Freetech P8F161G-e User manual

P8F161G-e
MOTHER BOARD
USER’S MANUAL
Ver 2.
NOV.26.2003

i
Copyright Notice
©Copyright 2000
The information contained in this user’s manual and all
accompanying documentation is copyrighted and all rights are
reserved. This publication may not, in whole or in part, be
reproduced, transcribed, stored in a retrieval system, translated into
any language or computer language, or transmitted in any form
whatsoever without the prior written consent from the manufacturer,
except for copies retained by the purchasers for their personal
archival purposes.
The manufacturer reserves the right to revise this user’s manual and
all accompanying documentation and to make changes in the
content without obligation to notify any person or organization of the
revision or change.
IN NO EVENT WILL THE VENDOR BE LIABLE FOR DIRECT,
INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE
THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, THE
VENDOR SHALL NOT HAVE LIABILITY FOR ANY HARDWARE,
SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING,
REPLACING, OR RECOVERING SUCH HARDWARE,
SOFTWARE, OR DATA.
All trademarks mentioned in this document are acknowledged.
The specifications in this manual are subject to change without
notice.

Perface
ii
Using This Manual
This manual is designed to help you build a reliable Personal
Computer based on the P8F161G-e platform.
Chapter 1—Quick Reference
This chapter is for advanced users who want to quickly assemble a system.
The mainboard layout along with jumper and switch settings, and memory
configuration are provided.
Chapter 2—Introduction
This chapter includes an introduction, a checklist of the items that ship with
this mainboard, and a summary of the principal features and components.
Chapter 3—Hardware Installation
This chapter explains how to prepare your mainboard for use and how to
make the various connections to other computer components and peripheral
items.
Chapter 4—etBIOS Configuration
This chapter explains how to use the system setup utility that is stored in the
mainboard’s firmware.
Chapter 5—etDVD Guide
This chapter explains how to use the etDVD.
Chapter 6—Driver and Utility
This chapter briefly describes the drivers and utility programs that are
packaged with the mainboard.

Perface
iii
Table of Contents
1. P8F161G-e QUICK REFERENCE.................................
.
1.1. Mainboard Layout ....................................................
1.2. I/O Ports...................................................................
1.3. Front Panel Connector.............................................
1.4. Jumpers ...................................................................
1.5. PCI Frequency Settings...........................................
1.6. Memory Installation..................................................
1.7. Connectors...............................................................
1.8. Note..........................................................................
1.9. Remote Controller....................................................
2. INTRODUCTION............................................................
.
2.1. Overview..................................................................
2.2. Mainboard Specifications and Features...................
2.2.1. Hardware..................................................................
.
2.2.2. Software...................................................................
.
2.3. Mainboard Layout ....................................................
2.4. Microprocessor.........................................................
2.5. CPU Packaging........................................................
2.6. AC97 Codec.............................................................
2.7. Chipset.....................................................................
3. HARDWARE INSTALLATION....................................
.
3.1. Unpacking................................................................
3.2. Installation................................................................
3.3. Safety Measures......................................................
3.4. Connector/Jumper Location.....................................
1
1
2
2
3
3
3
4
5
5
6
6
7
7
9
10
12
12
12
13
15
15
16
16
17

Perface
iv
3.5. Attaching Connectors...............................................
3.5.1. Front Panel Connectors (JP1) ..................................
.
3.5.2. Audio CD-In Connector (CD IN) ............................
.
3.5.3. Audio AUX-IN Connector (AUX1).........................
.
3.5.4. S/P DIF Connector (SPDIF) ....................................
.
3.5.5. Infrared (IR) Connector (IR)....................................
.
3.5.6. LAN connectors (LAN CON)..................................
.
3.5.7. Extend USB Header (USB1~3) ...............................
.
3.5.8. Power Supply Connector (PW / CON2) ..................
.
3.5.9. CPU/System FAN Power Supplies ........................
.
3.5.10. IDE Connectors ......................................................
.
3.5.11. Floppy Drive Header (FDC)....................................
.
3.5.12. PCI Connector (PCI1)..............................................
.
3.5.13. AGP Connector (AGP1)..........................................
.
3.5.14. Front Mic-IN, Line-IN Connector (JP2)..................
.
3.5.15. Front Speaker Connector (JP3)................................
.
3.5.16. 1394 Connector (1394)............................................
.
3.5.17. Serial ATA Connector (SATA)...............................
.
3.5.18. COM2 Connector (COM2)......................................
.
3.5.19. Game Connector (JP3) (Optional) ...........................
.
3.5.20. Extend Mouse / Keyboard (J25) (Optional).............
.
3.5.21. Back Panel Connectors............................................
.
3.5.22. 5.1 Channel Sound Connectors................................
.
3.6. Installing the CPU ....................................................
3.6.1. Before You Begin....................................................
.
3.6.2. Installation Procedure ..............................................
.
3.6.3. Removing the Processor ..........................................
.
3.7. Installing System Memory................................................
.
3.8. Setting Jumpers...................................................................
.
3.8.1. Clear CMOS Jumper (JP4) ......................................
.
18
18
19
19
20
20
21
21
22
23
24
25
25
26
26
27
27
28
28
29
29
30
30
34
34
34
35
36
37
37

