Frico sirefa User manual

SIRe Advanced
Fan Heater - Water
With quick guide
SIReFA
SIReFAWM
For wiring diagram, please see last pages.
Original instructions
.... 102
IT
.... 82
ES .... 122 NL .... 142
NO
.... 182
RU
.... 162
PL
.... 22
GB
.... 2
SE .... 42 DE .... 62
FR

SIRe Advanced Fan Heater Water
22
GB
0
1
2
3
45
6
7
8
90
1
2
3
45
6
7
8
9
To run the unit
temporarily
without external
control select
mode 0.
Each unit should have
a unique ID on its
SIReB1X card.
Quick guide/start up
Check that all constituent parts are present
(see section Constituent parts).
Advice about location
PC board HUB SIReA1X is installed close to
the unit.
Control unit SIReUA1 has an integrated
room temperature sensor and is installed so
that it is easily accessible to the user. RJ12
(6p/6c) modular cables, which are available in
different lengths, are used to connect the PC
board and the control unit. Longer cables are
available as options. Maximum cable lengths
see section Options.
To prevent unauthorised people from
accessing the Control unit it can instead
be placed in another area and an external
room sensor, SIReRTX (option), can be
installed in the premises to sense the correct
temperature.
Connect the system
In control board base SIReB1(X) the unit is
connected further with RJ12 (6p/6c) modular
cable if several units are to be connected in
parallell.
If an external room temperature sensor
SIReRTX (option) is used it is connected
using modular cable RJ11 (4p/4c) on HUB
SIReA1X.
The actuator for water control and outdoor
sensor SIReOTX is connected on PC Board
HUB SIReA1X.
Transformer for voltage supply of the valve
actuator is connected with quick terminal
block on PC Board Base SIReB1(X) (230V)
and 24V and onward to the actuator.
If return water temp. sensor SIReWTA is
used, it is connected with modular cable RJ11
(4p/4c) on PC Board Base SIReB1(X).
Control board Base SIReB1(X) in/at the
unit and control unit SIReUA1 are connected
by PC board HUB SIReA1X with RJ12 (6p/6c)
modular cables, after the other units are
powered up.
For fixed installation requirements, remove
the supplied cable and plug. Perform the
installation in accordance with applicable
regulations.
Wiring diagrams
The wiring diagrams are in a separate section
at the end of this manual.
When external PC board Base SIReB1X is
used, wiring between the PC board base and
the unit must be done. Please see separate
manual for SIReB1X.
Enter ID/Operation without control unit
The control system can control one or more
units in parallel (max 9). Each unit must get
a unique ID number (1-9) which is set in the
ID selector of the PC board. E.g. Unit 1: ID=1,
unit 2: ID=3
If the external control for some reason has
not been installed the unit can still be run
temporarily. The ID selector is then set to
mode 0 see the image below.
The function is half speed and heating is on.
When the ID number must be changed the
unit must be disconnected from power.

SIRe Advanced Fan Heater Water
23
GB
Start-up wizard
Fan step 1-5
Heating step off-1
Checking system...
Set language
English
Start-up wizard
1
Start-up wizard
Set temp. unit
°C
°F
2
Start-up wizard
Set date
2011-05-28
YYYY-MM-DD
3
Start-up wizard
Set time
14:07
24h format
4
Start-up wizard
Function test
Start test
Skip test
5
Start-up wizard
Function test
Test completed
Restart test
6
Start-up wizard
Start-up finished
Proceed
Restart wizard
10
Start-up wizard
External filter guard
OFF
ON
8
Start-up wizard
Mixing cabinet on/off
OFF
ON
9
Start-up wizard
Eco / Comfort
Comfort mode
Eco mode
7
Start up
System supplied with power. At the first start
up, the start-up wizard is run and the basic
settings are made. Fan and heating steps
are tested through the test program. Then a
status window is displayed.
At the first start up alarm and error codes
can occur, these will usually be reset without
actions.
Unit with mixing cabinet
When a mixing cabinet is used the supplied
Return temp. sensor SIReWTA must be
installed. SIReWTA is a clamp-on sensor
which is installed on the return water pipe as
close to the coil as possible. The sensor must
be insulated so it is not influenced by the
ambient temperature.
In order for the Return temp. Sensor to
detect the correct temperature in the return
circuit when the valve actuator is closed, a
circulation pump must be installed in the
secondary circuit.
Damper motor PSM01 must be installed on
the throttle spindle to the mixing cabinet.
Electrical connection between the damper
motor and PC board HUB SIReA1X and
transformer ST23024 (see the wiring diagram
at the end of the manual).
Start up
Select mixing cabinet On in the start-up
wizard.
Jumper settings
Actuator SDM24 (included in the valve kit) is
adjustable, this is done with jumpers. These
are located under the hatch of the actuator.
To SDM24 to work with SIRe the setting
should be as follows:
1
2
3
4
5
6
1-4, 6:Jumper in place
5:Jumper not in place
Jumper 4 and 6 are not in use.
Start-up wizard
Screen function test

