Francis Searchlights FL710 User manual

User Instruction & Installation Manual
FL710 Suez
Tungsten Halogen Searchlight
Product Reference Number:
FL710 Suez Tungsten Halogen Searchlight
Manufacturers details: Distributor details:
Manual Part Number: C14852
Issue: 3
Francis Searchlights Ltd
Union Road, Bolton
Lancashire, BL2 2HJ, UK
Tel: [phone]
Fax: [phone]
http://www.francis.co.uk
E-mail: [e-mail]

CONTENTS
1 - Introduction
2 - Safety Precautions
3 - Technical Information
4 - Unpacking and Installation Instructions
5 - Electrical Installation
6 - Operating Instructions
7 - Fault Finding
8 - Maintenance and Servicing
9 - General Assembly
10 - Spare Parts List

1 - Introduction
It is imperative that this manual is read carefully and understood before
installing your equipment. For your future reference please keep this manual in
a safe place.
Thank you for specifying a product from the Francis Searchlights range. All Francis products are
designed to give complete customer satisfaction and are manufactured to the highest engineering
standards in order to ensure optimum performance and service life.
The Francis FL range combines features proven over many years service in the most hazardous
conditions in both marine and land installations.
In order to prolong the life and performance of your product, we recommend that you only specify
Francis Searchlights spare parts. This will also ensure that any warranties on your equipment will
not be invalidated. Information on spares ordering and parts is provided in this manual.
Should you ever need to contact Francis Searchlights Ltd. regarding your equipment, please quote
the Product Serial Number at all times.
Back To Top

2 - Safety Precautions
The following instructions must be adhered to, in order to ensure a safe working environment and
the safety of the user.
Note: When unpacking or manoeuvring the searchlight into its fixing position, suitable
lifting points must be used in order to prevent damage to the equipment or personal injury.
Prevent rain, snow, condensation and water droplets from contacting the lamp as this may
cause bulb failure and possible shattering;
Quartz halogen bulbs run with a high internal pressure in excess of atmospheric. Whilst the
construction is inherently strong, there is a slight risk of the bulb shattering;
Never look directly into an illuminated searchlight as this may cause severe damage to
eyesight. If it is necessary to inspect a lamp whilst in operation, always wear suitable protective
goggles;
Should it be necessary to examine the lamp with the front bezel removed, always use a
protective shield and wear goggles to ensure a safe working environment;
Never attempt to clean a lamp whilst in use;
Searchlights get hot. Never touch the unit when lit and always allow 15 to 20 minutes for
cooling down after turning the searchlight off;
Never place anything on or cover the searchlight when in use;
Ensure the lamp has cooled sufficiently before removal;
If undue force appears necessary to remove the lamp, the equipment should be inspected by a
competent person or contact the manufacturer;
When breaking a lamp for disposal, care must be taken to ensure the glass fragments are
safely contained. This operation must be performed out of doors in free air. In all
circumstances refer to the lamp manufacturers instructions packed with the lamp;
Due to the vast range of lamps available it may appear possible that more powerful lamps can
be used in the equipment than for which it was designed. Even when the unit will physically
accept a higher wattage or voltage lamp, this substitution is not recommended and is
dangerous. This action will also void any warranties on the equipment.
Always refer to the lamp manufacturers technical data when dealing with lamps.
Back To Top

3 - Technical Information
This product has been designed to operate in accordance with the product specification. The
FL710 Suez searchlight has the following features:
All marine grade materials and fixings;
Parabolic split glass reflector;
Stove enamel painted;
360° horizontal rotation;
Vertical movement +40° to -35°;
Toughened front glass;
Gas proofed for use on tankers;
Fitted with a pressure relief valve & exhaust cock;
Lamp changeover system in event of lamp failure;
Single beam 5-10° split beam of two 5° sections with 0-10° dark centre;
The searchlight also performs to the following optical data:
Single Beam Split Beam
Lamp Vert. P.B.C.P. Range Hor. Vert. Centre P.B.C.P. Range
Metres Angle Metres
D1823 2.5° 4,945,000 2,212 5° 2.5° 0-10° 2,472,500 1,563
D9843 3° 5,796,000 2,600 5° 3° 0-10° 2,898,000 1,600
D4604 3° 3,719,000 1,946 6° 3° 0-10° 1,859,500 1,383
D9841 4° 4,820,000 2,589 6° 4° 0-10° 2,410,900 1,585
D1839 4° 3,718,000 1,942 6° 3° 0-10° 1,859,000 1,381
D9842 4° 4,821,000 2,600 6° 4° 0-10° 2,410,950 1,600
In order that the searchlight operates correctly it is imperative that competent personnel are
responsible for the installation, operation and servicing of this equipment. Failure to adhere to this
advice may cause premature failure or incorrect operation of the searchlight, which may damage
the equipment or cause personal injury.
Back To Top

