Frigidaire FDB836GF User manual

PRODUCT NO. BASE MODEL NO. COLOR WIRING DIAGRAM OWNER’S GUIDE
FDB836GFB3 FDB836GF black 154320701 154314301
FDB836GFS3 FDB836GF white 154320701 154314301
FDB836GFT3 FDB836GF almond 154320701 154314301
Publication No.
5995310785
980723
-EN/SERVICE /JLT
821
24" BUILT-IN
DISHWASHER
Model No.
FDB836GF
©1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
DISHWASHER
SERVICE DATA SHEET # - 154320701
OWNER’S GUIDE # - 154314301
INSTALLATION INST - 154309602
101 Masters Blvd.
Anderson, SC 29624

7/98 2
Publication No. FDB836GF
5995310785
CONTROL PANEL

# = Fast Moving Part 3 7/98
* = Non-Illustrated Part
FDB836GF Publication No.
5995310785
CONTROL PANEL
A = FDB836GF (FDB836GFB3)
B = FDB836GF (FDB836GFS3)
C = FDB836GF (FDB836GFT3)
POS. NO PART NO DESCRIPTION
1 154253103 A - - Panel-control,black
1 154253101 - B - Panel-control,white
1 154253102 - - C Panel-control,almond
2 154236903 A - - Insert-control pnl,black
2 154236901 - B - Insert-control pnl,white
2 154236902 - - C Insert-control pnl,almond
3 # 154227703 A B C Control
4 154287901 A B C Cover-control
4A 154301301 A B C Cover-pc protector
20 154228301 A B C Duct-dynamic
25 154229201 A B C Seal-chamber
26 154303901 A B C Gasket-vent
27 154226701 A B C Actuator-wax
28 154226901 A B C Valve-vent
29 154226401 A B C Gasket-valve
30 154226802 A B C Blower-crossflow
31 154228101 A B C Chamber-vapor
33 154292402 A B C Gasket-cover
34 154321901 A B C Keypad,8pad
* 154200401 A B C Screw,6-10 x 3/8 ,pan plask
* 154283901 A B C Screw,#8-10 ,3/8 phillips
* 154301202 A B C Harness-wiring,main
* 154302303 A - - Nameplate Assy,black
* 154302301 - B - Nameplate Assy,white
* 154302302 - - C Nameplate Assy,almond

7/98 4
Publication No. FDB836GF
5995310785
DOOR

# = Fast Moving Part 5 7/98
* = Non-Illustrated Part
FDB836GF Publication No.
5995310785
A = FDB836GF (FDB836GFB3)
B = FDB836GF (FDB836GFS3)
C = FDB836GF (FDB836GFT3)
POS. NO PART NO DESCRIPTION
1 154226002 A B C Spring-door,(2)
2 154093301 A B C Screw-arm assy
3 154225902 A B C Arm Assy,LH
3* 154211501 A B C Pin-arm
3A 154225901 A B C Arm Assy,RH
5 154079601 A B C Nut-arm assy
7 154299002 A B C Door-inner assy
9 154230101 A B C Dispenser-det/rinse aid
10 154304301 A B C Screw-latch mtg,(2)
12 # 154308103 A - - Latch assy,black
12 # 154308101 - B - Latch assy,white
12 # 154308102 - - C Latch assy,almond
20 154292603 A - - Door,black
20 154292601 - B - Door,white
20 154292602 - - C Door,almond
49 154297601 A B C Gasket-door,bottom
50 154211401 A B C Support-door hinge
* 154200601 A B C Screw-#10-16 x 3/8
* 154253201 A B C Insulation,door
* 154298101 A B C Washer,arm
* 5300808749 A B C Screw,C.R. truss ,#8 .625
DOOR

7/98 6
Publication No. FDB836GF
5995310785
TUB

# = Fast Moving Part 7 7/98
* = Non-Illustrated Part
FDB836GF Publication No.
5995310785
A = FDB836GF (FDB836GFB3)
B = FDB836GF (FDB836GFS3)
C = FDB836GF (FDB836GFT3)
POS. NO PART NO DESCRIPTION
1 # 154209301 A B C Tub assy,w/frame parts
2 154211601 A B C Strike-door
3 # 154211801 A B C Gasket-tub
4 5300807270 A B C Screw
5 154080001 A B C Roller-tub
6 5303943103 A B C Screw w/washer,(8)
22 154239801 A B C Tubing-water inlet
23 5303318539 A B C Clamp-tubing,(2)
24 # 154225602 A B C Hose-drain
25 # 154209701 A B C Float
28 # 154225501 A B C Switch-float
28* 154200701 A B C Screw-#10-32 x 3/8
28* 154209801 A B C Bracket-float switch
29 # 154290203 A B C Thermostat,high limit
29A# 154227501 A B C Thermister
30 154241101 A B C Retainer-thermostat
30* 154297701 A B C Screw,retainer-thermo
* 154041001 A B C Screw,plask #1 ,10-10 x 9/16
* 154238303 A B C Insulation,blanket
* 154249401 A B C Dampener-tub,front
* 154249402 A B C Dampener-tub,back
TUB