SIRe Advanced Fan Heater Water
24
GB
Contents
Wiring diagrams, see last pages
Quick guide/start up
Advice about location 22
Connect the system 22
Wiring diagrams 22
Enter ID/Operation without control unit 22
Start up 23
Unit with mixing cabinet 23
Start up 23
Jumper settings 23
Constituent parts
SIReFA (without mixing cabinet) 25
SIREFAWM (with mixing cabinet) 26
Operating modes
Operating modes (without mixing cabinet) 29
Operating modes (with mixing cabinet) 29
Control unit SIReUA1
Overview 30
Statuswindow 30
Main menu
Current settings 31
Temperature settings 31
Fan control 31
System on/off 31
Installer menu 31
Installer menu
Installer status screen 32
Week program 32
Fan settings 33
Heating settings 33
Filter guard settings 35
External filter guard 35
Mixing cabinet 35
External control (BMS) 36
General settings 37
Service menu 37
Alarm and error codes
Displaying alarm and error codes 38
Reset alarm 38
Overheat protection 38
Power failure 38
Frost protection function 38

SIRe Advanced Fan Heater Water
25
GB
X5
C2
X4
C1
X3
ROOM
PE N L
SUPPLY 230V
ACTUATOR
230V
Type Description HxWxD
[mm]
L
[m]
SIReUA1 Control unit Competent and Advanced 120x70x35
SIReB1 Integrated PC board Base
SIReIT Internal temperature sensor 1
SIReA1X PC Board HUB Advanced 202x139x50
SIReOTX Outdoor temperature sensor 70x33x23
SIReCC603 Modular cable RJ12 (6/6) 3
SIReCC605 Modular cable RJ12 (6/6) 5
Integrated in fan heater
Wall unit cover
SIReFA (without mixing cabinet)
SIReA1X,
PC board HUB Advanced
SIReB1,
integrated PC
Board Base
SIReIT, internal
temperature
sensor
SIReUA1,
control unit
Competent and
Advanced
SIReCC,
modular cable
Constituent parts
Dimensions constituent parts
SIReOTX,
outdoor temperature
sensor

SIRe Advanced Fan Heater Water
26
GB
90
0
30
60
30
60
0
90
X5
C2
X4
C1
X3
ROOM
PE N L
SUPPLY 230V
ACTUATOR
230V
Type Description HxWxD
[mm]
L
[m]
SIReUA1 Control unit Competent and Advanced 120x70x35
SIReB1 Integrated PC board Base
SIReIT Internal temperature sensor 1
SIReA1X PC Board HUB Advanced 202x139x50
SIReOTX Outdoor temperature sensor 70x33x23
SMM24 Damper motor 24V 241x116x88
SIReWTA Clamp-on sensor RJ11 (4/4) 3
SIReCC603 Modular cable RJ12(6/6) 3
SIReCC605 Modular cable RJ12 (6/6) 5
SIREFAWM (with mixing cabinet)
SIReCC,
modular cable
SIReUA1,
control unit
Competent and
Advanced
SMM24,
damper motor
SIReWTA,
clamp-on sensor
SIReA1X,
PC board HUB
Advanced
SIReB1, integrated
PC Board Base
Wall unit cover
Dimensions constituent parts
SIReIT, internal
temperature
sensor
SIReOTX,
outdoor
temperature
sensor

