FourStarGroup MS30-084-008-16 User manual

UPC#4893948113408 MODEL: MS30-084-008-16
TV STAND & TABLE SET
Do you have any questions? Missing small parts or hardware?
If you need assistance with the assembly of your TV STAND &
TABLE SET please e-mail our Customer Service Department at:
[email protected] or call us at 1-800-639-3803
Please let customer service know:
1. You purchased this item from Wal-Mart
2. The item description is: TV STAND & TABLE SET
3. The item number is MS30-084-008-16
4. The part number/letter and quantity needed
If you have this information ready, we will be able to
process your request promptly. Thank you
LOT#0308-00000 DATE PURCHASED_______________
/ /
ITEM: MS30-084-008-16
Do not return to the store
STOP
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
THIS INSTRUCTION MANUAL IS PRINTED ON RECYCLED PAPER
USING EARTH FRIENDLY SOY BASED INK.

2
HAMMER
OR
CAUTION :
1. Read this instruction manual and keep it for reference.
2. Adult supervision is required due to small parts.
3. Assemble on soft surfaces to prevent damage to the
product finish.
4. Recommended two people to assemble the product.
5. Estimated half hour for assembly.
6. Make sure all parts are included before assembly.
7. Call our toll-free customer service if needed.
ASSEMBLY TOOLS REQUIRED
RUBBER HAMMER
This unit is intended for use only with the
products and maximum weights indicated. Use
with other products or products heavier than the
maximum weights indicated may result in
instability causing possible injury. Furniture can
tip over or break if improperly moved. Have a
friend help to lift and carry the unit to it's new
location.
80 lbs.
(37 in Flat Panel TV)
20 lbs.
30 lbs.
20 lbs.
10 lbs.
40 lbs.
40 lbs.
20 lbs.

33
PARTS AND HARDWARE
BEFORE YOU BEGIN, PLEASE FOLLOW ASSEMBLY INSTRUCTIONS CAREFULLY.
FOLLOW THEM STEP BY STEP.
1
2
3
4
5
6
7
8
A
B
C
D
E
F
G
H
I
Part Name
Long Tube 3.8 x 3.8 x 47cm 4 PE Black
PE Black
PE Black
PE Black
PE Black
PE Black
Wood Brown
PE White
Particleboard Black
Particleboard Black
Particleboard Black 4
Particleboard Black 2
4
4
Particleboard Black 2
Particleboard Black 4
Particleboard Black 4
Particleboard Black 4
Particleboard Black 4
12
8
8
8
4
8
4
1
1
1
2
1
1
1
1
1
3.4 x 3.4 x 37cm
3.4 x 3.4 x 19.2cm
3.4 x 3.4 x 4.8cm
3.4 x 3.4 x 2.4cm
4 x 4 x 2.2cm
0.6 x 0.6 x 3cm
0.9 x 0.9 x 1.5cm
1.5 x 39.5 x 106.7cm
1.15 x 32 x 106.7cm
1.15 x 47 x 106.7cm
1.15 x 29 x 34cm
1.15 x 28.6 x 45cm
1.5 x 50 x 90cm
1.15 x 39.5 x 80cm
1.5 x 39.5 x 39.5cm
1.15 x 39.5 x 39.5cm
Medium Tube
Short Tube
Long Foot
Short Foot
Foot
Wooden Dowel
Shelf Support
Top Panel
(Entertainment)
Center Panel
(Entertainment)
Bottom Panel
(Entertainment)
Side Panel
(Entertainment)
Shelf Panel
(Entertainment)
Shelf Panel
(Coffee Table)
Top Panel
(Coffee Table)
Shelf Panel
(End Table)
Top Panel
(End Table)
SizeLine-art Drawing Quantity Material Finish
Finished
Edges
9Warning Label Label White
1
5.6 x 6.4cm
Never use this furniture with a TV that is
too large or too heavy.Severe injury or
death can occur. The TV and furniture will
be unstable and may tip.
- The TV must weight less than 80 lbs.
- The base of the TV must be able to sit
completely on this shelf.
- The edge of the TV base must be
positioned 3 inches from the rear edge of
the table top.
This item is designed for most flat panel
type TV having up to 37" diagonal screen
measurement.
Refer to instruction book for complete
safety information.
WARNING
!

