Frigidaire GLDB653A User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR
GLDB653AB1 GLDB653A 24" Built-in black
GLDB653AQ1 GLDB653A 24" Built-in bisque
GLDB653AS1 GLDB653A 24" Built-in white
MARKET
North America
Publication No.
5995375325
020702
-EN/SERVICE /ECL
821
24" Built-In
DISHWASHER
Model No.
GLDB653A
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
DISHWASHER
SERVICE DATA SHEET # - 154414501
OWNER’S GUIDE # - 154409901
INSTALLATION INSTRUCTIONS # - 154415901
ENERGY GUIDE LABEL # - 154399010
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917

07/02 2
Publication No. GLDB653A
5995375325
CONTROL PANEL

# = Fast Moving Part 3 07/02
* = Non-Illustrated Part
GLDB653A Publication No.
5995375325
CONTROL PANEL
A = GLDB653A (GLDB653AS1)
B = GLDB653A (GLDB653AB1)
C = GLDB653A (GLDB653AQ1)
POS. NO PART NO DESCRIPTION
1 154368204 A - - Panel,control ,white
1 154368206 - B - Panel,control ,black
1 154368207 - - C Panel,control ,bisque
2 154401301 A - - Insert,control panel ,white
2 154401303 - B - Insert,control panel ,black
2 154401304 - - C Insert,control panel ,bisque
3 # 154408901 A B C Timer
3* 154095701 A B C Screw,thread rolling ,(2) ,timer
3* 154131203 A B C Shield,timer
8 # 154368601 A B C Switch,selector ,6 button
8* 154248601 A B C Shield,switch
8* 5303318719 A B C Screw,mtg.
13 154239504 A - - Knob,timer ,white
13 154239509 - B - Knob,timer ,black
13 154239508 - - C Knob,timer ,bisque
20 154345102 A B C Vapor Chamber Assy,w/vent gasket
25 154229201 A B C Seal,chamber
* 154402001 A B C Wiring Harness,main
* 154399010 A B C Label,energy guide
* 154283901 A B C Screw,#8-10 ,3/8 phillips

07/02 4
Publication No. GLDB653A
5995375325
DOOR

# = Fast Moving Part 5 07/02
* = Non-Illustrated Part
GLDB653A Publication No.
5995375325
A = GLDB653A (GLDB653AS1)
B = GLDB653A (GLDB653AB1)
C = GLDB653A (GLDB653AQ1)
POS. NO PART NO DESCRIPTION
1 154365701 A B C Spring,door ,(2)
1A 154325201 A B C Linkage,door spring ,(2)
2 154093301 A B C Screw,arm assy ,(4)
3 154325304 A B C Arm Assy,LH
3A 154325303 A B C Arm Assy,RH
* 154400601 A B C Pin,arm assy
5 154079601 A B C Nut,arm assy ,(4)
7 154299002 A B C Door,inner assy
7A 154332701 A B C Grate,liner
9 154230101 A B C Dispenser,det/rinse aid ,includes #22
9* 154294701 A B C Screw,#7 plas .375 ,(6) ,disp. assy.
10 154103702 A B C Screw,latch mtg ,(2)
12 # 154361201 A - - Latch assy,white
12 154361203 - B - Latch assy,black
12 # 154361204 - - C Latch assy,bisque
20 154359105 A - - Door,white
20 154359107 - B - Door,black
20 154359110 - - C Door,bisque
20* 5304428306 A B C Screw,door mtg. ,(2)
22 154388801 A B C Cap,Rinse aid
49 154297602 A B C Gasket,door ,bottom
50 154211401 A B C Support,door hinge
51 154320301 A B C Clamp,drip loop ,wire
* 154227808 A B C Thermostat,temp boost
* # 154227805 A B C Thermostat,temp assure
* 154200601 A B C Screw,#10-16 x 3/8
DOOR

07/02 6
Publication No. GLDB653A
5995375325
TUB

# = Fast Moving Part 7 07/02
* = Non-Illustrated Part
GLDB653A Publication No.
5995375325
A = GLDB653A (GLDB653AS1)
B = GLDB653A (GLDB653AB1)
C = GLDB653A (GLDB653AQ1)
POS. NO PART NO DESCRIPTION
1 # 154209301 A B C Tub assy,w/frame parts
2 154211601 A B C Strike,door
3 # 154211801 A B C Gasket,tub
4 154200602 A B C Screw,10-16 x 3/8 ,hex
5 154333901 A B C Roller,tub
6 5303943103 A B C Screw,w/washer ,(8)
22 154239801 A B C Tubing,water inlet
23 5303318539 A B C Clamp,tubing ,(2)
24 # 154411002 A B C Hose,drain
25 # 154209701 A B C Float
28 154408701 A B C Switch assy,float
29 # 154290204 A B C Thermostat,re-settable
30 154241101 A B C Retainer,thermostat
30* 154297701 A B C Screw,retainer-thermo
* 154238304 A B C Insulation,tub
* 5300807270 A B C Screw,(2) ,countertop mtg.
TUB

