1Notices
The following notices apply to the ReACT GNSS receiver.
1.1 CE Notice
The ReACT GNSS system enclosures carry the CE mark in accordance with EN ISO/EC 17050-1 2004.
1.2 Environmental Standards
The ReACT GNSS system has been tested to the following standards:
Temperature
Operating
Storage
–32 oC to +75 oC
–40 oC to +85 oC
Electromagnetic Compatibility (EMC)
European CE, 89/ EEC EN 55022 Class B, EN50082-1
EMC
MIL-STD-461F (Ground, Army), FCC Class A
Immersion
MIL-STD 810F, method 512.4,
IEC 60529 IPX7
Humidity
MIL-STD 810F, method 507.4, procedure 1
Salt Spray
MIL-STD 810F, method 509.4
Sand and Dust
MIL-STD 810F, method 510.4
Fluids Susceptibility
MIL-STD-810F, method 504
Vibration
MIL-STD 810F, method 514.5, Category 20
MIL-STD 810E, method 514.4 tbl. 514.4-AXVII
Shock
MIL-STD 810F, method 516.5, Procedure I, IV
Electrostatic Discharge (ESD)
IEC 61000-4-2 level 2 (± 4 KV)
Ultraviolet Light Protection
MIL-STD-810F, method 505.4
1.3 Environmental Standards
The ReACT is compliant with the European Union (EU) Restriction of Hazardous Substances (RoHS) Directive
2002/95/EC.

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 7
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
2Warranty Information
Forsberg Services Ltd Warranty Policy
Warranty
Forsberg Services Ltd (FSL) warrants that the navigation products manufactured by FSL are free from defects in
materials and workmanship, subject to the conditions set forth below, for the following periods of time:
ReACT - One (1) Year from the date of sale
Software Support - One (1) Year from the date of sale
Date of sale shall mean the date of the invoice to the original customer for the product. FSL’s responsibility
respecting this warranty is solely to product replacement or product repair at an authorized FSL location only.
The FSL warranty does not extend to the following:
I. Non-conformities, defects or errors in the products due to accident, abuse, misuse or negligent use of
the products or use in other than a normal and customary manner, environmental conditions not
conforming to FSL’s specifications, or failure to follow prescribed installation, operating and
maintenance procedures.
II. Defects, errors or non-conformities in the products due to modifications, alterations, additions or
changes not made in accordance with FSL’s specifications or authorised by FSL.
III. Normal wear and tear.
IV. Damage caused by force of nature or act of any third person.
V. Shipping damage; or
VI. Service or repair of product by the user without prior written consent from FSL. In addition, the
foregoing warranties shall not apply to products designated by FSL as beta site test samples,
experimental, developmental, preproduction, sample, incomplete or out of specification products or
to be returned products if the original identification marks have been removed or altered.
The warranties and remedies are exclusive and all other warranties, expressed or implied, written or oral,
including the implied warranties of merchantability or fitness for any particular purpose are excluded. FSL shall
not be liable for any loss, damage, expense, or injury arising directly or indirectly out of the purchase,
installation, operation, use of licensing or products or services. In no event shall FSL be liable for special,
indirect, incidental or consequential damages of any kind or nature due to any cause.

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 8
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
3ReACT D5 Model – Functionality Notice
3.1 Important Functionality Note
The FSL ReACT D5 model utilizes an internal connection to the GNSS COM2 port. Therefore, any
commands sent through GPS COM1 or GPS COM3 that will affect the COM2 configuration could
reduce functionality.
When connected to either GPS com port the following commands should be avoided.
UNLOGALL
If UNLOGALL is sent to a GPS com port it will stop the output of commands on all GPS com ports and
all of the EDGE com ports.
UNLOG
If UNLOG is sent to a GPS com port it will stop the output of the specific log command on all GPS
com ports and all the EDGE com ports. If using this command, ensure either COM1 or COM3 is
specified.
COM COM2 or SERIALCONFIG COM2
GPS COM2 has been specifically configured for communicating with the FS-D5 and changing the
baud rate of GPS COM2 will disable communications between the micro and the GPS receiver and
therefore the micro com ports will no longer function.
FRESET / RESET
These commands will reset the GPS receiver to its original state and will disable communications
between the micro and the GPS receiver and therefore the micro com ports will no longer function.
A power cycle will recover the unit and allow the FS-D5 to reconfigure the receiver.
Please reference document A0072-09-0067 ReACT D5 Installation Manual for details on ReACT D5
EDGE-WARE firmware.
3.2 Reconfiguring COM2
Functionality can be retained using either of the methods outlined below.
Reconfigure COM2
Connect to GPS COM1 through a PC running Text Terminal Software and send the following
commands to the unit.
SERIALCONFIG COM2 9600 8 N 1 N OFF ON
INTERFACEMODE COM2 NOVATEL NOVATEL OFF
SAVECONFIG
Power cycle
If SAVECONFIG has not been applied, remove power from the ReACT unit by removing the connector
plug and ensure that the unit is off, then re-apply power. The unit will configure itself for full
functionality.

