Foxconn 945GZ7MC User manual

Statement:
Thismanualistheintellectualpropertyof Foxconn,Inc.Althoughthe
informationinthismanualmaybechangedormodifiedatanytime,
Foxconn doesnot obligateitself toinformtheuser of these changes.
Trademark:
Alltrademarksarethepropertyoftheir respectiveowners.
Version:
User sManualV1.0for 945GZ7MCmotherboard.
Symboldescription:
Note: referstoimportantinformationthatcanhelpyoutousemotherboard
better.
Attention: indicatesthat itmaydamagehardwareor cause dataloss,
and tellsyou howtoavoidsuch problems.
Warning: meansthat apotentialrisk of propertydamage orphysical
injuryexists.
Moreinformation:
If youwantmoreinformationabout our products,pleasevisit Foxconn s
website: http://www.foxconnchannel.com
WEEE:The useof thesymbolindicatesthat thisproductmay notbe treated
ashouseholdwaste.ByEnsuringthisproductisdisposedofcorrectly,youwill
helppreventpotentialnegativeconsequences fortheenvironmentandhuman
health,which couldotherwise becausebyinappropriatewastehandling ofthis
product.For moredetailedinformationaboutrecyclingofthisproduct,please
contactyour localcityoffice, yourhouseholdwastedisposalservice ortheshop
whereyoupurchasedthe product.
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Declaration ofconformity
HONHAIPRECISIONINDUSTRYCOMPANYLTD
66,CHUNGSHAN RD.,TU-CHENGINDUSTRIALDISTRICT,
TAIPEI HSIEN,TAIWAN, R.O.C.
declaresthatthe product
Motherboard
945GZ7MC
isinconformitywith
(referencetothespecification under which conformityisdeclared in
accordance with89/336EEC-EMCDirective)
þEN55022:1998/A2:2003Limitsandmethodsofmeasurementsofradiodisturbance
characteristicsofinformationtechnologyequipment
þEN61000-3-2/:2000 Electromagneticcompatibility(EMC)
Part3: Limits
Section 2:Limitsforharmoniccurrent emissions
(equipmentinput current <=16Aperphase)
þEN61000-3-3/A1:2001 Electromagneticcompatibility(EMC)
Part3: Limits
Section2:Limitsof voltagefluctuationsand flickerin low-voltage
supplysystems forequipmentwithratedcurrent<= 16A
þEN55024/A2:2003 Informationtechnologyequipment-Immunitycharacteristicslimits
andmethodsof measurement
Signature: Place/ Date: TAIPEI/2007
PrintedName: JamesLiangPosition/Title: AssistantPresident
PDF 件使用 "pdfFactory" 试用版本创建 ³ ³www.fineprint.com.cn

Declaration ofconformity
Trade Name: FOXCONN
ModelName: 945GZ7MC
ResponsibleParty: PCE IndustryInc.
Address: 458 E.Lambert Rd.
Fullerton,CA92835
Telephone: [phone]
Facsimile: 714-738-8838
Equipment Classification: FCCClassBSubassembly
Type ofProduct: Motherboard
Manufacturer:HON HAIPRECISION INDUSTRY
COMPANYLTD
Address: 66,CHUNG SHANRD.,TU-CHENG
INDUSTRIALDISTRICT, TAIPEIHSIEN,
TAIWAN,R.O.C.
SupplementaryInformation:
ThisdevicecomplieswithPart15oftheFCC Rules. Operationissubjecttothefollow-
ingtwoconditions:(1) thisdevice maynotcauseharmfulinterference,and(2) this
devicemustacceptanyinterference received,includinginterferencethat maycause
undesiredoperation.
TestedtocomplywithFCC standards.
Signature: Date: 2007
PDF 件使用 "pdfFactory" 试用版本创建 ³ ³www.fineprint.com.cn

ProductIntroduction
MainFeatures.............................................................................................2
Layout........................................................................................................3
RearI/OPorts.............................................................................................4
InstallationInstructions
CPU...........................................................................................................6
Memory......................................................................................................9
PowerSupply...........................................................................................10
OtherConnectors.....................................................................................11
Expansion Slots........................................................................................13
Jumpers...................................................................................................14
BIOSDescription
EnterBIOSSetup......................................................................................16
Mainmenu................................................................................................16
AdvancedMenu.......................................................................................18
PowerMenu.............................................................................................20
BootMenu................................................................................................21
Exit Menu.................................................................................................22
TableofContents
Chapter 3
3
Chapter 22
Chapter 1
1
PDF 件使用 "pdfFactory" 试用版本创建 ÿwww.fineprint.com.cn

