension. If necessary, adjust the Spine Offset from the
centre of the sheet.
5. Select the arrow button to set the hinge Dimension.
Cover Crease button
Paper Length
Spine Offset Spine Width
Arrow Button Hinge Distance
Quick Start Guide

Quick Start Guide
Cross Perforating (Optional).
1. A cross perforating kit is available as an optional part, the blades available are:
Full Width - Coarse
Full Width - Fine
150mm - Coarse
150mm - Fine
100mm - Coarse
100mm - Fine
50mm - Coarse
50mm - Fine
Refer to page 38 for fitting of the perforator blade set.
2. Select the Perforating Button to turn on the Perforating, this mode slows down
the machine cycle to allow the ejectors on the perforation blade set release the
paper from the blade.
3. The procedure for setting the perforation positions from the lead edge is
identical to positioning creases on a sheet.
Page 14 CREASING
6. Enter the Hinge Dimension.
7. Select the arrow button to highlight the Spine Offset and the Spine Width
dimensions.
8. Run the sheets of paper through the machine to make the Spine creases.
TO MAKE THE HINGE CREASES.
9. Remove the sheets of paper from the stacker tray. TURN THE SHEETS OVER,
and put them back onto the loading table. MAKE SURE THAT THE LEAD EDGE
OF THE SHEETS POINT IN THE SAME DIRECTION AS BEFORE.
10. Select the arrow button to highlight the Hinge Dimension.
11. Run the sheets of paper through the machine to make the Hinge creases.
Hinge Dimension
Quick Start Guide
Page 15
SYSTEM
Perforating Button

Quick Start Guide
Cross Perforating (Optional).
1. A cross perforating kit is available as an optional part, the blades available are:
Full Width - Course
Full Width - Fine
150mm - Course
150mm - Fine
100mm - Course
100mm - Fine
50mm - Course
50mm - Fine
Refer to page 38 for fitting of the perforator blade set.
2. Select the Perforating Button to turn on the Perforating, this mode slows down
the machine cycle to allow the ejectors on the perforation blade set release the
paper from the blade.
3. The procedure for setting the perforation positions from the lead edge is
identical to positioning creases on a sheet.
Page 14 CREASING
6. Enter the Hinge Dimension.
7. Select the arrow button to highlight the Spine Offset and the Spine Width
dimensions.
8. Run the sheets of paper through the machine to make the Spine creases.
TO MAKE THE HINGE CREASES.
9. Remove the sheets of paper from the stacker tray. TURN THE SHEETS OVER,
and put them back onto the loading table. MAKE SURE THAT THE LEAD EDGE
OF THE SHEETS POINT IN THE SAME DIRECTION AS BEFORE.
10. Select the arrow button to highlight the Hinge Dimension.
11. Run the sheets of paper through the machine to make the Hinge creases.
Hinge Dimension
Quick Start Guide
Page 15
SYSTEM
Perforating Button

Status Screen
Number of creases - this
may alter automatically if
a pre - defined fold is
selected. Adjustments
may be made in the
crease setting screen
Green icon indicates
settings are saved - a red
icon would show that
settings have been
changed but the job has
not been saved.
Batch quantity -
this is
input from the batch
calculator on the paper
setting screen - max. 999
confirm that you want to
Sheet count -click to zero
A screen will appear to
reset the count.
Click to start machine with settings currently
shown -
you will receive a notification if
system switch is not on. Press again to stop
Job
Paper length -
input from
the paper setting screen
Touching in this area will take you
to the paper setting page
page
Touching in this area will take
you to the Crease setting
you to the paper setting
page.
Clicking in this area will take
Current machine speed setting
Batch count - click to zero
A screen will appear to confirm that
you want to reset the count.
Lead Edge Sensor Strength,
Indicator Bar
Select this button to produce
3 test sheets with the
settings currently shown.
Touch this area to alternate
Cross perfoating to on/off/X2
indicates on
indicates 2 x activations
of the blade set
indicates off
Quick Start Guide
Page 16 CREASING
Quick Start Guide
The Status Screen will on occasions be replaced with an Input Calculator Screen
as shown below.
Paper size Batch size Crease position
input calculator input calculator input calculator
NOTE:
The green tick or the red cross must be selected on the Calculator Screen to
make the left hand side of the touchscreen active again.
Pre - set Paper sizes for quick
insertion – Standard sizes for
country origin would be shown
Pre - set Batch sizes for quick
insertion.
Currently selected fold type
-
can be one of the
following.
Currently selected Vacuum
Suck setting - for stream
setting choose selection 2
Page 17
SYSTEM

