Foxconn BLACKOPS User manual

BLACKOPS Motherboard
User’s Manual

Statement:
This manual is the intellectual property of Foxconn, Inc. Although the information
in this manual may be changed or modied at any time, Foxconn does not obligate
itself to inform the user of these changes.
Trademark:
All trademarks are the property of their respective owners.
Version:
User’s Manual V1.1 for BLACKOPS motherboard.
Symbol description:
Caution: refers to important information that can help you to use motherboard
better, and tells you how to avoid problems.
Warning: indicating a potential risk of hardware damage or physical injury may
exist.
WEEE:
The use of this symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could otherwise
be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city ofce, your
household waste disposal service or the shop where you purchased this product.
More information:
If you want more information about our products, please visit Foxconn’s
website: http://www.foxconnchannel.com
CAUTION
!
W
A
R
N
I
N
G
!
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
All images are for reference only, please refer to the physical motherboard for specic features.

Declaration of conformity
HON HAI PRECISION INDUSTRY COMPANY LTD
66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,
TAIPEI HSIEN, TAIWAN, R.O.C.
declares that the product
Motherboard BLACKOPS
is in conformity with
(reference to the specication under which conformity is declared in
accordance with 89/336 EEC-EMC Directive)
■ EN 55022: 1998/A2: 2003 Limits and methods of measurements of radio
disturbance characteristics of information technology
equipment
■ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits for harmonic current emissions
(equipment input current <= 16A per phase)
■ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits of voltage uctuations and icker in low
voltage supply systems for equipment with rated current <=
16A
■ EN 55024/A2:2003 Information technology equipment-Immunity characteristics
limits and methods of measurement
Signature : Place / Date : TAIPEI/2008
Printed Name : James Liang

Declaration of conformity
Trade Name: FOXCONN
Model Name: BLACKOPS
Responsible Party: PCE Industry Inc.
Address: 458 E. Lambert Rd.
Fullerton, CA 92835
Telephone: [phone]
Facsimile: 714-738-8838
Equipment Classication: FCC Class B Subassembly
Type of Product: Motherboard
Manufacturer: HON HAI PRECISION INDUSTRY
COMPANY LTD
Address: 66 , CHUNG SHAN RD., TU-CHENG
INDUSTRIAL DISTRICT, TAIPEI HSIEN,
TAIWAN, R.O.C.
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions : (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Tested to comply with FCC standards.
Signature : Date : 2008

Installation Precautions
Please carefully read the following procedures to install your computer :
■ It is suggested to select high-quality, certied fans in order to avoid damage
to the motherboard and CPU due to high temperature. Never turn on the
computer if the CPU fan is not properly installed.
■ We cannot guarantee that your system can operate normally when your
CPU is overclocked. Normal operation depends on the overclocking capac-
ity of your device.
■ If there is any, when connecting USB, audio, 1394a, RS232 COM, IrDA or
S/PDIF cables to the internal connectors on the motherboard, make sure
their pinouts are matching with the connectors on the motherboard. Incorrect
connections might damage the motherboard.
■ When handling the motherboard, avoid touching any metal leads or connec-
tors.
■ If there is a PCI Express x16 graphics card installed in your system, we
recommend using a 24-pin ATX power supply to get the best performance.
■ Before turning on the power, please make sure the power supply AC input
voltage setting has been congured to the local standard.
■ To prevent damage to the motherboard, do not allow screws to come in contact
with the motherboard circuit or its components. Also, make sure there are no
leftover screws or metal components placed on the motherboard or within the
computer casing.
■ If you are uncertain about any installation steps or have a problem related to
the use of the product, please consult a certied computer technician.
CAUTION
!
■ Electrostatic discharge (ESD) is the sudden and momentary electric current
that ows between two objects at different electrical potentials. Normally it
comes out as a spark which will quickly damage your electronic equipment.
Please wear an electrostatic discharge (ESD) wrist strap when handling
components such as a motherboard, CPU or memory.
■ Ensure that the DC power supply is turned off before installing or removing
CPU, memory, expansion cards or other peripherals. It is recommended to
unplug the AC power cord from the power supply outlet. Failure to unplug
the power supply cord may result in serious damage to your system.
W
A
R
N
I
N
G
!

