Freetech P8F152 User manual

P8F152
MOTHER BOARD
USER’SMANUAL

CopyrightNotice
©Copyright2002
The information contained inthisuser’smanualand all accompa-
nying documentation iscopyrighted and all rightsarereserved.
Thispublication maynot, inwholeorinpart, be reproduced,
transcribed,stored inaretrievalsystem,translated intoany
language orcomputerlanguage,ortransmitted inanyform
whatsoeverwithoutthe priorwritten consentfromthe manufac-
turer,exceptforcopiesretained bythe purchasersfortheir
personalarchivalpurposes.
The manufacturerreservesthe righttorevisethisuser’smanual
and all accompanying documentation and tomakechangesinthe
contentwithoutobligation tonotifyanyperson ororganization of
the revision orchange.
INNOEVENTWILL THEVENDORBE LIABLEFORDIRECT,
INDIRECT,SPECIAL,INCIDENTAL,ORCONSEQUENTIAL
DAMAGES ARISINGOUTOFTHEUSE ORINABILITYTOUSE
THISPRODUCTORDOCUMENTATION,EVENIFADVISED
OFTHEPOSSIBILITYOFSUCH DAMAGES.INPARTICULAR,
THEVENDORSHALL NOTHAVE LIABILITYFORANYHARD-
WARE,SOFTWARE,ORDATASTOREDORUSEDWITHTHE
PRODUCT,INCLUDINGTHECOSTSOFREPAIRING,RE-
PLACING,ORRECOVERINGSUCH HARDWARE,SOFT-
WARE,ORDATA.
All trademarks mentioned inthisdocumentareacknowledged.
The specificationsinthismanualaresubjecttochange without
notice.

Using ThisManual
Thismanualisdesignedtohelpyou buildareliablePersonalComputer
basedon theP8F152 platform.
Chapter1-Quick Reference
Thischapterisforadvanceduserswho wanttoquicklyassembleasystem.
Themainboardlayoutalong withjumperand switchsettings,and memory
configuration areprovided.
Chapter2-Introduction
Thischapterincludesanintroduction,achecklistoftheitemsthatship
withthismainboard,and asummaryoftheprincipalfeaturesand compo-
nents.
Chapter3-HardwareInstallation
Thischapterexplainshowtoprepareyourmainboardforuseand howto
makethevariousconnectionstoothercomputercomponentsand periph-
eralitems.
Chapter4-BIOSConfiguration
Thischapterexplainshowtousethesystemsetup utilitythatisstoredin
themainboard’sfirmware.
Chapter5-Driverand Utility
Thischapterbrieflydescribesthedriversand utilityprogramsthatare
packagedwiththemainboard.
ii

TableofContents
1. P8F152 QUICKREFERENCE................................................ 1
1.1.MainboardLayout ........................................................... 1
1.2. I/O Ports......................................................................... 2
1.3.FrontPanelConnector................................................... 2
1.4.Jumpers......................................................................... 3
1.5.PCIand AGPFrequency Settings................................... 3
1.6.MemoryInstallation......................................................... 3
1.7.Connectors.................................................................... 4
2. INTRODUCTION.................................................................... 5
2.1. Overview........................................................................ 5
2.2.MainboardSpecificationsand Features.......................... 6
2.2.1.Hardware............................................................................ 6
2.2.2.Software............................................................................. 8
2.3.MainboardLayout ........................................................... 9
2.4.Microprocessor.............................................................11
2.5.CPUPackaging.............................................................11
2.6.AC97 Codec..................................................................11
2.7.Chipset......................................................................... 12
2.8.RAID(Optional)............................................................ 13
3. HARDWAREINSTALLATION............................................ 14
3.1.Unpacking .................................................................... 14
3.2. Installation .................................................................... 15
3.3.SafetyMeasures.......................................................... 15
3.4.Connector/JumperLocation ......................................... 16
3.5.Attaching Connectors................................................... 17
3.5.1.FrontPanelConnectors(JP1)........................................... 17
iii

