Frico Sunnan SUN30 User manual

Sunnan SUN30
Original instructions
.... 2
EN .... 9 SE .... 15
NO .... 21 FR .... 28 DE
.... 35
NL .... 42 ES .... 49 PL .... 56 RU .... 63 FI
.... 69
DK

SUN30
2
EN
Installation and operating instructions
Safety instructions
• This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
• Children of less than 3 years should be kept
away unless continuously supervised.
• Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed
in its intended normal operating position
and they have been given supervision or
instruction concerning use of the appliance
in a safe way and understand the hazards
involved.
• Children aged from 3 years and less than 8
years shall not plug in, regulate and clean the
appliance or perform user maintenance.
• The unit is designed only for use with R290
(propane) gas as the designated refrigerant.
• The refrigerant loop is sealed. Only a
qualied technician should attempt to
service.
• Do not discharge the refrigerant into the
atmosphere. R290 (propane) is ammable
and heavier than air.
• The gas rst collects in low areas but can be
circulated by the fans.
• If propane gas is present or even suspected,
do not allow untrained personnel to attempt
to nd the cause.
• The propane gas used in the unit has no
odor. The lack of smell does not indicate a
lack of escaped gas.
• If a leak is detected, immediately evacuate
all persons from the premises, ventilate
the premises and contact the local re
department to advise them that a propane
leak has occurred.
• Do not let any persons back into the premises
until the qualied service technician has
arrived and that technician advises that it is
safe to return.
• No open ames, cigarettes or other possible
sources of ignition should be used inside or
in the vicinity of the units.
This unit uses a ammable refrigerant.
If refrigerant leaks and comes in
contact with re or heating part, it will
create harmful gas and there is risk
of re. Service personnel are required
to carefully read the user manual
and the safety manual "Repair and
maintenance - units with R290" at
www.frico.net.
Product instructions
The dehumidier is used to remove excessive
moisture from the air. The reduction in relative
humidity protects buildings and their contents
from the negative effects of excess humidity.
The dehumidier is portable. Protection class:
IPX4. The dehumidier is stackable, maximum
two units, for storage on the oor.
The environmentally friendly R290 is used
as the refrigerant. R290 has no damaging
inuence on the ozone layer (ODP), a negligible
greenhouse effect (GWP) and is available
worldwide.
Special precautions must be taken into
consideration due to the high ammability of
the refrigerant. The dehumidier is CE marked
and approved by Intertek according to EN
60335-1, EN 60335-2-40, EN 62233, EN 55014-1,
EN 55014-2, EN 61000-3-2 and EN 61000-3-3.
General Instructions
Read these instructions carefully
prior to installation and use. Keep this
manual for future reference.
The product may only be used as set
out in the assembly and operating
instructions. The guarantee is only valid
should the product be used in the manner
intended and in accordance with the
instructions.

SUN30
3
EN
• After transport or if the unit has been tilted
(e.g. during cleaning), leave it for an hour
before connecting it to the mains supply.
• Always keep the unit in an upright/vertical
position.
• Never use the plug to start and stop the unit.
Always use switch on the control panel.
• Before moving the unit, rst switch off, then
unplug and empty the water tank.
• Do not use ammable cleaners on the unit.
• Never pour or spray water over the unit.
• Component parts are designed for propane
and non-incentive and non-sparking.
Component parts shall only be replaced with
identical repair parts.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualied persons in order
to avoid a hazard.
• The unit shall be disconnected from its power
source during maintenance.
• Ensure the unit is far away from re,
inammable, or explosive objects.
• Do not use means to accelerate the
defrosting process or to clean, other than
those recommended by the manufacturer.
• The unit shall be stored in a room without
continuously operation sources (for example:
open ames, an operating gas appliance or
an operating electric heater).
• The unit shall be stored so as to prevent
mechanical damage from occurring. Do not
pierce or burn, even after use.
• The unit shall be protected from physical
damage and shall be installed, operated and
stored in a room with a oor area larger than
4 m2.
• Compliance with national gas regulations
shall be observed.
• Keep any required ventilation openings clear
of obstruction.
Warning
• Failure to abide by this warning could result
in an explosion, death, injury and property
damage.
• Any person who is involved with working on
or breaking into a refrigerant circuit should
hold a current valid certicate from an
industry-accredited assessment authority,
which authorizes their competence to
handle refrigerants safely in accordance
with an industry, recognized assessment
specication.
• Servicing shall only be performed
as recommended by the equipment
manufacturer. Maintenance and repair
requiring the assistance of other skilled
personnel shall be carried out under the
supervision of the person competent in the
use of ammable refrigerants. See the safety
manual "Repair and maintenance - units with
R290" at www.frico.net.
Positioning
• Ensure that the dehumidier is placed on a
level surface and that there is a minimum of
50 cm of space on either side of the unit to
allow for ecient airow.
• This dehumidier is tted with castors for
extra mobility, if you move the unit, it should
rst be switched off and the water tank
emptied.
• We do not recommend the use of an
extension lead, so please try to ensure
that the unit is suciently close to a xed
mains socket. When the dehumidier is in
operation, front doors and windows should
be closed when necessary for most ecient
use.
Important!
To ensure correct operation of the
dehumidier, do not use it at ambient
temperatures below 8°C.