Perface
v
3.9. Auto Power On.....................................................................
.
4. etBIOS CONFIGURATION ...........................................
.
4.1. Entering Setup .........................................................
4.2. Setup Main Menu.....................................................
4.3. System Information..................................................
4.4. General Configuration..............................................
4.5. Advanced Configuration...........................................
4.6. etBIOS Configuration...............................................
4.7. System Specific Setup.............................................
4.8. Primary / Secondary IDE Drivers.............................
4.9. Peripherals...............................................................
4.10. Power Management.................................................
4.11. PCI & PnP................................................................
4.12. Hardware Monitor.....................................................
4.13. Restore Manufacturer Settings ................................
4.14. Exit...........................................................................
5. etDVD Guide.....................................................................
.
5.1. Starting etDVD.........................................................
5.2. Main Screen.............................................................
5.3. Using the etDVD Player...........................................
5.3.1. The etDVD Interface................................................
.
5.3.2. General Control........................................................
.
5.3.2.1. Play Mode.......................................................
.
5.3.2.2. Drive Select ....................................................
.
5.3.2.3. Play.................................................................
.
5.3.2.4. Pause...............................................................
.
5.3.2.5. Stop.................................................................
.
5.3.2.6. Forward...........................................................
.
38
39
40
42
43
44
46
48
49
50
52
55
58
59
60
61
62
62
63
64
64
65
65
65
65
66
66
66

Perface
vi
5.3.2.7. Backward........................................................
.
5.3.2.8. Next Track/Chapter.........................................
.
5.3.2.9. Previous Track/Chapter ..................................
.
5.3.2.10. Progress Indicator...........................................
.
5.3.2.11. Volume ...........................................................
.
5.3.2.12. Mute................................................................
.
5.3.2.13. Eject................................................................
.
5.3.2.14. Exit..................................................................
.
5.3.2.15. Step Frame ....................................................
.
5.3.3. Exclusive CD/MP3 Controls....................................
.
5.3.3.1 Shuffle .............................................................
.
5.3.4. Exclusive VCD Controls..........................................
.
5.3.4.1 Audio Channel Select ......................................
.
5.3.5. Exclusive DVD Controls .........................................
.
5.3.5.1. Using the Menu...............................................
.
5.3.5.2. Displaying Subtitles........................................
.
5.3.5.3. Switching Language (Audio Streams)............
.
5.3.5.4. Switching Language (Audio Streams)............
.
5.3.5.5. Region Setup...................................................
.
5.4. TV Tuner (Optional) .................................................
5.4.1. Audio Input Options ................................................
.
5.4.1.1. Line-In ............................................................
.
5.4.1.2. CD-In..............................................................
.
5.4.1.3. TV...................................................................
.
5.4.1.4. Validated TV Tuner Cards..............................
.
5.5. Function Reference..................................................
5.5.1. System Keys ............................................................
.
5.5.2. General.....................................................................
.
5.5.3. Audio CD/MP3........................................................
.
5.5.4. VCD.........................................................................
.
67
67
67
68
68
68
68
69
69
70
70
70
70
70
70
71
71
71
72
73
74
74
74
75
75
76
76
76
78
78

Perface
vii
5.5.5. DVD.........................................................................
.
5.5.6. Region Setup............................................................
.
5.5.7. TV Tuner .................................................................
.
5.6. Specification.............................................................
5.6.1. Video..........................................................................
.
5.6.2. Audio .........................................................................
.
5.6.3. Navigational Support.................................................
.
5.6.4. DVD Support.............................................................
.
6. DRIVER AND UTILITY.................................................
.
6.1. Flash Utility...............................................................
6.2 CD Driver Overview .................................................
6.2.1. Intel Chipset 865 INF Driver...................................
.
6.2.2. Intel Chipset 865 Busmaster IDE Driver.................
.
6.2.3. 865G Family Video Driver......................................
.
6.2.4. ALC650 Audio Driver.............................................
.
6.2.5. LAN Driver..............................................................
.
6.3. Online Services................................................................
.
79
79
80
82
82
82
82
82
83
83
84
85
85
86
86
87
88