TABLE OF CONTENTS
Chapter 1 Product Introduction
Package ListPackage List..................................................................................................2
Product Specications...................................................................................3
Layout............................................................................................................5
Back Panel Connectors.................................................................................6
Chapter 2 Hardware Install
Install the CPU and CPU Cooler ...................................................................9
Install the Memory .......................................................................................12
Install an Expansion Card............................................................................14
Install other Internal Connectors..................................................................15
Install the Optional Accessory .....................................................................20
Jumpers.......................................................................................................22
Onboard Button ...........................................................................................24
Onboard LED...............................................................................................24
Onboard Debug LED...................................................................................25
Chapter 3 BIOS Setup
Enter BIOS Setup........................................................................................27
Main Menu...................................................................................................27
Standard CMOS Features...........................................................................29
Advanced BIOS Features............................................................................31
Advanced Chipset FeaturesAdvanced Chipset Features ........................................................................33
Integrated Peripherals .................................................................................34
Power Management Setup..........................................................................38
PnP/PCI Congurations...............................................................................41
PC Health Status.........................................................................................42
Quantum BIOS ...........................................................................................44
Board Information........................................................................................51
Load Optimized DefaultsOptimized DefaultsDefaults .............................................................................52
Set Supervisor Password ............................................................................52
Set User Password......................................................................................52
Save & Exit Setup........................................................................................52
Exit Without Saving .....................................................................................52
Chapter 4 CD Instruction
Utility CD Introduction..................................................................................54
AEGIS PANELAEGIS PANELAEGIS PANEL
Main Panel .............................................................................................57
Overclocking...........................................................................................58

HWM INFO.............................................................................................59
ALARM ...................................................................................................60
CONFIG .................................................................................................61
FOX LiveUpdate
Local Update ..........................................................................................62
Online Update ........................................................................................64
Congure ...............................................................................................67
About & Help ..........................................................................................69
FOX DMI......................................................................................................70
FOX LOGO..................................................................................................71
Chapter 5 RAID Conguration
RAID Conguration Introduction..................................................................74
IntelIntel®Matrix Storage Manager.....................................................................76
Create a RAID Driver Diskette.....................................................................77
BIOS Conguration......................................................................................79
Create RAID in BIOS...................................................................................79
Install a New Windows XP.........................................................................103
Existing Windows XP with RAID built as data storage ..............................107
Appendix - CrossFileTM Technology............................................................. 111
Technical Support :
Website :
http://www.foxconnchannel.com
Support Website :
http://www.foxconnsupport.com
Worldwide online contact Support :
http://www.foxconnchannel.com/support/online.aspx
CPU, Memory, VGA Compatibility Supporting Website :
http://www.foxconnchannel.com/product/Motherboards/compatibility.aspx
Support

Thank you for buying Foxconn Quantum Force series motherboard-
BLACKOPS. Foxconn Quantum Force products are engineered
to maximize computing power, providing only what you need for
break-through performance.
With advanced overclocking capability and a range of connectivity
features for today multi-media computing requirements, BLACKOPS
enables you to unleash more power from your computer.
This chapter includes the following information:
■ Package List
■ Product Specications
■ Layout
■ Back Panel Connectors

2
1
Package List
Check your product package for the following items:
Before your purchase, if any of the above items is damaged or missing, please contact
your retailer. Accessories are not in the warranty, only motherboard is.
CAUTION
!
Motherboard Foxconn BLACKOPS motherboard
I/O modules 1 X USB 2.0 x 2 ports and 1 x 1394a module
Cables 4 X SATA Power and Signal cables
2 X SATA Power and Signal cables right angle
1 X Ultra DMA 133/100/66 cable
1 X Floppy Disk Drive cable
15 X Cable Tie
Accessory I/O Shield
1 X SONAR Card
1 X Quantum Flow-GPU Blower
1 X Chipset Fan
1 X Extreme-Cooling Tower
2 X Hose Barbs
1 X PCB Tray
1 X 20K Variable Resistor
1 X 50K Variable Resistor
Copper Column Bolt
Application CD Foxconn motherboard support CD
Documentation User’s Manual
Quick Installation Guide
Registration Card
Quantum Force stickers
Quantum Force tattoos
Quantum Force Dogtags

