Avantes AvaLight-D-S User manual

ID: 020407
Revision: 1-00
1
© Avantes BV
www.avantes.com
[email protected]om
This document is protected by copyright. Do not copy or publish this document or parts of it without
written permission of Avantes BV.
Product specifications and descriptions in this manual are subject to change without notice. Avantes
BV will not be responsible for errors and omissions in this manual or for direct or incidental damages
in connection with the use of this device or information.
© 2016 Avantes BV
Oude Apeldoornseweg 28
7333 NS Apeldoorn
The Netherlands
Phone: [phone]
Website: http://www.avantes.com
E-Mail: [e-mail]

ID: 020407
Revision: 1-00
2
© Avantes BV
www.avantes.com
[email protected]om
Table of Content
1Introduction ......................................................................................................3
2AvaLight-D(H)-S ..................................................................................................4
2.1 Quick start ..................................................................................................4
2.2 Deuterium Light............................................................................................5
2.3 Halogen Light...............................................................................................5
2.4 TTL Shutter –Open.........................................................................................5
2.5 Power connector with double Fuse and switch ......................................................5
2.6 Halogen light power adjustment........................................................................6
2.7 I/O connector ..............................................................................................6
3Replacement of Deuterium or Halogen Lamp ..............................................................7
4Technical support................................................................................................9
4.1 Getting Help................................................................................................9
4.2 AvaSoft updates............................................................................................9
4.3 Trouble Shooting...........................................................................................9
4.3.1 Deuterium and Halogen lamps ....................................................................9
4.3.2 Deuterium Lamp Only ..............................................................................9
4.3.3 Halogen Lamp Only................................................................................ 10
5Specifications................................................................................................... 11
5.1 Ordering Information ................................................................................... 11

ID: 020407
Revision: 1-00
3
© Avantes BV
www.avantes.com
[email protected]om
1Introduction
Thank you for purchasing the Avantes AvaLight-D(H)-S. This light source will provide outstanding
performance. To get the best of its performance it perfectly matches all Avantes AvaSpec
spectrometers.
The AvaLight-D(H)-S provides more power than the AvaLight-DHc. The AvaLight-DH-S is Avantes most
powerful deuterium halogen light source. The AvaLight-D(H)-S is a combined deuterium and halogen
light source, capable of transmitting light in the UV/VIS/NIR-range.
The AvaLight-D-S is a deuterium light source only, making it a great option for measurements in the
UV range, 190-400 nm. The AvaLight-D-S-DUV version starts even lower at 175 nm, for your deep-UV
experiments. This version also offers twice the intensity at 200 nm.
The output of the AvaLight-DH-S is optimized for fibers or bundles upto 600 micrometers. For larger
fibers the focal point is manually adjustable to optimize the light coupling into your fiber.
The AvaLight-D(H)-S features an integrated TTL-shutter and filter holder for filters of up to
50x50x5.0 mm.
The AvaLight-D(H)-S is a risk group 3 product for the actinic UV range of the EN-IEC 62471 Photo
biological Safety Assessment.
Therefore additional measures are required for the AvaLight-D(H)-S.
Warning:
This lamp produces ultraviolet radiation, which are harmful to the eyes and skin. Avoid eye and
skin exposure to unshielded product.
DO NOT LOOK INTO THE LIGHT BEAM. THIS CAN CAUSE PERMANENT EYE DAMAGE –
WEAR PROTECTIVE EYE WEAR –USE THE SUPPLIED SAFETY GOGGLES.

ID: 020407
Revision: 1-00
4
© Avantes BV
www.avantes.com
[email protected]om
2AvaLight-D(H)-S
2.1 Quick start
SMA-plug
Connect the SMA connector of the fiber to the SMA-plug of the Light Source.
Connect your Fiber optic Cable first before starting the Deuterium Lamp. Please be sure to
avoid direct radiation of skin and eyes at the fiber output.
TTL shutter
Shutter LED
SMA-plug
Halogen switch
Halogen LED
Deuterium
switch
Deuterium LED
Power
connector
Double fuse
Power switch
I/O connector
Halogen
adjustment port

ID: 020407
Revision: 1-00
5
© Avantes BV
www.avantes.com
[email protected]om
2.2 Deuterium Light
By switching the Deuterium switch downwards to ON the Deuterium lamp is preheated. After a
warm-up time of 10-20 sec. the Deuterium lamp will ignite automatically.
After successful ignition the Deuterium LED lights up green and indicates that the Deuterium lamp is
in operation. Should the Deuterium lamp not ignite the Deuterium LED lights up red. This indicates a
malfunction of the lamp. See section “4.3 Trouble Shooting”. Switch to OFF to reset the Error LED.
Switching the Deuterium switch to upwards to OFF the Deuterium lamp switches off.
Switch position
Deuterium light
Up
OFF
Down
ON (after 10-20 seconds)
2.3 Halogen Light
Switching the Halogen switch downwards to ON, the Halogen lamp switches on. The Halogen LED
indicates the operation mode.
Switching the Halogen switch upwards to OFF, the Halogen lamp switches off.
Switch position
Halogen light
Up
OFF
Down
ON
2.4 TTL Shutter –Open
This switch is used to open and close the shutter either manually or by TTL pulse.
The LED indicated if the shutter open (LED on) or closed.
Position switch
Shutter
Up
Closed or TTL activated
Down
Open
2.5 Power connector with double Fuse and switch
The power connector for 100-240 VAC is located on the rear of the AvaLight-D(H)-S. Be careful to
use it with a designated power range only, please use the included power cord with the instrument.
For UK, US and Australian power cords, contact Avantes Technical Support.
The 2 Fuses are 1A slow blowing Fuses.
Disconnect power before opening housing or replace Fuse.
The installation category for this equipment is Class 2.

ID: 020407
Revision: 1-00
6
© Avantes BV
www.avantes.com
[email protected]om
2.6 Halogen light power adjustment
The halogen light, that is focused through the Deuterium Lamp 0,5 mm aperture, can be regulated
in the optical power to match the Deuterium output. In order to obtain a more “ balanced”
spectrum, the multi-turn potentiometer in the backside of the light source can be turned to
regulate the halogen power.
2.7 I/O connector
For automatic shutter control to be controlled by software it is needed to connect an AvaSpec
spectrometer to the AvaLight-D(H)-S with the interface cable IC-DB26-2. Now it is possible to
control the shutter by software (AvaSoft).
The signals on the I/O connector are described below.
Pin configuration
Pin
Name
Description
10
GND
Ground
13
shutter
Input, used to close/open the shutter
Below the electrical characteristics for the input signals.
Electrical characteristics
Name
Low level detection
High level detection
Maximum voltage
Shutter
< 1.0V
> 2.0V
5.0V

ID: 020407
Revision: 1-00
7
© Avantes BV
www.avantes.com
[email protected]om
3Replacement of Deuterium or Halogen Lamp
Warning:
Make sure the Deuterium Lamp is switched OFF before disconnecting the power cord.
Before re-connecting the power cord, make sure that the power switch, the Deuterium lamp and
the Halogen lamp switch are switched off.
Warning:
During operation the lamp envelope reaches a temperature of approx. 250°C. Should you intend to
change the lamp please wait for at least 20 minutes for cooling before touching the lamp. The lamp
envelope (quartz glass) should not be touched with bare fingers, otherwise lifetime will be severely
reduced.
Please follow these instructions for the bulb replacement:
1. Switch off the light source and disconnect the unit from the mains power supply.
2. Remove both side covers by unclicking.
3. Remove the 4 screws securing the top cover by using a torx screwdriver to remove the top
cover.
4. Disconnect the deuterium power connector.
5. Dismount the front panel by unscrewing the 4 front screws.
6. Carefully slide out the front panel until the green connector is visible and disconnect the
connector of the switches.
7. Turn the light source upside down and carefully slide out the front panel.
Switch
connector
Deuterium
connector

ID: 020407
Revision: 1-00
8
© Avantes BV
www.avantes.com
[email protected]om
For the deuterium bulb replacement please follow step 8 - 11.
For the halogen bulb replacement please follow step 12 - 16.
8. Remove the 2 screws securing the metal ring around the deuterium lamp.
9. Take out the deuterium lamp, caution: lamp may be hot.
10. Fit a new deuterium lamp, caution: do not touch the lamp glass with your bare fingers.
11. Replace the metal ring and replace the 2 screws to secure the deuterium lamp.
12. Remove the 2 screws of the halogen lamp fitting.
13. Take out the halogen lamp fitting.
14. Replace the halogen bulb with new 5W bulb, caution: do not touch the lamp glass with your
bare fingers.
15. Replace the halogen lamp fitting.
16. Replace the 2 screws to secure the halogen lamp fitting.
17. Slide back the front panel into the housing, take care of wires not getting pinched.
18. Turn the light source housing top-up and re-connect the deuterium power connector and
switch connector.
19. Replace the top cover.
20. Replace the 4 screws to secure the top cover.
21. Replace the side covers.
Halogen
screws
Deuterium
screws

