FRANCE ETUVES C3030 User manual

Rev 2 FRANCE-ETUVES 65/67 rue Auguste Meunier 77500 Chelles (FRANCE)
Temperature controller C3030
Original instructions
READ THIS MANUAL BEFORE SWITCHING ON THE DEVICE

C3030 - 2021-09
Page 2of 44
Thank you for choosing a France Etuves product, we hope it
will bring you complete satisfaction

C3030 - 2021-09
Page 3of 44
1 Introduction..................................................................................................................................................... 5
1.1 Safety precautions to take when using and repairing the device ............................................................ 5
1.2 Temperature controller description.......................................................................................................... 6
1.3 Graphic display presentation ................................................................................................................... 7
2 Electronic thermostat for protection against overheating.......................................................................... 10
2.1 Protecting thermostat description .......................................................................................................... 10
2.2 Electronic protection thermostat function in TWW mode (automatic reset)........................................... 12
2.3 Electronic protection thermostat function in TWB mode (manual reset) ............................................... 13
2.4 TWB mode electronic thermostat reset.................................................................................................. 13
2.5 Setpoint Deviation Tracking (SDT) system working .............................................................................. 14
2.6 Overheating protection thermostat and SDT settings............................................................................ 15
3 Manual regulation......................................................................................................................................... 17
4 Program........................................................................................................................................................ 18
4.1 Program structure .................................................................................................................................. 18
4.2 Program creation.................................................................................................................................... 19
4.2.1 Step setting...................................................................................................................................... 19
4.2.2 Number of program iteration setting................................................................................................ 20
4.2.4 Guaranteed Soak Band settings : ................................................................................................... 21
4.2.5 Delayed start setting :...................................................................................................................... 22
4.2.6 Program example............................................................................................................................ 22
4.3 Starting a program ................................................................................................................................. 23
4.4 Program pause....................................................................................................................................... 24
4.5 Stopping the program ............................................................................................................................ 25
4.6 Program end .......................................................................................................................................... 25
4.7 Power failure controller reaction ............................................................................................................ 25
5. Weekly timer (option)................................................................................................................................... 26
5.1 Working principle.................................................................................................................................... 26
5.2 Setting and operation............................................................................................................................. 26
6. Controller settings........................................................................................................................................ 27
6.1 Settings parameters description ............................................................................................................ 27
6.2 Defining the parameters......................................................................................................................... 29
6.2.1 : PID regulation................................................................................................................................ 29
6.2.2 Temperature correction :................................................................................................................. 30
6.2.3 Temperature coefficient (for XFE range)......................................................................................... 33
6.2.4 XFE range working principle : ......................................................................................................... 33
6.2.5 Temperature coefficient function working ....................................................................................... 33
6.2.6 Date and time.................................................................................................................................. 34
6.2.7 RS 485 connection :........................................................................................................................ 34
6.2.8 Password......................................................................................................................................... 35
6.2.9 Beep................................................................................................................................................ 35
6.2.10 Heating and fan stop when door is open....................................................................................... 36

C3030 - 2021-09
Page 4of 44
7. Remote oven control from a P.C. ................................................................................................................ 37
7.1. Modbus protocol.................................................................................................................................... 37
7.1.1 Data frame to send to the controller................................................................................................ 37
7.1.2 Controller-returned data frame........................................................................................................ 38
7.2. List of available parameters via Modbus communication ................................................................. 38
7.3. France-étuves remote control software ................................................................................................ 40
8 Troubleshooting............................................................................................................................................ 41
8.1 General safety instructions .................................................................................................................... 41
8.2 Failures displayed.................................................................................................................................. 41
8.2.1. Electronic thermostat failures......................................................................................................... 41
8.2.2. Other failures.................................................................................................................................. 42
8.3 Breakdowns ........................................................................................................................................... 43

C3030 - 2021-09
Page 5of 44
1 Introduction
1.1 Safety precautions to take when using and repairing the device
- The overheating protection must always be adjusted on the electronic
thermostat before using the oven.
- Do not turn off the oven when the inside temperature is over 50°C.
- The condition of the door gasket and internal fan must be strictly checked
before starting the oven.
- The oven must be disconnected from the electric grid for any intervention
which doesn’t need its power up.
- Any intervention must be realized with oven at room temperature
- Any intervention must be realized by a right skilled engineer.
- Engineers and users must be provided with the appropriate safety equipment.

