USE & CARE MANUAL
THIS AIR CONDITIONER IS EQUIPPED WITH A NEW INDUSTRY
STANDARD POWER SUPPLY CORD WITH ATEST-RESET FUNCTION
READ AND SAVE THESE INSTRUCTIONS
AIR CONDITIONER
P/N 819042151-01
77
99

2
ROOM AIR CONDITIONER WARRANTY
Your product is protected by this warranty
Frigidaire
P.O. Box 212378
Augusta, GA30917
800-444-4944
*NORMAL
RESPONSIBILITIES
OF THE CONSUMER
EXCLUSIONS
IF YOU NEED SERVICE
FULL ONE-YEAR
WARRANTY
LIMITED 2-5 YEAR
WARRANTY (Sealed
LIMITED WARRANTY
(Applicable to the
WARRANTY THE CONSUMER WILLBE
RESPONSIBLE FOR:
Costs of servicecalls that arelisted under
NORMAL RESPONSIBILITIES OF THE
CONSUMER.*
Diagnostic costs and any removal,
transportation and reinstallation costs
which are requiredbecause of service.
Costs for labor, parts andtransportation
other than with respect to the Sealed
Refrigeration System.
Costs of the technician’s travel to the
home and any costs for pick up and
delivery of the appliance required
because of service.
One year fromoriginal
purchase date.
Second through fifth
years from original
Time periods listed
above.
Pay all costs for repairing or replacing
parts of thisappliance which proveto be
defective in materials or workmanship.
Repair or replaceany parts inthe Sealed
Refrigeration System (compressor,
condenser,evaporator and tubing)
proves to be defective in materials or
All of theprovisions of thefull and limited
warranties above and the exclusions
listed below apply.
FRIGIDAIRE, THROUGH ITS
AUTHORIZED SERVICERS, WILL
This warranty applies only to products in ordinary household use, and the consumer is
responsible for theitems listed below.
1. Proper useof the appliancein accordance withinstructions provided withthe product.
2. Proper installation by an authorized servicer in accordance with instructions provided with the
appliance and inaccordance with alllocal plumbing, electricaland/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blownfuses,
repair of loose connections or defects in house wiring.
4. Expenses for making the appliance accessible for servicing, such as removalof trim, cupboards,
shelves, etc., whichare not apart of theappliance when itwas shipped fromthe factory.
5. Damages tofinish after installation.
This warranty doesnot cover thefollowing:
1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL
EXPENSES RESULTING FROMANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
Note: Some statesdo not allowthe exclusion orlimitation of incidentalor consequential damages,so
this limitation orexclusion may notapply to you.
2. Service callswhich do notinvolve malfunction ordefects in workmanshipor material, orfor appliances
not in ordinaryhousehold use. The consumer shallpay for suchservice calls.
3. Damages causedby services performedby persons other than authorized Frigidaire servicers; use
of parts other than Frigidaire Genuine Renewal Parts; obtained from persons other than such
servicers; or externalcauses such asabuse, misuse, inadequatepower supply oracts of God.
4. Products with original serial numbers that have been removed or altered and cannot be readily
determined.
Keep your bill of sale, delivery slip, or some other appropriate paymentrecord. The date on thebill
establishes the warranty period should service be required. If service is performed, it is in your best
interest to obtain and keep all receipts. This written warranty gives you specific legal rights. You may
also have other rights that vary from state to state. Service under this warranty must be obtained by
following these steps,in order:
1. Contact FrigidaireConsumer Services oran authorized Frigidaireservicer.
2. If thereis a questionas to whereto obtain service,contact our ConsumerRelations Department at::
Product features orspecifications as describedor illustrated aresubject to changewithout notice.All warranties aremade by Electrolux.
This warranty appliesonly in the50 states ofthe U.S.A., PuertoRico and Canada.
Your appliance is warranted by Electrolux. Electrolux has authorized Frigidaire Consumer Services andtheir authorized servicersto
perform service under this warranty. Electrolux authorizes no one else to change or add to any of these obligations under this
warranty. Any obligations for service and parts under this warranty must be performed by Frigidaire Consumer Services or an
authorized Frigidaire servicer.
system)
State of Alaska)
purchase date.
workmanship.

7
9
Record Your Model and Serial Numbers
Record in thespace provided belowthe model andserial numbers. Onall models, theserial
plate is locatedon the outsideof the interiorbulkhead left side.
