Change Log
Date Change Description
Sept 19, 2014 Initial release.

Page 5
Introduction
Welcome and thank you for selecting Fortinet products for your network configuration.
This guide contains information about the administration of a FortiSwitch unit in standalone
mode. In standalone mode, a FortiSwitch is managed by connected directly to the unit, either
using the web-based manager (also known as the GUI) or the CLI.
If you will be managing your FortiSwitch unit using a FortiGate, please see the guide Managing
a FortiSwitch unit with a FortiGate.
Supported Models
This guide is for all FortiSwitch models that are supported by FortiSwitchOS. This includes the
following models:
FortiSwitch-28C, FortiSwitch-108D-POE, FortiSwitch-124D, FortiSwitch-124D-POE,
FortiSwitch Rugged-124D, FortiSwitch-224D-POE, FortiSwitch-324B-POE,
FortiSwitch-348B, FortiSwitch-448B, FortiSwitch-1024D, FortiSwitch-1048D, and
FortiSwitch-3032D
Before You Begin
Before you start administrating your FortiSwitch unit, it is assumed that you have completed the
initial configuration of the FortiSwitch unit, as outlined in the QuickStart Guide for your
FortiSwitch model and have administrative access to the FortiSwitch unit’s web-based manager
and CLI.
How this Guide is Organized
This guide is organized into the following chapters:
•System Settings contains information about the initial configuration of your FortiSwitch unit.
•Ports contains information on configuring your FortiSwitch’s ports.
•802.1x contains information on using 802.1x protocol.
•LACP Mode contains information on using a FortiSwitch in Link Aggregation Control
Protocol (LACP) mode.
•TACACS contains information on using TACACS authetication with your FortiSwitch unit.
•Power over Ethernet contains information on using Power over Ethernet (PoE) with your
FortiSwitch.

Page 6
System Settings
This chapter contains information about the initial configuration of your FortiSwitch unit.
Configuring the Management Ports
Using the web-based manager:
First start by editing the default internal interface’s configuration.
1. Go to System > Network > Interface and edit the internal interface.
2. Assign an IP/Netmask.
3. Set Administrative Access to use the desired protocols to connect to the interface.
4. Select OK.
Next, create a new interface to be used for management.
1. Go to System > Network > Interface and select Create New to create a management VLAN.
2. Give the interface an appropriate name.
3. Set Interface to internal.
4. Set a VLAN ID.
5. Assign an IP/Netmask.
6. Set Administrative Access to use the desired protocols to connect to the interface.
7. Select OK.
Using the CLI:
config system interface
edit internal
set ip <address>
set allowaccess <access_types>
set type physical
next
edit <name>
set ip <address>
set allowaccess <access_types>
set interface internal
set vlanid 10
end
end
Example Configurations
The following are four example configurations for management ports, with the CLI syntax
shown to create them.

System Settings Page 7 Managing a FortiSwitch unit with a FortiGate
Example 1: Port 48 as an inbound management interface
In this example, a physical port is used as an inbound management interface. Also, the
FortiSwitch in the example has no default VLAN configured to connect its internal interface to
any physical port.
Figure 1: Using Port 48 of a FortiSwitch-448B unit
Syntax
config system interface
edit internal
set type physical
next
edit mgmt-vlan
set ip 10.105.142.22 255.255.255.0
set allowaccess ping https ssh
set interface "internal"
set vlanid 4090
next
end
Port 48 used as an
inbound management interface

System Settings Page 8 Managing a FortiSwitch unit with a FortiGate
config switch interface
edit port48
set native-vlan 4090
set stp-state disabled
next
edit uplink1
next
edit uplink2
next
edit internal
set native-vlan 4095
set allowed-vlans 4090
set stp-state disabled
end
end
Example 2: Internal interface as an inbound management interface
In this example, the internal interface is used as an inbound management interface. Also, the
FortiSwitch has a default VLAN across all physical ports and its internal port.
Figure 2: Using the internaI interface of a FortiSwitch-108D-POE
Syntax
config system interface
edit internal
set ip 192.168.1.99 255.255.255.0
set allowaccess ping https http ssh
set type physical
end
end
Port 1 (part of the internal interface)
used as an inband management interface

