Frigidaire FAS225J2A2 User manual

PRODUCT NO. BASE MODEL NO. BTU-COOLING
FAS225J2A2 FAS225J2A 20000BTU
Publication No.
5995348652
010118
-EN/SERVICE /DJH
345
ROOM AIR CONDITIONER
Model No.
FAS225J2A2
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
WIRING DIAGRAM - # 309343701
OWNER’S GUIDE - # 309000825
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.BOX 212378, AUGUSTA, GA 30917

08/01 2
Publication No. FAS225J2A2
5995348652
CABINET FRONT AND WRAPPER

# = Fast-moving Parts 3 08/01
* = Non-Illustrated Parts
FAS225J2A2 Publication No.
5995348652
CABINET FRONT AND WRAPPER
POS. NO PART NO DESCRIPTION
1 309632704 Cabinet,sleeve ,top louvers
2 309632804 Grille,rear ,with rail
7 309631104 Link,vertical louver
8 309630804 Louver,horizontal
8* 309633305 Louver Assy,horizontal
9 309631004 Louver
12 309631404 Filter-air,molded plastic
17 309633205 Front-cabinet,complete assy
19 309341002 Overlay,Frig Gallery
25 309321401 Door-vent,actuator
26 309330404 Handle-vent,gray
26A 309330202 Detent-vent
26A* 309330206 Detent Assy-vent,with adhesive
29 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs
43 309630904 Panel,cabinet front
70 309342401 Enclosure,elec control mt
78 309350502 Remote Control,transmitter ,with batteries

08/01 4
Publication No. FAS225J2A2
5995348652 CONTROLS

# = Fast-moving Parts 5 08/01
* = Non-Illustrated Parts
FAS225J2A2 Publication No.
5995348652
CONTROLS
POS. NO PART NO DESCRIPTION
7 309630403 Control Box
7* 5303015427 Screw,truss head ,8-18AB x 0.47
10 309623601 Bulkhead,control system
13 # 5303316594 Capacitor,370 V ,7.5x35 mfd
14 3015312 Screw,8-18AB x 0.500
15 5303303077 Strap-capacitor
16 # 5304408751 Wiring Harness
17 309343113 Cord-service,Type-D 14AWG
70 # 309342401 Enclosure,electrical control mtg
71 # 309350401 PC Board,power,Sagem
72 # 309350403 Board-input,Sagem HD
72* 5304417643 Ribbon Protector
74 5303301590 Screw-bracket
75 5304413781 Support-pc board
76 309111602 Transformer,240/12 Volt
* 5304415035 Defrost-thermister
* 5304413782 Holder-thermistor,assy with seal
* 5304414108 Holder-thermistor,without seal

08/01 6
Publication No. FAS225J2A2
5995348652
AIR HANDLING PARTS

# = Fast-moving Parts 7 08/01
* = Non-Illustrated Parts
FAS225J2A2 Publication No.
5995348652
AIR HANDLING PARTS
POS. NO PART NO DESCRIPTION
1 # 5303321440 Fan blade & clamp
2 3202975 Screw,10-16 x 0.72 ,square drive
3 309623201 Shroud-condenser,one piece
5 5303015311 Seal,fan housing ,lower
7 5303015427 Screw,truss head ,8-18AB x 0.47
8 # 309630604 Motor-fan,YSK 250B-6
10 309623401 Bulkhead,air system
11 309633001 Blower Wheel,plastic ,with clamp
13 309630301 Cover-blower wheel,top
15 309630101 Housing-blower,evap scroll
20 309630201 Plate-blower housing,scroll plate

08/01 8
Publication No. FAS225J2A2
5995348652
COMPRESSOR PARTS

# = Fast-moving Parts 9 08/01
* = Non-Illustrated Parts
FAS225J2A2 Publication No.
5995348652
COMPRESSOR PARTS
POS. NO PART NO DESCRIPTION
1 # 5304408297 Compressor,H29B24UABCX
2 5303286606 Grommet,compressor mtg ,(3)
3 5308006948 Nut,compressor mtg ,(3)
5 5303002069 Wire-Bale,terminal cover
6 5303002068 Gasket,terminal cover
7 5303002067 Cover,compr terminal
11 # 309634201 Evaporator
12 # 5304408769 Condenser-assy,3R/15FPI
13 309623501 Tray-evaporator
14 309632906 Base stud ASSY
16 # 5303209547 Capillary Tube,50 inch long
19 309112501 Washer,metallic
19* 5303002664 Washer,compressor mtg

08/01 10
Publication No. FAS225J2A2
5995348652
WINDOW MOUNTING PARTS

# = Fast-moving Parts 11 08/01
* = Non-Illustrated Parts
FAS225J2A2 Publication No.
5995348652
WINDOW MOUNTING PARTS
POS. NO PART NO DESCRIPTION
1 5304407729 Seal-window frame,stuffer
4 5304414928 Frame,LH
5 5304409250 Seal-top rail
6 5304414933 Retainer,accordian
7 5304414105 Bracket-support,RH
11 5304414106 Bracket-support,LH
14 5304414929 Frame,RH
15 5304414930 Closure,accordian type ,window mount
16 5304414116 Rail,top
21 5303212504 Seal-sleeve/chassis,bottom
* 309313204 Kit-mounting support
* 309313303 Kit-window mounting,heavy duty
* 5304409248 Hardware-mounting
* 5304409249 Seal-hole,shipping screws

Publication No. FAS225J2A2
5995348652
# = Fast-moving Parts 12 08/01
* = Non-Illustrated Parts
WIRING DIAGRAM