Model Number
Serial Number
Register Your Product
The self-addressed PRODUCT REGISTRATION CARD should be filled in completely,
signed and returnedto the FrigidaireCompany.
2 Warranty
3 Product Registration
3 Normal Sounds
4 Important SafetyInstructions
4 Energy Saving Ideas
5 Operation of Current Device
5 Using Air Conditioner
5-6 Air Conditioner Features
6 Care and Cleaning
7 Avoid Service Checklist
Normal Sounds
Product Registration
3
Gurgle/Hiss
“Gurgling or hissing” noise may be heard
due to refrigerant passing through the
evaporator during normaloperation.
High Pitched Chatter
Today'shigh efficiency compressors
may have a high pitched chatter
during the coolingcycle.
Sound of Rushing Air
At the frontof the unit,you may
hear the sound of rushing air
being moved bythe fan.
Pinging or Swishing
Droplets of water hitting the
condenser during normal
operation may cause“pinging
or swishing” sounds.
Vibration
Unit may vibrate and make noise
because of poor wall or window
construction or incorrectinstallation.
Contents
NOTE: This USE & CARE MANUAL
provides specific operatinginstructions
for your model. Use the room air
conditioner only as instructed in this
USE & CARE MANUAL. These
instructions are not meant to cover
every possible condition and situation
that may occur. Common sense and
caution must be practiced when
installing, operating, and maintaining
any appliance.

4
Important Safety
Instructions
The power supplycord with
this air conditioner contains a current
detection device designed to reduce the
risk of fire.
Please refer to the section ‘Operation of
Current Device’ for details.
In the event that the power supply cord is
damaged, it cannot be repaired it must be
replaced with a cord from the Product
Manufacturer.
Energy Saving Ideas
Read all instructionsbefore using this air conditioner.
For Your Safety
Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance. Read product labels for
flammability and otherwarnings.
Prevent Accidents
To reduce the risk of fire, electrical shock, or injury to persons when
using your air conditioner, follow basic precautions, including the
following:
Be sure the electrical service is adequate for the model you have
chosen. This information can be found on the serial plate, which is
located on the side of the cabinet and behind the grille.
If the air conditioner is to be installed in a window, you will probably
want to clean both sides of the glass first. If the window is a triple-track
type with a screen panel included, remove the screen completely
before installation.
Be sure the air conditioner has been securely and correctly installed
according to the separate installation instructions provided with this
manual. Save this manual and the installation instructions for
possible future use in removing orreinstalling this unit.
When handling theair conditioner, be careful toavoid cuts fromsharp
metal fins onfront and rear coils.
Electrical Information
The complete electricalrating of your new room airconditioner is stated
on the serial plate. Refer to the rating when checking the electrical
requirements.
Be sure the air conditioner is properly grounded. To minimize shock
and fire hazards, proper grounding is important. The power cord is
equipped with a three-prong grounding plug and a current leakage
detection device forprotection against shock & firehazards.
Your air conditioner must be used in a properly grounded wall
receptacle. If the wall receptacle you intend to useis not adequately
grounded or protected by a time delay fuse or circuit breaker, have a
qualified electrician install the proper receptacle.
Do not run air conditioner with outside protective cover in place. This
could result in mechanical damage within the air conditioner.
Do not usean extension cord or an adapter plug.
Do not block inside air flow with blinds, curtains or furniture; or
outside with shrubs,enclosures, or other buildings.
The capacity of the room air conditioner must fit the room size for
efficient and satisfactory operation.
Install the room air conditioner on the shady side of your home. A
window that faces north is best because it is shaded most of the day.
Close the fireplace damper, floor and wall registers so cool air does
not escape upthe chimney and into the ductwork.
Keep blinds and drapes in other windows closed during the sunniest
part of the day.
Clean the air filter as recommended in the section “Care and Cleaning”
Proper insulation and weather stripping in your home will help keep
warm air out and cool air in.
External house shadingwith trees, plants or awnings will help reduce
the air conditioner work load.
Operate heat producing appliances such as ranges, washers, dryers
and dishwashers during the coolest part of the day.
WARNINGWARNING
!
WARNINGWARNING
!
NOTENOTE
!
Do not, under any
circumstances, cut,
remove, or bypass
the grounding prong.
Power supply cord
with 3-prong grounding
plug and current
detection device
Grounding type wall
receptacle
WARNINGWARNING
!