SUN30
4
EN
*1) Conditions: 30°C 80% RH, 24 h.
*2) Distance to unit 3 meters.
Components
Technical specications
SUN30 R290 (IPX4)
Art.no Type Power*1
[W]
Airow
[m³/h]
Sound
level*2
[dB(A)]
Humidity
range
[% RH]
Temp.
range
[°C]
Voltage
[V]
Amperage
[A]
Weight
[kg]
247275 SUN30 660 200/280 47/51 30-100 8-32 230V~ 2,9 18,5
At 30 °C
80% RH
At 20 °C
60% RH
Water tank
capacity
30 13 6,2 l
Capacity (liters/day)
12
3
4
5
6
1. Handle
2. Control panel
3. Operating hour meter
4. Air lter
5. Water tank
6. Adapter for continous drain.
Placed in the water tank.
528 mm
327 mm 337 mm

SUN30
5
EN
Art.no Type Power*1
[W]
Airow
[m³/h]
Sound
level*2
[dB(A)]
Humidity
range
[% RH]
Temp.
range
[°C]
Voltage
[V]
Amperage
[A]
Weight
[kg]
247275 SUN30 660 200/280 47/51 30-100 8-32 230V~ 2,9 18,5
1. Timer (button, 1-24 hours)
2. Timer indicator (LED)
3. Humidity selection button
4. Humidity indicator (LED)
5. Full tank indicator (LED)
6. Low speed indicator (LED)
7. Fan speed
8. High speed indicator (LED)
9. ON/OFF (power) indicator (LED)
10.ON/OFF button
11.Display (shows current humidity)
1
2
3
4 5
6
78
9
1011
Operating hour meter
• The operating hour meter counts the
compressor operating time.
• The 5 rst digits shows the operating time in
hours.
• The operating hour meter will count-on
continuously and never reset back to "zero".
Operation - settings
Start up
Plug the unit into a 230V earthed socket.
Press the ON/OFF button to turn on the unit.
The dehumidier will start to work in CONT
mode (continuous dehumidication). If the
dehumidier is not turned off by the ON/OFF
button or has been turned off for at least 3
minutes, the start of the compressor will be
delayed for 3 minutes.
To turn off the unit, press the ON/OFF button
again.
Setting of fan speed (low/high).
Press the SPEED button to select the fan
speed, high or low. High speed increases
dehumidication.
Setting desired humidity
Press button HUM to set the humidity:
continuous dehumidication, 40%, 50%, 60% or
70%. When the current humidity is below 35%,
the display will show ‘LO’ and if the current
humidity is over 95%, it will show ‘HI’. If the fan
speed HI is selected, it will change to LO when
the compressor stops and change to HI again
when the compressor starts.
Timer function
When the Timer button is pressed, its LED (2)
lights up. Press the Timer button to set the time
of operation, between 0 and 24 hours. The time
increases by one hour with each press of the
button. The set time will ash before the display
returns to show humidity. To see the remaining
time, press the Timer button again. The timer is
activated as long as its LED (2) is lit. The unit will
be on continuous dehumidication if no time is
set.

