REPORT NO. :E930560
Page 1 of 31
NVLAP LAB CODE: 200097-0-
PEP Testing Laboratory
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL: [phone] FAX: [phone]
FCC DoC TEST REPORT
According to
FCC Part 15 Subpart B
Test Item
Κ
Switching Power Supply
Model No.
Κ ISO-Pxxxy (where xxx = 250, 300, 350, 400, 450, 500Ιy = S, D or L),
ISO-xxxy (where xxx = 200, 230, 250, 300, 350, 400, 450, 500Ιy = D,
L or blank)
Responsible
Party
Κ
CHANNEL WELL TECHNOLOGY CO., LTD
Address 3F-2, 888 Jing-Gwo Rd., Tao Yuan City, Taiwan, R. O. C.
Test Engineer : STEVEN CHEN
Test Date : OCT. 07, 2004
Issued Date : NOV. 09, 2004
NVLAP Signature : Peter Kao
Peter Kao / President
ΘThe test report shall not be reproduced except in full, without the written approval of
the laboratory.
ΘThe report must not be used by the client to claim product endorsement by NVLAP or any
agency of the United States government.
ΘThis report is only for item test which described in page 5.
ΘThe testing result in this report are traceable to national and international standard.
PEP TESTING LABORATORY
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL : [phone] FAX : [phone]

REPORT NO. :E930560
Page 2 of 31
NVLAP LAB CODE: 200097-0-
PEP Testing Laboratory
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL: [phone] FAX: [phone]
Table of Contents
1. SCOPE 3
2. PRODUCT INFORMATION 4
3. EUT DESCRIPTION AND TEST CONCLUSION 5
4. MODIFICATION(S) 8
5. TEST SOFTWARE USED 8
6. SUPPORT EQUIPMENT USED 9
7. DESCRIPTION OF CONDUCTED EMISSIONS TEST 11
8. DESCRIPTION OF RADIATED EMISSIONS TEST 12
9. CONDUCTED EMISSIONS TEST SETUP PHOTO 15
10. CONDUCTED EMISSIONS TEST DATA 16
11. RADIATED EMISSIONS TEST SETUP PHOTOS 21
12. RADIATED EMISSIONS TEST DATA 22
13. LIST OF MEASURED INSTRUMENTS 24
14. DUTIES OF THE RESPONSIBLE PARTY 25
15. LABELLING REQUIREMENTS 26
16. INFORMATION TO THE USER 27
17. EUT PHOTOGRAPHS 28

REPORT NO. :E930560
Page 3 of 31
NVLAP LAB CODE: 200097-0-
PEP Testing Laboratory
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL: [phone] FAX: [phone]
1. Scope
Measurement and determination of electromagnetic emissions (EME) of radio frequency devices
including intentional and/or unintentional radiators for compliance with the technical rules and
regulations of the Federal Communications Commission under EUT Docket 95-19 Declaration of
Conformity(DoC).
Responsible Party*: CHANNEL WELL TECHNOLOGY CO., LTD
Address: 3F-2, 888 Jing Rd., Tao Yuan City, Taiwan, R. O. C.
Contact Person: Jacky Hsieh / Engineer
Phone No.: 886-3-3163111 Fax No.: 886-3-3160455
 Regulation: FCC Part 15 & Part 2; Docket 95-19
 Limitation: CISPR 22 CLASS B
 Test Procedure: ANSI C63.4(1992)
 Test Item: Switching Power Supply
 Model No.: ISO-Pxxxy, ISO-xxxy
 Serial No.: N/A
 Place of Test: PEP Testing Laboratory
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL : [phone] FAX : [phone]
Measurement Uncertainty :
The uncertainty of the testing result is given as below. The method of uncertainty
Calculation is provided in PEP Testing Lab document No. QP-T-28-A & QP-T-27-A
Frequency ( MHz ) 0.15 Д30 30 Д1000
Expanded Uncertainty Ӵc1.4 (dB) 2.8 (dB)
ϡʳ 95% Confidence Level; K=2

