Frigidaire 131883500 User manual

2
Important Safety Instructions
Read all instructions before using this dryer.
Toreducetheriskoffire,electricalshock,orinjurytopersonswhen
using this dryer, comply with the basic warnings listed below.

3
Protect Children
Donotallowchildrentoplay onorin the dryer.Close supervision of
children is necessary when the dryer is used near children. As children grow, teach
them the proper, safe use of all appliances.
Destroythecarton,plasticbagandotherpackingmaterialsafterthe
dryer is unpacked. Children might use them for play. Cartons covered with rugs,
bedspreads or plastic sheets can become airtight chambers.
Keep laundry products out of children's reach. To prevent personal
injury, observe all warnings on product labels.
Before the dryer is removed from service or discarded, remove the
dryerdoorto prevent accidental entrapment.
Failure to comply with these warnings could result in serious personal injuries.
Prevent Injury
To prevent shock hazard and assure stability during operation, the
dryer must be installed and electrically grounded by a qualified service person in
accordancewithlocal codes.Installationinstructionsarepackedinthedryer forthe
installer'sreference.Refer toINSTALLATIONINSTRUCTIONSfordetailedgrounding
procedures. If the dryer is moved to a new location, have it checked and reinstalled
by a qualified service person.
To prevent personal injury or damage to the dryer, the electrical
powercordof a gas dryer must be plugged into a properly grounded andpolarized
3-prong outlet. The third grounding prong must never be removed. Never
ground the dryer to a gas pipe. Do not use an extension cord or an adaptor
plug.
ALWAYS disconnect the dryer from the electrical supply before
attempting any service or cleaning. Failure to do so can result in electrical shock or
injury.
Do not use any type spray cleanser when cleaning dryer interior.
Hazardous fumes or electrical shock could occur.
To prevent injury, do not reach into the dryer if the drum is moving.
Wait until the dryer has stopped completely before reaching into the drum.
To prevent injury and damage to the dryer:
• All repairs and servicing must be performed by an authorized servicer
unless specifically recommended in this Owner's Guide. Use only authorized
factoryparts.
• Do not tamper with controls.
• Do not install or store the dryer where it will be exposed to the weather.
A thermal limiter switch automatically turns off the motor in the unlikely event
ofanoverheatedsituation(electricdryersonly).Aservicetechnicianmustreplacethe
thermal limiter switch after correcting the fault.
Failure to comply with these warnings could result in serious personal injuries.
SAVE THESE INSTRUCTIONS
Note: The instructions appearing in this
Owner's Guide are not meant to cover
every possible condition and situation
that may occur. Common sense and
cautionmustbepracticedwheninstalling,
operatingandmaintaininganyappliance.

4
•Follow the guidelines below for preparing the load for drying.
•Read the Operating Instructions card for operating your specific model.
• Always read and follow fabric care labels and laundry product labels.

5
Features
PROBLEM • Add a few bath towels to small loads for
proper tumbling.
• Some "silk-like" fabrics should be air dried.
• Use proper drying temperature.
• Place fabric softener sheet on top of load
before starting the dryer.
• Do not overload dryer.
• Use fabric softener in washer or dryer to
reduce static electricity.
• Remove items when they are slightly damp
to avoid overdrying.
• Check that lint screen is clean and in place.
• Use fabric softener to lubricate fibers.
• When ironing, use spray starch or fabric
finish on collars and cuffs.
• Turn items inside out to reduce abrasion.
• Follow fabric care label directions.
• If shrinking is a concern, check load often.
• Remove items while slightly damp and
hang or lay flat to complete drying.
• Block knits into shape.
• Do not overload dryer.
• Remove items as soon as cycle ends.
PREVENTIVE MEASURES
Many drying problems involve poor cleaning results, poor soil and stain removal, residues of lint and scum, and fabric damage.
For satisfactory drying results, follow these suggestions provided by The Soap and Detergent Association.
Common Drying Problems
Greasy, oily
stains
Lint
Pilling
(Fibers break
off, ball up and
cling to fabric.)
Shrinking
Wrinkling
POSSIBLE CAUSES
• Fabric softener sheet.
• Overloading.
• Overdrying causes static
electricity.
• Lint screen not clean
when cycle began.
• Lint is attached to "pills."
• Pilling is normal with
synthetic and permanent
press fabrics. This is due
to abrasion from normal
wear.
• Overdrying.
• Overloading.
• Leaving items in dryer
after cycle ends.
SOLUTIONS
• Rub fabric softener stains with bar soap.
Rinse and rewash.
• Reduce load size and rewash using liquid
fabric softener in the final rinse.
• Or, add a fabric softener sheet and
tumble without heat.
• Use lint brush or roller to remove lint.
• Use a lint brush or shaver to remove pills.
• Irreversible condition.
• Reduce load size and tumble at medium
or low heat for 5-10 minutes.
• Remove items immediately. Hang or fold.
Place the front bar under
the lip of the lint screen opening.
Cycle Signal Control (some models)
When the Cycle Signal Control is ON, a signal will sound at the end of each cycle
and during the Press Saver setting (some models). The volume is adjustable on
some models.
Drum Light (some models)
A drum light will come on whenever the door is opened to illuminate the dryer
drum during loading and unloading. Closing the door turns off the light.
Reversible Dryer Door
Yourdryer is equippedwitha reversibledoor.The door canbehinged on theright
or left side. Refer to the INSTALLATION INSTRUCTIONS for directions on changing
the door.
Drying Rack (some models)
Use the drying rack to dry items which should not be tumble dried.
1. Open the dryer door and remove the lint screen.
2. Insert drying rack into the dryer drum. Place the front bar under the lip of the
lint screen opening.