4 - Unpacking and Installation Instructions
The following instructions should be read and fully understood prior to installing the equipment to
ensure that the correct procedures are followed, and all safety precautions are observed.
Note: If the equipment has been in storage for a considerable amount of time, it is advisable
to conduct a routine maintenance check on all parts before installation.
Safety Precautions
This equipment should not be connected to an electrical supply before being installed. Installation
procedures should be adhered to in order to ensure a safe working environment and reduce the
risk of damage or personal injury.
Preparing the Mounting Position
Mark out and drill the fixing holes through the deck. If anti-vibration mounts are to be fitted, the
fixing holes for the mounts should also be marked out and drilled. Prior to manoeuvring the
searchlight into its’ fixing position, the AV mounts should be fitted to the base. When in the desired
position and bolt the searchlight firmly down. On and uneven surface it may be necessary to use a
suitable sealant such as silicone, in order to ensure a weatherproofed joint.
Back To Top

5 - Electrical Installation
For safety purposes, only competent personnel should perform the electrical installation. All
equipment should be installed to current Electrical Regulations and Standards.
In order to obtain the maximum light output from the searchlight, it is essential that the full
operating voltage of the lamp fitted be applied to the lampholder contacts.
Method of Electrical Connection
1) Disconnect the supply before working on the electrical system;
2) The searchlight must be connected to a fused electrical supply, using suitably sized cable;
3) If the searchlight is located a considerable distance from the supply, provision must be made in
the cable size in order to overcome the voltage drop. The following table should be used for
indication purposes only:
Searchlight FL
115v 2Kw
115v 3Kw
220v 2Kw
240v 2Kw
240v 3Kw
Cable Size (mm²)
Distance Max
Distance Max
Distance Max
Distance Max
Distance Max
1.5
8 MTRS
5 MTRS
31 MTRS
37 MTRS
24 MTRS
2.5
14 MTRS
9 MTRS
51 MTRS
60 MTRS
40 MTRS
4
22 MTRS
14 MTRS
88 MTRS
96 MTRS
64 MTRS
6
34 MTRS
23 MTRS
125 MTRS
150 MTRS
99 MTRS
10
57 MTRS
38 MTRS
210 MTRS
250 MTRS
167 MTRS
4) Whenever possible cable terminations should be made below deck and with approved terminal
devices;
5) If a spare auxiliary fuse or circuit breaker is not available, one of the correct type and rating
should be fitted and connected to a positive supply. It is advisable to locate a bus bar or main
connection and avoid any direct connection to the supply:
6) For 110/220v AC products, the following colour coding system should be used for the customer
supply cable:
Brown - Live
Blue - Negative
Green/Yellow - Earth
Note: This equipment must be earthed.
Back To Top

6 - Operating Instructions
This equipment is designed for use out of doors, in free air. Never place anything on, or cover, the
searchlight when in use as this may present a hazard.
The beam of the searchlight can be adjusted to give a variety of beam types. Using the external
focus wheel situated to the rear of the searchlight, the desired beam can be achieved for any
particular application.
This product should not be used for any purpose other than for which it was designed. Any
modifications to the product should not be undertaken without consulting the manufacturer.
Setting to Work
Safe service in use necessitates the strict observance of the following precautions.
Any article fabricated from quartz or glass is inherently fragile and care should
therefore be taken, at all times, when handling lamps;
Eye protection must be worn when handling lamps that have been removed from their
packaging materials. The protective jacket should not be removed from the lamp for
safety reasons, as there is a remote possibility of the lamp shattering violently,
especially if it is subjected to mechanical shock or vibration;
Always isolate the equipment from the supply before inserting a lamp;
Before inserting the lamp ensure that all contacts are clean. Contacts must be
renewed at the slightest sign of corrosion. Sanding or filing down corroded areas is not
recommended as this will only make the conducting surface between the pin and
lampholder smaller, thus causing the lamp to overheat;
Do not twist or bend the fused quartz bulb when fitting the lamp as mechanical
stresses MUST be avoided;
The lamp must be capable of unimpeded expansion when it warms up to operating
temperature. Mechanical forces must not be applied to the fused quartz bulb;
Before the protective jacket is removed, suitable protection must be worn i.e face mask
and gloves with wrist protection;
Never touch the quartz bulb with bare hands, as fingerprints will make the glass cloudy
and cause a severe loss of light. This may also cause recrystallisation and thus
weaken the bulb material. Should the bulb be inadvertently touched, remove
fingerprints with methylated spirit and a clean, soft paper towel. The bulb should then
be wiped with distilled water. NOTE: ALWAYS WEAR MASK AND GLOVES DURING
CLEANING);
In all circumstances the lamp manufacturers data should be referred to when dealing with
lamps.

