Foxun SX-SDH1 User manual

Operating Instructions
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to
clean this unit.
PRODUCT SERVICE
1) Damage requiring service: The unit should be serviced by qualified service
personnel if:
(a)The DC power supply cord or AC adaptor has been damaged;
(b)Objects or liquids have gotten into the unit;
(c)The unit has been exposed to rain;
(d)The unit does not operate normally or exhibits a marked change in
performance;
(e)The unit has been dropped or the cabinet damaged.
2) Servicing Personnel: Do not attempt to service the unit beyond that described
in these operating instructions. Refer all other servicing to authorized servicing
personnel.
3) Replacement parts: When parts need replacing ensure the servicer uses
parts specified by the manufacturer or parts that have the same characteristics as
the original parts. Unauthorized substitutes may result in fire, electric shock, or
other hazards.
4) Safety check: After repairs or service, ask the servicer to perform safety
checks to confirm that the unit is in proper working condition.
4
Operating Instructions
HDMI Converter
MODEL:SX-SDH1
Operating Instructions
Dear Customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
FEATURES
SDI/HD-SDI to HDMI
Equalized Looping SDI/HD-SDI output
Support 1080p@25Hz,[email protected],1080p@30Hz,1080P@60Hz
Compliant HDCP .
Uses 5V power
NOTICE
Our company reserve the right to make changes in the hardware, packaging and
any accompanying documentation without prior written notice.

1
Operating Instructions
TABLE OF CONTENTS
Specifications
Package Contents
Panel Descriptions
Connecting and Operating
Maintenance
Product service
Warranty
SPECIFICATIONS
Operating Temperature
Range
-5 to +35℃(+23 to +95℉)
Operating Humidity
Range
5 to 90%RH (No Condensation)
Input Formats
1080i (30/29.97/25Hz,)
1080p(60/59.94/50/30/29.97/25/24/23.976)
Video Input
3G-SDI/HD-SDI/SDI
Outputs
HDMI
1 Looping SDI/HD-SDI output of the SDI input (75
ohm,
unterminated)
HDMI
Standard Type A connector
HDCP
Compliant HDCP .
Power consumption
2.5watts(Maximum)
Dimension (L×W×H)
95x95x29mm
Net Weight
245g
Note: Specifications are subject to change without notice. Mass and
dimensions are approximate.
PACKING CONTENTS
1) Main Unit. SDI-HDMI converter
2) DC5V 1A Power Supply.
3) Operating Instructions
2
Operating Instructions
PANEL DESCRIPTIONS
Input Panel Output Panel
1) Indicator of HDMI Output
2) Indicator of power Input
3) SDI/HD-SDI input port
4) SDI/HD-SDI output port
5) HDMI output port
6) Power input
Connecting and Operating
1. Ensure the Converter is disconnected from power.
2. Connect source to the SDI input and sink to HDMI output and SDI output .
3. Connect 5VDC power to the converter.
Attention:Insert/Extract cable gently
Typical Application

3