1
This section is for users to get started using the mainboard straight away.
1.1. Mainboard Layout
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
mPGA478B CPU socket (PGA478)
184-pin DIMM DDR module sockets (DIMM1~2)
IDE connector (IDE1)
IDE connector (IDE2)
Floppy drive connector (FDC)
PCI expansion connector (PCI1)
Accelerated Graphics Port Slot (AGP1)
ATX power connector (PW)
ATX 12V power connector (CN2)
Front Panel connectors (JP1)
S/P DIF Connector (SPDIF)
AUDIO connector (AUX)
AUDIO connector (CD IN)
Front Mic-IN, Line-IN Connector (JP2)
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
Front Speaker Connector (JP3)
1394 Connector (1394)
IR connector (IR)
LAN Connector (LAN CON) (Optional)
USB ports connector (USB1~3)
Serial ATA Connector (SATA)
Game Connector (Game) (Optional)
COM2 Connector (COM2)
Extend Mouse/Keyboard(J25)(Optional)
CPU FAN
SYS FAN
CMOS Jumper (JP4)
RTC Battery
Flash BIOS
1. P8F161G-e Quick Reference

Mainboard User’s Manual
I/O Ports
2
1.2. I/O Ports
1.3. Front Panel Connector
The following illustration shows the front panel connector pin
assignments:

Quick Reference
Jumper 3
1.4. Jumpers
1-2 Normal ModeJP4
(CMOS Clear) 2-3 Clear CMOS
1.5. PCI Frequency Setting
The PCI frequency settings are automatically set by the system
1.6. Memory Installation
Note: a) This mainboard supports up to two double-sided or two
single-sided DDR.
b) Supports only x8, x16 DDR devices.
c) Supports up to 6.4 GB/s (DDR400) in dual-channel
mode.
184-Pin DIMM DDR SDRAM Memory Configuration.
Each 184-pin DIMM bank can install from 128MB up to 1GB of
DDR166 / DDR333 / DDR400 compliant 2.5V single or double side
buffered with or without ECC DDR SDRAM modules.
Bank 0 (DIMM1) 128MB, 256MB, 512MB, 1GB
Bank 1 (DIMM2) 128MB, 256MB, 512MB, 1GB
Total 2 GB

Mainboard User’s Manual
Connectors
4
1.7. Connectors
JP2 Front Mic-IN, Line-IN Connector
JP3 Front Speaker connector
1-2, 4-5 : Rear side Lineout
Open : Front side Lineout
J25
(Optional) Extend Mouse / Keyboard : This 6-pin header is
used for connecting mouse or keyboard.
1394 1394 connector : Compliant with the latest IEEE
standards.
AUX Auxiliary-IN connector : This 4-pin header is an
auxiliary input connector.
CD IN CD-IN connector : This 4-pin header is used for
connecting the CD ROM audio input to the sound
card.
COM2 COM2 connector
CPU FAN CPU FAN : This 3-pin header is used for connecting
a CPU fan.
Game
(Optional) Game connector : This connector is used for
connecting a game cable.
IR Infrared (IR) connector : This 5-pin header is used
to connect an IR port for using IR devices.
LAN CON LAN connector : This LAN CON is for supporting
extra LAN port.
PW
ATX power connector : This 20-pin header is for
connecting the power supply plug to ATX power
connector to provide Pentium 4 standard power for
devices.
CN2 ATX 12V power connector : This 4-pin header is for
connecting the power supply 12V plug into ATX
power connector to provide 12V power for devices.

Quick Reference
Connectors 5
SYS FAN SYS FAN : The 3-pin header is for connecting the
case fan that keeps the system cool.
SATA SATA connector : S-ATAstands for serial
ATA .Serial ATA is newest ATA transmission
interface. Serial ATA is able to reach 150mb/sec.
SPDIF
SPDIF connector : SPDIF stands for Sony/Philips
digital interface. It’s a standard audio transfer file
format. It allows the transfer of audio from one file to
another without the conversion to and from an
analog format.
USB1~3 Front USB connector : This 10-pin header is used
connecting front panel USB port 1.2, 3, 4, 5 or 6.
1.8. Note
865G/845G Family Video Driver
865G/845G video drivers in shipping CD have a path problem. When
you finished the video driver installed, reboot the system and you
would get the message as below:
You can select the path D:\Driver\Intel\845\VGA\win98-me\graphics\win9x
or D:\Driver\Intel\865\VGA\win98-me\graphics\win9x to clean the message.
1.9. Remote Controller (Optional)
See as attached

6
2.1. Overview
The high quality P8F161G-e family is a high-performance, enhanced
function mainboard that supports mPGA478 Intel®Pentium®4
processors that support a 800 MHz front side bus (FSB). This
mainboard is designed around the latest and fastest Intel 865G chipset
in a mini FATX form factor.
The mainboard delivers workstation-level performance with bus
mastering EIDE (Enhanced IDE) controller, and concurrent PCI bus.
The mainboard accommodates DDR SDRAM (Synchronous DRAM)
memory and supports ATA 66/100.
In addition to superior hardware capabilities, provided with this
platform are these features:
➏ Supports Intel®Pentium®4 processors in a 478-pin package
Supports 400 / 533 / 800 MHz FSB
Supports Dual channel DDR266 / 333 / 400 MHz operation.
Bus mastering EIDE driver
Supports two USB 2.0 ports, six USB2.0 ports by cable
accommodating Plug and Play devices
AC97 2.2 interface
PCI 2.3 interface
Integrated LAN controller
AGP 4x / 8x
2 Serial ATA host controllers
LAN wake up
BIOS upgrade
2. Introduction

Introduction
Mainboard Specification and Feature 7
2.2. Mainboard Specifications and Features
2.2.1. Hardware
CPU -Intel® Pentium® 4 processors in a 478-pin
package, compatibleAuto-detection CPU
-Supports 400/533/800 MHz FSB
-Compatible “Hyper-Threading” technology
CPU
VRM -Onboard Voltage Regulator Module
-Provides 0.8375V to 1.6V operating voltage
(VRM10.0)
Coprocessor
Speed -CPU has built-in floating point unit
-System bus clock 100/133/200 MHz
Chipset -Intel 865G(GMCH) and 82801 EB(ICH5)
chipset
-Supports 400/533/800 MHz FSB
-Supports DDR266/333/400 MHz
DRAM -Two 184-pin DDR sockets, up to 2GB
-Supports 128MB to 2GB DDR SDRAM
memory types
EIDE
Controller -Supports four IDE devices in two channels
-Supports PIO mode 0 through mode 4 drives
-Supports Bus Mastering DMA mode 2 drives
-Supports two Bus Mastering Ultra DMA-ATA
33/66/100 drives
-Supports Iomega ZIP or LS-120 removable
drives
Sound Chip -Chip integrated direct Sound AC97 2.2
interface.
-Realtek ALC650
-S/P DIF out

Mainboard User’s Manual
Mainboard Specification and Feature
8
On-Board LAN -Intel 8100 LAN chipset, supports 10/100 Mb/s
-Fully compliant with IEEE 802.3.
Enhanced I/O -One floppy disk controller
-One Standard/EPP/ECP parallel port
connector
-Two 16550 compatible serial port connectors
-Two USB2.0 (Universal Serial Bus) ports
-One audio port connector, include line-out,
line-in, mic-in, and midi/game(optional) ports
I/O Options -Three connectors for front panel USB2.0
ports 1/2, 3/4, 5/6
-One IrDA compatible infrared (IR) connector
Mouse -PS/2 mouse connector
Keyboard -PS/2 keyboard connector
Expansion Slots -One 32-bit PCI slot
-One AGP Slot
Power
Management -Compliant with EPA, APM 1.2 and ACPI
-ATX soft-off power control
-Power on by keyboard and mouse
-Power on by external modem ring
-Power on by alarm
-Power on by LAN wake up
-Fan off in sleep mode
System
Management -CPU and system voltage detection
-CPU and secondary fan RPM detection
Voltage Regulator -Switching regulator
-CPU voltage auto-detection
Form Factor -Mini Flex ATX
Board Size 180 × 245 mm

Introduction
Mainboard Specification and Feature 9
2.2.2. Software
BIOS WHIZPRO AGP/PCI BIOS
2M-bit Flash BIOS with ESCD (Extended
System Configuration Data) block
Supports APM, Plug and Play, Multi-Boot, DMI
and EIDE devices
Supports ACPI
Supports high-capacity LS-120 and ZIP
removable media drive
Driver and
Utility IDE Bus mastering Ultra DMA driver
AC97 codec audio driver
Flash utility for BIOS upgrade
System Environment Monitoring Utility
Operating
System Operates with MS_DOS, Windows
3.x/9x/ME/XP/2000/NT, OS/2, Novell
NetWare/UnixWare, and SCO Unix

Mainboard User’s Manual
Mainboard Layout
10
2.3. Mainboard Layout
Note: Because of optional items and design changes, your
mainboard may not be identical to the one shown in the
illustration.