System Settings Page 9 Managing a FortiSwitch unit with a FortiGate
Example 3: WAN interface as an inbound management port
In this example, the WAN interface is used as an inbound management port.
Figure 3: WAN interface of a FortiSwitch-28C
Syntax
config system interface
edit wan2
set ip 10.105.142.10 255.255.255.0
set allowaccess ping https ssh
set type physical
next
edit wan1
set mode dhcp
set allowaccess ping https ssh
set type physical
set defaultgw enable
next
edit internal
set type physical
end
end
Example 4: Out of band management interface
In the example, an out of band management interface is used as the dedicated management
port.
WAN 2 port used as an
inbound management port

System Settings Page 10 Managing a FortiSwitch unit with a FortiGate
Figure 4: Out of band management on a FortiSwitch-1024D
Syntax
config system interface
edit mgmt
set ip 10.105.142.19 255.255.255.0
set allowaccess ping https http ssh snmp telnet
set type physical
next
edit internal
set type physical
end
end
Configuring Static Routing for the Internal Management Port
Using the CLI:
config router static
edit 1
set device <internal>
set default gateway
set gateway 192.168.0.10
end
end
Port 1 used as an
Ethernet data port Dedicated
MGMT port

Page 11
Ports
This chapter contains information on configuring your FortiSwitch’s ports.
Configuring a Port Mirror
Using the web-based manager:
1. Go to Switch > Port > Mirror.
2. Enable Status.
3. Select a Destination Port.
4. Select available ports to be used for Ingress Monitoring and Egress Monitoring.
Using the CLI:
config switch mirror
set dst "port5"
set src-egress "port2" "port3"
set src-ingress "port2" "port4"
set status active
end

Page 12
802.1x
This chapter contains information on using 802.1x protocol.
Authenticating with a RADIUS server
1. Creating a RADIUS user group:
config user radius
edit <name>
set server <address>
end
end
2. Creating a user group:
config user group
edit <name>
set member <list>
config match
edit 1
set group-name <name>
set server-name <name>
end
end
end
end
3. Configuring the switch interface for 802.1x
config switch interface
edit <interface>
set security-mode 802.1X
set security-groups <name>
end
end
4. Configuring an STP instance
config switch stp instance
edit <name>
set priority <integer>
end
end
Example Configuration
The following is an example configuration for a RADIUS user group, with the CLI syntax shown
to create it.

802.1x Page 13 Managing a FortiSwitch unit with a FortiGate
1. Creating a RADIUS user group
config user radius
edit R1
set server “192.160.10.98”
next
end
2. Creating a user group
config user group
edit 802group
set member user1 R1
config match
edit 1
set group-name 802group
set server-name R1
end
end
end
end

Page 14
LACP Mode
This chapter contains information on using a FortiSwitch in Link Aggregation Control Protocol
(LACP) mode.
Configuring the Trunk/LAG Ports
Using the web-based manager:
1. Go to Switch > Switch > Port and select Create Trunk.
2. Give the trunk an appropriate name.
3. Set Mode to either lacp-active or lacp-passive.
4. Add the required ports to the Members list.
5. Select OK.
Using the CLI:
config switch trunk
edit <name>
set description <description_str>
set lacp-speed {fast | slow}
set max-miss-heartbeats <int>
set members <ports>
set member-withdrawal-behaviour {block | forward}
set mode {lacp-active | lacp-passive}
set port-extension {enable | disable}
set port-extension-trigger <min_value_int>
set port-selection-criteria {src-ip | dst-ip | src-dst-ip}
end
end
Example Configuration
The following is an example CLI configurations for trunk/LAG ports:
It is important to configure the trunk to prevent loops.