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 9
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
4Introduction
4.1 Scope
This manual provides the information required for installation and operation of the ReACT GNSS
system. The ReACT can be fitted with multiple GNSS receiver options and therefore an
accompanying manual will be provided for specific receiver operation.
4.2 ReACT Overview
The Forsberg Services Ltd (FSL) ReACT (Receiver Antenna Compact Technology) is a compact, rugged
enclosure including a high quality GNSS receiver, antenna and optional DSP module. ReACT has
been designed for compatibility with NovAtel’s OEMStar, OEM719 and legacy OEM615 GNSS
receivers. This family of receivers offer a range of functionality that can be controlled through
firmware upgrades. The antenna fitted inside the system will be tuned for use with, GPS L1 and
GLONASS L1 (R) or GPS L1/L2, GLONASS G1/G2/G3, BeiDou B1/B2 and Galileo E1/E5b (Q). This
option is controlled through hardware and is non-upgradeable in the field. Further information
about the two different antenna models can be found in the appendix.
The unit is available in three model types:
4.3 ReACT NS
The NS model combines a GNSS receiver and antenna into a single enclosure.
This model provides direct comms to the GNSS receiver. A metal 19 pin Fischer
connector is provided for access to I/O. FSL provide various cable options with
the system.
Note: Selecting the OEMSTAR as the receiver will disable Event-In and COM3.
Connectivity
Strobes
•1 ×configurable RS232/422 serial port
•1 ×RS232 serial port
•1 ×RS232 or USB (3 ×virtual RS232 ports) (Configured at factory)
•1 ×CAN NMEA 2000 port
•PPS
•Event-in
•VARF
4.4 ReACT NSc
The NSc model provides the same functionality as the NS with a centre mount
cable. A metal 19 pin Fischer connector is provided for access to I/O.
Note: Selecting the OEMSTAR as the receiver will disable Event-In and COM3.

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 10
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
4.5 ReACT D5
The D5 model is the enhanced model of the ReACT by combining a GNSS receiver and antenna with
our FS-D5 processor module. This provides enhanced functionality and additional I/O through our
range of EDGE-WARE products. A metal 19-pin Fischer connector is provided for access to I/O. FSL
provide various cable options with the system.
Note: Selecting the OEMSTAR as the receiver will disable Event-In and COM3.
Connectivity
Strobes
•1 ×configurable RS232/422 serial port
•1 ×RS232 serial port or USB (3 ×virtual RS232 ports)
•3 ×EDGE RS232 serial ports
•1 ×EDGE-CAN port
•PPS
•Event-in
•VARF
4.6 EDGE-WARE
The ReACT D5 model is capable of running EDGE-WARE, a firmware product developed by FSL. This
firmware provides additional functionality and I/O. More details of the EDGE-WARE functionality and
modules are provided later in this document.
4.7 Included with the ReACT
The ReACT system comes with:
1 x ReACT GNSS System
1 x USB drive with
1 x ReACT Manual
1 x NovAtel GNSS Firmware Manual and access to on-line OEM7 user manuals
(https://docs.novatel.com/oem7/Content/Home.htm).
Due to the range of applications and bespoke requirements the ReACT NS and D5 are supplied with
an I/O cable. This may be ordered separately and can be provided as a terminated cable or with
flying leads. The standard cable versions are available either with a straight or right-angled Fischer
connector.
Connectivity
Strobes
•1 ×configurable RS232/422 serial port
•1 ×RS232 serial port
•1 ×RS232 or USB (3 ×virtual RS232 ports)
•PPS
•Event-in