REPORT NO. :E930560
Page 4 of 31
NVLAP LAB CODE: 200097-0-
PEP Testing Laboratory
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL: [phone] FAX: [phone]
2. Product Information
a. EUT Name: Switching Power Supply
b. Model No. Κ ISO-P500D
c. Chassis Used Κ Steel
d. Port/Connector(s) Κ N/A
e. Power Rating Κ Switching Power Supply -----
Model No.: ISO-P500D
Input: AC 120V 9A 60Hz 420W
Output:DC+3.3V, +5V, +12V1, +12V2, -12V, +5Vsb
22A, 32A, 14A, 15A, 0.5A, 2.0A
f. Condition of the EUT : ϭPrototype Sample Engineering Sample
ʳϭ
Production Sample
g. Test Item Receipt Date : OCT. 07, 2004

REPORT NO. :E930560
Page 5 of 31
NVLAP LAB CODE: 200097-0-
PEP Testing Laboratory
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL: [phone] FAX: [phone]
3. EUT Description and Test Conclusion
The equipment under test (EUT) is Switching Power Supply model ISO-500y, ISO-450y,
ISO-400y, ISO-350y, ISO-300y, ISO-250y, ISO-230y, ISO-200y (where y=”D” indicates
8cm and 9cm dual fans, “L” indicates 12cm fan or “being blank” indicates 8cm single fan)
and ISO-P500y, ISO-P450y, ISO-P400y, ISO-P350y, ISO-P300y and ISO-P250y (where
y=”S” indicates 8cm single fan, “D” indicates 8cm and 9cm dual fans or “L” indicates
12cm fan). These models have identical electrical design and construction except that they
are different in I/O ratings. From technical point of view, we only took the worst-case
model ISO-P500D for test. The EUT is power switching device designed for the use to
transform AC mains to DC power used by PC system. For more detail information about
EUT, please refer to user manual.
Test method: According to the major function design, the EUT was installed on PC system
inside enclosure for test. The test was carried out on EUT operational
condition and the worst-case test result was recorded and provided in this
report.
Conducted emission test:
The system was setup with the EMI diagnostic software running. The power line conducted
EMI tests were run on the line and neutral conductors of the power cord and the results
were recorded. The effect of varying the position of the interface cables has been
investigated to find the worst-case configuration that produces maximum emission.
At the frequencies where the peak values of the emission exceeded the quasi-peak limit, the
emissions were also measured with the quasi-peak detectors. The average detector also
measured the emission either (A) quasi-peak values were under quasi-peak limit but
exceeded average limit, or (B) peak values were under quasi-peak limit but exceeded
average limit.
Radiated emission test:
The maximum readings were found by varying the height of antenna and then rotating the
turntable. Both polarization of antenna, horizontal and vertical, are measured. The effect of
varying the position of the interface cables has been investigated to find the configuration
that produces maximum emission.
The highest emissions were also analyzed in details by operating the spectrum analyzer in
fixed tuned quasi-peak mode to determine the precise amplitude of the emissions.

REPORT NO. :E930560
Page 6 of 31
NVLAP LAB CODE: 200097-0-
PEP Testing Laboratory
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL: [phone] FAX: [phone]
ISO-Pxxxy Series I/O List
Output rating (dc)
Model I/P rating (ac) +3.3V +5V +12V1 +12V2 -12V -5V* +5Vsb
+3.3V
&
+5V
Total
ISO-P500y
y=S, D or L
115/230Vac,
9/5A, 60/50Hz 22 32 14 15 0.5 0.5 2.0 220W 420W
ISO-P450y
y=S, D or L
115/230Vac,
8/5A, 60/50Hz 20 28 10 15 0.5 0.5 2.0 200W 350W
ISO-P400y
y=S, D or L
115/230Vac,
7/4A, 60/50Hz 20 26 8 14 0.5 0.5 2.0 185W 300W
ISO-P350y
y=S, D or L
115/230Vac,
7/4A, 60/50Hz 16 22 6 12 0.5 0.5 2.0 150W 250W
ISO-P300y
y=S, D or L
115/230Vac,
6/4A, 60/50Hz 14 20 6 10 0.5 0.5 1.5 135W 235W
ISO-P250y
y=S, D or L
115/230Vac,
5/3A, 60/50Hz 14 18 6 8 0.5 0.5 1.5 120W 200W
* -5V optional