LACP Mode Page 15 Managing a FortiSwitch unit with a FortiGate
Figure 5: Trunk/LAG ports
1. Configure the trunk 1 interface and assign member ports as a LAG group:
config switch trunk
edit trunk1
set members "port1" "port2" "port3"
set description test
set mode lacp-passive
set port-selection criteria src-dst-ip
end
end
2. Configure the switch ports to have native vlan assignments and allow those vlans on the port
that will be the uplink port:
config switch interface
edit port 1
set native-vlan 1
next
edit port 2
set native-vlan 2
next
edit port 3
set native-vlan 3
next
edit port 4
set native-vlan 4
set allowed vlans 1 2 3
next
edit port 5
set native-vlan 5
set allowed-vlans 1 2 3
end
end

LACP Mode Page 16 Managing a FortiSwitch unit with a FortiGate
3. Configure the trunk 2 interface and assign member ports as a LAG group:
config switch trunk
edit trunk2
set members "port4" "port5"
set description test
set mode lacp-passive
set port-selection criteria src-dst-ip
end
end
Viewing the Configured Trunk
In order to see the details of a configured trunk, use the following command:
diagnose switch trunk list

Page 17
TACACS
This chapter contains information on using TACACS authetication with your FortiSwitch unit.
Administrative Accounts
Administrative, or admin, accounts allow access to various aspects of the FortiSwitch
configuration. The level of access is determined by the access profile used in the admin
account.
Configuring an Access Profile for Admin Accounts
Using the web-based manager:
1. Go to System > Admin > Admin Profile and select Create New.
2. Give the profile an appropriate name.
3. Set Access Control as desired, choosing between None, Read Only, or Read-Write.
4. Select OK.
Using the CLI:
config system accprofile
edit <name>
set admingrp {none | read | read-write}
set loggrp {none | read | read-write}
set netgrp {none | read | read-write}
set routegrp {none | read | read-write}
set sysgrp {none | read | read-write}
end
end
Configuring a TACACS Admin Account
Using the web-based manager:
1. Go to System > Admin > Administrators and select Create New.
2. Give the administrator account an appropriate name.
3. Set Type as Remote.
4. Set User Group to a group for remote users.
5. Enable Wildcard.
6. Set Admin Profile to use the new profile.
7. Select OK.

TACACS Page 18 Managing a FortiSwitch unit with a FortiGate
Using the CLI:
config system admin
edit tacuser
set remote-auth enable
set wildcard enable
set remote-group <group>
set accprofile <profile>
end
end
User Accounts
User accounts can be used to identify a network user and determine what parts of the network
the user is allowed to access.
Configuring a User Account
config user tacacs+
edit <tacserver>
set authen-type {ascii | auto | chap | ms_chap | pap}
set authorization enable
set key <authorization_key>
set server <server>
end
end
Configuring a User Group
config user group
edit <tacgroup>
set member <tacserver>
config match
edit 1
set server-name <server>
set group-name <group>
end
end
end
end
Example Configuration
The following is an example configuration of a TACACS user account, with the CLI syntax
shown to create it:

TACACS Page 19 Managing a FortiSwitch unit with a FortiGate
1. Configuring a TACACS user account for login authentication:
config user tacacs+
edit tacserver
set authen-type ascii
set authorization enable
set key temporary
set server tacacs_server
end
2. Configuring a TACACS user group:
config user group
edit tacgroup
set member tacserver
config match
edit 1
set server-name tacserver
set group-name tacgroup
end
end
end
end
3. Configuring a TACACs system admin user account:
config system admin
edit tacuser
set remote-auth enable
set wildcard enable
set remote-group tacgroup
set accprofile noaccess
end
end

Page 20
Power over Ethernet
This chapter contains information on using Power over Ethernet (PoE) with your FortiSwitch.
Power over Ethernet is only available on the following models: FortiSwitch-108D-POE,
FortiSwitch-124D-POE, FortiSwitch-224D-POE, and FortiSwitch-324B-POE.
Enabling PoE on a Port
config switch physical-port
edit <port>
set poe-status enable
end
end
Determining the PoE Power Capacity
To determine the PoE power capacity, use the following command:
get switch poe inline
Reset the PoE Power on a Port
To reset the PoE power on a port, use the following command:
execute poe-reset <port>