C3030 - 2021-09
Page 6of 44
1.2 Temperature controller description
Objet
Description
Graphic display :
Displays the measured temperature, the set point temperature and
other running parameters.
Backspace key :
Allows to return to the main screen
Validation key :
On the main screen :
Allows to select successively different icons
In a page with several adjustable parameters :
Allows to confirm the parameter and proceed to the next parameter.
Decrement
Increment
Increment / decrement keys :
On the main screen :
Allows to increase or decrease the set point temperature in “manual
regulation” mode, if no icon is selected
In the main menu :
Allows to enter in the selected icon display or increase / decrease the
internal fan speed if the fan icon is selected.
In a display with editable parameters :
Allows to adjust the value of the selected parameter.

C3030 - 2021-09
Page 7of 44
1.3 Graphic display presentation
Display at starting (manual regulation mode)
XUE ; XUELT ; XBE
XL ; XXL
XFE
Item
Description
26-10-2020 09:21:26
Date and time
Oven’s chamber measured temperature.
Set Point temperature
Heating power (% of the total oven’s power). If no
heating, the following icon is not displayed.
Going to an information display (software version,
oven type, maximal oven temperature)
Weekly timer setting
Start the program

C3030 - 2021-09
Page 8of 44
Item
Description
Programming display access (see §4. Program)
Setting display access (see §5. Controller Settings)
On XUE ; XUELT ; XBE range
Inside fan speed dimmer
To change the fan speed, select the icon with
key. Then adjust the fan speed with or
key.
On XUE ; XUELT ; XBE ; XFE range
Electronic thermostat against overheating settings
access. (see §2 Electronic thermostat for protection
against overheating)
XFE range
Measured vacuum level in mbar
The measured vacuum level is displayed under the heating
power.
If the weekly timer is active and out of the working set period, the icon disappears and the icon
appears blinking.

C3030 - 2021-09
Page 9of 44
Display when a program is running
XUE ; XUELT ; XBE range
XL ; XXL range
XFE range
Item
Description
Running program displays :
Temperature gradient number Temperature target number
Number of loops remaining
Temperature set point for the next target.
Remaining step duration or delayed start duration
Stop or pause the program
Depending on the action you made, the following messages can appear :
: Program paused
: Program stop must be validated.
: The program is finished
If a delayed start has been set :
: Wait before starting the program

C3030 - 2021-09
Page 10 of 44
2 Electronic thermostat for protection against overheating
The overheating protection by electronic thermostat must always be set before
using the oven.
2.1 Protecting thermostat description
The thermostat turns off heating if the measured temperature exceed the thermostat set point temperature. It
allows to protect the oven and its content against overheating.
This thermostat also allows to monitor the difference between the measured temperature and the set point
temperature with the SDT function: Set point Deviation Tracking. If the gap is over the tolerance set, the
duration while the temperature is out of tolerance won’t be deducted from the dwell duration set.
In order to compensate the gap between the thermostat probe and the regulation probe, it is possible to define
an offset parameter. This offset is used for the whole operating range of the oven.
The C3030 controller allows for XUE ; XUELT ; XBE ; XFE range a DIN 12 880 compliant thermostat.
The electronic thermostat can be used in 2 different ways
- TWW mode: with automatic reset (3.1. protection class according to the DIN 12 880 standard).
- TWB mode with manual reset (2.0 protection class according to the DIN 12 880 standard)
Thermostat Limit: 320°C
Temperature: 51.0°C Offset : 0.0°C
Protection mode: TWW Set: 320°C
Relay position: ON Iheat: 5.9 A
Setpoint Deviation Tracking
Tolerance ± 3°C
Active : OFF Alarm:NO
Item
Description
Thermostat parameters
Thermostat setpoint limit indication. Depending on your oven’s
features.
Measured temperature inside the oven indication, in Celsius.
Thermostat offset : gap between the thermostat measured value and
measure value given by a standard.
Electronic thermostat reset mode : réarmement automatic (TWW) or
manual (TWB).
Thermostat setpoint, in °C
Thermostat card relay status : ON or OFF
Resistors current indication, in Amps

C3030 - 2021-09
Page 11 of 44
Objet
Description
SDT parameters
Temperature gap allowed for the SDT, in Celsius.
Set to 0°C, SDT tracking disabled
SDT activation status indication.
SDT status indication