SIRe Advanced Fan Heater Water
27
GB
Type RSK-no. E-no. Description HxWxD L
[m]
SIReRTX 673 09 22 87 510 12 External room temperature sensor 70x33x23
SIReUR* 673 09 21 87 510 11 Kit for recessed installation 114x70x50
SIReCJ4 Joint piece for two pcs. RJ11 (4/4)
SIReCJ6 Joint piece for two pcs. RJ12 (6/6)
SIReWTA Clamp-on sensor RJ11 (4/4)
SIReCC603 673 09 23 87 510 13 Modular cable RJ12 (6/6) 3
SIReCC605 673 09 24 87 510 14 Modular cable RJ12 (6/6) 5
SIReCC610 673 09 25 87 510 15 Modular cable RJ12 (6/6) 10
SIReCC615 673 09 26 87 510 16 Modular cable RJ12 (6/6) 15
SIReCC403 673 09 27 87 510 17 Modular cable RJ11 (4/4) 3
SIReCC405 673 09 28 87 510 18 Modular cable RJ11 (4/4) 5
SIReCC410 673 09 29 87 510 19 Modular cable RJ11 (4/4) 10
SIReCC415 673 09 30 87 510 20 Modular cable RJ11 (4/4) 15
SIReCC,
modular cable
*) See separate manual.
SIReUR, kit
for recessed
installation
SIReRTX, external
room temperature
sensor
SIReWTA,
clamp-on sensor
SIReCJ4,
joint piece
Max. cable lengths
Modular cable RJ12 (6p/6c) between SIReUA1 and SIReA1X: max. 50 m.
Modular cable RJ12 (6p/6c) between SIReA1X and SIReB1(X): max. 10 m.
Modular cable RJ12 (6p/6c) between two SIReB1(X): max. 50 m.
Modular cable RJ11 (4p/4c) to room sensor SIReRTX: max. 20 m.
Cable for outdoor sensor SIReOTX (not modular): max. 50 m.
Total cable length permitted in the system is a maximum of 300 m.
Option
SIReCJ6,
joint piece

SIRe Advanced Fan Heater Water
28
GB
VMOP
VMO
SDM24
TBVCM
AV
SDM24
TBVCMP
AV
Type RSK-no. Description Connection
VMO15LF 673 09 47 Modulating DN15
VMO15NF 673 09 48 Modulating DN15
VMO20 673 09 49 Modulating DN20
VMO25 673 09 50 Modulating DN25
VMOP15LF 673 09 51 Pressure independent and modulating DN15
VMOP15NF 673 09 52 Pressure independent and modulating DN15
VMOP20 673 09 53 Pressure independent and modulating DN20
VMOP25 673 09 54 Pressure independent and modulating DN25
VMT15 Three way valve and modulating actuator DN15
VMT20 Three way valve and modulating actuator DN20
VMT25 Three way valve and modulating actuator DN25
VAT Adjustment tool for valve package
VMT
SDM24
TRVS
Water control - valve kit
Water control - option
VAT, adjustment tool for
valve package.

SIRe Advanced Fan Heater Water
29
GB
Operating modes
Operating modes (without mixing cabinet)
Control is based on the four operating modes:
•Auto
•Thermostat/Manualfan
•Thermostat/Automaticfan
•Manual
Auto
When the set point value is undercut by 0.5 K
the fan starts at speed 1 and the valve motor
starts to open stepless. If a fully open valve is
not sufficient to maintain the temperature,
the fan control increases to a max of step 4.
The difference between the setpoint value and
the room temperature for the fan to increase
one step is set under Heating step diff., see
Installer menu > Settings heating > Heating
step diff.
When Auto is active the fan speed and heating
cannot be changed in the status window.
Thermostat / Manual fan
The thermostat just controls the heating and
the fan runs continually. The fan speed is set
manually. The fan symbol is marked in the
status window, select desired speed with the
rotary dial and confirm.
Thermostat / Automatic fan
The thermostat controls both the heating and
the fan. The fan speed is set manually in the
status window. [Installer menu > Settings fan
> Fan mode.]
[Installer menu > Settings fan > Fan mode.]
Manual
The fan speed and heating is set manually in
the status window. Heating can be set to 3
steps (33%, 66% and 100%). Heating is blocked
by the outdoor temperature, see: [Installer
menu > Settings heating > Outdoor temp.
limit]
Operating modes (with mixing cabinet)
The control is based on two operating modes:
Thermostat / Manual fan
Manual
Thermostat / Manual fan
The thermostat just controls the heating and
the fan runs continually. The fan speed is set
manually. The fan symbol is marked in the
status window, select desired speed with the
rotary dial and confirm.
Day mode
In day mode or if no week program is
activated, the fan runs continuously at the
fixed fan control and the damper is open
according to the setting under Day damper
pos.. The heating is controlled via the room
temperature. If the inflow temperature drops
below the set minimum value, heat connects
even if it is sufficiently warm in the premises.
Night mode
Night time (when the week program is
activated or via external signal for night
reduction) the damper is fully closed or
open according to the setting under Night
damper pos. Heating is controlled by the
room temperature and the fan is running
continously.
Manual
The fan speed and heating is set manually in
the status window. Heating can be set to 3
steps (33%, 66% and 100%). Heating is blocked
by the outdoor temperature, see: [Installer
menu > Settings heating > Outdoor temp.
limit]
When the mixing cabinet is activated
the Return temp. sensor SIReWTA is also
activated. If this sensor is not installed an
alarm is indicated. The return temperature
sensor must be installed to reset the alarm
[Settings heating> Return water temp.

SIRe Advanced Fan Heater Water
30
GB
19
IN
-5
.0
.0
OUT °C
°C
Statuswindow (Auto mode)
-5.0
OUT °C
Statuswindow (Manual mode)
19
.0
IN °C
OFF
Rotary dial
Overview
Week program
Day
Week program
Night
Week program
Out of operation
Back arrow
Control unit SIReUA1
Forward arrow
Statuswindow
Fan speed step
Heating step
Explanations
Statuswindow
The display shows prevailing room
temperature, outdoor temperature, fan and
heating step and day, night mode, or Off when
week program is used.
This also displays whether the control is set
to auto mode or manual mode.
Forward arrow
Confirm selection and proceed.
Rotary dial
Scroll between alternatives
Back arrow
Go back.
After three minutes the control unit goes back
to displaying the status window.
Statuswindow
For thermostat/manual control of the fan and
heating the relevant symbol is marked in the
status window with the forward arrow. Steps
can then be set, confirm with the forward
arrow. For description, see section Operating
modes.
Press the forward arrow to access the main
menu.
Alarm Red led
Run signal
Green led
Meny

SIRe Advanced Fan Heater Water
31
GB
Main menu
Fan control
Current settings
Temperature settings
Main menu>Temperature
settings
Room temp. day
Room temp. night
Main menu
System on/off
Fan control
Installer menu
Main menu>Installer menu
Enter password
(See manual)
0000
Main menu
Installer menu
Fan control
System on/off
Main menu>System on/off
System on/off
•ON
Main menu
System on/off
Temperature settings
Fan control
Main menu>Fan control
High speed limit
Main menu>Fan control
High speed limit
•Step 5
Main menu
Fan control
Current settings
Temperature settings
20°C
18°C
Current settings
Room temp. day
Room temp. night
High speed limit
Week program
Step 5
No program
Main menu
Current settings
Displays set room temp, high speed limit and
week program status.
Temperature settings
Set the desired room temperatures to apply
for day respectively night mode, when the
door is closed (room temperature night is
used for week program/night reduction).
Factory setting
Room temp. day: 20°C (5 – 35°C)
Room temp. night: 18°C (0 – 20°C)
Fan control
Possibility of limiting high speed mode. In
Auto mode (see fan settings) the fan high
speed limit is set automatically to step 4 in
order to keep the sound level down. If you
wish to further restrict the fan control it can
be done here.
System on/off
Switch the whole unit off manually. In Off the
display goes out; as soon as a button is pushed
the display lights and shows System on/off. To
activate the unit again select On.
The unit’s safety functions are still active
when the system is switched off, which means
that the fan can continue to run for a moment
after mode Off has been selected.
Installer menu
The installer menu is at the bottom of the
main menu, this is password protected. See
Installer menu in this manual.
Factory setting
High speed limit: 5 (1-5)

SIRe Advanced Fan Heater Water
32
GB
FF
FF
FF
Tu e 10:45
00:00
Tu e 10:45
Main menu
System on/off
Fan control
Installer menu
Main menu>Installer menu
Enter password
(See manual)
0000
>Installer menu
Installer status screen
Week program
>Installer menu
Installer status screen
Week program
>Installer menu>Week
program
Change program
New program step
Check program
>Installer menu>Week
program
Check program
Week program on/off
New program step
Check program
Tu e Wed Thu Fri Sat SunMon
08:00
18:00
Check program
Tu e Wed Thu Fri Sat SunMon
08:00
18:00
Day (1)
Night (2)
Day (1)
Night (2)
>Installer menu>Week
program
Remove program
Check program
Change program
>Installer menu>Week
program
Change program
Check program
Remove program
Remove program
Reset all
Remove single
Remove all
New program step 7/16
Mode
Day
Tu e 10:45
Tu e Wed Thu Fri Sat SunMon
Tu e 10:45
Tu e Wed Thu Fri Sat SunMon
End
Fan settings
Fan settings
2°C
002
FH4
Tu e 10:45
00:00
Tu e 10:45
Change program
Tu e 10:45
Tu e Wed Thu Fri Sat SunMon
Tu e 10:45
Tu e Wed Thu Fri Sat SunMon
End
Tu e Wed Thu Fri Sat SunMon
1. 08:00
2. 18:00
3. 10:00
4. 16:00
Night
Day
Night
Day
>Installer status screen
Functionality mode
Eco / Comfort mode
Program
Adv.
Comfort
Installer menu
To enter the Installer menu, code 1932 is
entered. Select the digits using the rotary dial
and confirm using the forward arrow.
Installer status screen
Check the settings. The installer status screen
consists of three pages with settings, scroll
using the rotary dial.
Week program
Make settings for week program.
A basic program is pre-entered in SIRe.
Mon-Fri Day from 08:00, Night from 18:00
Sat Day from 10:00, Night from 16:00
Sun Day from 11:00:00, Night from 14:00
To check which program is set for a particular
day, select Check program and then switch
between the days using the rotary dial.
To check which days a certain program is
active, select a week day by pressing the
forward arrow, the program is marked and
those days that the program is used will be
underlined, switch between the programs for
a particular day using the rotary wheel.
To add program step, select New program
step. Confirm your selection with the forward
arrow. Select Day, Night or Off (if the unit
should not be in operation), set the time
for switch on and then for which days the
program applies, then go to End to finish.
A new program step does not replace a set
time for Day for example, but you can instead
select to change a program step.
To change a program step, select Change
program.
The program steps that should not apply
are removed in Remove program. One or all
program steps can be removed in the menu.
To return to the factory set basic program,
select Reset all.

SIRe Advanced Fan Heater Water
33
GB
>Installer menu>Week
program
Check program
Week program on/off
New program step
>Installer menu>Week
program
Week program on/off
•OFF
>Installer menu
Heating settings
Week program
Fan settings
>Installer menu>Fan settings
Fan mode
•Auto
>Installer menu>Fan settings
Fan mode
>Installer menu>Fan settings
Fan mode
•Manual
>Installer menu>Fan settings
Fan mode
Thermostat
Manual fan
>Installer menu>Fan settings
Fan mode
Thermostat
Auto fan
>Installer menu
Filter guard settings
Fan settings
Heating settings
>Installer menu>Heating
settings
Outdoor temp. limit
>Installer menu>Heating
settings
Outdoor temp. limit
Eco / Comfort
Heating step diff.
•
>Installer menu>Heating
settings
Outdoor temp. limit
Eco / Comfort
>Installer menu>Heating
settings
Eco / Comfort
•
Heating step diff.
15°C
Comfort mode
Eco mode
Stepless fan
•
>Installer menu>Fan settings
Fan mode
Stepless fan OFF
>Installer menu>Fan settings
Week program is activated by selecting On,
under Week program on/off. In On-mode,
a sun, moon or Off in the Status window
appears to indicate day, night respectively
Off-function.
Fan settings
Make settings for fan mode (see also
Operating modes section).
Factory setting
Fan mode: Auto (Thermostat / Manual fan,
Thermostat / Automatic fan, Manual)
Outdoor temp. limit
Blocking heating summer time.
Factory setting
Outdoor temp. limit: 15°C (5 – 30°C)
Eco / Comfort (without mixing cabinet)
Select Comfort to prioritise temperature and
ventilation comfort.
Select Eco to prioritise low energy
consumption by maximize the outlet
temperature to +32°C
Stepless fan control
Settings for stepless fan control.
Fan control can be controlled in 5 steps or
steplessly through external steering from
BMS (0-10V). During stepless control, 0-10V
output (terminal block 1-2 on SIReA1X) is
used, connected to external speed control
(not included). Stepless control is not possible
when a mixing cabinet is used.
Factory setting
Stepless fan control: Off (On)
Heating settings
Make settings for heating.

SIRe Advanced Fan Heater Water
34
GB
>Installer menu>Heating
settings
Control range limit
Heating step diff.
Sensor calibration >Installer menu>Heating
settings>Sensor calibration
Room temp. sensor
>Installer menu>Heating
settings>Sensor calibration
Room temp. sensor
Outdoor temp. sensor
•0.0 K
>Installer menu>Heating
settings
Stepless heat control
•ON
>Installer menu>Heating
settings
Control range limit
Return water temp.
Stepless heat control
Installer menu>Heating
settings>Return water temp.
Return temp. sensor
Not connected
Installer menu>Heating
settings>Return water temp.
Return temp. sensor
Return temp. limit •
Stepless heat control
Sensor calibration
Return water temp.
>Installer menu>Heating
settings
Connected
Installer menu>Heating
settings>Return water temp.
Return temp. limit
•OFF
Installer menu>Heating
settings>Return water temp.
Return temp. sensor
Return temp. limit
>Installer menu>Heating
settings
Heating step limit
•
>Installer menu>Heating
settings
Sensor calibration
Eco / Comfort
Heating step limit 1.0 K
Control with mixing cabinet, with falling outlet
temp
Comfort:
1. Opens the valve gradually to fully open
valve.
2. Gradually closes damper to night mode
3. Slows down the fan.
Eco:
1. Gradually closes damper to night mode
2. Opens the valve gradually to full heating.
3. Slows down the fan.
Max. outlet temp. limit +32°C.
Heating step diff.
When the temperature falls below the set
point value the fan speed increases (the high
speed limit is position 4). Which temperature
difference the speed is to be increased by a
step for is selected in Heating step diff.
Factory setting
Heating step diff.: 1.0 K (-10 K – 10 K)
Sensor calibration
If the sensor displays the wrong values these
can be calibrated. Some display errors may
occur, but this is primarily due to the location
(cold/hot surfaces etc). The value + or – adds
to or subtracts from the measured value
(for example +2K gives an increase of the
displayed value of 2 degrees).
Return water temp.
If there is a demand for the temperature
of the return water not to exceed a certain
value, this function is activated under Return
water temp. A return water temperature
sensor (proximity sensor SIReWTA, option)
must then be installed on the return water
pipe.
Install Return temp. Sensor to Connected
and select max return temperature (15-90 °C)
using the turn wheel. During operation, this
function limits the valve’s degree of opening,
which reduces the flow and the return
temperature.
Factory setting
Return temp. sensor: Not connected
(Connected)
Return temp. limit: Off (15 – 90°C)
Stepless heat control
To use Advanced fully, stepless heat control
must be used.
Factory setting
Stepless heat control: ON (Off - not
selectable)
Factory setting
Room temperature sensor: 0.0 K (-10 K – 10
K)

SIRe Advanced Fan Heater Water
35
GB
>Installer menu
External control
Heating settings
Filter guard settings
>Installer menu>Filter guard
settings
External filter guard
Filter timer on/off
Filter timer setting
>Installer menu>Filter guard
settings
Filter timer setting
•1500 h
>Installer menu>Filter guard
settings
External filter guard
Filter timer on/off
Filter timer setting
>Installer menu>Heating
settings
Control range limit
•35°C
>Installer menu>Heating
settings
Stepless heat control
Return water temp.
Control range limit
Last filter change
Filter timer setting
External filter guard
>Installer menu
>Installer menu>Filter guard
settings
External filter guard
Filter timer setting
Last filter change
>Installer menu>Filter guard
settings
Last filter change
0 h
>Installer menu>Mixing
cabinet
Day damper pos.
Mixing cabinet on/off
Min outlet temp.
>Installer menu>Mixing
cabinet
Min outlet temp.
•15°C
External control
Filter guard settings
Mixing cabinet
>Installer menu>Mixing
cabinet
Mixing cabinet on/off
>Installer menu
Filter timer on/off
Filter alarm is activated by selecting On,
under Filter timer on/off.
Factory setting
Filter timer on/off: Off (On)
External filter guard
If an external filter guard, e.g. a pressure
switch, is used, it is activated under External
filter guard, select On.
Factory setting
External filter guard: Off (On)
Last filter change
To check the number of run time hours since
the last filter replacement, select Last filter
change. The time is reset when the filter
alarm is reset. If the time is to be reset before
the alarm has gone, switch the filter timer on
and off.
Mixing cabinet
When the mixing part is used, it is activated
under Mixing cabinet settings.
Factory setting
Mixing cabinet on/off: Off (On)
When the mixing cabinet is activated, more
options are available in the menu under
Mixing cabinet settings.
Min outlet temp.
The outlet temperature must be limited under
Min. outlet temp.
Factory setting
Min outlet temp.: 15°C (5 – 30°C)
Control range limit
The maximum room temperature that a user
can select is limited to between 5 – 35°C.
Factory setting
Control range limit temperature: 35°C (5 –
35°C)
Filter guard settings
Filter alarm alarms when the set fixed run
time has been exceeded.
Filter timer setting
Under Filter timer setting, set the desired run
time to between 50 and 9950 hours.
Factory setting
Filter timer setting: 1500 h (50 - 9950 h)

