Ducting Systems
Installation Instructions
The APT™ ducting system allows primary or secondarily contained pipe to be easily retracted and then reinstalled. This
ducting acts as a conduit for the pipe to run through and should not be considered an additional containment layer. APT™
ducting can be air tested to check system integrity.
Follow all federal, state and local laws governing the installation of this product and its associated
systems. When no other regulations apply, follow NFPA codes 30, 30A and 70 from the National
Fire Protection Association. Failure to follow these codes could result in severe injury, death,
serious property damage and/or environmental contamination.
The part described in this document is one element of a system. All components of this system
should be installed according to the manufacturer’s specications so that the system’s integrity is
not compromised. Test the complete system after installation according to all pertinent local, state
and federal laws to ensure its proper operation. Failure to properly verify operation could lead to
environmental contamination.
Warning
Caution
Install Ducting
1. Install the ducted-style pipe entry boots in the sump wall per the entry boot installation instructions (Figure 1).
Refer to Table 1 for torque specications.
Sump
Ducted Entry Boot
Ducting
DUCT-400-XXX
Measure to Faceplate
Figure 1: Ducted and Rigid Entry Boot Connection
2. Pull the ducting and cut it to the length measured from faceplate to faceplate of the entry boots. Set it on the entry
boots at this time.
Note: Cut the ducting to the measured length when installing ducting. Do NOT allow excess ducting to be installed.
Note: Do not tighten the ducting onto the entry boot until after the XP piping has been installed
Keep the Duct Run as Straight as Possible Keep Curved Duct runs no less
than 36" Bend Radius
Sump
Sump Duct Run: Curved
36" Minimum
Bend Radius
Figure 2: Duct Layout
Ducting
DUCT-400-XXX
Rigid Entry Boot
Sump Wall Measure to Faceplate
2
Note: Do NOT over-tighten the band clamps. Follow the
Torque guidelines in Table 1.
3. If you’re using air-testable entry boots, check the
system integrity by attaching a TRK-200 (Test
Regulator Kit) to the ducted entry boot (DEB) or
ducted bulkhead boot (DBB) air tting and charge
the lines to 2 to 4 PSI. Expect some initial line
expansion which will result in some pressure loss.
After the line pressure has stabilized, test the line
for 30 minutes with no pressure drop.
4. Soap all of the boot/ducting interfaces to check for
leaks. If any leaks are found, tighten the clamps
and retest.
Do NOT over-tighten the band clamps.
5. After installation is complete, the backlling
process can begin. Only backll with pea gravel,
clean compacted sand or crushed stone when
using DUCT-400-XXX ducting.
6. If you’re using air-testable boots, recheck the air
test after backlling to conrm system integrity.
Application
Torque
(Inch-
Pounds)
Torque
(N-m)
Boot Fastening Nuts
HDPE without Permathane 60 7
Fiberglass without
Permathane
75 9
HDPE with Permathane 55 6
Fiberglass with
Permathane
55 6
Band Clamp
Flexible side 25 3
Ducted side 20 2
Table 1: Torque Specications
Preparing to Backll over Ducting
Sump Sump
Sump
NTS
Place 3' piles of gravel every 6 feet to
prevent duct movement during backfilling.
6'
Measure and Install XP Piping
1. Run a measuring tape / line through the duct, pull it tight and measure the distance from the Pipe Termination Collars.
Figure 3: Pipe Termination Collar Location
CAUTION: Do NOT cut the pipe longer than required. Excess pipe inside of ducting can cause pipe movement due to
line shock.
2. Cut the pipe to the measurement from step 1.
3. Remove the duct from the entry boots.
4. Extend the pipe through the ducting.
Note: Attach a rounded object to the end of the pipe to keep it from catching on the ducting ribs as it moves through.
5. Push the pipe through the entry boots.
6. If the necessary tting connections or test boots have not already been installed, then do so now.
7. Attach the piping to the tting.
3
Unused Page
©2015 APT 771-206-00 Rev.9