Avoid fire hazard or
electric shock. Do not use an extension
cord or an adaptor plug. Do not remove
any prong from the power cord.
WARNINGWARNING
!
N
E
E
R
E
G
V
A
Y
S
S
Y
A
E
V
N
E
O
M

Operation of Current
Device
To reduce therisk of fire,electric shock, orinjury to persons,read the
IMPORTANTSAFETY INSTRUCTIONS before operating this appliance.
WARNING
!
The power supplycord contains acurrent device thatsenses damage tothe power cord.To
test your powersupply cord dothe following:
1. Plug inthe AirConditioner.
2. The power supply cord will have TWO buttons on the plug head. Press the TEST button.
Youwill notice aclick as theRESET button pops out.
3. Press theRESET button. Again youwill notice aclick as thebutton engages.
4. The power supply cord is now supplying electricity to the unit. (On some products this is
also indicated bya light onthe plug head).
NOTES:
Do not usethis device toturn the uniton or off.
Always make surethe RESET button is pushedin for correctoperation.
The power supply cord must be replaced if it fails to reset when either the TEST button is
pushed, or itcannot be reset.A new one can be obtained from the product manufacturer.
If power supply cord is damaged, it CANNOT be repaired. It MUST be replaced by one
obtained from theproduct manufacturer.
To begin operating theair conditioner,follow these steps:
1. Set thethermostat to thehighest number (coldestor cooler setting).
2. Set theselector control tothe highest COOLsetting.
3. Adjustthe louvers forcomfortable air flow(see AirDirectional Louvers).
4. Once theroom has cooled,adjust the thermostatto the settingyou find mostcomfortable.
Review the “Air ConditionerFeatures” section forother settings.
Using Air Conditioner
NOTE: If the air conditioner is turned
off, wait 3 minutes before restarting.
This allows pressure inside the
compressor and equalize. Failure to
follow these instructions may be
harmful to yourunit.
5
The controls featured in this manual are representative of many available models.Your
model may offerslightly different features.
Cool Mode
The desired cool setting is selected by rotating the knob to the right to theappropriate
location.
“high cool” has maximum cooling effect and airflow.
“low cool” has minimum cooling effect and airflow.
“Mid cool” has the intermediate cooling effect and airflow.
Note: If yourunit is equippedwith a venthandle, keep itclosed for maximumefficiency.
Fan Mode
Rotate the knobto the leftto select yourchoice of fanspeeds for aircirculation.
Note: When selecting a fan speed, the compressor will not run. On models with a vent
control, this modecan be usedto remove staleair from theroom, or todraw fresh airinto the
room. Check thesection 'Additional Things You Should Know'.
Thermostat
The thermostat isused to setthe desired roomtemperature when theunit is beingoperated
in the “COOL MODE”.
To set the desired room temperature, rotate the thermostat switchto the desiredsetting.
After the set temperature is achieved the thermostat will automatically start and stop the
compressor in orderto maintain thedesired set temperature.
Rotate the thermostat selector clockwise for higher cool settings. Higher cool settings will
provide lower roomtemperature.
Rotate the thermostatselector counter clockwisefor lower coolsettings. Lower coolsettings
will provide higherroom temperature.
Air Conditioner
Features
1
3
7
9

10
ADDITIONAL THINGS YOU SHOULD KNOW
Now that youhave mastered the operating procedure, here are more features in your controlthat you should become
Fresh Air Vent Control
Fresh Air Vent Control
The Fresh Air Vent allows the air conditioner to:
1.Recirculate inside air - Vent Closed (See Fig.1)
2.Draw fresh air into the room - Vent Open(See Fig.2)
3.Exchange air from the room and draws fresh air into the room - Vent
and Exhaust Open (See Fig.3)
familiar with.
Figure 1 (VENT CLOSED) Figure 2 (VENT OPEN) Figure 3 (VENT &
EXHAUST OPEN)
Air Directional Louvers
Air directional louverscontrol air flowdirection. Your air conditionerhas the louver
type described below.
Auger Type
The louvers will allow you to direct the air flow Up or Down and Left or Right
throughout the room as needed. Rotate the Auger Wheel until the desired
Left/Right direction is obtained. Pivot horizontal louvers until the desired
Up/Down direction isobtained.
Air Conditioner
Features (Continued)
1
3
7
9
Care and Cleaning
Clean your air conditioner occasionally to keep it looking new. Be
sure to unplug the unit before cleaning to preventshock or fire
hazards:
Air Filter Cleaning
The air filter should be checked at least once a month to see if
cleaning is necessary.