3
1
1-1 Product Specications
CPU Support LGA775 socket Intel®CPU:
CoreTM 2 Extreme / CoreTM 2 Quad / CoreTM 2 Duo
Pentium® 4 Extreme Edition / Pentium®D / Pentium® 4 processors
Supports 45nm processors45nm processors
Support Intel®Hyper-Threading Technology
Front Side Bus 1600/1333/1066/800 MHz FSB
Chipset North Bridge: Intel® X48 chipset
South Bridge: Intel®ICH9R
Memory 4 x 240-pin DDR3 DIMM sockets
Support up to 8GB of system memory
Dual channel DDR3 1600/1333/1066/800MHz architecture
Audio Realtek ALC885 chipchip
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF out
Support Jack-Sensing function
LAN Broadcom 5786 (PCI Express) Gigabit LAN chipBroadcom 5786 (PCI Express) Gigabit LAN chip 5786 (PCI Express) Gigabit LAN chip
Broadcom 5788 (PCI) Gigabit LAN chipBroadcom 5788 (PCI) Gigabit LAN chip
Expansion Slots 3 x PCI Express x16 slots
3 x PCI slots
Onboard Serial ATA 6 x SATA connectors
2 x External SATA connectorsconnectors
300MB/s data transfer rate
Support hot plug and NCQ (Native Command Queuing )
Support RAID 0, RAID 1, RAID 5, RAID 10
Support Intel®Matrix Storage Technology
USB Support hot plug
Support up to 12 USB 2.0 ports (6 rear panel ports, 3 onboard USB
connectors providing 6 extra ports)
Support USB 2.0 protocol up to 480Mb/s
Internal Connectors 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x Floppy disk drive connector
1 x IDE connector
6 x SATA connectors
3 x USB 2.0 connectors (supporting 6 x USB devices)connectors (supporting 6 x USB devices)s (supporting 6 x USB devices)
1 x CPU fan header (4-pin)
1 x System fan header (3-pin)
1 x NB fan header (3-pin)1 x NB fan header (3-pin)
3 x Power fan headers (3-pin)(FAN1, FAN2, FAN3)
1 x Front panel connectorconnector
1 x 1394a connectorconnector
1 x Speaker connectorconnector

4
1
1 x COM1 connectorconnector
1 x IrDA connectorconnector
Back Panel 1 x PS/2 Keyboard port
Connectors 1 x PS/2 Mouse port
1 x Optical S/PDIF out connector
1 x Coaxial S/PDIF out connector
6 x USB 2.0 ports
2 x RJ-45 LAN ports
1 x 1394a port
2 x External SATA ports
Hardware Monitor System voltage detection
CPU/System/NB temperature detection
CPU/System/NB fan speed detection
CPU/System/NB overheating shutdown/System/NB overheating shutdownoverheating shutdown
CPU/System/NB fan speed control/System/NB fan speed controlfan speed control
Onboard 1394a Support hot plug
400Mb/s transmission rate
Support 2 independent 1394a units synchronously at most
PCI Express x16 Support 4GB/s (8GB/s concurrent) bandwidth
Low power consumption and power management features
Green Function Support ACPI (Advanced Conguration and Power Interface)
Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4
(suspend to disk), and S5 (soft - off)
Bundled Software AEGIS PANEL
FOX LiveUpdate
FOX DMI
FOX LOGO
Operating System Support for Microsoft®Windows®Vista/XP/2000
Form Factor ATX Form Factor, 12 inches x 9.6 inches (30.5cm x 24.4cm)

5
1
1-2 Layout
Note : The above motherboard layout is for reference only, please refer to the physical
motherboard for detail.
13
14
17
18
3 20
23 25
24
27
32
12
26
30
31
15
8
9
11
67 15 4
29
3
10
3 2
22
16 2819 21
1. 8-pin ATX 12V Power Connector
2. NB(North Bridge) FAN Header
3. FAN1/FAN2/FAN3 Header
4. FSB Select Jumper
5. HDA_DH Header
6. PCI Slots
7. PCI Express x16 Slots
8. SYS_FAN Header
9. Speaker Connector
10. 1394a Connector
11. COM1 Connector
12. Front USB Connectors
13. SATA Connectors
14. Front Panel Connector
15. Power on Button
16. +5V Standby LED
17. Reset Button
18. Clear CMOS Button
19. Debug LED
20. BIOS Select Jumper
21. BIOS ROM 1, BIOS ROM 2
22. Clear CMOS Jumper
23. South Bridge: Intel® ICH9R
24. IrDA Connector
25. IDE Connector
26. Floppy Connector
27. 24-pin ATX Power Connector
28. DRAM Power LED
29. DDR3 DIMM Slots
30. CPU_FAN Header
31. North Bridge: Intel® X48 Chipset
32. LGA 775 CPU Socket