1.Attach the CPUand heatsinkusing silicageltoensurefullcontact.
2.Itissuggestedtoselecthigh-quality, certified fansinordertoavoid
damagetothemotherboardandCPU duehigh temperatures.
3.Neverturnon themachineiftheCPU fanisnot properlyinstalled.
4.EnsurethattheDC powersupplyisturnedoff beforeinserting or
removingexpansioncardsorotherperipherals,especiallywhen
youinsert orremoveamemorymodule.Failuretoswitchoff the DC
powersupplymayresultinseriousdamagetoyoursystemor
memorymodule.
Attention:
Wecannotguarantee thatyoursystemwill operatenormallywhile
over-clocked. Normaloperation dependson theover-clock capacity
ofyourdevice.
Attention:
Attention:
SinceBIOSprogramsareupgradedfromtimetotime,theBIOS
description inthismanualisjustforreference.Wedo notguarantee
thatthecontentofthismanualwillremainconsistentwiththeactual
BIOSversion atanygiventimeinthefuture.
Attention:
The pictures of objectsusedinthismanualarejustforyour reference.
Pleaserefertothe physicalmotherboard.
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Thismanualissuitablefor motherboardof945GZ7MC. Each
motherboardiscarefullydesignedfor the PCuser whowants
diverse features.
-6with6-Channelaudio(Defaultisomitted)
-8with8-Channelaudio
-Lwithonboard10/100MLAN (Default isomitted)
-KwithonboardGigabit LAN
-SwithSATAfunction
-2withDDR2Slots
-HcomplywithRoHSdirective
Youcanfind PPIDlabelonthemotherboard.It indicatesthe
functions thatthemotherboardhas.
Forexample:
Thelattersonthe black markof the PPIDlabelmeanthat the
motherboardsupports6-channelAudio(-6,Defaultisomitted),
onboard10/100MLAN (-L, Default isomitted), SATAfunction (-
S), DDR2slots(-2),RoHS directive(-H).
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter
ThankyouforbuyingFoxconn s945GZ7MCmotherboard.This
motherboardisoneof ournewproducts,andofferssuperior
performance,reliabilityand quality,atareasonableprice.This
motherboardadoptstheadvancedIntel®945GZ+ICH7chipset,
providingusersacomputerplatformwithahighintegration-
compatibility-performanceprice ratio.
Thischapterincludes thefollowing information:
v MainFeatures
v Layout
v RearI/OPorts
1
1
PDF 件使用 "pdfFactory" 试用版本创建 × ÿ ×www.fineprint.com.cn

Chapter1ProductIntroduction
2
MainFeatures
Size
·uATXformfactorof 9.6inchx8.8inch
Microprocessor
·SupportsIntel®CoreTM2DuoE4xx0series(65W),Pentium®D9xxseries
(95W),Pentium®E2xxxseries(65W),Pentium®46x1series(65W),Celeron®
D3xxseries(65W),Celeron®4xxseries(35W)processorsinanLGA775pack
age
·SupportsFSBat800MHz/533MHz
Chipset
·Intel®945GZ(NorthBridge)+ICH7(SouthBridge)
SystemMemory
·Two240-pinDIMMslots
·SupportsdualchannelDDR2533/400Memory
·Supportsup to4GBDDR2memory
USB2.0Ports
·Supportshotplug
·SixUSB2.0ports(Tworearpanelports,twoonboardUSBheaders
providingfourextraports)
·SupportsUSB 2.0protocolupto480Mb/stransmissionrate
OnboardSerialATAII
·300MB/sdatatransferrate
·Supportsuptotwoserial ATAII devices
OnboardGraphics
·SupportsintegratedVGAdisplayfunction
OnboardAudio(-6)
·SupportsIntel®High Definition Audio
·SupportsS/PDIFoutput
·Supports6-channelaudio
DualOnboardLAN (-L)
·OneLAN interfacebuilt-inonboard
·Supports10/100(-L)Mb/sEthernet
PDF 件使用 "pdfFactory" 试用版本创建 Æ Æwww.fineprint.com.cn