C3030 - 2021-09
Page 12 of 44
2.2 Electronic protection thermostat function in TWW mode (automatic
reset)
When the measured temperature is over the thermostat set point temperature, the thermostat stops the oven
heating. The measured temperature is displayed on a red background, a “TWW” indication appears and an
audible alarm is triggered.
TWW trigger example:
Press any key to disable the audible alarm. When the failure disappear, the heating can restart and all failure
indications also disappear.
TWW protection working principle:
Temperature
in Celsius
Time
Thermostat set point Controller
set point
Normal running Thermostat
take-over
Measured
temperature
Regulation
failure

C3030 - 2021-09
Page 13 of 44
2.3 Electronic protection thermostat function in TWB mode (manual
reset)
When the measured temperature is over the thermostat set point temperature, the thermostat stops the oven
heating. The measured temperature is displayed on a red background, a “TWB” indication appears and an
audible alarm is triggered.
TWB trigger example:
Press any key to stop the audible alarm. But the oven heating can restart only after a manual reset. Even if
the measured temperature has gone under the thermostat trigger temperature.
2.4 TWB mode electronic thermostat reset
Note: The measured temperature must be under the thermostat trigger temperature.
1
“Thermostat”display access :
- If a program is running, press the key to
select the icon. Then press twice or
key to stop the program.
- Press several times the key to scroll the
menu icons until the icon is selected
- Press the or key to enter the
electronic thermostat settings display.
2
Thermostat reset :
- Press several times the key to scroll the
parameters until the « Alarm Reset » button
is selected.
- Press the or key to reset the
thermostat.
The “Alarm Reset” disappears : the
thermostat is reset.
Press the key to return to the main
display.
Thermostat Limit: 320°C
Temperature: 329.0°C Offset : 0.0°C
Protection mode: TWB Set: 320°C
Relay position: ON Iheat: 5.9 A
Setpoint Deviation Tracking
Tolerance ± 3°C
Active : OFF Alarm:NO
Alarm Reset

C3030 - 2021-09
Page 14 of 44
TWB mode thermostat working principle :
Temperature
In Celsius
Time
Electronic thermostat set
point Controller
set point
Normal running Thermostat
take-over
After
manual
reset
Measured
temperature
Regulation
failure
2.5 Setpoint Deviation Tracking (SDT) system working
The SDT monitoring allows to warn a for gap between the measured temperature and the controller’s set
point target temperature. It’s defined by a gap tolerance parameter, in Degree Celsius.
For example, for a 2°C tolerance and a set point target of 100°C, the measured temperature must be
situated between 98°C and 102 °C.
The SDT temperature monitoring starts once the temperature is within the tolerances. If the measured
temperature exceed the tolerance, then temperature is displayed on a red background with a “SDT”
indication:
The red display and the “SDT” indication disappear when the measured temperature value goes back within
the tolerance.

C3030 - 2021-09
Page 15 of 44
SDT working principle :
Temperature
in Celsius
100
200
Time
1234 5
102°C
98°C
202°C
198°C
67
1 : The SDT monitoring is enabled when the temperature measure reaches the target tolerance.
2 and 4 : The SDT alarm is triggered because the measured temperature value goes out of the tolerance.
3 and 5 : The SDT alarm disappear when the measured temperature value goes back within the tolerance.
6 : The SDT monitoring is disabled when the temperature set point is changed.
7 : The SDT monitoring is enabled anew when the measured temperature reaches the tolerance defined
around the new set point temperature.
2.6 Overheating protection thermostat and SDT settings
1
“Thermostat” display access :
- Press several times the key to scroll
the menu icons until the icon is
selected
- Press the or key to enter the
electronic thermostat settings display.
2
Protection mode :
- Change the « Protection Mode »
parameter with the or key to
define it in TWW (automatic reset) or TWB
(manual reset) mode.
- Confirm with the key to proceed to the
next parameter.
Thermostat Limit: 320°C
Temperature: 29.0°C Offset : 0.0°C
Protection mode: TWB Set: 320°C
Relay position: ON Iheat: 5.9 A
Setpoint Deviation Tracking
Tolerance ± 3°C
Active : OFF Alarm:NO

