Robomower®Service Guide
 Read carefully and thoroughly all relevant sections before servicing Robomower.
 It is very important to read and follow all warning and safety instructions in this
manual and in the Robomower Operating Manual.
 All maintenance procedures and troubleshooting must be carried out exactly as
given in this manual.
All rights reserved. No part of this book may be reproduced or used in any form
or by any means – graphic, electronic or mechanical, including photocopying,
recording, taping or by any electronic information storage and retrieval systems
without a prior written consent of F. Robotics Acquisitions Ltd.
This book was carefully prepared. However, F. Robotics Acquisitions Ltd. will
not bear any responsibility for any errors, mistakes or misunderstandings. F. Robotics
Acquisitions Ltd. shall not bear responsibility for any damage resulting from faulty
instructions in this manual.
F. Robotics Acquisitions Ltd. reserves the right to introduce changes in the
product and/or to this manual without any prior notice.
© 2006. All rights reserved to F. Robotics Acquisitions Ltd.
I

Table of contents
Introduction
Chapter 1- Robomower Layout & IPL’s (Illustrated Parts List)
Chapter 2 - Menu Items
Chapter 3 - Troubleshooting
Chapter 4 - Repair and Maintenance Procedures
Chapter 5 - Diagnostics
Chapter 6 – General Procedures
Chapter 7 - Service Bulletins
II

Introduction
The purpose of this Service Guide is to allow trained and certified technicians to
efficiently inspect, diagnose and repair the Robomower. If you have not completed
training, please contact your manager or supervisor to arrange training completion.
The Service Guide is divided into various sections to allow access to information in an
easy to use format. The sections in the beginning show the layout, wiring, parts and
construction of the Robomower. Mid sections show diagnostic techniques and the last
sections show repair and warranty procedures.
IMPORTANT: it is the policy of F. Robotics Acquisitions Ltd. that all agents, either
directly appointed or appointed by a distributor, should always show a duty of care to
customers. In most countries this is a legal requirement and. F. Robotics Acquisitions
Ltd. policy is to always meet these standards and to surpass them wherever possible.
All units inspected by a technician MUST, as a minimum standard, pass the General
Test prior to return to the customer.
Units which were actually repaired or had a certain part replaced, must go through
specific testing, of that system, in line with the procedures set out in this Service Guide.
The last part of each procedure has the appropriate test for that system.
In addition to testing a specific system or part, a General Test should always be
undertaken to ensure no hidden problems are missed and, most importantly, to ensure that
all safety systems are functioning.
If any doubt exists about diagnosis, repair, testing or any other technical aspect of the
Robomower, always be sure to seek further advice from a qualified source.
Finally, if you have any suggestions for improvement of this guide, either in content,
layout or additional material, please contact F. Robotics Acquisitions Ltd. through the
correct channels and this will be considered for future updates.
III

1. Robomow Layout & Spare Parts
This first section is dedicated to the layout of the Robomow, how it is
constructed, part numbers and identification of parts.
Important: Be sure to review section 1.1 (Orientation). It explains what is referred
to as “right”, “left” etc. Failure to understand this can result in a mistake or problem in
the analysis or repair of the product.
Table of Contents
1.1 Robomow layout and main components………………2
1.2 IPL’s (Illustrated Parts List) ……………………….….6
1.3 Fuse location…….…………………………….………..19
1.4 Board identification ……………………………………20
1.5 Wiring Layout…….…………………………………….22
1.6 Parts List…….…………………………..………………24
1.7 Parts Compatibility Table…….…………..……………30
1
1

1.1 Robomow layout and main components
1.1.1 Robomow top view
89
10
2
Charging contacts
(for Charging
Station
)
SPP0026A
Knobby drive wheel
MSB0099A
Smooth drive wheel
MSB0078A
Manual Controllers
MSB0112A (tones)
MSB0114A (speech)
MSB0118A (ESBC050B+)
MSB0119A (Enhanced)
Manual Controlle
r
holder assembly
MSB0105B
Operation lamp
cover
S
PP
003
2A
Front Bumper
MSB0106B
RL Model Stickers
RL350 – STC0057A
RL800 – STC0051A
RL550 – STC0048A
RL850 – STC0049A
RL1000 – STC0056A
1
RL Yellow Cover GEN0094A
RL Green Cover GEN0227A
Left
Side Right
side
7
2
6
54
3
Power Pack
UNT0009A
Rear
Rear Bumper
MSB0107A
Figure 1.1.1 Top view
1

1.1.2 Robomow bottom view
Note: Mower sides are determined by its top view
16
Snap lock (curved)
GEN0163A
(
x4
)
Snap lock (straight)
GEN0162A
(
x6
)
11
Front Wheel
SPP0011A
Front Bumper
MSB0106B
12
Mowing Motor
MSB0065B
(
x3
)
15
High cut blades
MRK0002A
Low cut blades
MRK0003A
14
5
Rear Bumper
MSB0107B
3
Knobby drive wheel
MSB0099A
13
10
RL plastic base
GEN0095A
Figure 1.1.2 Bottom view
1
3

1.1.3 Robomow internal views
4
Front right
Wire sensor
SPP0018A
Right Mowing
Motor
MSB0065B
Front left
Wire sensor
SPP0018A
Drive Motor
SPP0008B
Thermistor Kit
SPP0020A
Rear right
Wire sensor
SPP0018A
Rear left
Wire sensor
SPP0018A
Cover-base seal ring
GEN0182A
Ground
clearance limiter
GEN0202A
Main Board
SPP0019B
Drop-off Board
SPP0005B
Battery contacts
(RL side)
SPP0014A
Front wheel stopper
GEN0207A
& Spring GEN0208A
Odometer board R
ESBC024C
Center
Mowing Motor
MSB0065B
Odometer board L
ESBC025C
17
21
22
27 &28 17
82
12
12
Left Mowing
Motor
MSB0065B
12
23
24
25
18
19
20
17
17
Figure 1.1.3 Internal view
1

1.1.4 Charging Station views
5
30
Charging
Station Base
SPP0029A
Charging Station
contacts assembly
SPP0031A
32
Charging
Station Cover
SPP0030A 29
Charging
Station Drive
Wheel support
123
122
Charging
Station Fence
GEN0215B 31
Figure 1.1.4 Charging Station view
1

1.2 IPL’s / Exploded views
1.2.1 Robomow – bottom view……………………..…7
1.2.2 Base – top view.…………………………………8
1.2.3 Cover – top view…….……………………….….9
1.2.4 Charging Station…….……………………..…..10
1.2.5 Gear Case ……………………………………...11
1.2.6 Power Pack & Power Supply………………….12
1.2.7 Fuses.....................................................................13
1.2.8 Perimeter Switch…….…………………………14
1.2.9 Bumpers………………………………………...14
1.2.10 Front Wheel…….……………………………..15
1.2.11 Thermistors…….……………………………...16
1.2.12 Add-on Items…….…………………………….16
1.2.13 Decals…….…………………………………….17
1.2.14 Old configuration spare parts………………..18
1
6

1
1.2.1 Robomow bottom view
7
DETAIL A
34
35
36
12
16
14
SEE DETAIL A
39
37
38
3
34 DETAIL A
15
7
