Freedom Scientific TOPAZ Connectivity Pack User manual

Part Number # 440340-001 Rev. D
TOPAZ™
Connectivity Pack
User's Guide
Freedom Scientific Blind/Low Vision Group, Inc.
July 2007

ii TOPAZ Connectivity Pack User’s Guide
PUBLISHED BY
Freedom Scientific
11800 31st Court North
St. Petersburg, Florida 33716-1805
USA
www.FreedomScientific.com
Information in this document is subject to change without notice. No part of this publication
may be reproduced or transmitted in any form or by any means electronic or mechanical, for
any purpose, without the express written permission of Freedom Scientific.
© 2007 Freedom Scientific Blind/Low Vision Group, Inc. All Rights Reserved.
TOPAZ™is a trademark of Freedom Scientific Blind/Low Vision Group, Inc. in the United
States and other countries.

TOPAZ Connectivity Pack User’s Guide iii
Table of Contents
Introduction..................................................................................... 1
What’s Included with the TOPAZ Connectivity Pack .................... 2
Installing the Connectivity Pack to TOPAZ................................... 3
Attaching Components to the Pack............................................... 7
Power............................................................................................ 9
Control Pad................................................................................... 9
Computer Monitor ....................................................................... 10
Foot Pedal................................................................................... 11
Distance Camera (Optional) ....................................................... 11
Using the TOPAZ Camera Controls............................................. 12
Brightness Dial (Yellow –Left).................................................... 14
Focus Lock Button (Orange –Second From Left) ...................... 15

iv TOPAZ Connectivity Pack User’s Guide
Magnification Dial (Center) ......................................................... 16
Position Locator Button (Red –Center)...................................... 17
Video Mode Button (Blue –Second From Right)........................ 17
Power Button (Green)................................................................. 18
Using the Control Pad .................................................................. 19
Power Button (Green –Bottom Right) ........................................ 21
View Selection Button (Orange –Bottom Center)....................... 21
Camera Selection Button (Yellow –Bottom Left)........................ 22
Line Button (Red –Top).............................................................. 22
Masking Button (Blue –Center).................................................. 23
Position Dial (Top Left) ............................................................... 23
Width Dial.................................................................................... 24
Using the Foot Pedal .................................................................... 25
What To Do If You Have Difficulty ............................................... 27

TOPAZ Connectivity Pack User’s Guide 1
Introduction
The TOPAZ Connectivity Pack lets you connect a computer and a
camera to the TOPAZ. The Connectivity Pack also provides:
Additional display controls via a control pad and a foot pedal
The ability to cycle through the document camera, an optional
distance camera (if available), and the computer screen
Split-screen displays of the document and the computer screen,
or the distance camera and the computer screen
Masking
Line display

2TOPAZ Connectivity Pack User’s Guide
What’s Included with the TOPAZ Connectivity Pack
The TOPAZ Connectivity Pack includes the following:
Connectivity Pack
Power supply
Hand-operated control pad
Foot pedal (with attached cable)
RJ11 cable (for the control pad)
TOPAZ Connectivity Pack User’s Guide
VGA-type Computer Monitor Input Port (for computer
connection)

TOPAZ Connectivity Pack User’s Guide 3
Installing the Connectivity Pack to TOPAZ
The TOPAZ Connectivity Pack connects to the back of the TOPAZ
and requires no special tools or equipment to install. Before you
begin, turn off the TOPAZ move to the back of the TOPAZ.
1. Disconnect the video cable from the back of the camera module.
2. Line up the screws on the Connectivity Pack with the keyhole
locks on the back of the TOPAZ support column and slide the
Pack firmly into place. (See illustration on next page.)

4TOPAZ Connectivity Pack User’s Guide
Keyhole
Locks
Keyhole
Locks

TOPAZ Connectivity Pack User’s Guide 5
3. Connect the TOPAZ monitor’s video cable to the monitor video
port on the top of the Connectivity Pack.
Top view of Connectivity Pack and input port

6TOPAZ Connectivity Pack User’s Guide
4. Plug one end of the short RJ45 cable into the top of the
Connectivity Pack and the other end into the rectangular RJ45
port on the back of the TOPAZ just below the power input ports.
5. Connect the power adapter to the port on the lower right of the
Connectivity Pack.
You are now ready to connect the components that you want to use
with the TOPAZ. (See the section Attaching Components to the Pack
on the next page.)