When fitting the lamp:
-Always isolate the equipment from the supply when inserting a lamp;
-Ensure the circuit is suitably fused;
-Ensure the lamp is of the correct power rating and type;
-Check lampholder is in good condition. If the contacts show any sign of corrosion, replace the
lampholder;
-Check the lampholder is in a good dry condition. Never allow water to collect in the lamp fitting
or come into contact with the lamp.
To fit the lamp:
-Unfasten the latches on the front of the searchlight, remove the bezel and glass and store in a
safe place;
-For easier access the light shield/spill ring may be removed by undoing the fasteners;
-Using a cloth to prevent the fingers coming into contact with the lamp, position the two pins
above the holes in the lampholder;
-Gently push the lamp into the lampholder;
-Replace the light shield/spill ring and front bezel assembly, ensuring the latches are securely
fastened.
Testing
Upon correct installation and connection to an electrical supply, the equipment can be tested in
order to ensure its’ correct performance. A competent person with some knowledge of electrical
equipment must carry out this work.
Equipment required: Multimeter with leads
Ammeter
Using the equation P=VI, the approximate power output of the equipment can be calculated in the
following way:
-Using the multimeter, take a voltage reading;
-Using the ammeter, take an amp reading from the live cable to the lamp;
-Multiply these figures together to give an approximate wattage (Power output).
For example:
Using a 240v 1000w Tungsten halogen lamp:
Voltage reading = 240v; Amps reading = 4 amps
Therefore, Wattage = 240 x 4 = 960 watts
Back To Top

7- Fault Finding
All fault finding must be conducted by a competent person or qualified Electrical Engineer.
Failure of Lamp to light
Causes:
1) Power not supplied;
2) Fuse blown;
3) Failed lamp
Remedy:
1) Check voltage at supply. If supply is not present the fault is at the customer supply. If power is
present, see remedy 2;
2) Check fuse for visual failure. If none noticeable check fuse for continuity using a multimeter. If
fuse found to be faulty, replace with new part and test equipment again for correct working
order. If found to be working correctly see remedy 3;
3) Firstly, check supply at lampholder connecting block (within searchlight barrel). If supply is
present, disconnect unit from power supply before removing the lamp. If noticeable damage to
filament is present, the lamp will have failed. The lamp can also be checked for continuity using
a multimeter. Replace lamp ensuring all precautions and instructions previously outlined in this
manual are adhered to.
Back To Top

8 - Maintenance and Servicing
In order to prolong the service life and performance of your searchlight, the following maintenance
guidelines are recommended:
Maintenance checks should be conducted before very voyage or at least every three months;
Before checking, disconnect the equipment from the supply;
Visually inspect the condition of the equipment;
Any major or minor structural damage should be rectified immediately in order to reduce
sympathetic wear;
After inspection it may be necessary to clean the inside of the searchlight. The following
procedure should be adhered to:
Remove the front bezel;
Clean the front glass inside and out using a proprietary glass cleaner;
Clean the reflector if required;
Check the reflector mounting gaskets. If signs of corrosion or damage are
evident, replace as necessary;
Ensure that the lampholder is free from corrosion or other damage;
Check earthing point for conductivity;
It is advisable to check all seals and gaskets for signs of degradation. Renew if necessary;
Upon completing all maintenance requirements, the searchlight should be tested for full
working order (approximately 20 minutes).
If in any doubt as to the correct servicing procedures to adopt please contact your
distributor/agent or the manufacturer who will be able to advise the best course of action for
your product.
Back To Top

9 - General Assembly
Drawing Number Description
A2703 FL710 Suez 2/3Kw T/H G38 G.A.

10 - Spare Parts List
The following spare parts can be ordered directly from the manufacturer:
Part Number Description
D1823 115v 2Kw G38 T/H Lamp
D9843 115v 3Kw G38 T/H Lamp
D4604 220v 2Kw G38 T/H Lamp
D1839 240v 2Kw G38 T/H Lamp
D9841 220v 3Kw G38 T/H Lamp
D9842 240v 3Kw G38 T/H Lamp
C11025 Lock Wheel Assembly
C20904 Focus handle
C12365 Switch
C15394 Switch Knob
C14320 Breather
C03818 Stop cock & handle
C02067 Stop cock hose adaptor male
C04036 Stop cock hose adaptor female
C20550 Latch
C14239 Rear handle
C01964 Reflector
C09868 Lampholder
C21252 Front glass
C21253 Front glass gasket
C20943 Lifting handle
C22003 Clamping lever (Base)
In order to prolong the life and performance of your product, we recommend that you only specify
Francis Searchlights spare parts. This will ensure that any warranties on your equipment will not be
invalidated.
When ordering spare parts please contact the Sales Department at Francis Searchlights Limited.
Please quote searchlight model and serial number at all times. This will enable a fast response to
your spares’ requirements.
Back To Top