3.5.2.Infrared(IR)Connectors(J1)............................................ 18
3.5.3.LAN/ModemWakeup Connectors(WOL1).................... 18
3.5.4.FrontUSBHeader(USB2,USB3)...................................... 19
3.5.5.AudioCD-INConnector(CD1)......................................... 19
3.5.6.AudioAUX-INConnector(AUX1).................................. 20
3.5.7.FloppyDriveConnector(FLOPPY).................................. 20
3.5.8.IDEConnectors(IDE1,IDE2,IDE3,IDE4)........................ 21
3.5.9.BackPanelConnectors..................................................... 22
3.5.10.PowerSupplyConnector(PW2)....................................... 25
3.5.11.CPU/AGP/SystemFANPowerSupplies(FAN1/FAN2).... 26
3.5.12.PCIConnector(PCI1~PCI6).............................................. 27
3.6. Installing the CPU......................................................... 28
3.6.1.BeforeYouBegin.............................................................. 28
3.6.2.Installation Procedure....................................................... 28
3.6.3.Removing theProcessor................................................... 29
3.7. Installing SystemMemory............................................. 30
3.8.Setting Jumpers........................................................... 31
3.8.1.ClearCMOSJumper(JBAT1)............................................ 31
3.8.2.CPUFSBJumper(JCK1)................................................... 32
3.8.3.DIMMVoltageJumper(JV1)............................................. 32
3.9.AutoPowerOn............................................................. 33
4. BIOSCONFIGURATION..................................................... 34
4.1.Entering Setup ............................................................. 35
4.2.StandardCMOSFeatures............................................ 37
4.3.Advanced BIOSFeatures............................................. 40
4.4.Advanced ChipsetFeatures......................................... 43
4.5. Integrated Peripherals.................................................. 50
4.6.PowerManagementSetup ........................................... 57
4.7.PnP/PCIConfigurations................................................ 63
iv

4.8.PCHealthStatusOption .............................................. 65
4.9.Frequency/Voltage Control........................................... 67
4.10.Load Fail-SafeDefaultsOption..................................... 68
4.11.Load Optimized DefaultsOption................................... 68
4.12.SetSupervisor/UserPassword.................................... 69
4.13.Save&ExitSetup ........................................................ 70
4.14.ExitWithoutSaving ...................................................... 70
5. DRIVERAND UTILITY....................................................... 71
5.1.FlashUtility................................................................... 71
5.2CD DriverOverview..................................................... 72
5.2.1.IntelChipset845INFDriver............................................. 73
5.2.2.IntelChipset845 BusmaterIDEDriver.............................. 73
5.2.3.AD1881AudioDriver....................................................... 74
5.3. Online Services............................................................ 75
v

1.P8F152 Quick Reference
Thissection isforuserstogetstartedusing themainboardstraightaway.
1.1.MainboardLayout
1.mPGA478CPUsocket(mPGA478)
2.ATXpowerconnector(PW2)
3.ATX12Vpowerconnector(PW1)
4.184-pinDIMM DDR modulesockets(DIM1~3)
5.AcceleratedGraphicsPortslot(AGP)
6.PCIexpansionconnector(PCI1~PCI6)
7. IDEconnector(IDE1~2)
8.RAIDconnector(IDE3~4)
9.Floppydriveconnector(FDD1)
10.FrontPanelconnectors(JP1)
11.FrontUSBportsconnectors(USB2/USB3)
12.ClearCMOS(JBAT1)
13. IRconnector(IR)
14.DIMMvoltageselector(JV1)
15.WakeonLANconnector(WOL1)
16.Audioconnectors(CD1)
17.Audioconnectors(AUX1)
18.FANconnectors(FAN1/FAN2)
19.CPUFSB(JCK1)
20.RTCbattery(BAT1)
21.FlashBIOS
1MainboardLayout
IDE4
IDE3
IDE2
IDE1
DIM3
DIM2DIM1
P
S
/
2
M
O
US
E
&
P
S
/
2
K E
Y
B O
A R D
P
O
R T
S
U S
B
P
O
R T
S
S
E
R I
AL
&
P
A RA L
L
E
L
P
O
R T
S
L
I
N E
-
I
N,
L
I
N E
-
O
UT
,
M
I
C-
I
N
&
G
A M
E
/
M
I
DI
P
O
R T
S
U M770045
0 149
9 50202CF
KB1
USB1
COM1
COM2
AUD1
AUDIO CODEC
2M FLASH EPROM
AGP
PCI 3
PCI 2
PCI 1
PCI 4
WOL1
I/O CHIPSET
RAID CHIPSET
PCI 6
PCI 5
IR
L
O
T
E
S
FDD1
USB2 USB3
A
T
X
P
O
W
E
R
PW2
C
D
1
A
U
X
1
PW1
A
T
X
1 2V
P
O
W
E
R
FAN1
S
Y
S
F
A
N
F
A
N
2
R
C
VIA
VT8235
0217CD TAIWAN
23A1009406 MC
T014.318
C E
B
6 0 3 0 L
CE T
FRONT PANEL CONNECTOR
W
i
n b o n d
W83697 HF 203 W5F
21 18 81 90 2
VIA
P4X400
0217CD TAIWAN
2IA2003622
1
2
3
4
5
6
7
7
8
8
9
10
1111
13
12
14
15
16 17
18
18
19
20
21