REPORT NO. :E930560
Page 7 of 31
NVLAP LAB CODE: 200097-0-
PEP Testing Laboratory
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL: [phone] FAX: [phone]
ISO-xxxy Series I/O Rating List
Output rating (dc)
Model I/P rating (ac) +3.3V +5V +12V -12V -5V +5Vsb +3.3V,
+5V Total
ISO-500y
y=D, L or blank
115/230Vac, 9/5A,
60/50Hz 22 36 18 0.5 0.5 2.0 220W 420W
ISO-450y
y=D, L or blank
115/230Vac, 8/5A,
60/50Hz 20 32 16 0.5 0.5 2.0 200W 350W
ISO-400y
y=D, L or blank
115/230Vac, 7/4A,
60/50Hz 20 30 15 0.5 0.5 2.0 185W 300W
ISO-350y
y=D, L or blank
115/230Vac, 7/4A,
60/50Hz 16 25 13 0.5 0.5 1.5 150W 250W
ISO-300y
y=D, L or blank
115/230Vac, 6/4A,
60/50Hz 14 20 12 0.5 0.5 1.5 135W 235W
ISO-250y
y=D, L or blank
115/230Vac, 5/3A,
60/50Hz 14 18 10 0.5 0.3 1.5 120W 200W
ISO-230y
y=D, L or blank
115/230Vac, 5/3A,
60/50Hz 10 16 7 0.3 0.3 1.5 110W 180W
ISO-200y
y=D, L or blank
115/230Vac, 4/3A,
60/50Hz 10 14 6 0.3 0.3 1.5 100W 150W

REPORT NO. :E930560
Page 8 of 31
NVLAP LAB CODE: 200097-0-
PEP Testing Laboratory
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL: [phone] FAX: [phone]
4. Modification(s):
N/A
5. Test Software Used
(A) EMITEST program that continuously generates a complete line of repeating “H” letter
was the software used during test.

REPORT NO. :E930560
Page 9 of 31
NVLAP LAB CODE: 200097-0-
PEP Testing Laboratory
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL: [phone] FAX: [phone]
6. Support Equipment Used
1.Personal Computer CPU : Intel P4 Xeon 2.4GHz
FCC ID Κ Declaration of Conformity(DoC)
Manufacturer Κ IWILL
Model Number Κ DPL533
Power Supply Κ Switching
Power Cord Κ Non-Shielded, Detachable, 1.8m
Data Cable Κ N/A
2.Keyboard (KBS1 PS/2) FCC ID Κ E5XKB5121WTH0110
Manufacturer Κ BTC
Model Number Κ 5121W
Power Supply Κ +5Vdc from PS2 of PC
Power Cord Κ N/A
Data Cable Κ 1 > Shielded , Non-detachable,1.6m
2 > Back Shell : Metal
3.Monitor (MON1 15”) FCC ID Κ Declaration of Conformity(DoC)
Manufacturer Κ SAMSUNG
Model Number Κ 550S
Power Supply Κ Switching
Power Cord Κ Non-Shielded, Detachable, 1.8m
Data Cable Κ 1 > Shielded , Non-detachable,1.5m
2 > Back Shell : Metal
4.Printer (PRN1) FCC ID Κ Declaration of Conformity(DoC)
Manufacturer Κ Hewlett-Packard
Model Number Κ C2642E
Power Supply Κ Linear, 30Vdc O/P
Power Cable Κ Non-Shielded , Detachable,1.7m
Data Cable Κ 1 > Shielded , Detachable,1m
2 > Back Shell : Metal

REPORT NO. :E930560
Page 10 of 31
NVLAP LAB CODE: 200097-0-
PEP Testing Laboratory
12-3Fl, No. 27-1, Lane 169, Kang-Ning St., Hsi-Chih,
Taipei Hsien, Taiwan, R. O. C.
TEL: [phone] FAX: [phone]
5.Modem (MOD1)  2 FCC ID Κ IFAXDM1414
Manufacturer Κ ACEEX
Model Number Κ 1414
Power Supply Κ Linear, 9Vac O/P
Power Cable Κ Non-Shielded , Detachable,1.7m
Data Cable Κ 1 > Shielded , Detachable,1m
2 > Back Shell : Metal
6.Mouse (MOUS/1 PS/2) FCC ID Κ DZL211106
Manufacturer Κ ACER
Model Number Κ M-S42
Power Supply Κ +5Vdc from PS2 of PC
Power Cord Κ N/A
Data Cable Κ 1 > Shielded , Non-detachable,1.8m
2 > Back Shell : Metal