ID: 020407
Revision: 1-00
9
© Avantes BV
www.avantes.com
[email protected]om
4Technical support
4.1 Getting Help
If you have any questions, comments or requests concerning your AvaLight-DHS or the AvaSoft
software, please visit: http://www.avantes.com
In case you have any questions or need support, please send us an email via [e-mail]
4.2 AvaSoft updates
To check for updates, you can choose “Check for Updates” from the Help menu or go to the
“Support” section on our website www.avantes.com.
4.3 Trouble Shooting
4.3.1 Deuterium and Halogen lamps
FAULT
POSSIBLE CAUSE
REMEDY
Light doesn’t turn on, clicking
sound is audible
Front light switches are ON
before main power is
switched on.
Put buttons for Deuterium and
Halogen in OFF position before
switching on main power.
4.3.2 Deuterium Lamp Only
FAULT
POSSIBLE CAUSE
REMEDY
Power switch on, fan not
working, nor one of the LED's
or lights
Line power not present
Check line voltage
Fuse defective
Check /replace fuse(s)
Deuterium Lamp does not
ignite.
The Two-Color-LED of
deuterium lights up red
(ERROR)
Deuterium Lamp too hot
Allow Deuterium Lamp to cool
down.
Switch to OFF to reset the
Deuterium lamp, then switch to
ON to restart.
Lifetime of Deuterium
Lamp has expired
Replace Deuterium Lamp
Deuterium Lamp internal
connection plug is not
connected right
Open Unit and connect connector
plug
Deuterium Lamp extinguishes
during operation
When this fault appears always switch off the deuterium power
and then - after cool down - restart

ID: 020407
Revision: 1-00
10
© Avantes BV
www.avantes.com
[email protected]om
4.3.3 Halogen Lamp Only
FAULT
POSSIBLE CAUSE
REMEDY
Halogen Lamp does not work
after switching on
Halogen Lamp defective
Replace Halogen Lamp
LED does not light up after
switching on Halogen lamp
Internal Power Supply is
defective
Disconnect the unit from mains
power and inform your dealer

ID: 020407
Revision: 1-00
11
© Avantes BV
www.avantes.com
[email protected]om
5Specifications
Deuterium (Deep UV)/
Long life
Deuterium (Standard)/
Long life
Halogen Lamp
Wavelength Range
175-400nm
190-400nm
360-2500nm
Warm-up Time
30 min.
20 min.
Lamp Power
78W / 0.75A
5W /0.5A
Lamp Lifetime
2000 hrs.
1000 hrs.
Noise (AU)
2x 10-5
10-4
Max. drift
± 0.5%/hr.
± 0.1%/hr.
Color Temperature
-
3000 K
Optical Power* in
200μm fiber
11 µW
43 µW
Optical Power* in
600μm fiber
72 µW
239 µW
Optical Power* in
1000μm fiber
206 µW
354 µW
Power consumption
90 Watt (190Watt for heating D-Lamp 4-5 sec.)
Power Requirements
100-240VAC 50/60 Hz
Dimensions / Weight
315 x 165 x 140 mm / ca 5 kg.
*) total power for the specified wavelength range.
5.1 Ordering Information
AvaLight-D-S
Deuterium light source, 190-400 nm, incl. TTL shutter, -SR fibers needed
AvaLight-DH-S
Deuterium-Halogen light source, 190-2500 nm, incl. TTL shutter, -SR fibers
needed
AvaLight-D-S-DUV
Deep UV deuterium light source, 175-400 nm, incl. TTL shutter, -SR fibers
needed!
AvaLight-DH-S-DUV
Deep UV deuterium-halogen light source, 175-2500 nm, incl. TTL shutter, -SR
fibers needed!
IC-DB26-2
Interface cable AvaSpec-USB2 platform to AvaLight-D(H)S
AvaLight-D-B
Replacement deuterium bulb for AvaLight-D/AvaLight-DH light source
AvaLight-D-B-DUV
Replacement deep UV deuterium bulb for AvaLight-D/AvaLight-DH light source
AvaLight-DH-B
Replacement halogen bulb for AvaLight-DH light source
CUV-DA-DHS
Direct attach cuvette holder for AvaLight-D(H)S