3
Chapter1ProductIntroduction
Layout
Note: Theabovemotherboardlayoutisprovidedforreferenceonly,please
refertothe physicalmotherboard.
Expansion Slots
·TwoPCIslots
·OnePCIExpressx1slot
PDF 件使用 "pdfFactory" 试用版本创建 Æ Æwww.fineprint.com.cn

Chapter1ProductIntroduction
4
RearI/OPorts
Thismotherboardprovides theportsas below:
PS/2 Mouse
Port
PS/2 Key-
boardPort
USB2.0Ports
LANPort(-L)
1
2
VGAPort
34
6
Line-in
(Rear)
Line-out
(Front)
Microphone
(CEN/LFE)
5
Line-injack,Line-outjack,Microphonejack
Whenusing a2-channelsound source,theLine-outjackisusedtoconnectto
speakerorheadphone;The Line-inport connectstoanexternalCD player, tape
playeror other audiodevice.TheMicrophonejack isusedtoconnecttothe
microphone.
Whenusing a6-channelsound source, connectthefrontspeakertothegreen
audiooutput; Connect therearspeaker totheblueaudiooutput; Connectthe
centerspeaker/subwoofertotheredMicrophoneoutput.
5
PDF 件使用 "pdfFactory" 试用版本创建 ÿwww.fineprint.com.cn

5
Chapter1ProductIntroduction
Thischapterintroduces thehardwareinstallation process,in-
cluding theinstallationof theCPU,memory,powersupply,slots,
andpinheaders,andthe mounting ofjumpers.Caution
shouldbeexercisedduringtheinstallationofthese modules.
Please refertothemotherboardlayoutpriortoanyinstallation
andreadthe contentsinthischaptercarefully.
Thischapterincludes thefollowing information:
v CPU
v Memory
v Powersupply
v OtherConnectors
v Expansion Slots
v Jumpers
Chapter2
2
PDF 件使用 "pdfFactory" 试用版本创建 × ÿ ×www.fineprint.com.cn

Chapter2InstallationInstructions
6
CPU
ThismotherboardsupportsIntel®CoreTM2DuoE4xx0series(65W), Pentium®D
9xx series(95W), Pentium®E2xxx series(65W), Pentium®46x1series(65W),
Celeron®D3xx series(65W), Celeron®4xx series(35W) processorsinanLGA775
packagewithaFrontSideBus (FSB)of800/533MHz.
ForthedetailedCPU support listonthismotherboard,please visitthe
website: http://www.foxconnchannel.com
Installation ofCPU
Belowisthe CPU socketillustration. Followtheseprocedures toinstallaCPU.
Loadlever Load plate
Protectivecover
1.Use thumbandforefinger toholdthehookofthe loadlever andpullthe lever
downandaway fromsockettounlock it.Lift theload lever.
2.Pushdownthe rear tab withyourforefingertobringthefrontendofthe load
plateupslightly.Open the loadplatewiththumb.Becarefulnottotouch the
contacts.
PDF 件使用 "pdfFactory" 试用版本创建 Æ Æwww.fineprint.com.cn

Chapter2InstallationInstructions
7
3.HoldCPUwiththumbandforefinger.Ensurefingersaligntosocket cutouts.
Match theCPUtrianglemarkertoPin1positionasshownbelow.Thealignment
key also providestheorientation directedfunction.Lower the CPUstraight down
withouttiltingorslidingtheCPU inthesocket.
4.Afterinstalling theCPU,removetheprotectivecoverfromload plate. The
protectivecoverisusedtoprotectthecontactsofthe socket. Donotdiscardthe
protective cover.Always replacethesocketcover if theCPUisremovedfromthe
socket.
AlignmentKey
SocketCutouts
Pin1position
PDF 件使用 "pdfFactory" 试用版本创建 Æ Æ Æwww.fineprint.com.cn

Chapter2InstallationInstructions
8
5.Closetheloadplate,andslightlypushdownthe tongueside.
6.Lowertheleverand lock ittotheloadplate,thentheCPU islockedcompletely.
Warning:
Excessive temperatures willseverelydamage theCPU and
system.Therefore, you shouldinstall CPU coolingfanand make
surethatthe coolingfanworksnormallyatalltimesinorderto
preventoverheatinganddamagingtotheCPU.Pleaserefertoyour
CPU fanuserguidetoinstall itproperly.
PDF 件使用 "pdfFactory" 试用版本创建 ³ ³www.fineprint.com.cn