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 11
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
5ReACT Installation and setup
5.1 Power
The ReACT GNSS system requires an input supply voltage between +9 VDC and +36 VDC.
5.2 ReACT NS
5.2.1 Mechanical Dimensions
Dimensions
116 mm x 116 mm x 85 mm
Weight
600 g
5.2.2 Connectivity Overview
GNSS COM 1
RS232 or RS422
GNSS COM3
RS232 or USB
VARF
EVENT2
GNSS COM2
RS232
PPS
Pwr
CAN NMEA2000
CONFIG
Figure 1 ReACT NS Connectivity Overview
5.2.3 Configuring the com ports: COM1 and USB/COM3
The configuration port allows for the ReACT GNSS COM1 and USB/COM3 to be configured. The
following commands can be sent to the ReACT through the configuration port to configure the
ReACT GNSS COM1 and USB/GNSS COM3.
1
1
The OEMStar receiver only allows for GNSS COM1 RS232/RS422 and USB to be enabled. COM3 is not
available on this receiver model.

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 12
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
Default settings for the ReACT are:
COM1 RS232
USB and Event 1 enabled
5.2.3.1 Connect to the configuration port
Using a serial terminal program, connect to the config port (D3) at a baud rate of 9600.
5.2.3.2 COM1 RS232
EDGINTERFACEMODE COM1 232
5.2.3.3 COM1 RS422
EDGINTERFACEMODE COM1 422
5.2.3.4 COM3 configuration
EDGINTERFACEMODE COM3 232
Whilst connected to GPS COM1 enter the commands:
INTERFACEMODE USB1 NONE NONE
INTERFACEMODE USB2 NONE NONE
INTERFACEMODE USB3 NONE NONE
EVENTINCONTROL MARK1 DISABLE
INTERFACEMODE COM3 NOVATEL NOVATEL
SAVECONFIG
5.2.3.5 USB configuration
EDGINTERFACEMODE COM3 USB
Whilst connected to GPS COM1 enter the commands:
INTERFACEMODE COM3 NONE NONE
INTERFACEMODE USB1 NOVATEL NOVATEL
INTERFACEMODE USB2 NOVATEL NOVATEL
INTERFACEMODE USB3 NOVATEL NOVATEL
EVENTINCONTROL MARK1 ENABLE
SAVECONFIG
5.2.4 Mounting Points
The ReACT NS comes with two mechanical mounting options.
3 x M6 screw points for vehicle mounting. The thread depth is 12mm
1 x 5/8”thread for centre/ pole mounting. The thread depth is 22mm

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 13
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
Figure 2 Mounting points for ReACT NS
5.2.5 Connector and Pinout
Description
Fischer Part Number
UltiMate, 19Way Panel Mounted Socket
UR02W11 F019P BK1 E1AA
Pin
Signal
Description
1
COM3 TXD / USB_D-
GNSS COM3 or USB
(OEM719 Model Only)
2
COM3 RXD / USB_D+
3
GNSS CAN High
CAN NMEA 2000
4
GNSS CAN Low
5
COM2 TXD
GNSS COM2
6
COM2 RXD
7
CONFIG TXD*
Com port configuration
8
CONFIG RXD*
9
NC
Reserved/ Not Connected
10
NC
11
GNSS PPS
GNSS PPS strobe
12
GNSS EVENT2
GNSS Event In strobe
(OEM719 Model Only)
13
GNSS VARF
GNSS Variable frequency strobe
14
COM1 TXD / TX+
GNSS COM1
(RS232 or RS422)
15
COM1 TX-
16
COM1 RXD / RX+
17
COM1 RX-
18
Power Return
Power
19
9-36VDC Power Input
Shield.
Signal Ground
5.2.5.1 Connector and Pinout
Label
Description
A
Free Plug, Fischer UP01L11
B
USB plug, moulded connector
C
Free plug, 9-way D-type male, moulded connector

