FourStarGroup 11210652V User manual
ITEM# 11210652
SIZE: 21L X 29.7H(CM)
11210652
FOUR TIER AUDIO RACK
STEP 2
ATTACH TUBES ( 1 ) AND LEGS ( 6 ) TO A SHELF PANEL ( B )
AND THEN USING SCREWS ( 2 ) TO BACK PANEL ( C )
AS SHOWN.
STEP 3
ATTACH SHELF PANEL ( B ) TO ASSEMBLED FROM STEP 2
USING TUBES ( 1 ) AND SCREWS ( 2 ) AS SHOWN.
2 4 5 6 9
ASSEMBLY INSTRUCTIONS
STEP 1
ATTACH 2PCS NAIL WITH PINS ( 4 ) TO BACK PANEL ( C )
AS SHOWN.
BEFORE YOU BEGIN, PLEASE READ ASSEMBLY
INSTRUCTIONS CAREFULLY. FOLLOW THEM STEP BY STEP.
Do you have any questions ? Missing small parts or hardware?
If you need assistance with the assembly of your 4 Tier Audio
Rack please e-mail our Customer Service
Department at:
or call us at (508) 435-4830
or (800) 639-3803
Please include the following information in your email:
• Where item was purchased
• Item, model, style or SKU number listed on instructions
or box
• Part number, description of the part and quantity needed
This information will help us get the proper part to you faster
This unit is intended for use only with the
products and maximum weights indicated. Use
with other products or products heavier than the
maximum weights indicated may result in
instability causing possible injury. Furniture can
tip over or break if improperly moved. Have a
friend help to lift and carry the unit to it's new
location.
FDS 11210652 FOUR TIER AUDIO RACK DorisJosh 2008
01/24
ITEM DESCRIPTIONITEM NO. DESIGNERMDSERCUSTOMER DATEA/W NO.
This proprietary artwork and concepts are copyright designs of Fourstar Group Inc. 2007. No part of this artwork may be
reproduced or transmitted in any form without express written consent. © Fourstar Group Inc. All Rights Reserved.
2 SCREW - 2 PCS
1 TUBE - 2 PCS
6 LEG - 2 PCS
4 NAIL WITH PIN - 2 PCS
3
PARTS LIST
TOP PANEL
SHELF PANEL
BACK PANEL
C
B
NO
A
1 pc
QTY
1 pc
3 pcs
STEP 4
ATTACH SHELF PANEL ( B ) TO PREVIOUSLY ASSEMBLED
SECTION FROM STEP 3 USING TUBES ( 1 ) AND SCREWS ( 2 )
AS SHOWN.
7
STEP 5
ATTACH TOP PANEL ( A ) TO PREVIOUSLY ASSEMBLED
SECTION FROM STEP 4 USING DOWELS ( 3 ) AND CAPS ( 5 )
AS SHOWN.
89 lbs
89 lbs
89 lbs
89 lbs
8
3 DOWEL - 2 PCS
BEFORE YOU BEGIN, PLEASE READ ASSEMBLY
INSTRUCTIONS CAREFULLY. FOLLOW THEM STEP BY STEP.
CAUTION :
1. ADULT SUPERVISION IS REQUIRED DUE TO SMALL PARTS.
CARE SHOULD BE TAKEN IN THE UNPACKING AND
ASSEMBLY OF THE PRODUCT.
2. ASSEMBLE ON SOFT SURFACES TO PREVENT DAMAGE TO
THE PRODUCT FINISH.
3. MAKE SURE ALL PARTS ARE INCLUDED BEFORE ASSEMBLY.
ASSEMBLY TOOLS REQUIRED
RUBBER MALLET
PARTS
HARDWARE LIST
NAIL WITH PIN
4
TUBE
SCREW
DOWEL
3
2
NO
1
2 pcs
2 pcs
QTY
6 pcs
5 CAP 2 pcs
6 LEG 2 pcs
6 pcs
5 CAP - 2 PCS
A
B
B
B
C
C
4
BACK VIEW
B
C
C
B
6
1
2
2
6
1
PHILLIPS
SCREWDRIVER
BACK VIEW
B
B
C
C
B
2
1
2
1
BACK VIEW
B
B
B
C
C
B
11
2
2
A
B
B
B
C
55
3
2 SCREW - 2 PCS
1 TUBE - 2 PCS
2 SCREW - 2 PCS
1 TUBE - 2 PCS