TOPAZ Connectivity Pack User’s Guide 7
Attaching Components to the Pack
Right-side of Connectivity Pack and input ports when
viewed from rear of TOPAZ

8TOPAZ Connectivity Pack User’s Guide
Left-side view of Connectivity Pack and input ports
when viewed from rear of TOPAZ

TOPAZ Connectivity Pack User’s Guide 9
Power
The power connector is located on the lower left side of the
Connectivity Pack and supplies power to all the components in the
TOPAZ Connectivity Pack. To connect the power adapter, plug it into
the small round port.
Control Pad
The control pad port is located on the lower left side of the
Connectivity Pack. The control pad port is slightly smaller than the
distance camera port and just above the power input port. To connect
the external control pad to the TOPAZ, push the control pad’s cable
into the port until you hear a click. For information on using the
control pad, see the section on Using the Control Pad.

10 TOPAZ Connectivity Pack User’s Guide
Computer Monitor
The computer port is located on the lower right side of the
Connectivity Pack and allows you to use your TOPAZ as your
computer monitor. To connect your computer to TOPAZ, plug a VGA-
type computer monitor input port cable (440340-001) into both the
monitor port on your computer and the computer input port on the
Connectivity Pack.
Note: Your computer must be set for a screen resolution of
1024 x 768 and at 60 Hertz. Any settings other than this
will cause the screen view to roll.

TOPAZ Connectivity Pack User’s Guide 11
Foot Pedal
The foot pedal port is located on the lower right side of the
Connectivity Pack. The foot pedal lets you cycle through various
screen-views as desired. The foot pedal plug is a standard 1/8”
audio-type jack which you attach directly to the foot pedal. To connect
the foot pedal to the Connectivity Pack, push the plug firmly into the
port. For more information, see the section on Using the Foot Pedal.
Distance Camera (Optional)
The optional distance camera port is located on the lower left side of
the Connectivity Pack and connects the distance camera to the
TOPAZ. The distance camera port is slightly larger than the control
pad port and just above it. To connect the distance camera, push the
camera cable into the port until you hear a click.

12 TOPAZ Connectivity Pack User’s Guide
Using the TOPAZ Camera Controls
The following diagram illustrates the various controls located on the
front of the TOPAZ. These controls operate differently while the
Connectivity Pack is attached. Below you will find descriptions of their
new behaviors. Each control on the camera module is described from
left to right.
Note: When the Connectivity Pack is connected the POWER
button on the TOPAZ will only control the TOPAZ lights
and Camera. The POWER button on the control pad will
turn the Connectivity Pack and the TOPAZ on and off
including putting the monitor in standby (you still need to
turn your computer on and off in the usual way).

TOPAZ Connectivity Pack User’s Guide 13
TOPAZ camera controls.

14 TOPAZ Connectivity Pack User’s Guide
Brightness Dial (Yellow –Left)
Turn the yellow BRIGHTNESS dial , located to the left of the
MAGNIFICATION dial, clockwise to increase the brightness of the
screen. Turn the yellow BRIGHTNESS dial counter-clockwise to
decrease the brightness.

TOPAZ Connectivity Pack User’s Guide 15
Focus Lock Button (Orange –Second From Left)
Press the orange FOCUS LOCK button to turn Auto Focus on or
off. When Auto Focus is on, the camera automatically focuses on the
object closest to the camera. When Auto Focus is off, TOPAZ does
not adjust the camera focus. Turning Auto Focus off makes it easier
to write or work with an object, because the camera will not
automatically focus on your hand. During normal operation, it is
recommended that you leave Auto Focus on.

16 TOPAZ Connectivity Pack User’s Guide
Magnification Dial (Center)
The MAGNIFICATION dial is located in the center of the camera
control panel. This control allows you to change the level of
magnification. A high level of magnification can help you see small
text and details. A low level of magnification allows you to see more
of the item on the screen. Turn the MAGNIFICATION dial to the left
to decrease the magnification level. Turn the MAGNIFICATION dial
to the right to increase the magnification level.