MainboardUser’sManual
2
1.2.I/OPorts
1.3.FrontPanelConnector
Thefollowing illustration showsthefrontpanelconnectorpinas-
signments:
I/OPorts
PS/2 Keyboard port
PS/2 Mouse port
COM1 port
Parallel port
MIDI/GAME port
COM2 port
USB ports Line-Out / Line-In / Mic-In ports
LAN port
LED anode
Speaker-out
Ground
Ground
+5V
Non
LED cathode
LED anode
LED cathode
LED anode
LED cathode
Reset Single
Power on/off
Ground
Ground
Pin 1
(PW SW)
POWER SWITCH
SPEAKER
(RST SW)
RESET SWITCH
(SBLLED)
STANDBY LED
(HLED)
HDD LED
(PWR LED & keylock)
POWER LED
& KEYLOCK
Keyboard
Ground

3
1.4Jumpers
1.5.PCIand AGPFrequency Setting
ThePCIand AGPfrequencysettingsareautomaticallysetby thesystem.
1.6.MemoryInstallation
Note:TheVT8754 chipsetfamilyusedinthismainboardallowszerowait
statebursting betweentheDRAMand thedatabuffersat133/100MHz.
184-PinDIMM DDRSDRAMMemoryConfiguration.
Each184-pinDIMM bank caninstall from64MBup to1GB
ofPC1600/PC2100/PC2700compliant2.5Vsingleordoubleside
unbufferedwithorwithoutECC DDRSDRAMmodules.
Jumper
P8F152 QuickReference
Bank 0 (DIMM1) 64MB, 128MB, 256MB, 512MB, 1GB
Bank 1 (DIMM2) 64MB, 128MB, 256MB, 512MB, 1GB
Bank 2 (DIMM3) 64MB, 128MB, 256MB, 512MB, 1GB
Total 64MB to 3GB
JBAT1 1-2 Normal Mode
2-3 Clear CMOS
JCK1 1-2 Auto
2-3 133MHz
JV1
1-2 2.5V
3-4 2.6V
5-6 2.7V
7-8 2.8V

MainboardUser’sManual
4Connectors
1.7.Connectors
FAN1 CPU/Chipset FAN Connector: This 3-pin header is used
for connecting a CPU chipset fan.
FAN2 System Fan Connector: This 3-pin header is for
connecting the case fan that keeps the system cool.
USB2/3 Front USB Connector: This 10-pin headers is used for
connecting front panel USB ports 3 and 4 or 5 and 6.
IR IR Connector: This 5-pin header is used to connect an IR
port for use of IR device.
WOL1 Wake On LAN Connector: This 3-pin header is used for
remote wake up ot the computer through a network card.
PW2
ATX Power Connector: This 20-pin header is connect the
power supply plug to ATX power connector to provide
Pentium 4 standard power for devices.
PW1
ATX 12V Power Connector: This 4-pin header is connect
the power supply 12V plug to ATX power connector to
provide 12V power for devices.
CD1 CD-IN Connector: This 4-pin header is used for
connecting the CD-ROM audio input to the sound card.
AUX1 Auxiliary-IN Connector: This 4-pin header is an auxiliary
input connector.

