STARVILLE DJ Lase 400-B Blue DMX showlaser User manual

DJ Lase 400-B Blue DMX
showlaser
user manual

Musikhaus Thomann e.K.
Treppendorf 30
96138 Burgebrach
Germany
Telephone: [phone]
email: [email protected]
Internet: www.thomann.de
19.03.2012

Table of contents
1 General notes............................................................................................................................................... 5
2 Safety instructions..................................................................................................................................... 8
3 Features....................................................................................................................................................... 16
4 Installation.................................................................................................................................................. 17
5 Starting up.................................................................................................................................................. 21
6 Components and functions................................................................................................................ 24
7 Operation.................................................................................................................................................... 32
7.1 Starting the device........................................................................................................................... 32
7.2 Main menu.......................................................................................................................................... 33
7.3 Menu overview................................................................................................................................. 36
7.4 Functions in ‘DMX’ mode ............................................................................................................. 37
7.5 Pattern list........................................................................................................................................... 40
7.6 Stopping the device........................................................................................................................ 42
8 Troubleshooting...................................................................................................................................... 43
Table of contents
DJ Lase 400-B Blue DMX
3

9 Cleaning....................................................................................................................................................... 46
10 Technical specifications....................................................................................................................... 47
11 Protecting the environment.............................................................................................................. 49
Table of contents
showlaser
4

1 General notes
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.
This section gives an overview of the symbols and signal words used in this user manual.Symbols and signal words
General notes
DJ Lase 400-B Blue DMX
5

Signal word Meaning
DANGER! This combination of symbol and signal word
indicates an immediate dangerous situation
that will result in death or serious injury if it is
not avoided.
WARNING! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in death or serious injury if it is not
avoided.
NOTICE! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in material and environmental
damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
General notes
showlaser
6

Warning signs Type of danger
Warning – laser radiation.
Warning – suspended load.
Warning – danger zone.
General notes
DJ Lase 400-B Blue DMX
7

2 Safety instructions
Use the device only as described in this user manual. Any other use or use under other oper‐
ating conditions is considered to be improper and may result in personal injury or property
damage. No liability will be assumed for damages resulting from improper use.
This device has been designed exclusively for show applications. Any claims for damages
resulting from improper use or use that is not intended shall be excluded in all cases.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
showlaser
8

Laser safety requirements are based on DIN EN 60825-1. The corresponding accident preven‐
tion regulation of the Accident Prevention and Insurance Association in Germany is BGV-B2.
This device contains a class-3B laser. It is equipped with a safety key. Always remove the key
when the device is not attended by a trained operator.
As an operator you are responsible for the safety of all persons present. Familiarize yourself
with the laser safety regulations that apply in your country. To ensure safe operation, it is
important to pay attention to the following instructions.
Prior to commissioning, the company/operator must appoint a qualified person as laser pro‐
tection officer in writing and notify the operation of the laser equipment to the Accident Pre‐
vention and Insurance Association and to the authority responsible for occupational safety. In
the event of public use, the complete laser equipment must be approved by an expert (e. g.
the Technical Control Board TÜV) prior to commissioning.
Laser safety basics
Safety instructions
DJ Lase 400-B Blue DMX
9

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Safety
Safety instructions
showlaser
10

DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis‐
tered electrician.
DANGER!
Laser radiation – avoid exposure to beam
The device contains a class-3B laser, classified according to EN 60825-1. Do not
look into the laser beam. The laser beam can injure your eyes when you directly
look into it. Do not expose yourself to the laser beam. The laser beam can cause
skin burns.
In this context take extreme care when using converging optical instruments.
Safety instructions
DJ Lase 400-B Blue DMX
11

WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
NOTICE!
Laser radiation – risk of fire
Keep the area exposed to laser radiation free from flammable substances.
Safety instructions
showlaser
12

NOTICE!
Risk of fire
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked flames.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety instructions
DJ Lase 400-B Blue DMX
13

NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
NOTICE!
Risk of fire due to incorrect polarity
Incorrectly inserted batteries may destroy the device or the batteries.
Ensure that proper polarity is observed when inserting batteries.
Safety instructions
showlaser
14

NOTICE!
Possible damage by leaking batteries
Leaking batteries can cause permanent damage to the device.
Take batteries out of the device if it is not going to be used for a longer period.
Safety instructions
DJ Lase 400-B Blue DMX
15

3 Features
This showlaser is specially suited for discos, clubs, bars, small stages, etc. and can be easily inte‐
grated into the light show.
Special features of this device:
nControl via DMX (8 channels), via infrared remote control and via buttons and display on
the unit
nBuilt-in automatic show programmes
nSound control
nMaster / slave mode
n32 different patterns
nBlue laser diode (400 mW)
Features
showlaser
16

4 Installation
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the device against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
You can install the device on the wall, ceiling or floor. A mounting bracket and the necessary
screws are included in the package.
DANGER!
Laser radiation
During installation you have to follow the instructions given here: Ä Chapter 2
‘Safety instructions’ on page 8.
To avoid unintended laser radiation, remove the safety switch before you start
the installation of the device.
Installation
DJ Lase 400-B Blue DMX
17

WARNING!
Stray laser radiation
Inadequately secured additional components may cause stray laser radiation.
Make sure that all additional components are adequately secured.
WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
Installation
showlaser
18

NOTICE!
Risk of overheating
The distance between the light output and the illuminated surface must be more
than 0.5 m (19.7 in).
Always ensure sufficient ventilation.
The ambient temperature must always be below 40 °C (104 °F).
The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please
refer to the drawing and table below for pin assignment.
1 Ground, shielding
2 DMX data (–)
3 DMX data (+)
DMX connections
Installation
DJ Lase 400-B Blue DMX
19

Push the lock of the battery holder towards the centre of the housing and pull out the battery
holder like a drawer. Insert the battery. The battery is correct, if the positive pole points to the
housing bottom of the remote control. Slide the battery holder back into the remote until it
clicks into place.
Insert the battery into the
remote control
Installation
showlaser