Chapter2InstallationInstructions
9
Memory
Thismotherboardincludestwo240-pinslotswith1.8VforDDR2. Youmust
install atleastonememorybank toensurenormaloperation.
Forthe detailedmemorysupportliston thismotherboard,please visitthe
website: http://www.foxconnchannel.com
InstallationofDDR2Memory
1.ThereisonlyonegapnearthecenteroftheDIMMslot, and thememory
modulecan be fixedinonedirection only.Unlock aDIMM slotbypressing the
moduleclips outward.
2.AlignthememorymoduletotheDIMM slot,and insert the modulevertically
intotheDIMMslot.
3.Theplasticclipsatbothsides oftheDIMM slotwill lock automatically.
128 针112 针
Warning:
Besuretounplugthe ACpowersupplybeforeaddingorremoving
expansion cardsorothersystemperipherals,especiallythe
memorydevices,otherwiseyourmotherboardorthesystem
memorymightbeseriouslydamaged.
PDF 件使用 "pdfFactory" 试用版本创建 ³ ³www.fineprint.com.cn

Chapter2InstallationInstructions
10
Power Supply
Thismotherboarduses anATX powersupply.Inordertoavoiddamaging any
devices,make surethat they havebeeninstalledproperlypriortoconnecting
thepowersupply.
24-pinATX powerconnector:PWR1
PWR1istheATXpower supplyconnector. Make
surethatthepowersupplycableandpinsare
properlyalignedwiththeconnectoron the
motherboard.Firmlyplugthepowersupplycable
intotheconnectorand makesureitissecure.
4-pinATX_12 VPowerConnector:PWR2
The4-pinATX12VpowersupplyconnecttoPWR2
andprovides powertotheCPU.
12V
12V
31
PWR2
42
GND
GND
20-PinPowersupply 24-PinPowersupply
Note:
Werecommend you use 24-pinATX powersupply.If youwanttouse
20-pin powersupply,you need toalign theATX powerconnectorac-
cording tothefollowing picture.
13
1
PWR1
+3.3V
GND
+12V
GND
+5V_AUX
+3.3V
+5V
+12V
GND
+5V
+3.3V
PWROK
+3.3V
-12V
NC
+5V GND GND
GND
PSON
+5V
GND GND
+5V
24
12
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter2InstallationInstructions
11
OtherConnectors
ThismotherboardincludesconnectorsforFDDdevices,IDEdevices,Serial
ATAII devices,USB devices,andothers.
FDDConnector:FLOPPY
Thismotherboardincludes astandardFDD connector FLOPPY, supporting [360K,
5.25in], [1.2M,5.25in], [720K,3.5in],[1.44M,3.5in]and [2.88M, 3.5in] floppydisks.
IDEConnector: PIDE
The PIDEconnectorsupportsUltraATA100/66IDEharddisk drives.
AudioConnector:CD_IN
CD_INisSonystandardCDaudioconnector,it canbe
connected toaCD-ROMDrivethroughaCDaudio
cable. CD_IN
1
CD_R
GND
CD_L
FanConnectors:SYS_FAN,CPU_FAN
The fanspeed can be detectedand viewedin “PCHealth
Status”section oftheCMOSSetup.These fanswillbe
automaticallyturnedoff afterthesystementersS3,S4
and S5mode.
SYS_FAN
1
SENSE
+12V
GND
CPU_FAN
POWER
GND
1
CONTROL
SENSE
USBHeaders:F_USB1,F_USB2
Inaddition tothetwoUSB portson therearpanel,this
seriesofmotherboards alsohave two10-pinheaders
on-board,which maybeusedtoconnectafrontpanel
USB cable/brackettoprovide additionalfourUSB ports. F_USB1/2
109
VCC
D+
D-
Empty
GND
NC
VCC
GND
D+
21
D-
Note:
Beforeinstalling the USB cables, pleasepay attention tothemarker foreach
individualconnector;make suretomatch themtotheUSB pinheaders
correctly,otherwise theUSB portswill notwork. Incorrectconnection could
alsodamagethemotherboard!
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter2InstallationInstructions
12
FrontPanelConnector: FP1
Thismotherboardincludesoneconnectorforcon-
nectingthefrontpanelswitch and LED indicators.
HDDLEDConnector(HD-LED)
Theconnectorconnectstothecase sHDD indicator LED indicatingtheactivity
