Digikeijs DR100 User manual

1
www.digikeijs.com
DR100/DR110 28cm led strip (yellow/white/warm white)
DR100/DR110 28cm led
strip (yellow/white/warm
white) Manual
V1.0B
01-07-2021
© Copyright 2005 - 2021 Digikeijs, The Netherlands. All rights reser-
ved. Informaon, images or any part of this document may not be
copied without Digikeijs' prior wrien consent.

2
www.digikeijs.com
DR100/DR110 28cm led strip (yellow/white/warm white)
Contents Page
Contents 2
Packaging contents/Warranty condions 2
Product descripon/Funcons and features 3
Shortening the LED strip /Dividable lengths 4
Adjusng brightness/An-blink soluon 5
Connecon example 6
Addional product numbers 7
WARRANTY All our products have a 24-month manufacturer's warranty.
However, please read this manual carefully. Any damage to the product caused
by failure to follow these instrucons will invalidate the warranty. We are also
not liable for any other damage caused by not following the instrucons as sta-
ted in this manual. Installaon of this LED strip is at your own risk. Digikeijs is
not liable for damage caused to the wagon or other object. Digikeijs is also not
liable for the lapsing of the guarantee of your wagon or other object.
Content DR100W/Y and warm-white
1 Led strip 28cm
2 Capacitors
2 Contacts
20 Sing gures
Content DR110W/Y and warm-white
1 Led strip 28cm

3
www.digikeijs.com
DR100/DR110 28cm led strip (yellow/white/warm white)
Product descripon
General
This LED strip with yellow, white or warm-white LEDs can be used to illuminate wagons,
plaorm lighng or buildings.
Funcons and features
The LED strip features a special circuit that always provides the LEDs with a constant vol-
tage and also limits the maximum current consumpon to 40mA.
Features at a glance:
- 10 Leds (yellow, white or warm-white).
- Size LxWxH: 280mm x 6mm x 3.3mm
- Maximum current consumpon of 40mA ( 20mA per segment )
- Voltage consumpon 5V to 30V
- Track connecon (1)
- Connecon for external lighng (2)
- Extra an ash capacitor connecon (3)
- An-ashing capacitor (4)
- Adjustable light intensity (5)
- Divisible in dierent lengths up to a minimum length of 2 LEDs (+/- 4cm). (6)

4
www.digikeijs.com
DR100/DR110 28cm led strip (yellow/white/warm white)
Shortening the LED strip
You can bring the LED strip to the right length yourself depending on the size of your car-
riage. This can be done with a pair of cuers, for example. The LED strip can be shorte-
ned per LED.
Dividable lengths
Below is an illustraon of all dividable opons.
0CM 5CM 8CM 11CM 14CM 19CM 22CM 25CM

5
www.digikeijs.com
DR100/DR110 28cm led strip (yellow/white/warm white)
Adjusng brightness
All colour versions of the DR110 have an adjustable brightness by means of a miniature
potenometer (5). This can be turned with a small screwdriver to adjust the brightness.
Do it yourself an blink soluon
Why?
It is possible to t an extra capacitor per voltage group yourself. An extra capacitor provi-
des a larger current buer and prevents the LED strip from ashing if the track contact is
poor.
PLEASE NOTE: Your warranty will be voided by carrying out this an-blinking soluon.
Requirements
Electrolyc capacitor with a minimum capacity of 220uF and a minimum voltage of 16
Volt. (2 capacitors are required for the complete strip).
Arcle number: DR60023 to DR60026 (dierent numbers per package) see also overview
on page 7.

6
www.digikeijs.com
DR100/DR110 28cm led strip (yellow/white/warm white)
Connecon example
The LED strips are equipped with the correct connecon opons for the capacitors. The
illustraon below shows how to mount the capacitors. NOTE: Polarity is very important.
So pay aenon to plus and minus of the capacitor.
+
-

7
www.digikeijs.com
DR100/DR110 28cm led strip (yellow/white/warm white)
Addional product numbers
DR60005 Contacts H0 10 pieces
DR60010 Contacts N 10 pieces
DR60023 Capacitor 220uF /16V 20 pieces
DR60024 Capacitor 470uF/16V 10 pieces
DR60025 Capacitor 1000uF/16V 10 Pieces
DR60026 Capacitor 2200uF/16V 5 Pieces
DR60105-N Mixed Figures standing/sing 1000 Pieces
DR60105-H0 Mixed gures standing/sing 1000 pieces
DR60110-N Standing gures 100 pieces
DR60110-H0 Standing gures 100 pieces
DR60120-N Sing gures N scale 100 pieces
DR60120-H0 Sing gures H0 scale 100 pieces
