Foxtech EH50 User manual

EH50 TIRM Thermal Camera
User Manual
V1.0 2022.5

1.Product Introduction
1.1 Introduction
EH50 is a high-precision 3-axis gimbal integrated with a 50mm lens
640*480 IR thermal sensor. It supports IR thermal image switch, IR
color palette switch, photographing and video, target tracking and
thermal digital zoom. OSD can display angle, digital zoom times, status of
record and picture mode, tracking frame, also can select to turn off the OSD.
When the external GPS and time input, GPS coordinate and shooting time
can be saved in image file, OSD can display GPS and real-time as well. The 3
axis gimbal can achieve stabilization in yaw, roll and pitch. The integrated
design of damping system and gimbal can greatly reduce
mechanical vibration.
EH50 is widely used in UAV industries of public security, electric power,
fire fighting, zoom aerial photography and other industrial applications.
1.2 In the Box
Gimbal Camera
x 1 pc
USB to TTL Cable
x 1 pc
Copper Cylinder
x 4 pcs
Power Cable
x 1 pc
PWM Control Cable
x 1 pc
M3 Screw
x 8 pcs
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 1

2.1 Overview
TTL / S.BUS Control
Cable x 1 pc
TTL Connect Cable
x 3 pcs
Ethernet Cable x 1 pc
[12]
[13]
[11]
[10]
2. Installation Instruction
[3]
[2]
[1]
[8]
[6]
[5
[9]
[4]
]
[7]
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 2

[1] Control box
[2] Upper damping board
[3] Lower damping board
[4] Infrared thermal camera
[6] Yaw axis motor
[7] Roll axis motor
[8] TF card slot
[9] Pitch axis motor
[10] 3-6S power interface
[11] Micro HDMI interface
[12] Ethernet interface
[13] Unlock button
[5] Damping ball
Please ensure that there isn’t any obstacle while the
motor rotating.
Please remove the obstacle immediately if gimbal
camera is blocked during rotation.
Don’t put the infrared thermal camera towards the
sun in case any burn to the camera
Front Side
2.2 Control Box Printing
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 3

Left Side
Right Side
PITCH
YAW
MODE
ZOOM
FOCUS/PPM
PIC/REC
MULTI
5V
GND
CVBS
3S-6S
GND
POWER PWM
GND
CANL
CANH
DC5V
GND
5V
S.BUS
TTX
GND
RXD
TXD
RX-
RX+
TX-
TX+
ETHERNET UART & S.BUS CAN
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 4

2.3 Device Dimensions
Unit: mm
Control Box
φ120.0
φ3.1
78.0
78.0
91.0
91.0
73.6
111.4
133.6
193.6
16.0
91.0
91.0
118.6
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 5

2.4 Install Mounting Part
(1) Find out the arrow on the gimbal which indicating the yaw
heading of the payload (i.e. the lens direction when the camera
power on), and synchronize with the direction specified by the UAV.
(2) Fix one end of the copper cylinder on the screw hole of lower
damping board, and use M3 screw to fasten it.
(3) According to the provided screw hole dimension you can make
suitable mounting holes on the UAV mounting board, and fixes the
other end of the copper cylinder on the mounting board of the UAV.
Front
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 6

2.5 Quick-mount Release Instruction
1. Make sure the two white stripes indicated in above picture are
aligned with each other. (If the stripes are not aligned to each other,
please pinch the connector part and turn it to left manually)
×
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 7

2. Align the white dot (unlock icon) to the red triangle (below unlock
button), push the gimbal into the board completely and then
rotate the gimbal camera anticlockwise.
3. When you hear "click" sound (when red dot is aligned to the red
triangle) means the gimbal camera and the board has been locked.
4. To unlock the gimbal, you need to press on unlock button and
rotate the gimbal camera clockwise till the white dot align to the red
triangle. Then pull the gimbal out from the board.
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 8