6
1
1-3 Back Panel Connectors
1. PS/2 Mouse Port
Use the upper port (green) to connect a PS/2 mouse.
2. PS/2 Keyboard Port
Use the lower port (purple) to connect a PS/2 keyboard.
3. External SATA Port
To connect external SATA device(s) to your system by expanding the internal SATA port(s) to the
chassis back panel. External SATA device shall provide power by its own.
4. USB Port
The USB port supports the USB 2.0/1.1 specication. Use this port for USB devices such as an
USB keyboard/mouse, USB printer, USB ash drive and etc.
5.Optical S/PDIF Out Connector
This connector provides digital audio out to an external audio system that supports digital optical
audio.
6. Audio Ports (SONAR Card)Audio Ports (SONAR Card)
For the denition of each audio port, please refer to the table below :
External SATA
Port
USB Port
LAN Port
Optical
S/PDIF Out
PS/2 Keyboard
Port
PS/2 Mouse Port
Coaxial
S/PDIF Out
1394a Port
7
9
18
45
23 6
Audio Ports
Line Out
Microphone
Subwoofer
Rear Speaker
Side Speaker
Line In

7
1
Note: The SONAR card is in the package, you can connect it to the back panel.
7. Coaxial S/PDIF Out ConnectorCoaxial S/PDIF Out Connector
This connector provides digital audio out to an external audio system that supports digital coaxial
audio. Before using this feature, ensure that your audio system provides a coaxial digital audio in
connector.
8. RJ-45 LAN Port
The Gigabit Ethernet LAN port provides Internet connection at up to 1Gb/s data rate.
9. 1394a Port
This port is used to connect a 1394a device.
Port 2-channel 4-channel 5.1-channel 7.1-channel
Blue Line In Line In Line In Line In
Green Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Microphone In Microphone In Microphone In Microphone In
Orange - - Center/Subwoofer Out Center/Subwoofer Out
Black - Rear Speaker Out Rear Speaker Out Rear Speaker Out
Grey - - - Side Speaker Out
LAN Type Left: Active Right: Link
Status Description Status Description
1000M
Off No Link Off No Link
Green
Blinking
Data
Activity
Off 10 Mb/s Connection
Green 100 Mb/s Connection
Orange 1000 Mb/s Connection
Active
LED
Link
LED

This chapter introduces the hardware installation process, including
the installation of the CPU, memory, power supply, slots, pin
headers and the mounting of jumpers. Caution should be exercised
during the installation of these modules. Please refer to the
motherboard layout prior to any installation and read the contents in
this chapter carefully.
This chapter includes the following information :
■ Install the CPU and CPU Cooler
■ Install the Memory
■ Install an Expansion Card
■ Install other Internal Connectors
■ Install the Optional Accessory
■ Jumpers
■ Onboard Button
■ Onboard LED
■ Onboard Debug LED
Please visit this website for more supporting information about CPU, Memory and
VGA for your motherboard :
http://www.foxconnchannel.com/product/Motherboards/compatibility.aspx

9
2
2-1 Install the CPU and CPU Cooler
Install the CPU
Locate the alignment keys on the motherboard CPU socket and the notches on the CPU.
LGA775 CPU Socket
Alignment Key
Pin_1 Corner of the
CPU Socket
LGA775 CPU
Notch
Pin_1 triangle marking
of CPU
Read the following guidelines before you begin to install the CPU :
■ Make sure that the motherboard supports the CPU.
■ Always turn off the computer and unplug the power cord from the power supply before
installing the CPU to prevent hardware damage.
■ Locate the Pin_1 of the CPU. The CPU cannot be inserted if oriented incorrectly. (Or
you may locate the notches on both sides of the CPU and alignment keys on the CPU
socket.)
■ Apply an even and thin layer of thermal grease on the surface of the CPU.
■ Do not turn on the computer if the CPU cooler is not installed, otherwise overheating
and damage of the CPU may occur.
■ Set the CPU host frequency in accordance with the CPU specications. It is not
recommended that the system bus frequency be set beyond hardware specications
since it does not meet the standard requirements for the peripherals. If you wish to
set the frequency beyond the standard specications, please do so according to your
hardware specications including the CPU, graphics card, memory, hard drive, etc.
Hyper-Threading Technology System Requirements:
(Go to Intel's website for more information about the Hyper-Threading Technology)
■ An Intel®CPU that supports HT Technology
■ A chipset that supports HT Technology
■ An operating system that is optimized for HT Technology
■ A BIOS that supports HT Technology and has it enabled
CAUTION
!

