Frigidaire FAS184N2A User manual

Product No. FAS184N2A FAS184N2A2
Series heavy duty heavy duty
Color N/A N/A
Volts 230/208 230/208
BTU-Cooling 18000 BTU 18000 BTU
Wiring Diagram 5995437919 5995437919
Owner's Guide 309000855 309000855
Market North America North America
P40L2006.eps FAS184N2A.eps Heavy Duty FAS Wiring Diagram.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995437919
05/05/27
(EN/SERVICE/WC)
099
ROOM AIR
CONDITIONER
Model No.
FAS184N2
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995437919 FAS184N2
05/05 2
RECOMMENDED SPARE PARTS

FAS184N2 Publication No: 5995437919
# Functional Parts 3 05/05
* Non-Illustrated Parts
RECOMMENDED SPARE PARTS
Model Index: AFAS184N2 (FAS184N2A)
BFAS184N2 (FAS184N2A2)
POS. NO PART NO. DESCRIPTION
1 5304414097 A B Rail, cabinet bottom, rear
2 5304408741 A B Grille, rear panel, aluminum
3 309623906 A B Cabinet, wrapper/sleeve
4 5303211056 A B Bracket, sash lock
5 5304414116 A B Rail, cabinet top, front
6 5304414933 A B Retainer, shutter mount, cabinet side
7 309645602 A B Shutter, accordion panel, RH/LH, window closure
8 5304414929 A B Frame, shutter, gray, RH, extension
9 5304416310 A B Rail, cabinet bottom, front
10 # 5304414111 A B Overload Protector
11 # 309603113 A B Compressor
12 # 5303208581 A B Condenser
13 309632910 A B Base, compressor mtg., with studs
14 309623201 A B Shroud, cond fan motor
15 309623501 A B Tray, evap drip
16 # 309634103 A B Evaporator
17 # 5303311048 A B Fan Blade, with clamp
18 # 309630613 A B Motor, fan, 1 Speed
19 309630302 A B Cover, blower wheel, top
20 309623602 A B Bulkhead, control system
21 309623403 A B Bulkhead, air system
22 5300105402 A B Grommet, motor, (3)
23 5303317224 A B Screw, indt hex head, 10-16, (3)
24 309900101 A B Frame, cabinet front
25 309900301 A B Louver, horizontal
26 309630101 A B Housing, blower scroll
27 # 309633001 A B Blower Wheel, plastic, with clamp
28 309630203 A B Plate, scroll cover
29 # 309902202 A B Remote Control, transmitter
30 309900201 A B Panel, front grille
31 309900601 A B Handle, vent opener
32 309639001 A B Filter, micro-biologic, framed
33 309902801 A B Detent, vent handle
34 309321402 A B Door, vent, with actuator
35 309901702 A B Overlay, control display
36 309900501 A B Enclosure, input pcb, control panel
37 # 309901601 A B PC Board, input/display
38 5304413781 A B Hardware, PCB support
39 309630404 A B Control Box
40 309111201 A B Grommet, wire protector
41 309904601 A B Louver, vertical
42 # 309901501 A B PC Board, power, 230 V, variable speed
43 309900401 A B Wheel, louver adjuster
44 # 5304427210 A B Capacitor, 440 VAC, 25+6 microfarad
45 5304414108 A B Holder, thermistor clip, 5/16"
46 5303303077 A B Strap, capacitor mtg.
47 # 309343112 A - Power Cord, electric, 16 AWG, 230 V, type C
47 # 309343134 - B Power Cord, ELECT W/LCDI, 16 AWG, 230 V, type C
48 # 309201602 A B Sensor, thermistor, ambient temp

Publication No: 5995437919 FAS184N2
05/05 4
RECOMMENDED SPARE PARTS

FAS184N2 Publication No: 5995437919
# Functional Parts 5 05/05
* Non-Illustrated Parts
RECOMMENDED SPARE PARTS
Model Index: AFAS184N2 (FAS184N2A)
BFAS184N2 (FAS184N2A2)
POS. NO PART NO. DESCRIPTION
49 # 309201603 A B Sensor, thermistor, evap defrost
50 # 309330502 A B Manifold Assembly, with rings
51 5303302254 A B Nut, expansion type
56 # 309371801 A B Tube, suction, copper
57 # 309371701 A B Tube, discharge, copper
58 # 309374301 A B Tube, capillary, copper, top
59 # 309374401 A B Tube, capillary, copper, middle
60 # 309374501 A B Tube, capillary, copper, bottom
61 # 309111001 A B Fitting, reducer, .101/.104 ID, copper tube
62 # 5303290357 A B Strainer
64 # 5304417722 A B Tube, process, copper, cond. outlet
65 5304414105 A B Bracket, cab support, RH
66 3001815 A B Support, angle bracket, window sill mt.
67 5304414106 A B Bracket, cab support, LH
68 5304414928 A B Frame, shutter, gray, LH, extension

Publication No: 5995437919 FAS184N2
05/05 6
WIRING DIAGRAM
BK=Black(Noir) BL=Blue(Bleu) BR=Brown(Brun) G=Green(Vert) R=Red(Rouge) W=White(Blanc) Y=Yellow(Jaune)
Alternate Internal Overload Compressor (Autre Surcharge Interne Du Compresseur)
Ion.
J3210
309902101/01
Fan(Ventilateur)
Room Sensor (Sonde D' Ambiance)
Evap Sensor (Sonde Anti Givre)
Compressor (Compresseur)
Fan motor (Moteur Du Ventilateur)
Compressor capacitor (Condensateur Du Compresseur)
C
S
W
R
R
BK
Fan motor capacitor (Condensateur Du Ventilateur)
S
W
C
Connector (Connecteur)
Compressor Overload (Surcharge Du Compresseur)
R
R
BR
G (Vert)
GND
BK
N
Compressor Relay (Relais Du Compresseur)
3
4
BK
R
Ionizer(Ion)
(Optional) (Facultatif)
G (Vert)
GND
Ribbed (Blue) Raye(Bleu)
Plain (Brown) Ordinaire(Brun)
BK
WOR Y
(OU)