5Overview
2.Introduction
2.1.Overview
Thehigh qualityP8F152 isahigh performance,enhancedfunction
mainboardthatsupportsSocket478 IntelPentium4processorsthat
supporta533MHzfrontsidebus(FSB).TheP8F152 isbasedon theVIA
P4X400 chipset.Inteldeliverssuperiorhigh performance withall the
innovativefeaturesand provenreliabilityoftheVIAP4X400 chipset
family.Pin-to-pincompatiblewiththeVIAVT8235 chipset.
Themainboarddeliversworkstation levelperformance withanintegrated
AGP(AcceleratedGraphicsPort),busmasteringEIDE(EnhancedIDE)
controller,and concurrentPCIbus.ThemainboardaccommodatesDDR
SDRAM(SynchronousDRAM)memoryand supportsATA33/66/100/133.
Themainboardachievesthehighestreliabilityby supporting ECC (Error
Checking and Correction)memoryprotection,enabling themainboardto
achievesuperiordataintegrityand fault-tolerance withrespecttomemory
errorswhilerunning applications.
Inaddition tosuperiorhardwarecapabilities,providedwiththisplatformare
thesefeatures:
uSupportsIntel®Pentium®4processorsina478-pinpackage
uSupportsa66/100/133 memorybus
uSupportfor8x/4xAGP
uSupportsupto3GBofPC1600/PC2100/PC2700DDRSDRAM
uBusmasteringEIDEdriver
uSupportssixUSBportsaccommodating Plug and Playdevices
uSoft-off APM(AdvancedPowerManagement)
uACPI(AdvancedConfiguration and PowerInterface)
uKeyboardpoweron
uExternalmodemring on
uLAN wakeup
uBIOSupgradability

MainboardUser’sManual
6
2.2.MainboardSpecificationsand Features
2.2.1.Hardware
Intel®Pentium®4processorsina478-pin
package,compatibleAuto-detection CPU
OnboardVoltageRegulatorModule
Provides1.05Vto1.825Voperating voltage
CPUhasbuilt-infloating pointunit
Systembusclock 100/133 MHz
AGP8X
PCIbusclock 33 MHz
VIAP4X400 chipsetsupporting:
8x/4xAGPBusPlusAdvanced ECC
Memorycontroller
PC2700/PC2100/PC1600DDRSDREAM
SupportATA133
Three 184-pinDIMM sockets,up to3GB
Supports64 MBto1GBDDR SDRAMmemory
types
SupportseightIDEdevicesinfourchannels
SupportsPIOmode 0through mode 4drives
SupportsBusMastering DMAmode 2drives
SupportstwoBusMastering UltraATA66/100/133
drives
SupportsIomegaZIPorLS-120removabledrives
Chipintegrated directSound AC97
ALC-201A(2Channels,optional)
ALC-650(5.1Channel)
CPU
VRM
Coprocessor
Speed
Chipset
DRAM
EIDE
Controller
Sound Chip
MainboardSpecification and Features

7
One floppydisk controller
One Standard/EPP/ECPparallelportconnector
Two16550 compatibleserialportconnectors
TwoUSB (UniversalSerialBus)ports
One audioportconnectors,include line-out, line-
in,mic-in,and midi/gameports
TwoconnectorforfrontpanelUSB ports3/4,5/6
One IrDAcompatibleinfrared(IR)connector
PS/2mouseconnector
PS/2keyboardconnector
One 32-bit8xAGP(3.0)slot
Six32-bitPCIslots
CompliantwithEPA,APM1.2and ACPI
ATXsoft-offpowercontrol
Poweron bykeyboardand PS/2mouse
Poweron byexternalmodemring
Poweron byalarm
Poweron byLANwakeup
Fan off insleep mode
CPUtemperaturewarning and systemtempera-
turedetection
CPUand systemvoltage detection
CPUand secondaryfan RPMdetection
Switching regulator
CPUvoltage auto-detection
ATXformfactor
23 cmx305 cm(9.1x12-inch)
EnhancedI/O
I/OOptions
Mouse
Keyboard
Expansion
Slots
Power
Management
System
Management
Voltage
Regulator
FormFactor
BoardSize
MainboardSpecification and Features
Introduction

MainboardUser’sManual
8MainboardSpecification and Features
2.2.2.Software
BIOS
Driverand
Utility
Operating
System
AWARD AGP/PCIBIOS
2M-bitFlashBIOSwithESCD (Extended System
Configuration Data)block
SupportsAPM,Plug and Play,Multi-Boot, DMI
and EIDEdevices
SupportsACPI
Supportshigh-capacityLS-120 and ZIPremov-
ablemediadrive
IDEBusmastering UltraDMAdriver
AC97 codecaudiodriver
FlashutilityforBIOSupgrade
SystemEnvironmentMonitoring Utility
OperateswithMS_DOS,Windows3.x/9x/ME/XP/
2000/NT,OS/2,Novell NetWare/UnixWare,and
SCOUnix

9
2.3.MainboardLayout
Note:Becauseofoptionalitemsand design changes,yourmainboard
maynotbeidenticaltotheoneshownintheillustration.
MainboardLayout
Introduction
1
2
20
4
3
5
6
6
7
7
9
10
13
12
12
14
15
16
17
18
19
21
11
IDE4
IDE3
IDE2
IDE1
DIM3
DIM2DIM1
P
S
/
2
MO
U S
E
&
P
S
/
2
K E
Y
B O
AR D
P
O
R T S
U S
B
P
O
R T S
S
E
R I
A L
&
P
A R AL L E
L
P
O
R T S
L I
N E
- I
N ,
L I
N E
- O
U T ,
M I
C -I
N
&
G
A M E
/
MI
D I
P
O
R T S
U M 770 045
0 149
9 502 02 C F
KB1
USB1
COM1
COM2
AUD1
AUDIO CODEC
2M FLASH EPROM
AGP
PCI 3
PCI 2
PCI 1
PCI 4
WOL1
I/O CHIPSET RAID CHIPSET
PCI 6
PCI 5
IR
L O
T ES
FDD1
USB2 USB3
A
T
X
P
O W
E
R
PW2
C
D
1
A
U
X
1
PW1
A
T
X
1 2 V
P
OW
E
R
FAN1
S
Y
S
F
A
N
F
A
N
2
R
C
VIA
VT8235
0217CD TAIWAN
23A1009406
MC
T014.318
C
E B6
0
3
0
L
C
E
T
FRONT PANEL CONNECTOR
Wi n
b
o
n
d
W83697H
F
203W5F21 1881902
VIA
P4X400
0217CD TAIWAN
2IA2003622

MainboardUser’sManual
10
Key toMainboardComponents
MainboardLayout
No. Name Function
1mPGA478 CPU socket
2AGP Accelerated Graphics Port (AGP) slot
3FAN1 CPU fan connector
4DIMM1~3 DDR SDRAM Memory module slots
5JV1 DIMM voltage jumper
6IDE1~2 IDE 1~2 connector
7IDE3~4 RAID 3~4 connector
8FDD1 Floppy drive connector
9FAN2 System fan connector
10 JP1 Front Panel connector
11 JBAT1 Clear CMOS
12 USB2~3 Front USB port
13 BAT1 RTC battery
14 PCI1~6 32-bit PCI slots
15 IR IrDA compliant Infrared (IR) connector
16 U5 Flash BIOS
17 CD1 CD-in connector
18 AUX1 Auxiliary connector
19 PW2 ATX Pentium 4 standard power connector
20 PW1 ATX 12V power connector
21 JCK1 CPU FSB jumper

11
Microprocessor
2.4.Microprocessor
Themainboardisdesignedtooperatewiththefollowing processor:
Anonboardswitching voltageregulatorprovidestherequired1.05 to
1.825 voltsfortheprocessor.TheprocessorsendsfiveVID(Voltage
Identification)signalstotheswitching voltageregulator.Theswitch-
ing regulatorgeneratesthecorrectvoltagefortheprocessor.
2.5.CPUPackaging
Themainboard’sCPUsocketisasurface mount,mPGA478BtypeZIF
(ZeroInsertion Force)socket.Thesockethas478 pinswith50 mil pin
pitch.
Note:ZIFsocketsaresocketsdesignedforeasyinsertion ofpingrid
array(PGA)chips.Thechipisdroppedintothesocket,
and aleverisusedtosecurethechipinplace.
2.6.AC 97 Codec
u18-bit ADCand 20-bit DACresolution
uCompliantwithAC’972.2specifications
u18-bit stereofull-duplexCODECwithindependentandvariablesampling
rate
u3DStereoenhancement
uNoexternalcrystal/clockrequired
uPowersupply:digital:3.3V;analog:5V/3.3V
uStandard48-pinLQFP package
Introduction
Processor Type Speed FSB
Intel Pentium 4 1.4~2.4GHz+ 400/ 533MHz

MainboardUser’sManual
12 Chipset
2.7.Chipset
TheP8F152 supportstheVIAP4X400 chipset.TheVIAVT8235 chipsetis
designedfordesktopsand workstationsthatprovideinternalorexternal
graphics,and providesATA-133 and DDRSDRAMsupport.
TheP4X400 I/Ocontrollerhub makesadirectconnection betweenthe
graphicssystem,theIDEcontroller,and thePCIbus.Itusesaccelerated
hub architecturetoeffectivelydoublethebandwidthbetweenthese
componentsenabling morelifelikeaudioand video.TheP4X400 I/O
controllerhub includesanintegratedaudiocodec controllerthatletsthe
processormoreeffectivelydecodesound generatedby theintegrated
audiosystem.
Inaddition tofutureapplication support,the845 chipsetwasdesigned
withthefollowing features:
uDefinesHighlyIntegratedSolutionsforPerformance PCDesktop
Designs.
uHigh Performance CPUInterface.
uFull FeaturedAcceleratedGraphicsPort(AGP)Controller.
uAdvancdHigh-Performance DDRDRAMController.
uHigh Band width533MB/Sec8-bit V-LinkHostController.
uAdvancedSystemPowerMangementSupport.
uInter-operablewithVIAHost-to-V-Link HostController.
uHigh Bandwidth533MB/s8-bitV-LinkClientController.
uIntegratedPeripheralControllers.
uIntegratedLegacyFunctions.
uConcurrentPCIBusController.
uFastEthernetController.
uUltraDMA-133/100/66/33MasterModeEIDEController.
uDirectSound Ready AC97 DigitalAudioController.
uSystemManagementBusInterface.
uUniversalSerialBusController.
uSophisticatedPC2001-CompatibleMobilePowerManagement.
uPlug and PlayController.

13
2.8.RAID(Optional)
Busmastering design allowsutilization ofaRAID(RedundantArrayof
IndependentDisks).ARAIDisasetoftwoormoreharddisksand a
specializeddiskcontroller,whichcontrolstheRAIDfunction.Using a
RAID,theusercanwriteand readtomorethanonediskatthesametime,
thatis,completedataduplication canbeachieved,or,excess datacanve
transferredtoanotherdisk.theproblemsofdiskfailureareminimizedwith
theuseofaRAID.
ThisconcludesChapter2.Chapter3covershardwareinstallation.
RAID
Introduction

MainboardUser’sManual
14 Unpacking
3.HardwareInstallation
Thischapterexplainshowtouseyourmainboardtobuildapowerful
computersystem.Ataminimum,you will needthefollowing components
inordertobuildafullyfunctioning system.
rComputercasewithP4standardATXpowersupply
rmPGA478BProcessor
rOneDDRSDRAMmemorymodule
rOnefloppy diskdrive
rOneUDMA-66/100IDEharddiskdrive
rOneCD-ROMdrive
rOnedisplaymonitor
rOnemouse
rOnePS/2keyboard
rOnesetofloudspeakers
Ofcourse,you canusethesystemI/Oportsand expansion slotstoadd
many morefeaturesand componentstoyoursystemthantheitemslisted
above.
3.1.Unpacking
TheP8F152 mainboardpackagecontainsthefollowing items:
uOnemainboard
uOneIDE66/100 40-pinribboncable
uOnefloppy 34-pinribbon cable
uDriverand utilityCD
uUser’smanualreference
Afterremoving themainboardfromitsanti-staticbag,place it on a
groundedorantistaticsurface (componentsideup).Inspectthemainboard
and contactyourvendorimmediatelyifit isdamaged.