AutoCreaser Pro 33A
Status Screen
Number of creases - this
may alter automatically if
a pre - defined fold is
selected. Adjustments
may be made in the
crease setting screen
Green icon indicates
settings are saved - a red
icon would show that
settings have been
changed but the job has
not been saved.
Batch quantity -
this is
input from the batch
calculator on the paper
setting screen - max. 999
confirm that you want to
Sheet count -click to zero
A screen will appear to
reset the count.
Click to start machine with settings currently
shown -
you will receive a notification if
system switch is not on. Press again to stop
Job
Paper length -
input from
the paper setting screen
Touching in this area will take you
to the paper setting page
page
Touching in this area will take
you to the Crease setting
you to the paper setting
page.
Clicking in this area will take
Current machine speed setting
Batch count - click to zero
A screen will appear to confirm that
you want to reset the count.
Lead Edge Sensor Strength,
Indicator Bar
Select this button to produce
3 test sheets with the
settings currently shown.
Touch this area to alternate
Cross perfoating to on/off/X2
indicates on
indicates 2 x activations
of the blade set
indicates off
Quick Start Guide
Page 16 CREASING
Quick Start Guide
The Status Screen will on occasions be replaced with an Input Calculator Screen
as shown below.
Paper size Batch size Crease position
input calculator input calculator input calculator
NOTE:
The green FKHFN or the red cross must be selected on the Calculator Screen to
make the left hand side of the touchscreen active again.
Pre - set Paper sizes for quick
insertion – Standard sizes for
country origin would be shown
Pre - set Batch sizes for quick
insertion.
Currently selected fold type
-
can be one of the
following.
Currently selected Vacuum
Suck setting - for stream
setting choose selection 2
Page 17
SYSTEM

Tools Screen
Clean Lead Edge Sensor
Clicking this icon will
show Machine
program revision &
Touch Screen
software revision.
Inch paper in direction
of arrow to clear jams
Click on Up Arrow to
put Anvil into Top
Dead Centre position
(TDC)
Inch paper in direction
of arrow to clear jams
Main Processor Program
version
Touch screen software
version
Machine Speed Adjustment:-
Speed setting 3 will give the fastest throughput of
stock through the machine.
Use speed setting 1 or 2 for troublesome stocks.
Touch Screen Calibration Change Machine measurement
settings, Imperial / Metric
See Page 19
Quick Start Guide
Page 18 CREASING
Screen Calibration
Touch Screen Calibration.
1. Switch the mains power on and wait for the main screen to appear before
commencing to check the horizontal and vertical position of the display.
The position of the display within the surround is achieved by operating the button
at the rear of the housing, press this a number of times to obtain the correct
orientation required, move to the next button to move the position to centralize
horizontal.
2. (i) Select the tools menu tab, and then Select the Touch Screen calibration icon.
(ii) Using a plastic pointer, soft leaded pencil, biro cap etc. and with gentle pressure.
Touch the centre of the cross in each corner of the Touch Screen, as prompted, by
the hand graphics. This procedure will calibrate the Touch Screen.
Brightness
Contrast
Horizontal
Vertical
UP
(Increase value)
DOWN
(Decrease value)
Display
ON/OFF)
AV / Display
Channel
Page 19
SYSTEM

Tools Screen
Clean Lead Edge Sensor
Clicking this icon will
show Machine
program revision &
Touch Screen
software revision.
Inch paper in direction
of arrow to clear jams
Click on Up Arrow to
put Anvil into Top
Dead Centre position
(TDC)
Inch paper in direction
of arrow to clear jams
Main Processor Program
version
Touch screen software
version
Machine Speed Adjustment:-
Speed setting 3 will give the fastest throughput of
stock through the machine.
Use speed setting 1 or 2 for troublesome stocks,
or to synchronise the speed of the AutoCreaser to a
Morgana Autofold Pro, when they are used together.
Touch Screen Calibration Change Machine measurement
settings, Imperial / Metric
See Page 19
AutoCreaser Pro 33A Quick Start Guide
Page 18 CREASING
Screen Calibration
Touch Screen Calibration.
1. Switch the mains power on and wait for the main screen to appear before
commencing to check the horizontal and vertical position of the display.
The position of the display within the surround is achieved by operating the button
at the rear of the housing, press this a number of times to obtain the correct
orientation required, move to the next button to move the position to centralize
horizontal.
2. (i) Select the tools menu tab, and then Select the Touch Screen calibration icon.
(ii) Using a plastic pointer, soft leaded pencil, pen cap etc. and with gentle pressure.
Touch the center of the cross in each corner of the Touch Screen, as prompted, by
the hand graphics. This procedure will calibrate the Touch Screen.
Brightness
Contrast
Horizontal
Vertical
UP
(Increase value)
DOWN
(Decrease value)
Display
ON/OFF)
AV / Display
Channel
Page 19
SYSTEM

Setting the Adjustable Side Lay
Place the paper stack on to the loading table and slide up to the fixed side lay and paper
gate. Release the clamps located at each end of the side lay and slide up towards the
paper stack as demonstrated in Fig. 1. Allow a gap of approximately 0.5mm (1/64 inch)
between the paper and the side lay.
Setting the Back Stop
Position the backstop and slide up towards the paper stack allowing a gap (as specified
in the above step).
Setting the Air Distribution
Depending on the length of the sheet to be creased, the air distribution knob (see Fig. 2) can
be rotated to various positions in order to supply air to different ports. Position 2 is
recommended for most sheet sizes. However, a better result may be obtained by using
the settings below or by experimentation.
Position 0 - For sheets longer than A3 (17”) in order to supply air to the center of the
stack, ports 2 and 3 open.
1 - For A5 sheets or 8 inches long, ports 1 and 2 open.
2 - For A4 sheets or 11 inches long, ports 1 and 3 open.
3 - For sheets longer than A3 (17”) in order to supply air evenly along the stack,
ports 1 and 4 open.
Setting the Air Separation Pressure
To control the amount of air supplied to the ports, the air separation knob can be rotated
clockwise to decrease the pressure or counter-clockwise to increase the pressure.
Port 1 Port 4
Knob Shown
Set To Posn. 1
Air Distribution
Operating The Machine
FIG. 2
Page 21
SYSTEM
Operating The Machine
J
TWO THICKNESSES
OF PAPER
WARNING.
DO NOT ADJUST THE
PAPER GATE WHILE THE
MACHINE IS RUNNING OR
THE SUCTION DRUM MAY
BECOME DAMAGED.
Setting the Machine
Adjusting the Paper Gate
Set the height of the Paper Gate to approximately two thicknesses of paper, by turning the
disc j. An excessive gap is a most likely cause of double sheet feeding.
This setting is only intended as a guide, for instance, sheets with an upward curl will
require this setting to be increased.
Setting the Suction Slot
The suction slot is located inside the vacuum roller and can be adjusted by releasing and
moving the suction knob horizontally in either direction to the required position.
For light stocks set the knob to the left and for heavier stocks set the knob to the right.
Adjustable
Side Lay
Suction
Slot Knob
AutoCreaser Pro 33A
FIG. 1
Page 20 CREASING