7/98 8
Publication No. FDB836GF
5995310785
MOTOR & PUMP

# = Fast Moving Part 9 7/98
* = Non-Illustrated Part
FDB836GF Publication No.
5995310785
A = FDB836GF (FDB836GFB3)
B = FDB836GF (FDB836GFS3)
C = FDB836GF (FDB836GFT3)
POS. NO PART NO DESCRIPTION
1 # 154247601 A B C Heater
1* 154106201 A B C Nut-heater,(2)
1* 154289801 A B C Shield-heater terminal
2 154211001 A B C Bracket-heater
7 154245901 A B C Macerator
10 154245501 A B C Cover-volute
12 154245801 A B C Impeller
12* 154282701 A B C Screw,ss impeller
13 154246801 A B C Gasket-sump
14 154245401 A B C Housing-sump
15 # 154246701 A B C Check valve
16 154246501 A B C Retainer,sump
24 # 154250901 A B C Spray arm-lower,w/cover
24* 154252001 A B C Nut-spray arm
24A 154313601 A B C Spray arm-center
32 154251701 A B C Tube-delivery
32A 154251601 A B C Gasket-delivery tube
34 154064901 A B C Washer-insulating
40 154106801 A B C Clamp-hose
40 154247301 A B C Clamp,drain pump
54 154234401 A B C Hose-connector
55 154245601 A B C Bracket-motor
55A 154246201 A B C Bracket-motor,front
56 # 154245706 A B C Motor,circulation
57 154246001 A B C Barrel,front
57* 154246101 A B C Barrel,rear
58 154246402 A B C Check ball
59 154246901 A B C O-ring,rear
59A 154247001 A B C O-ring,front
60 154247501 A B C Drain Pump Assy
60* 154234501 A B C Bracket-motor,drain
61 154250201 A B C Nozzle,3rd level ,spray arm
62 154294101 A B C Support-spray arm
63 154252201 A B C Base-soil director
64 154252301 A B C Filter-soil director
65 154283003 A B C Filter Assy
65 154283004 A B C Filter Assy
66 154252701 A B C Trap-glass
67 154246601 A B C Hose-drain,shunt
70 # 154291504 A B C Motor & Pump Assy,includes#7,#12 ,
#57A,#59 & #59A,#55A,#56,#57
* # 154289901 A B C Transformer
* 154200601 A B C Screw-#10-16 x 3/8
* 154241101 A B C Retainer-thermostat
* 154247101 A B C Clamp,drain side
* 154247201 A B C Clamp,intake
* 154247401 A B C Clamp,connector pump
* 154287201 A B C Screw,motor mounting
* 5303316032 A B C Screw,truss ss ,8 .625
* 154281101 A B C Shield-spray arm,white
MOTOR & PUMP

7/98 10
Publication No. FDB836GF
5995310785
FRAME

# = Fast Moving Part 11 7/98
* = Non-Illustrated Part
FDB836GF Publication No.
5995310785
FRAME
A = FDB836GF (FDB836GFB3)
B = FDB836GF (FDB836GFS3)
C = FDB836GF (FDB836GFT3)
POS. NO PART NO DESCRIPTION
3 # 154219601 A B C Valve-water
4 154208701 A B C Brace-front
8 154227002 A B C Toeplate-adjustable
9 154224702 A B C Toeplate
9* 154249301 A B C Insulation,kickplate
10 5300808658 A B C Screw,#8A x .375"
11 154294701 A B C Screw,#7 plas .375
15 154210901 A B C Screw-leveling
15* 154286801 A B C Ring-retaining,adj leg
15A 154227101 A B C Leveling-rear
20 154209601 A B C Cover-junction box
47 154227301 A B C Rod,rear leg
48 154227201 A B C Clip,rear leg
49 154227401 A B C Guard-motor
* 154321801 A B C Baffle-sound
* 154041001 A B C Screw,plask #1 ,10-10 x 9/16
* 154200601 A B C Screw-#10-16 x 3/8
* 154290001 A B C Insulation-baffle,side
* 154290101 A B C Guard-wire,baffle
* 5300807270 A B C Screw
* 5300807373 A B C Washer
* 5300808749 A B C Screw,C.R. truss ,#8 .625

7/98 12
Publication No. FDB836GF
5995310785
RACKS

# = Fast Moving Part 13 7/98
* = Non-Illustrated Part
FDB836GF Publication No.
5995310785
A = FDB836GF (FDB836GFB3)
B = FDB836GF (FDB836GFS3)
C = FDB836GF (FDB836GFT3)
POS. NO PART NO DESCRIPTION
1 154320904 A B C Rack assy-lower
2 154295201 A B C Basket-Silverware
3 154321104 A B C Rack assy-upper
4 5300809974 A B C Wheel & bracket assy,upper rack
5 5300809927 A B C Cap-slide,(4)
6 154232701 A B C Slide-rack,(2)
7 154174501 A B C Wheel & bracket assy,lower rack
8 154304001 A B C Base-funnel
9 154251801 A B C Funnel
10 154238801 A B C Basket-utility,white
11 154225203 A B C Shelf-cup
12 154238901 A B C Bracket-shelf cup
15 154254001 A B C Handle-siverware basket
16 154254101 A B C Cover-silverware basket,white
RACKS

7/98 14
Publication No. FDB836GF
5995310785
Service Data Sheet - 154278902
WIRING