10
2
Follow the steps to install the CPU onto the CPU socket :
1. Remove protective socket cover.Remove protective socket cover. 2. Release the CPU socket lever.Release the CPU socket lever.
3. Lift the metal cover on the CPU
socket.
5. When CPU is properly seated,
replace the metal cover and push the
CPU socket lever back to its locked
position.
4. Check pin one marking (triangle)
with the pin one corner of the CPU
socket, align the CPU notches with
the socket alignment keys and gently
put the CPU onto the socket.
Before installing the CPU, make sure to turn off the computer and unplug the power
cord from the power outlet to prevent damage to the CPU.
CAUTION
!

11
2
Install the CPU Cooler
Follow the steps below to correctly install the CPU cooler on the motherboard. (The following
procedures use Foxconn cooler as the example.)
1. Apply and spread an even thermal
grease on the surface of CPU.
2. Place the four bolts of the CPU
cooler to the holes of the motherboard,
push them straight down from the top,
and the bolts will be fastened on the
motherboard. That's it.
3. Check the solder side of the
motherboard, the push pin should be
xed as depicted in the picture.
3
2
1
4. Attach the 4-wire CPU cooler
connector to the CPU FAN socket on
the motherboard .
Release bolts of CPU cooler from
motherboard :
1. Turning the push pin (bolt)
along with the direction of arrow
(counterclockwise).
2. Pull the push pin straight up.
3. Turning push pin clockwise to its
default position.
Use extreme care when removing the CPU cooler because the thermal grease may
adhere to the CPU. Inadequately removing the CPU cooler may damage the CPU.
CAUTION
!

12
2
2-2 Install the Memory
Dual Channel Memory Conguration
This motherboard provides four DDR3 memory sockets and supports Dual Channel Technology.
When memory is installed, the BIOS will automatically check the memory in your system.
Four DDR3 memory sockets are divided into two channels and each channel has two memory
sockets as following:
Channel 0 : DIMM1, DIMM2
Channel 1 : DIMM3, DIMM4
The combinations of DIMM modules are :
DIMM1 DIMM2 DIMM3 DIMM4
Single Channel DS/SS - - -
Single Channel DS/SS DS/SS -
Single Channel - - DS/SS -
Single Channel - - DS/SS DS/SS
Dual Channel DS/SS - DS/SS -
Dual Channel - DS/SS - DS/SS
Dual Channel DS/SS DS/SS DS/SS DS/SS
(DS : Double Side, SS : Single Side, - : No Memory)
It is recommended that memory of the same capacity, brand, speed, and chips be
used and please select dual channel rst to achieve optimum performance.
CAUTION
!
Read the following guidelines before you begin to install the memory :
■ Make sure that the motherboard supports the memory. It is recommended that memory
of the same capacity, brand, speed, and chips be used.
■ Always turn off the computer and unplug the power cord from the power outlet before
installing the memory to prevent hardware damage.
■ Memory modules have a foolproof design. A memory module can be installed in only
one direction. If you are unable to insert the memory, switch the direction.
CAUTION
!

13
2
Installing a Memory
If you take a look at front side of memory module, it has asymmetric pin counts on both sides separated
by a notch in the middle, so it can only t in one direction. Follow the steps below to correctly install
your memory modules into the sockets.
Step 1:
Spread the clips at both ends of the memory socket.
Place the memory module onto the socket, then put
your ngers on top edge of the module, and push
it down rmly and seat it vertically into the memory
socket.
Step 2:
The clips at both ends of the socket will snap into place
when the memory module is securely inserted.
Before installing a memory module, make sure to turn off the computer and unplug the
power cord from the power outlet to prevent damage to the memory module. Be sure
to install DDR3 DIMMs on this motherboard.
CAUTION
!
Notch
144-Pin
96-Pin