SUN30
6
EN
Drainage
When the water tank is full, the dehumidier
will stop for self-protection and the "WATER
FULL" indicator will show a red light and the
buzzer will sound. To remove the water tank,
pull it straight out from the unit.
After empting the water tank, put it back into
position. Make sure it is properly positioned,
in order for the "WATER FULL" indicator to go
out and the dehumidier is operating. Please
note that the "WATER FULL" indicator will not
go out until the water tank has been positioned
correctly.
Continuous drainage
When the dehumidier is operated at high
temperatures and high humidity levels, the
water tank will require more frequent drainage.
In this situation, it may be more convenient to
set the unit up for continuous drainage with the
following procedure:
1. Pull out the water tank.
2. Connect the drain hole inside the unit with
the supplied "adapter for continuous drain".
3. Connect the adapter to a water hose with
an inner diameter of 12 mm (this hose is not
supplied with the unit).
4. Ensure the water will always drain away freely
and the hose remains in place.
NOTE! In cold weather conditions, precautions
should be taken to prevent the water in the
hose from freezing.

SUN30
7
EN
Cleaning
Switch off the unit and remove the plug from
the socket before cleaning.
Housing
Clean the housing with soft, dry cloth. If the unit
is extremely dirty, use a mild cleaning agent.
Wipe the unit with a slightly damp cloth. Never
spray the unit with water.
Filter
When used regularly, the lter may become
clogged with dust and particles. Therefore,
the lter should be cleaned at least every two
weeks. In dusty environments it should be
cleaned more often.
1. Remove the lter holder and take out the
lter. Clean the lter with a vacuum cleaner
or soapy water no hotter than 40°C.
2. Rinse and dry the lter completely before
putting it back in the unit.
3. Do not expose the lter to sunlight.
Storage
If the dehumidier will not be used for a long
period of time, do the following:
1. Remove the plug from the socket and empty
the tank, let the tank and the dehumidier
dry completely, this may take a couple of
days.
2. Clean the lter.
3. Check that the dehumidier is clean and in
good condition before the storage.
4. Protect the unit with a sheet of plastic.
5. Store the dehumidier in a dust-free location,
out of direct sunlight.
Storage of several dehumidifiers
NOTE! A maximum of two units can be placed
on top of each other. Make sure that the rubber
feet are placed in the hollows.
Packaging
Packaging materials are chosen with
consideration to the environment and are
therefore recyclable.
Handling of product at end of working
life
This product may contain substances necessary
for the functionality of the product but
potentially dangerous for the environment. The
product should not be disposed of mixed with
general household waste but delivered to a
designated collection point for environmental
recycling. Please contact the local authority
for further details of your nearest designated
collection point.

SUN30
8
EN
Troubleshooting
ActionCause
Symptom
Contact Frico Technical Support.
The unit's sound level
has increased. The lter is clogged or the unit is placed on an uneven surface. Clean the lter or put the unit on
a at surface.
The unit does not
work.
The power is not connected. Insert the plug into the wall
outlet and push the ON button.
The room is too big. Use several units or a
dehumidier with a greater
capacity.
The water tank is full. Empty the tank.
There is too much ventilation. Reduce ventilation, close doors
and windows.
The lter is clogged. Clean the lter.
The tank is not correctly inserted. Position the tank correctly.
Ambient temperature or humidity is
not within the recommended operating
ranges.
The air does not pass freely through the
unit. Make sure the air inlet and outlet are not obstructed.
The drain hole under the evaporator is
clogged. Clean the drain hole.
The continuous drainage is not working
correctly. Check that the hose is installed
correctly and that the water
drains away freely.
The display does not
show the set humidity. This is normal. The display shows the current humidity, not the set point. The set humidity is shown by
LEDs on the control panel.
There is water on the
oor.
The dehumidier has been moved with
its water tank lled or the water tank has
been removed carelessly.
Empty the water tank before
moving the dehumidier. Be
careful when removing the water
tank.
Recommended operating ranges
for SUN30 are 8-32°C, 30-100%
RH.
The dehumidication
capacity is too low.
The set humidity is higher than the
current humidity. Set the humidity lower than current humidity.
The water tank is broken.
If the fault cannot be rectied, please contact a qualied service technician.

Main offi ce
Frico AB Tel: [phone]
Industrivägen 41
SE-433 61 Sävedalen [email protected]
Sweden www.frico.net
For latest updated information and information
about your local contact: www.frico.net
2022-05-06 HH/CH