4
ASSEMBLY INSTRUCTIONS
Step 1.
Attach SHORT TUBES (3) to TOP PANEL (A).
A Top Panel - 1 PC
3 Short Tube - 8 PCS
3
A
ENTERTAINMENT CENTER

5
Step 2.
Attach CENTER PANEL (B) using MEDIUM TUBES (2).
B Center Panel - 1 PC
2 Medium Tube - 8 PCS
2
A
B

6
Step 3.
Insert WOODEN DOWELS (7) into SIDE PANEL (D).
Next attach SIDE PANEL (D) to CENTER PANEL (B).
D Side Panel - 2 PCS
7 Wooden Dowel - 8 PCS
A
B
D
D
7

7
Step 4.
Using a rubber hammer, attach FOOT (6) to BOTTOM PANEL (C).
C Bottom Panel - 1 PC
6 Foot - 4 PCS
6
C

8
Step 5.
Attach BOTTOM PANEL (C) using SHORT FOOT (5).
C Bottom Panel - 1 PC
5 Short Foot - 8 PCS
5
C
B
A
D
D

9
Step 6.
Insert SHELF SUPPORTS (8) into SIDE PANEL (D) and then add
SHELF PANEL (E).
E Shelf Panel - 1 PC
8 Shelf Support - 4 PCS
8
E
A
B
C
D
Apply the WARNING LABEL (9) to the TOP PANEL (A). You should be
able to read the label when the TV is removed from the unit. When the
TV is in place, it should hide the label. Peel off the backing and apply
the label as shown in the diagram.
NOTE: This is a permanent label intended to last for the life of the
product. Once applied, do not try to remove it.
9 Warning Label - 1 PC
9
Never use this furniture with a TV that is
too large or too heavy. Severe injury or
death can occur. The TV and furniture will
be unstable and may tip.
- The TV must weight less than 80 lbs.
- The base of the TV must be able to sit
completely on this shelf.
- The edge of the TV base must be
positioned 3 inches from the rear edge of
the table top.
This item is designed for most flat panel
type TV having up to 37" diagonal screen
measurement.
Refer to instruction book for complete
safety information.
WARNING
!
Never use this furniture with a TV that is
too large or too heavy.Severe injury or
death can occur. The TV and furniture will
be unstable and may tip.
- The TV must weight less than 80 lbs.
- The base of the TV must be able to sit
completely on this shelf.
- The edge of the TV base must be
positioned 3 inches from the rear edge of
the table top.
This item is designed for most flat panel
type TV having up to 37" diagonal screen
measurement.
Refer to instruction book for complete
safety information.
WARNING
!

10
Step 7.
Attach MEDIUM TUBES (2) to TOP PANEL (F).
F Top Panel - 1 PC
2 Medium Tube - 4 PCS
F
2
COFFEE TABLE

11
Step 8.
Attach SHELF PANEL (G) using LONG FOOT (4).
G Shelf Panel - 1 PC
4 Long Foot - 4 PCS
4
F
G

12
Step 9.
Attach LONG TUBES (1) to TOP PANEL (H).
H Top Panel - 1 PC
1 Long Tube - 4 PCS
1
H
END TABLE

13
Step 10.
Attach SHELF PANEL (I) using LONG FOOT (4).
I Shelf Panel - 1 PC
4 Long Foot - 4 PCS
I
4
H

14
This unit is intended for use only with the
products and maximum weights indicated. Use
with other products or products heavier than the
maximum weights indicated may result in
instability causing possible injury. Furniture can
tip over or break if improperly moved. Have a
friend help to lift and carry the unit to it's new
location.
Do you have any questions? Missing small parts or hardware?
If you need assistance with the assembly of your TV STAND &
TABLE SET please e-mail our Customer Service Department at:
[email protected] or call us at 1-800-639-3803
To clean the TV stand & table set, wipe with soft, dry cloth. Apply a small
amount of cleaning solution to the cloth if required. Do not use abrasive
cleaners in order to prevent scratching the surfaces.
20 lbs.
10 lbs.
30 lbs.
20 lbs.
80 lbs.
(37 in Flat Panel TV)
40 lbs.
40 lbs.
20 lbs.
NOTE:
away from the rear edge of the top. Put the T unit
BACK IEW
The base of the TV unit must be 3 inches
V
V
with equal distance side-to-side to ensure mounting
stability. Failure to mount the T unit properly can
V
render the product unstable which may cause
damage of in ury.