2.6 Install TF Card
2.7 Image Output Interface
TF (Micro SD card): Install the TF card to the card slot (Re. 2.1
Overview). Support max 128GB. Request Class 10 (10m/s) transmis-
sion speed or higher and FAT32 or exFAT format.
HDMI: micro HDMI output, HD 1080P 60/50/30/25fps, 1080P 60fps
as default. (Optional)
SDI: SMA outer screw inner hole interface, 1080P 30fps output.
(Optional)
AV: no AV output
Network: Ethernet output interface, support RTSP/RTMP/UDP/ON-
VIF video streaming. Default: RTSP output, IP address: RTSP:
//192.168.2.119:554, output resolution: 720P (record in 1080p),
frame rate: 25fps, bit rate: 2M. (Optional)
Make sure device is power off when inserting the TF
card, hot plugging is not supported.
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 9

3.1 PWM Control
Control the gimbal camera functions by the multiplex pulse width
modulation signal outputted by PWM channel of the remote control
receiver. The camera needs up to 6 control channels of PWM (to
expand tracking function use up to 7 PWM channels). You can choose
needed functions according to actual usage to reduce the required
number of PWM channels.
3.1.1 PWM Connection Diagram (Connect pitch chan-
nel as example)
3. Signal Control
Above output mode is optional, HDMI and SDI output
cannot coexist at the same time. Please subject to
your actual product.
When using user interface software Viewlink for
network connection, the network of external device
(computer) should be the IP address: 192.168.2.2
(choose the last byte among 2~254, can not be 119
same as the gimbal), subnet mask: 255.255.255.0,
Default gateway: 192.168.2.1, and all firewalls of the
computer must be closed. Then enter the IP address
of the gimbal camera, Open Video, the video stream
can be outputted.
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 10

Remote Controller
Connection Diagram
Receiver
3.1.2 PWM Control Operation Instruction
1)) Pit (PWM Pitch channel in to control Pitch. Joystick, rotary knob
or 3-gear switch on remote control are optional. 3-gear switch as
example.)
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 11

2) Yaw (PWM Yaw channel in to control Yaw. Joystick, rotary knob or
3-gear switch on remote control are optional. 3-gear switch as
example.)
3) Mode (PWM Mode channel in to adjust speed control/one key to
Home position etc functions. Rotary knob or 3-gear switch on remote
control are optional. 3-gear switch as example.)
Low Gear
Pitch Up
Position 1
Middle Gear
Pitch Stop
Position 2
High Gear
Pitch Down
Position 3
Low Gear
Yaw Left
Position 1
Middle Gear
Yaw Stop
Position 2
High Gear
Yaw Right
Position 3
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 12

Position 1: Low speed mode, control pitch / yaw with this mode at
lowest speed
Position 2: Middle speed mode, control pitch / yaw with this mode at
middle speed
Position 3: High speed mode, control pitch / yaw with this mode at
highest speed
(If it is controlled by rotary knob, the speed will change according to
switch position)
Function of continuous switching:
3.1) Operate 1 time continuously and quickly, from position 2 - 3 - 2,
to Home position.
3.2) Operate 2 times continuously and quickly, from position 2 - 3 - 2
-3 - 2, the camera lens looks vertically down.
3.3) Operate 3 times continuously and quickly, from position 2 - 3 - 2
-3 - 2 - 3 - 2, to disable Follow Yaw Mode (gimbal yaw not follows by
frame)
3.4) Operate 4 times continuously and quickly, from position 2 - 3 - 2
-3 - 2 - 3 - 2 - 3 - 2, to enable Follow Yaw Mode (gimbal yaw follows
by frame)
Low Gear
Position 1
Middle Gear
Position 2
High Gear
Position 3
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 13

4) Zoom (PWM Zoom channel in to control Zoom. Joystick, rotary
knob or 3-gear switch on remote control are optional. 3-gear switch as
example.)
Switch from Position 2 to 3: IR color switching: white hot, black hot,
pseudo color.
6) Pic/Rec (PWM Pic/Rec channel in to control take picture and
record. Joystick, rotary knob or 3-gear switch on remote control are
optional. 3-gear switch as example.)
Switch from Position 2 to 1: IR color switching: white hot, black hot,
pseudo color.
Switch from Position 2 to 3: IR digital zoom: 3x, 6x, 9x, 12x.
5) Focus (PWM Focus channel is to control IR color palette switch.
3-gear switch as example.)
Low Gear
IR digital zoom
Position 1
Middle Gear
No control
Position 2
High Gear
IR color palette switch
Position 3
Low Gear
No control
Position 1
Middle Gear
No control
Position 2
High Gear
IR color palette switch
Position 3
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 14

