foxunhd FX-SDI-102 User manual

Operating Instructions
www.foxunhd.com
FX-SDI-102
SD/HD/3G-SDI 1 to 2 Distribution Amplifier & Repeater
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this manual for
future reference.
ABLE OF CONTENTS
Feature
Introduction
Specifications
Package Contents
Panel Descriptions
Connecting and Operating
Typical Application
Product Service
Warranty

Operating Instructions
www.foxunhd.com
Feature
Distributes 1 SDI input to 2 SDI outputs simultaneously
Single unit can transmit up to 120m/390ft (Beldon 1694A)
Re-clocking function capability---unlimited repeater connection
Support SDI Standard :SD-SDI,HD-SDI, 3D-SDI
Data Rates: 270Mbps(SD-SDI), 1.485Gbps (HD-SDI), 2.97Gbps (3G-SDI)
Signal Type: SMPTE 292M, SMPTE 259M, SMPTE 424M
DC 5V~12V (Power consumption less than 2W)
Power consumption:2watts
Dimension (L×W×H):106x83x28mm
NOTICE
Our company reserve the right to make changes in the hardware, packaging and any accompanying
documentation without prior written notice.
INTRODUCTION
It is newest 1x2 3G SDI splitter&Repeater . It offers HD video solution for super market, shopping mall;
HDTV, STB, DVD and projector factory; data control center; conference rooms; education and training;
luxurious house; home theaters etc.
SPECIFICATIONS
Re-clocking Function
Yes
SDI Standards
SD-SDI, HD-SDI,3G-SDI
HD/SD-SDI Detection
Auto
Supported Protocols
SMPTE 259M
SMPTE 292M
SMPTE 424M
Data Rates
270Mbps(SD-SDI), 1.485Gbps (HD-SDI), 2.97Gbps
(3G-SDI)

Operating Instructions
www.foxunhd.com
Video Support
480i@60hz, 720p@50/59.94/60hz, 1080i@50/59.94/60hz,
1080p@23.98/24/25/29.97/30/50/59.94/60hz
SDI Signal Type
SMPTE-292M, SMPTE-259M, SMPTE-424M
Output Impedance
75 ohms
Cable Equalization
HD-SDI up to 120m
SD-SDI up to 200m
Unlimited repeater connection
Audio Sampling rate
48Khz
Impedance
75 ohms
Input
1x BNC [SDI]
Output
2x BNC [SDI]
Power Adapter
5V~12V DC
Power Consumption
2W
Operating
Temperature
-5 to +65℃(+23 to +149℉)
Storage Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity
20~90% RH (no condensation)
Housing Material
Metal case
Note: Specifications are subject to change without notice. Mass and dimensions are approximate.
PACKING CONTENTS
1) 1x2 SDI repeater
2) 5V DC power adaptor
3) Operating Instructions
Notes: Please confirm if the product and the accessories and all in duded, if not please contact with
the dealers.
PANEL DESCRIPTION

Operating Instructions
www.foxunhd.com
Panel
1) DC 5V~12V
2) Green indicator of source status
3) Red indicator of power input
4) SDI input
5) SDI output1
6) SDI output2
CONNECT AND OPERATE
1) Connect a camera or other device equipped with SDI output to FX-SDI-102 input.
2) Connect devices equipped with SDI input (e.g monitors or video processors) to the FX-SDI-102 outputs.
3) Plug power adapter into power jack.
Note:A .Connect a camera or other device equipped with SDI output to FX-SDI-102 input.
B.Connect devices equipped with SDI input (e.g monitors or video processors) to the FX-SDI-102 outputs.
C.Plug power adapter into power jack.
Typical Application
1) Distribute one SDI input to 2 SDI output
2) Connect with FX-HSD1 and FX-SDH1

Operating Instructions
www.foxunhd.com
3）Repeater connection
Attention: 1) Insert/Extract cable gently.
2) Please don’t insert into or pull out HDMI Cable when power on. please connect Cable
only when power is off.
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzene to clean this unit.
PRODUCT SERVICE
1) Damage requiring service: The unit should be serviced by qualified service personnel if:
(a)The DC power supply cord or AC adaptor has been damaged;
(b)Objects or liquids have gotten into the unit;
(c)The unit has been exposed to rain;
(d)The unit does not operate normally or exhibits a marked change in performance;
(e)The unit has been dropped or the cabinet damaged.
2) Servicing Personnel: Do not attempt to service the unit beyond that described in these operating
instructions. Refer all other servicing to authorized servicing personnel.
3) Replacement parts: When parts need replacing ensure the servicer uses parts specified by the
manufacturer or parts that have the same characteristics as the original parts. Unauthorized substitutes
may result in fire, electric shock, or other hazards.
4) Safety check: After repairs or service, ask the servicer to perform safety checks to confirm that the unit

Operating Instructions
www.foxunhd.com
is in proper working condition.
