Forward Industries PBB-200 User manual

Issue 1- 01/04/21
LEDFloating Ball
8” / 10” / 12”
Forward Industries, 33401. U.S.A
Please read these instructions carefully before using and keep for
future reference.

Technical Specification
Contents
1. LED Ball x1
2. USB cable charging cable x1
3. Remote control x1
4. User manual x1
-14˚ C to 35˚C
6RGB+6White LED, 1.2W max
0.2W max per piece
3.7V Lithium 1500mAh
CR2025 (3V)
315 ~ 394 Inch
Around 4 hours
around 6-8 hours;
Input: 5V, Max. 2A
LED Ball: IP66
USB cable: IP20
EN 55032, EN55035,
EN61000-3-2, EN61000-3-3
Battery Charging
A:ON/OFF
C:indication light
B: DC 5V charge Port
Ambient temperature for operation:
LEDs,
Rated Watt:
Battery:
Remote control battery:
Remote control effective distance:
Charging time:
Operation time:
Charging - USB cable:
IP protection:
Classification of radiation:
11
(Important! Never use the product, or allow it to get wet during charging.)
1. Please charge the battery fully before first use.
2. Connect your USB adapter (Use Output 5V ONLY!) to the product using the charge
port. On the underside during battery charging the indicator will be red.
3. Charge the ball until the indicator light is green. Cover the charge port after it is fully
charged.
4. To turn your device on or off, press and hold the ON / OFF button.
NOTE:
1.The built-in battery is not replaceable.
Please do not remove or replace it in the
trash. If you must dispose of this speaker,
bring it to your local recycling center.
2. Disconnect the external adapter/USB
cable from the charge port when not in
use or when the speaker is fully charged.

REPLACING REMOTE CONTROL BATTERIES:
Remote control
Before using the remote control remove the small plastic sheet from the battery cover.
1.Light ON
2.Light OFF
3.PLAY/PAUSE: The lamp will
gradually change between
7colors.
When the color is scrolling, press
again to hold and select your
favorite static color.
4.COLOR: Color selections, 7 static
colors
5.BRIGHT +/–: Light intensity up
and down
6.CANDLE: The light will simulate
the candle flicking effect.
7.SPEED: Light scrolling speed
selections.
8.WHITE
2
• Removing the old battery by pressing the tab on the side of the battery cover and
then sliding off the cover from the remote control.
• Take notice of the positive (+) and negative(–) direction of the battery. Make sure
that the new battery (CR2025) is inserted the right way.
• Dispose of the old battery responsibly.
Warnings and Cautions:
These products and their packaging are not toys; please keep out of reach of children.
• The remote control and USB Cable/charger are not waterproof and must be kept in a
dry location at all time.
• Never charge the product in a pool, water or rain; charge in a dry, indoor location.
• Disconnect the power adapter from main power outlet when not in use.
• Do not stand or jump on this product.
• Do not sit on this product if it is cracked or damaged.
• Keep the product away from chemicals and heat.
• Do not attempt to disassemble the product.
1
3
5
7
2
4
6
8
ON OFF
PLAY/PAUSE COLOR
BRIGHT ±CANDLE
SPEED WHITE

Information about the batteries
3
Outdoor Use:
• The external adapter should not be used outdoor, not exposed to rain, humidity, any
liquid, or heat.
• The remote control should not be exposed to rain, humidity, any liquid, or heat.
• Do not use these products outdoors if they are cracked or damaged;
• Never charge this product outdoor.
• Floating Pool ball has a waterproof level of protection, but should NOT be fully
submerged as it may damage the light.
General Care:
It is recommended that after use the products are turned off, rinsed using clean water
and dried using a soft cloth.Store these products out of reach of children and direct
sunlight when not in use.
• The polarity must be respected when you insert the batteries.
• The batteries must be inserted in such a way as to not cause any short circuit.
• Do not use old batteries with new ones.
• Do not use standard alkaline batteries (carbon-zinc) with rechargeable batteries
(nickel-cadmium)
• Do not expose the batteries to excessive heat, such as sunlight or flame.
• Remove the batteries when they have not been used for a long time.
• If the liquid contained in the batteries comes in contact with eyes or skin, immediately
and carefully wash the affected areas using clean water and consult a doctor.
• The product / remote control may contain a button cell type battery.
• Do not ingest the battery, Chemical Burn Hazard.
• (The remote control supplied with) This product contains a coin/button cell battery. If
the coin/button cell battery is swallowed, it can cause severe internal burns in just 2
hours and can lead to death. Keep new and used batteries away from children.
• If the battery compartment does not close securely, stop using the product and keep
it away from children. If you think batteries might have been swallowed or placed
inside any part of the body, seek immediate medical attention.

Warranty Information
• 1 year for electronic part
• 2 year for housing
After Sales Support / Product Returns
Care of the environment:
4
Your product contains batteries covered by the European Directive
2006/66/EC, which cannot be disposed with normal household waste.
Please inform yourself about the local rules on separate collection of
batteries because correct disposal helps to prevent negative conse-
quences for the environmental and human health.
When this crossed-out wheeled bin symbol is attached to a product it
means that the product is covered by the European Directive
2002/96/EC. Please inform yourself about the local separate collection
system for electrical and electronic products. Please act according to
your local rules and do not dispose of your old products with your
normal household waste. Correct disposal of your old product helps to
prevent potential negative consequences for the environment and
human health.
If you have questions regarding the operation of your koble purchase, or in the
unlikely event you need to return the unit because it is faulty or is no longer
wanted, please contact our product returns department at www.koble@forwardin-
dustries.com, or [phone], option 0. Address: Forward Industries, 105 South
Narcissus Avenue, Suite 412 West Palm Beach, FL 33401 USA