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 14
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
D
Free plug, 9-way D-type female, moulded connector
E
Un-terminated wires
F
Vehicle power plug
Figure 3 ReACT NS cable assembly
Description
Fischer Part Number
React NS Cable (5m long)
UP01L11 M019S BK1 Z1ZA
Pin
Signal
Description
Terminated to
Flying Lead colours (E)
1
COM3 TXD / USB_D-
GNSS COM3 RS 232
Or GNSS USB
Connector B pin 2 & D5 Pin 2
2
COM3 RXD / USB_D+
Connector B Pin 3 & D5 Pin 3
3
GNSS CAN High
GNSS CAN port
Connector C Pin 7
4
GNSS CAN Low
Connector C Pin 2
5
COM2 TXD
GNSS COM2
Connector D4 Pin 2
6
COM2 RXD
Connector D4 Pin 3
7
CONFIG TXD*
Com port configuration
Connector D3 Pin 2
8
CONFIG RXD*
Connector D3 Pin 3
9
NC
Reserved/ Not
Connected
NC
10
NC
NC
11
GNSS PPS
GNSS PPS strobe
(E) un-terminated
Red
12
GNSS EVENT2
GNSS Event In strobe
(E) un-terminated
Brown
13
GNSS VARF
GNSS Variable
frequency strobe
(E) un-terminated
Black
14
COM1 TXD / TX+
GNSS COM1 (RS232 or
RS422)
Connector D-1 Pin 2
15
COM1 TX-
Connector D-1 Pin 8
16
COM1 RXD / RX+
Connector D-1 Pin 3
17
COM1 RX-
Connector D-1 Pin 7
18
Power Return
Power
Connector F (Ring)
19
9-36V Power Input
Connector F (Tip)
Shield. Signal Ground
(E) un-terminated
Orange
Connector A , Shell
Connector B Pin 4
Connector C Pin 3

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 15
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
Connector D1 Pin 5
Connector D3 Pin 5
Connector D4 Pin 5
5.3 ReACT NSc
5.3.1 Mechanical Dimensions
Dimensions
116 mm x 116 mm x 85 mm
Weight
600 g
5.3.2 Connectivity Overview
GNSS COM 1
RS232 or RS422
GNSS COM3
RS232 or USB
EVENT2
PPS
Pwr
9 –36 VDC
VARF
Figure 4 ReACT NSc Connectivity Overview
5.3.3 Mounting Point
The ReACT NS comes with two mechanical mounting options.
3 x M6 screw points for vehicle mounting.
3 x 10-32 UNF screw points for vehicle mounting.

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 16
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
Figure 5 ReACT NSc mounting points
5.4 ReACT D5
5.4.1 Mechanical Dimensions
Dimensions
116 mm x 116 mm x 85 mm
Weight
600 g

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 17
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
5.4.2 Connectivity Overview
GNSS COM 1
RS232 or RS422
GNSS COM3
RS232 or USB
VARF
EVENT2
PPS
E1
RS232
E2
RS232
CAN1 E3
RS232
EDGE Output
EDGE Output
EDGE Output
Pwr
9-36V
EDGE Output
Figure 6 ReACT D5 connectivity overview
5.4.3 Mounting Point
The ReACT NS comes with two mechanical mounting options.
3 x M6 screw points for vehicle mounting.
1 x 5/8” thread for center/pole mounting.
Figure 7 Mounting options for ReACT D5

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 18
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
5.4.4 Connector and Pinout
Description
Fischer Part Number
UltiMate, 19-Way Panel Mounted Socket
UR02W11 F019P BK1 E1AA
Pin
Signal
Description
1
COM3 TXD / USB_D-
GNSS COM3 or USB
(OEM719 Model Only)
2
COM3 RXD / USB_D+
3
EDGE CAN High
EDGE-WARE CAN port
4
EDGE CAN Low
5
E3 TXD
EDGE COM3
6
E3 RXD
7
E2 TXD
EDGE COM2
8
E2 RXD
9
E1 TXD
EDGE COM1
10
E1 RXD
11
GNSS PPS
GNSS PPS strobe
12
GNSS EVENT2
GNSS Event In strobe (OEM719 Model Only)
13
GNSS VARF
GNSS Variable frequency strobe
14
COM1 TXD / TX+
GNSS COM1 (RS232 or RS422)
15
COM1 TX-
16
COM1 RXD / RX+
17
COM1 RX-
18
Power Return
Power
19
9-36V Power Input
Shield.
Signal Ground
5.4.5 ReACT D5 I/O Cable - Terminated
Label
Description
A
Free Plug, Fischer UP01L11
B
USB plug, moulded connector
C
Free plug, 9-way D-type male, moulded connector
D
Free plug, 9-way D-type female, moulded connector
E
Un-terminated wires
F
Vehicle power plug