statusofharddisks.
ResetSwitch (RESET)
Attach theconnectortothe Resetswitchonthe frontpanelofthecase;the
systemwillrestartwhenthe switch ispressed.
Power LEDConnector(PWRLED)
Attachtheconnectortothe powerLEDonthefront panelof thecase. ThePower
LEDindicatesthe system sstatus.When thesystemisinS0status,theLEDis
on.Whenthe systemisinS1status, the LEDisblink;When thesystemisinS3,
S4,S5status,the LED isoff.
PowerSwitch Connector(PWRSW)
Attachtheconnectortothepower buttonof the case.Pushingthisswitchallows
thesystemtobeturnedon and off ratherthan using the powersupplybutton.
AudioConnector: F_AUDIO
The audioconnectorsupportsHDaudiostandard.Itprovidestwokindsof
audiooutputchoices:theFrontAudioandthe RearAudio.FrontAudiosupports
re-taskingfunction.
F_AUDIO
PORT2_L
SENSE_SEND
PORT1_L
PORT1_R
AUD_GND
PRESENCEJ
PORT2_R SENSE1_RETURN
Empty
SENSE2_RETURN
12
910
+-
+-
1
FP1
NCHD-LED RESET
PWRLED
PWRSW
Empty
2
9
10
SerialATAII Connectors:SATA_1/2
The SerialATA IIconnectorisused toconnecttheSe-
rial ATAII devicetothemotherboard.These connec-
torssupport thethinSerialATAII cables forprimary
storage devices. The currentSerial ATAII interfaceal-
lowsup to300MB/sdatatransferrate. SATA_1/2
GND
TX+
1
GND
GND
TX-
RX-
RX+
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter2InstallationInstructions
13
Expansion Slots
Thismotherboardincludes two32-bitmasterPCIbusslots, onePCIExpress
x1slot.
PCISlots
Theexpansion cardscanbe installed inthetwoPCIslots.PCIslotssupport
cardssuchas aLAN card,USBcard,SCSIcardand othercardsthatcomply
withPCIspecifications.
PCIExpressx1Slot
Thismotherboardhas one PCIExpress x1slotthat designedtoaccommodate
less bandwidth-intensivecards,such asamodemorLAN card.
3.3V_DVDD_CORE
HDA_DH
SDI
SDO
BCLK
RST#
GND
3D3V_SYS
SYNC GND
+12V
12
15 16
RSVD
RSVD
RSVD
KEY
3D3V_DUAL
GND
HD AudioDigitalConnector:HDA_DH
Theconnectorisintel®HD AudioDigitalHeader.
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter2InstallationInstructions
14
Jumpers
Theuserscanchange the jumper settingson thismotherboardifneeded.This
sectionexplains howtousethevariousfunctions of thismotherboardbychang-
ingthejumpersettings. Usersshouldreadthe followingcontent carefullypriorto
modifying anyjumpersettings.
Description of Jumpers
1. Forthejumperson thismotherboard,pin1canbeidentifiedbyboldsilk-
screen.However, inthismanual, pin1issimplylabeledas “1”.
2. Thefollowing tableprovides someexplanation ofthejumperpinsettings.
Usershouldrefertothiswhen adjusting jumpersettings.
ClearCMOSJumper:CLR_CMOS
The motherboardusestheCMOSRAMtostoreall the set parameters. The
CMOScanbecleared byremoving theCMOSjumper.
Warning:
1. Disconnectthepowercablebeforeadjusting thejumpersettings.
2.DonotcleartheCMOSwhilethe systemisturnedon.
NORMAL
(Default)
CLR_CMOS
CLEAR
1
1
JumperDiagram Definition Description
1-2 Setpin1 andpin2 closed
2-3 Setpin2 andpin3 closed
Closed Setthepin closed
Open Setthepin opened
1
1
1
1
1
1
HowtoclearCMOS?
1.Turnoff theACpower supplyandconnect pins1
and 2togetherusing thejumpercap.
2.Returnthejumpersetting tonormal(pins2and 3
togetherwiththejumpercap).
3. TurntheACpower supplybackon.
NORMAL
PSWD
CLEAR 1
1
ClearPassword:PSWD
Connecting Pin2and Pin3 withjumperisthedefault
setting,andconnectingPin1 andPin2 withjumper
will clearbothsupervisor anduserpasswords inBIOS.
PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn
