Friedman Power Grid 10 User manual
FA_ Power Grid 10 Manual_9-19-16_R15.indd 1 9/19/16 3:10 PM
1 2
INSTRUCTIONS
Please keep this instruction manual for future reference and for the duration of owning this Friedman power supply. Please
carefully read and understand the instructions inside this user’s manual before attempting to operate your new power supply.
This instruction manual includes essential safety information regarding the use and maintenance of the power supply. Take
special care to heed all warning symbols and signs inside this manual and those printed on the Power Supply itself.
WARNING: Using this power supply contrary to the guidelines of this manual may damage your pedals. Friedman
Amplification is in no way responsible for damage of your pedals resulting in improper use of this power supply.
INPUT POWER CABLE: Insert the included universal IEC plug into the socket on the back of the Power Grid 10. Plug the
other end into a wall outlet or power strip.
CABLES INCLUDED:
• 2 x 2.1mm BLACK connector to 2.5mm BLUE connector polarity reversed - 20" long right angle connector on both sides.
• 10 x 2.1mm BLACK connector to 2.1mm BLACK connector regular polarity - 20" long right angle connector on both sides.
• 1 x 2.1mm BLACK connector to 1/8" phono BLACK connector 20" long right angle connector on 2.1mm connector.
• 1 x 2.1mm sleeve to 1/8" tip and 2.1mm center to 1/8" sleeve - 20" long.
• 1 x 18V cable 2.1mm BLACK connector with additional 2.1mm slave connector on one side to 2.1mm BLACK connector
regular polarity - 20" long right angle connector on both sides.
IMPORTANT: You must know the power requirements of your pedals and match them to the capabilities of the Power Grid
Power Supply. Mismatching your pedal’s requirements and the Power Grid's performance is the difference between your
pedal working correctly and potentially damaging it.
OUTPUTS: The Power Grid 10 provides 10 isolated outputs delivering a maximum 350mA per output at 9Vdc tip negative.
Guidelines: If you plug a pedal that requires more current than what the Power Grid output provides, your pedal will simply not
work correctly. We simply recommend not doing it!
KNOWING YOUR PEDALS POWER REQUIREMENTS:
You should know what pedal you are plugging into the Power Grid 10. Inspect your pedal, refer to the instruction manual of your
pedal, check online or contact the manufacturer - one way or another you should know what you plugging into this power supply.
9VDC 350mA
Congratulations on your purchase of the Friedman Power Grid 10
While Dave Friedman is world renowned for the great sound and functionality of his products, the Power
Grid’s claim to fame is its light weight, universal voltage and most importantly, the Power Grid 10 is dead
silent. After building pedal boards and rack systems for the who’s who in the industry for 25 years, Dave
knows the importance of a dead silent, hum free rig.
The Friedman Power Grid 10 is a universal input voltage pedal power supply. Meaning, you can plug it in
anywhere in the world without having to ip voltage switches or worrying about having to use a step up or
step down transformer. The Power Grid 10 utilizes an advanced switch mode power supply, which eliminates
the need to use large toroidal transformers. The result is no proximity hum will inltrate your pedals. This
allows your pedal board to be ultra quiet onstage or in the studio.
Additionally, the Power Grids switch mode power supply technology allows it to be much lighter in weight
than most if not all of the current power supplies on the market. And, when your lugging around your rig all
over the world, the lighter the better. The Power Grid 10 transforms the wall voltage from 100-240vac and
converts it to the stated voltages on the front panel of the Power Grid 10.
FA_ Power Grid 10 Manual_9-19-16_R15.indd 2-3 9/19/16 3:10 PM
34
Important:
• If your pedal's power requirement is 9Vdc (center negative) and does not draw more than 350mA, you can plug into any output.
• If your pedal's power requirement is 9Vdc (center positive) and does not draw more than 350mA you can plug into any
outputs - BUT, you must use the supplied black and blue cable supplied (which reverses the polarity)!
• If your pedal's power requirement is 18Vdc and does not draw more than 350mA, you will need to use two of the
9Vdc outputs and use the included 18V cable.
WARNING: DO NOT DISSAMBLE the power supply there are no serviceable parts inside.
WARNING!
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE POWER SUPPLY TO WATER OR MOISTURE.
DO NOT OPERATE NEAR ANY WATER SOURCE
WHAT’S THE MEANING OF THIS?
The lightning flash with an arrow triangular symbol is intended to alert the user to the presence of non‐insulated “dangerous
voltage” within the products enclosure, and may be of sufficient magnitude to constitute a risk of electric shock
WHAT’S THE MEANING OF THIS?
The exclamation point triangular symbol is intended to alert the user to the presence of important operating and maintenance
(servicing) instructions in the user manual accompanying this amplifier!
1. Read Instructions – All the safety and operating instructions should be read before this product is operated.
2. Retain Instructions – The safety and operating instructions should be retained for future reference.
3. Heed Warnings – All warnings on the Power Supply and in the operating instructions should be adhered to.
4. Follow Instructions – All operating and use instructions should be followed.
5. Water and Moisture – The Power Supply should not be used near water - for example, a bathtub, washbowl, kitchen sink,
laundry tub, wet basement, or near a swimming pool, and the like.
6. Wall or Ceiling Mounting – The product should never be mounted to a wall or ceiling.
7. Heat – Power Supply should be situated away from heat sources such as radiators, heat registers, stoves, or other Power
Supply (including amplifiers) that produce heat.
8. Power Sources – This product should be operated only from the type of power source indicated on the rating label. If you
are not sure of the type of power supply to your home, consult your product dealer or local power company.
9. Grounding or Polarization – This product may be equipped with a polarized alternation‐current line plug (a plug having one
blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
10. Power‐Cord Protection – Power‐supply cords should be routed so that they are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention to the cord in correspondence of plugs, convenience
receptacles, and the point where they exit from the power supply.
11. Cleaning – The Power Supply should be cleaned only as recommended by the manufacturer. Clean by wiping with a dry
only. Avoid getting water inside the power supply.
12. Non‐use Periods – The power cord of the Power Supply should be unplugged from the outlet when left unused
for a long period of time.
13. Object and Liquid Entry – Care should be taken so that objects do not fall and liquids are not spilled into the
enclosure through openings.
14. Damage Requiring Service – The Power Supply should be serviced by qualified service personnel when
FA_ Power Grid 10 Manual_9-19-16_R15.indd 4-5 9/19/16 3:10 PM
65
A. The power‐supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the power supply; or
C. The Power Supply has been exposed to rain; or
D. The Power Supply does not appear to operate normally or exhibits a marked change in performance; or
E. The Power Supply has been dropped, or the enclosure damaged.
15. Servicing – The user should not attempt any service to the Power Supply beyond that described in the operating instructions.
All other servicing should be referred to qualified service personnel.
16. Ventilation – Slots and openings in the power supply are provided for ventilation and to ensure reliable operation of the
product and to protect it from overheating, and these openings must not be blocked or covered. The openings should
never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed
in a built‐ in installation such as a bookcase or rack.
17. Attachments – do not use attachments not recommended by the product manufacturer as they may cause hazards.
18. Lightning – For added protection for this product before a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the product due to
lightning and powerline surges.
19. Replacement Parts – When replacement parts are required, be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result
in fire, electric shock, or other hazards.
20. Safety Check – Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks to determine that the product is in proper operating condition.
Limited Warranty
FRIEDMAN offers a three (3) year warranty to the original purchaser that this
FRIEDMAN product will be free from defects in material and workmanship. A
dated sales receipt will establish coverage under this warranty. This warranty
does not cover service or parts to repair damage caused by accident,
neglect, normal wear, disaster, misuse, abuse, negligence, inadequate
packing or shipping procedures and service, repair or modifications to the
product which have not been authorized or approved by FRIEDMAN. If this
product is defective in materials or workmanship as warranted above, your
sole remedy shall be repair or replacement as provided below.
RETURN PROCEDURES
In the unlikely event that a defect should occur, follow the procedure
outlined below. Defective products must be shipped, together with a
dated sales receipt, freight pre-paid and insured directly to FRIEDMAN. A
Return Authorization Number must be obtained from our Customer
Service Department prior to shipping the product. Products must be
shipped in their original packaging or its equivalent; in any case, the risk
of loss or damage in transit is to be borne by the purchaser. The Return
Authorization Number must appear in large print directly below the
shipping address. Always include a brief description of the defect, along
with your correct return address and telephone number.
When emailing to inquire about a returned product, always refer to the
Return Authorization Number. If FRIEDMAN determines that the unit was
defective in materials or workmanship at any time during the warranty
period, FRIEDMAN has the option of repairing or replacing the product at
no additional charge, except as set forth below. All replaced parts
become a property of FRIEDMAN. Products replaced or repaired under
this warranty will be returned via ground shipping within the United
States-freight prepaid. FRIEDMAN is not responsible for costs associated
with expedited shipping, either to FRIEDMAN or the return of the product
to the customer.
INCIDENTAL OR CONSEQUENTIAL DAMAGE In no event is
FRIEDMAN liable for any incidental or consequential damages arising out of
the use or inability to use of any FRIEDMAN product, even if FRIEDMAN or a
FRIEDMAN dealer has been advised of the possibility of such damages, or
any other claim by any other party. Some states do not allow the exclusion or
limitation of consequential damages, so the above limitation and exclusion
may not apply to you. This warranty gives you specific legal rights and you
may also have other rights which may vary from state to state.
FOR YOUR PROTECTION
Please complete the online warranty registration within (10) ten days of
the date of purchase so that we may contact you directly in the event a
safety notification issued in accordance with the 1972 Consumer
Product Safety Act.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
CUSTOMER SUPPORT
Our dedicated staff is ready to help you with any warranty or product
FA_ Power Grid 10 Manual_9-19-16_R15.indd 6-7 9/19/16 3:10 PM