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 19
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
Figure 8 ReACT D5 I/O cable
Description
Fischer Part Number
React D5 Cable assembly (5m)
UP01L11 M019S BK1 Z1ZA
Pin
Signal
Description
Terminated to
Flying Lead colours (E)
1
COM3 TXD / USB_D-
GNSS COM3 RS 232
Or GNSS USB
Connector B pin 2 & D5 Pin 2
2
COM3 RXD / USB_D+
Connector B Pin 3 & D5 Pin 3
3
GNSS CAN High
EDGE-WARE CAN port
Connector C Pin 7
4
GNSS CAN Low
Connector C Pin 2
5
EDGE3 TXD
EDGE COM3
Connector D4 Pin 2
6
EDGE3 RXD
Connector D4 Pin 3
7
EDGE2 TXD
EDGE COM2
Connector D3 Pin 2
8
EDGE2 RXD
Connector D3 Pin 3
9
EDGE1 TXD
EDGE COM1
Connector D2 Pin 2
10
EDGE1 RXD
Connector D2 Pin 3
11
GNSS PPS
GNSS PPS strobe
(E) un-terminated
Red
12
GNSS EVENT2
GNSS Event In strobe
(E) un-terminated
Brown
13
GNSS VARF
GNSS Variable
frequency strobe
(E) un-terminated
Black
14
COM1 TXD / TX+
GNSS COM1
(RS232 or RS422)
Connector D-1 Pin 2
15
COM1 TX-
Connector D-1 Pin 8
16
COM1 RXD / RX+
Connector D-1 Pin 3
17
COM1 RX-
Connector D-1 Pin 7
18
DC Power Return
Power
Connector F (Ring)
19
9-36VDC Power Input
Connector F (Tip)
Shield. Signal Ground
(E) un-terminated
Orange
Connector C Pin 3
Connector B Pin 4
Connector D-1 Pin 5
Connector D-2 Pin 5
Connector D-3 Pin 5
Connector D-4Pin 5

ReACT Operation and
User Manual
Tel.: [phone] | Web: www.forsbergpnt.com
Forsberg Services Ltd., North Quay Offices, Heysham Port, Heysham, LA3 2XF, United Kingdom.
Registered in Scotland (SC104949)
Template: FSL-19-200 v3.00 | Revision Date: 14.08.19
Page 20
A0072-09-0016 v2.00
©Forsberg Services Ltd. 2020
6Appendix
6.1 R-Antenna Model
The antenna element is a lightweight GPS L1 and GLONASS L1 frequency patch with a low noise
figure and a high-linearity LNA. This antenna element shows a high reliability in terms of satellite
reception while providing a high accuracy output.
Frequency
GPS L1: 1575.42 MHz
GLONASS L1: 1609MHz
Polarization
RHCP
DC voltage
2.5 to 5 V
DC current
11mA (max)
Axial ratio
1.5 dB (min)
Impedance
50 Ohm
Operating temperature
from -40°C to 85°C
6.2 Q-Antenna Model
The antenna element is a precision tuned, circular dual feed, stacked patch element with GPS L1/L2,
GLONASS G1/G2/G3, BeiDou B1/B2 and Galileo E1/E5b capabilities. The GPS and GLONASS
reception capabilities provide the user with a highly reliable and accurate position solution in highly
demanding environments.
Frequency
GPS L1: 1575.42MHz
GPS L2: 1227.60MHz
GLONASS G1: 1609MHz
GLONASS G2: 1248 MHz
GLONASS G3: 1202.02 MHz
BeiDou B1: 1575.42 MHz
BeiDou B2: 1207.14 MHz
Galileo E1: 1575.42 MHz
Galileo E5b: 1207.14 MHz
Polarization
RHCP
DC voltage
2.5V to 16 VDC
DC current
12mA typical
Axial ratio
< 2dB
Impedance
50 Ohm
Operating temperature
from -40°C to 85°C