07/02 8
Publication No. GLDB653A
5995375325
MOTOR & PUMP

# = Fast Moving Part 9 07/02
* = Non-Illustrated Part
GLDB653A Publication No.
5995375325
A = GLDB653A (GLDB653AS1)
B = GLDB653A (GLDB653AB1)
C = GLDB653A (GLDB653AQ1)
POS. NO PART NO DESCRIPTION
1 # 154247601 A B C Heater
1* 154106201 A B C Nut,heater ,(2)
1* 154289801 A B C Shield,heater terminal
2 154359701 A B C Bracket,heater ,(2)
10 154245501 A B C Cover,volute
13 154246801 A B C Gasket,sump
14 154365902 A B C Housing,sump
16 154246502 A B C Retainer,sump
24 154414101 A B C Spray arm,lower ,w/heat shield
24A 154313601 A B C Spray arm,center
24A* 154252001 A B C Nut,spray arm ,center
32 154406601 A B C Tube,delivery
32A 154406401 A B C Gasket,delivery tube
40 154348401 A B C Clamp,red ,pump
40 154348501 A B C Clamp,silver ,pump
40* 154106801 A B C Clamp,hose ,(2)
54 154234401 A B C Hose,connector
55 154362301 A B C Bracket,motor ,askoll
55* 5303316032 A B C Screw,truss ss ,8 .625
58 154246402 A B C Check ball
59 154246901 A B C O-ring,rear
59A 154247001 A B C O-ring,front
60 154407401 A B C Drain Pump Assy
60* 154234501 A B C Bracket,motor ,drain
61 154406501 A B C Nozzle,3rd level ,spray arm
62 154294101 A B C Support,spray arm ,lower
63 154252201 A B C Base,soil director
64 154252301 A B C Filter,soil director
65 154252401 A B C Filter,polypro
66 154252701 A B C Trap,glass
70 # 154395402 A B C Motor assembly,circulation ,w/o o’rings
* 154380601 A B C Clamp,hose ,(1)
* 154200601 A B C Screw,#10-16 x 3/8
MOTOR & PUMP

07/02 10
Publication No. GLDB653A
5995375325
FRAME

# = Fast Moving Part 11 07/02
* = Non-Illustrated Part
GLDB653A Publication No.
5995375325
FRAME
A = GLDB653A (GLDB653AS1)
B = GLDB653A (GLDB653AB1)
C = GLDB653A (GLDB653AQ1)
POS. NO PART NO DESCRIPTION
3 # 154373301 A B C Valve,water
4 154208701 A B C Brace,front frame
8 154322901 A - - Toeplate,adjustable ,white
8 154322903 - B - Toeplate,adjustable ,black
8 154322905 - - C Toeplate,adjustable ,bisque
9 154397201 A - - Kickplate Assy,white ,w/foam
9 154397203 - B - Kickplate Assy,black ,w/foam
9 154397204 - - C Kickplate Assy,bisque ,w/foam
10 154371301 A - - Screw,phillips head ,white
10 5300808658 - B - Screw,#8A x .375" ,black
10 154371303 - - C Screw,phillips head ,bisque
11 154200601 A B C Screw,#10-16 x 3/8
15 154405301 A B C Screw,leveling
20 154209601 A B C Cover,junction box
* 154200602 A B C Screw,10-16 x 3/8 ,hex

07/02 12
Publication No. GLDB653A
5995375325
RACKS

# = Fast Moving Part 13 07/02
* = Non-Illustrated Part
GLDB653A Publication No.
5995375325
RACKS
A = GLDB653A (GLDB653AS1)
B = GLDB653A (GLDB653AB1)
C = GLDB653A (GLDB653AQ1)
POS. NO PART NO DESCRIPTION
1 154319706 A B C Rack assy,lower
2 5300808994 A B C Basket,silverware
3 154319506 A B C Rack assy,upper
4 5304407064 A B C Wheel & bushing assy,upper rack
5 5300809927 A B C Cap,slide ,(4)
6 154232701 A B C Slide,rack ,(2)
7 154174501 A B C Wheel & bracket assy,lower rack
8 154304001 A B C Base,funnel
9 154251801 A B C Funnel
