Freecom CLASSIC SL NETWORK HARD DRIVE User manual

Freecom Classic SL Network Drive
www.freecom.com
The easiest way to add extra GigaBytes to your
network or computer
The new Freecom Classic SL Network Drive
combines the simplicity of a local drive with
networked drive sharing. Simply connect
your Classic SL Network Drive to your home
or office network (LAN) and instantly share
secure storage - no IP configuration or
separate fileserver needed. Multiple PC's can
simultaneously access files on the Classic SL
Network Drive, without sacrificing on
performance. The drive appears as a local
driveon each PCwithin the network -
making it the perfect centralized storage
center for your home, company work group
or small office. Easy to install and easy to
use..... Keep it Simple !!
Freecom Classic SL Network Drive
•Fast centralized network storage - add extra storage capacity to
your network in seconds!
•Can also be used as fast, portable USB-2 external hard drive
•Appears as local drive on each PC
•No IP address so the drive is invisible to anyone outside of your
network: your data is 100% secure!
•Can also be used in a mixed (PC/Mac) network environment
•Compatible with DSL, cable and wireless access modems/routers
•High quality aluminium enclosure
•Two years manufacturers warranty, free helpdesk support
Designed for:
•Adding secure storage to your home or small office network
•Personal storage, store and save entire MP3, photos and movie
collections
•Backups,copy your business data and irreplaceable family memories
•Transporting files, take movies, songs and pictures anywhere you go
1-3

NETWORK
STAND-ALONE
MAC OSX
WINDOWS
98SE/2000/XP
WINDOWS
98SE/2000/XP
LAPTOP PC
FULL DUPLEX
ETHERNET
SWITCH
FREECOM CLASSIC SL
NETWORK DRIVE
FREECOMCLASSIC SL
NETWORK DRIVE
FAST
ETHERNET
www.freecom.com
Freecom Classic SL Network Drive
The Freecom Network Drive provides ease in installing, operating and maintaining a storage system without professional
networking knowledge. As a result, Freecom dramatically reduces your costs.
The Freecom Network Drive connects as a local high-speed USB drive for personal data storage. The pre-formatted drive is
plug and play, hot-swappable and compact. Freecom.... Keep it Simple!
2-3

Freecom Classic SL Network Drive
Product specifications Freecom Classic SL Network Drive
Storage capacity 80GB, 120GB, 160GB, 250GB, 400GB, 500GB
Interface Ethernet (100Base-T), USB 2.0 (1.1)
Max. data transfer rate Upto 100Mbit/s when connected through Ethernet, up to 480 Mbit/s when
connected through USB 2.0
Hard drive type E-IDE/UDMA compatible 3.5" hard drive
Hard drive Buffer Size 2MB (400GB, 500GB version 8MB)
Performance Average seek time: <9 ms
Track to Track seek time: 0.8 ms
Average Latency: 4.2 ms
MTBF 50000 P.O.H.
Physical specifications LxWxH 215 x 115 x 30 mm / 8.5 x 4.5 x 1.2 inch - Weight 750 gr. / 26.5 Ounce
Environmental specifications Operating Temperature 5º C to 55º C
Storage Temperature -40º C to 65º C
System Requirements: PCwith Pentium II233MHz or higher, Windows98SE / Me / 2000 / XP
MAC: G4 Power Mac with OS X version 10.2 or higher
128MB RAM, USB port (USB 2.0 recommended), CD-ROM drive for installation,
100Base-Tfull duplexswitch for NDAS mode, internet access for driver updates
and warranty registration.
MAC OS X requires the drive formatted in FAT32.
Power Requirements Voltage Adapter 200~240VAC
Package includes: •Classic SL Network Drive (Windows NTFS pre-formatted)
• Power Adapter (EU/UK/US)
• Ethernet cable
• USB cable (USB 2.0 & 1.1)
• Manual & Software CD
• Quick Install Guide
•Free helpdesk support
• Two years manufacturer's warranty
80GB 120GB 160GB 250GB 400GB 500GB
Art.no 24356 24357 24358 24359 24360 25919
EAN 4021801243560 4021801243577 4021801243584 4021801243591 4021801243607 4021801259196
Color Black Black Black Black Black Black
www.freecom.com
ref. MM/PW/10-08-2005
NDAS is a trademark of Ximeta, Inc.
FAST
ETHERNET
Quality, made in EU
3-3