SIRe Advanced Fan Heater Water
36
GB
General settings
External control
>Installer menu>External
control
External on/off
0-10V fan control
>Installer menu>External
control
External on/off
0-10V heat control
>Installer menu
0-10V fan control
>Installer menu>External
control
External on/off
0-10V fan control
0-10V heat control
0-10V heat control
Mixing cabinet
Night damper pos.
•
Day damper pos.
Min outlet temp.
Night damper pos.
>Installer menu>Mixing
cabinet
>Installer menu>Mixing
cabinet
Day damper pos.
100 %
>Installer menu>Mixing
cabinet
>Installer menu>Mixing
cabinet
Night damper pos.
Min outlet temp.
Day damper pos.
0 %
Day damper pos.
Desired current damper position daytime.
Factory setting
Day damper pos.: 100% (0 – 100%)
Night damper pos.
Desired current damper position nighttime.
Factory setting
Night damper pos.: 0% (0 – 100%)
External control (BMS)
BMS functions can be activated under
External control.
Activate External on/off (5-30V AC/DC from
BMS) or 0-10V fan control by selecting On
under the respective one. See diagram on
next page and Connecting external control.

SIRe Advanced Fan Heater Water
37
GB
2,8
3,2
4,2
4,6
5,6
6,0
7, 0
7, 4
8,4
8,8
7,2
7,6
5,0
5,4
2,8
3,2
10987654321
4
3
2
1
3
2
1
5
11
1098765432111 [V]
[V]
>Installer menu>General
settings
Set language
Set date
Set time
>Installer menu
Support menu
External control
General settings
>Installer menu>General
settings
Function test
User reset
>Installer menu>User reset
Execute user reset?
No
Ye s
>Installer menu>General
settings
Function test
Start test
Skip test
>Installer menu>General
settings
Function test
Test completed
Restart test
>Installer menu>General
settings
Heating step off-1
Fan step 1-5
General settings
Possibility of making general settings that are
also in the Start-up wizard and execute user
reset.
Change the date, time, language and
temperature unit.
User reset
User reset (Room temp. day resp. night, high
speed limit) to factory setting.
Function test
To test the fan and heating steps, run the
function test.
Service menu
The service menu is password protected and
is used for support in contact with Frico or
authorised installer.
Diagram: Fan step at incoming 0-10V DC voltage level, 5 step

SIRe Advanced Fan Heater Water
38
GB
Alarm and error codes
SIRe has different alarms and error codes for
safe and problem free operation.
If alarms or error codes have been indicated
these must be reset in order to return to
normal operation, for example activating the
heating again. Fan mode is active even when,
for example, the over heating alarm has been
indicated.
Displaying alarm and error codes
In event of alarm or error the alarm/error
code is shown in the status window. In event
of alarm/error code the unit it applies to is
displayed.
See Table - Alarms and Table – Error codes.
Reset alarm
Note! Before resetting, check that the fault is
rectified and there is nothing to prevent the
unit from being recommissioned!
When the fault is rectified, the alarm is
reset by pressing the forward arrow and
selecting Reset alarm and then confirm.
If several units give an alarm at the same
time, the fact that there are several alarms
is indicated, but only one is shown in the
display. By resetting that alarm the next
alarm can be read.
At the first start up alarm and error codes
can occur, these can usually be reset without
action.
Overheat protection
The overheat protection is designed to limit
the temperature of the heater to a maximum
of +90° C. If the temperature should exceed
95°C e.g. in the event of a faulty valve or
actuator, the fan starts to speed up to keep
the temperature down.
At the same time there is an overheating
alarm A2. At internal temperatures of +100°C
the fan runs at maximum speed.
If the unit cools, heating is automatically
reengaged. The alarm remains in the control
unit’s display. If the unit overheats twice
within an hour, the fan operates until the
alarm is reset.
Power failure
Note that in case of power failure the time
settings need to be checked, if the time is not
set correctly week program will be affected.
Frost protection function
The frost protection function is intended to
prevent the water coil from freezing.
When the fan is in operation the valve
actuator opens the valve at an internal
temperature below +15°C regardless of
whether there is a heating requirement. If the
internal unit temperature continues to drop,
e.g. at low ambient temperatures, insufficient
flow line temperatures, low flow or fault valve
function, the frost protection alarm A3 will be
triggered when the internal unit temperature
drops +5°C. The fan then also stops and when
the mixing cabinet is used the dampers is also
closed.
With return temp. sensor SIReWTA
connected an advanced alarm function
occurs. At return temperatures less than
+15°C the actuator will open regardless of
the heat demand. Alarm is triggered at return
temperature +7°C and the fan also stops.
When the fan is not running there is a heat
retention function that opens the valve when
the water’s return temperature falls below
+25°C regardless of heat demand.
Note! In event of repeated alarms,
overheating alarms and frost protection
alarms, carry out a thorough check and if
the fault cause cannot be found contact
authorised installer or Frico.