Switch from Position 2 to 1: Take a picture
OSD display 'REC IMG' a second.
7) Multi: tracking control
Low Gear
Position 1
Middle Gear
Position 2
High Gear
Position 3
Low Gear
Position 1
Middle Gear
Position 2
High Gear
Position 3
Switch from Position 2 to 1: Cancel tracking
Switch from Position 2 to 3:
Exit the tracking, display the lock frame in the center of the screen,
start tracking
Switch from Position 3 to 2:
"+" appears in the center of the screen, adjust the cross cursor
UDLR with yaw and pitch control to lock target object
Switch from Position 2 to 3 again:
Choose another target for second tracking
Switch from Position 2 to 3: Start record / repeat operation to stop
record
Start record, the OSD display rec hh:mm:ss.
Stop record, the OSD display STBY.
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 15

3.2 Serial Port / TTL Control
PC
GND
S.BUS
TTX
RXD
GND
TXD
RX-
RX+
TX+
TX-
GND
GANL
CANH
DC5V
TTL communication requirements: TTL signal is 3.3V, baud rate:
115200, data bit 8, stop bit 1, no parity, HEX send and receive.
Control Box
USB to TTL Cable
Connection Diagram
Connection Diagram (PC - USB to TTL Cable- Gimbal Camera as
example):
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 16

3.3 S.BUS Control
Control the gimbal camera functions by one combining signals.
Connect the external S.Bus to S.Bus port on the control box, and the
external S.bus signal GND connect to the GND interface of the control
box.
Wiring Diagram (Take Futaba remote control for example):
Diagram of USB to TTL Cable:
Connect the camera to the upper computer by USB to TTL cable
(Adopt connection method of TX to RX, RX to TX, GNG to GND at
Dupont ends of the provided USB to TTL cable, connect to the
specified TTL of the gimbal, and the USB end of the cable connect to
computer).
Install Viewlink control software to test the functions directly.
Users may choose to develop their own software, please contact
technical support for TTL control protocol file.
Connect serial port of gimbal to pins, DO NOT connect
with power supply.
The default baud rate of serial port is 115200, which
can be changed according to the docking equipment.
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 17

GND
5V
S.BUS
TTX
RXD
GND
TXD
Remote Control
Receiver
Wiring Diagram
S.Bus control mode: default S.Bus signal channel 9-15 to control
gimbal camera functions (the function of channel is consistent with
corresponding channel in PWM function description)
Channel 9: Yaw Control
Channel 10: Pitch Control
Channel 11: Mode Control
Channel 12: Zoom Control
Channel 13: Focus Control
Channel 14: Pic/Rec Control
Channel 15: Multi Backup
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 18

3.4 TCP control
For cameras with Ethernet output, the default IP address is:
192.168.2.119, control port: 2000. You can send the
corresponding protocol to realize TCP control after connecting.
The TCP control protocol is [Frame header: EB + command ID: 90 +
data body (serial port protocol) + Checksum (CS = body checksum,
checksum is calculated as a sum of all bytes of data body modulo
256)]. Or directly use UI Viewlink to control after TCP connection.
TTL control and S.bus control cannot coexist at the
same time for standard version. The defualt control is
TTL if no requirement. The user can set to S.bus control
if needed (please contact with our technical support for
the setting instruction.)
User can set the channels by setting serial command
according to the actual requirement. The S.Bus channel
position can be arranged in any sequence within
channel 1-15 to connect with the flight controller or
remote control.
EH50-TIRM-Thermal-Camera-Manual
@2022 FOXTECH All Rights Reserved 19