C3030 - 2021-09
Page 16 of 44
3
Thermostat offset :
The offset parameter comprensate the gap
between the thermostat measure and a standard
mesure. It’s initially factory set.
- Adjust the « Offset » parameter
with or key.
- Confirm with the key.
- Press the key to return to the main
display.
Thermostat Limit: 320°C
Temperature: 329.0°C Offset : 0.0°C
Protection mode: TWB Set: 320°C
Relay position: ON Iheat: 5.9 A
Setpoint Deviation Tracking
Tolerance ± 3°C
Active : OFF Alarm:NO
4
Temperature set :
- Adjust the « TemperatureMax »
parameter with or key.
- Confirm with the key to proceed to
the next parameter.
Thermostat Limit: 320°C
Temperature: 29.0°C Offset : 0.0°C
Protection mode: TWB Set: 320°C
Relay position: ON Iheat: 5.9 A
Setpoint Deviation Tracking
Tolerance ± 3°C
Active : OFF Alarm:NO
5
SDT Tolerance :
- Adjust the « SDT Tolerance » parameter
with or key.
- Confirm with the key to proceed to
the next parameter
If you don’t want to use the SDT monitoring,
set the tolerance to ‘0’ °C.
Thermostat Limit: 320°C
Temperature: 329.0°C Offset : 0.0°C
Protection mode: TWB Set: 320°C
Relay position: ON Iheat: 5.9 A
Setpoint Deviation Tracking
Tolerance ± 3°C
Active : OFF Alarm:NO

C3030 - 2021-09
Page 17 of 44
3 Manual regulation
Never switch off the oven if the oven chamber’s temperature is above 50°C.
Manual regulation allows heating and maintaining the temperature in the oven at a constant value.
The main screen displays the measured temperature on the upper line (in green) and the temperature set point
on the bottom line (in red).
When the oven is switched-on, the temperature controller turns on, and activates the latest temperature set
point.
To define the set point temperature :
- Adjust the set point temperature (in Degree Celsius) with or key.
Set point value is automatically memorized.
It is advised to set to ‘0°C’the temperature set point, to make the oven cool down before switch it off.

C3030 - 2021-09
Page 18 of 44
4 Program
The C3030 controller allows to program an automatic heating sequence from 1 to 4 steps.
A step is contains at least a temperature set point. A target duration defining the temperature target holding
time and a temperature ramp in Degree Celsius per minute can also be defined for each step.
A cycle contains all the defined steps. The C3030 controller allows to repeat the cycle and to delay its start.
4.1 Program structure
Item
Description
Step
Step number (between 1 and 4 max.)
Ramp
°C/min
Temperature ramp in Degree Celsius per minute.
Setpoint
°C
Temperature target in Degree Celsius
Dwell
Hour : min
Target duration, in hour : minutes
Loop
Number of program iteration (default value : 1)
Guaranteed
Soak Band
Guaranteed Soak Band for each target, in Degree Celsius (default value : 2.0°C)
Start delay
Waiting duration before starting the program, in hour : minutes.

C3030 - 2021-09
Page 19 of 44
4.2 Program creation
4.2.1 Step setting
1
“Program” display access :
- Press several times the key to scroll the
menu icons until the icon is selected
- Press the or key to enter the
program display.
2
Temperature ramp :
- Let without any value (default setting) to get
the fastest temperature increase.
- To control the temperature increase, adjust
the parameter with the or key.
- Confirm with the key to proceed to the
next parameter
3
Temperature set point :
- Define the temperature set point with
the or key.
- Confirm with the key to proceed to the
next parameter
4
Temperature target duration :
- First define the hour duration with the or
key.
- Confirm with the key to procced to the
minute duration setting.
- Define the minute duration with
the or key.
- Confirm with the key to proceed to the
next parameter
The first step is now defined.

C3030 - 2021-09
Page 20 of 44
- To set another step, repeat the instructions above to define at least the target temperature set point.
- To end the program, let the default values of the next step. Confirm these empty values with the
key until the selection is on the loop parameter. The loop parameter is automatically selected if all the
parameter of a step are empty.
4.2.2 Number of program iteration setting
The « loop » parameter allows to repeat the program several times.
- If your program has only one step, it will only multiply the target duration by the number of loops.
Indeed, the measured temperature has already reached the set point temperature at the end of the
previous cycle.
- If you wish to decrease the oven temperature between 2 iterations, a new cooling step with a lower
set point than the first step must be defined, in order to allow the oven to cool down.
5
Number of program iterations :
- Define the number of loops with the or
key.
- Confirm with the key to proceed to the
next parameter
Program example with repetition and cooling between 2 cycles:
Time
Temperature
in Celsius
Cooling time to reach the 2nd step temperature set
point before starting a new heating cycle
11
100
200
3°/min 1h30
1
222
3°/min 1h30 3°/min 1h30