SIRe Advanced Fan Heater Water
39
GB
Table - Alarm
Alarm Cause Action
A1 Motor
alarm
Thermal switch has deployed.
One or several motors have
overheated. (Only units with
withdrawn thermal switches.)
Check that nothing is obstructing the
unit’s air intake and exhaust. When the
overheated motor has cooled the thermal
switch shuts again and the alarm can
be reset. At repeated alarms, check the
motors, replace damaged motors.
A2 Over heating
alarm
The temperature in the unit
has exceeded the alarm limit
for overheating.
Check that nothing is obstructing the unit’s
air intake and exhaust, the function of the
actuator and valve, flow temperature and
internal temperature sensor.
A3 Frost protection
alarm
The temperature in the unit has
fallen below the alarm limit for frost
protection. (Only applies to units with
internal unit temperature.)
Make sure that the ambient temperature
where the unit is installed exceeds +5°C.
Check the flow temperature, the flow of
hot water and the function of the actuator
and valve. In event of an alarm there a
risk that the battery is damaged, check
carefully for leakage and replace the
battery if damaged.
A4 Filter alarm Fixed run time before the filter alarm
has been reached.
or the external filter alarm has been
activated.
Replace or clean the filter, adjust any
alarm time based on how dirty the filter
was and reset the alarm.
A5 Ext. alarm External alarm input on SIReA1X has
been activated.
Check the external alarm.

SIRe Advanced Fan Heater Water
40
GB
Table - Error codes
Error code Cause Action
E1 SIReB1(X) has no contact
with SIReA1X.
Check connection between the
boards. Replace any modular
cables.
Communication
E2 ID Error Two or more SIReB1(X) have
the same ID-number.
Interrupt the current and select
different ID numbers for all
SIReB1(X) in the system.
E3
ID Error One or more SIReB1(X) do not
have programs.
Contact Frico for support.
E4 Room sensor
error
Fault on or missing external room
sensor SIReRTX connected to
SIReB1(X).
Always disconnect the power
when connecting or disconnecting
sensors. Check connection of the
sensor.
E6 Sensor alarm Return
water temp.
Fault on or missing return
water temp. sensor SIReWTA
connected to SIReB1(X).
Always disconnect the power when
connecting or disconnecting sensors.
Check connection of the sensor. If
the sensor is not used, it must not be
activated (see the Settings heating
section)
E8
Internal sensor faults Fault on or missing internal
sensor in the unit.
Check connection of the sensor. If
there is no sensor, contact Frico
for support.
E10 ID Error Two or more SIReB1(X) in
the system have different
programs.
Contact Frico for support.
E12 Room sensor error Fault on or missing external
room sensor SIReRTX
connected to SIReA1X.
Always disconnect the
power when connecting or
disconnecting sensors. Check
connection of the sensor.
E14
Outdoor sensor fault Fault on or missing outdoor
temperature sensor SIReOTX
connected to SIReA1X.
Always disconnect the power when
connecting or disconnecting sensors.
Check connection of the sensor.
E20 Communication Control unit SIReUA1 has no
contact with SIReA1X.
Check the connection. Replace any
modular cables.
E21 Room sensor error Error in the internal room
sensor in the control unit
SIReUA1.
Check connection between SIReUA1 and
SIReA1X. Replace any modular cables. If
the error is not rectified SIReUA1 must
be replaced.
E23
Soft ware error Contact Frico for support.