Trapped particles in the filter can build up and cause an accumulation
of frost on the cooling coils.
Open the front panel.
Grasp the filterby the center and pull up and out.
Wash the filter using liquid dishwashing detergent and warm
water. Rinse filter thoroughly. Gently shake excess water from the
filter. Be sure filteris thoroughly dry before replacing.
Or, instead of washing you may vacuum the filter clean.
Cabinet Cleaning
Be sure to unplug the air conditioner to prevent shock or fire
hazard. The cabinet and frontmay be dusted with an oil-free cloth
or washed with a cloth dampened in a solution of warm water and
mild liquid dishwashingdetergent. Rinse thoroughly and wipe dry.
Never use harshcleaner, wax or polish on the cabinet front.
Be sure to wring excess water from the cloth before wiping
around the controls. Excess water in or around the controls may
cause damage to the air conditioner.
Plug in air conditioner.
Winter Storage
If you plan to store the air conditioner during the winter, remove
it carefully from the window according to the installation
instructions. Cover itwith plastic or return it to the original carton.
NOTE: To prevent rust or electrical connections from being
damaged, store air conditioner in an upright position andin a
dry place.
Air Filter

7
Avoid Service Checklist Before calling for service, review this list. It may save you time and expense. This
list includes common occurrences that are not the result of defective workmanship
OCCURRENCE SOLUTION
Air conditioner will not operate. Wall plug disconnected. Push plugfirmly into walloutlet.
House fuse blown or circuit breaker tripped. Replace fuse with time delay type or
reset circuit breaker.
Selector Control inOFF position. Turn selector to ON (some models) orthe desired
FAN or COOL setting.
Unit turned off by moving thermostat to a higher number and then immediately
turning back to a colder number. Waitapproximately 3 minutes. Listen for compress
or to start.
Air from unit does not feel cold
enough.
Turn selector to a higher COOL position
Thermostat set too warm. Set thermostat to colder temperature.
Air conditioner cooling,but
room is toowarm- ice forming
on cooling coilbehind
decorative front.
Outdoor temperature below 60°F (15°C). To defrost the coil, set selector to FAN
position. Then, set thermostat to warmer position.
Air filter may be dirty. Clean filter. Refer to Care andCleaning section. To defrost, set
selector to FAN .
Thermostat set too cold for night-time cooling. To defrost thecoil, set selectorto a
FAN position. Then, set thermostat to a warmer position.
Air conditioner cooling,but
room is too warm-NO ice
forming on coolingcoil
behind decorative front.
Dirty air filter-airrestricted. Clean air filter. Refer to Care andCleaning section.
Thermostat set toowarm. Turn thermostat clockwise to a colder setting.
Plug current device tripped. Preset RESET button.
Room temperature below60°F (15°C). Cooling may notoccur until room temperature
rises above 60°F(15°C).
Temperature sensing tube touching cold coil, located behind air filter. Straighten
tube away from coil.
Air directional louvers positioned improperly. Position louvers for better air
distribution.
Front of unit is blocked by drapes, blinds, furniture,etc.-restricts air distribution.
Clear blockage in front of unit.
Doors, windows, registers, etc, open- cold air escapes. Close doors, windows,
registers, etc.
Unit recently turned on in hot room, allow additionaltime to remove “ stored heat”
from walls, ceiling, floor and furniture.
Air conditioner turnson and
off rapidly.
Dirty air filter-air restricted. Clean air filter.
Outside temperature extremely hot. Set to high cool to bring airpast cooling coils
more frequently.
Noise when unitis cooling Air movement sound.This is normal. If too loud, set to a slower FAN setting.
Sound of fan hitting water-moisture removal system. This is normal when humidity
is high. Closedoors windows and registers.
Window vibration- poor installation. Refer to installation instructions orcheck with
installer.
Water dripping INSIDE when
unit is cooling.
Improper installation. Tilt air conditioner slightly to the outside to allow water
drainage. Refer toinstallation instructions - check with installer.
Water dripping OUTSIDE when
unit is cooling.
Unit removing large quantity of moisture from humid room. This is normal during
excessively humid days.
or materials inthis appliance
Unit turned off and then on too quickly. Turn unit off and wait 3 minutes before
restarting.
Thermostat set too low. Adjust thermostat to higher numberfor cooling.