6
Care and Cleaning

7
A void Service
Checklist
Before calling for service, review this list. It may save both time and expense. The list includes
common occurrences that are not the result of defective workmanship or materials in this dryer.
OCCURRENCE SOLUTION
Make sure the plug fits tightly in wall outlet.
Reset circuit breaker or replace fuse.
Make sure electrical line is not overloaded and the dryer is
on a separate circuit.
Call authorized service person for replacement.
Replace fuse.
Checktomakesuresupplyvalveisopen. See INSTALLATION
INSTRUCTIONS for procedure.
See INSTALLATION INSTRUCTIONS.
Refill or replace tank.
Dryer should heat when utility service is restored.
Make sure all lint has been removed from the dryer lint
screen before starting each cycle.
Exhaustductmustbeatleast4inches in diameter and made
of rigid or flexible metal.
When in place, the duct must have no more than two 90°
bends and must not exceed length listed in INSTALLATION
INSTRUCTIONS.
Drying time will be 20% longer than drying on a 240 volt
circuit.
See Drying Procedures, page 4.
Clean out any obstruction.
Use a dehumidifier near the dryer.
Do not overload. See Drying Procedures, page 4.
Remove items as soon as cycle ends.
See Drying Procedures, page 4.
Follow fabric care label instructions.
Always remove foreign objects from pockets before
laundering. Remove objects from drum and restart dryer.
It may be necessary to baste a scrap of material securely
around ornaments before drying to prevent scratching and
damage to the dryer.
Drum damage caused by foreign objects or
permanently attached items is not covered by the
warranty.
POSSIBLE CAUSE
Electrical power cord is not securely plugged
in or plug may be loose.
House fuse blown or circuit breaker tripped.
Thermal limiter tripped.
Thereare 2 house fuses in the dryercircuit. If
1 of the 2 fuses is blown, the drum may turn
but the heater will not operate.
Gas supply valve is not open (gas models).
Dryer does not have enough air supply to
support the burner flame (gas models).
LPgassupplytankisemptyortherehasbeen
a utility interruption of natural gas (gas
models).
Lint screen is clogged with lint.
Exhaust duct requirements have not been
met.
Electricdryerisconnectedtoa208voltcircuit.
Drying procedures have not been followed.
Outside exhaust hood or exhaust duct may
be clogged or restricted.
High humidity.
Dryer is overloaded.
Items left in dryer too long.
Insufficient sorting of items.
Drying temperature too high.
Foreign objects such as coins, pins, clips or
buttons are inside the dryer.
Permanently attached items such as belt
buckles,zippersandfastenersmaybehitting
the inside of the drum.
Dryer does not start.
Dryer runs but won't heat.
Drying cycle takes too long,
outside of the dryer feels
too hot or smells hot.
Excessive wrinkling.
Scratching or chipping of the
drum finish.

8
THE CONSUMER WILL BE
RESPONSIBLE FOR:
Costs of service calls that are listed under
IMPORTANT RESPONSIBILITIES OF THE
CONSUMER.*
Costs of the technician's travel to the home and any
costs for pick up and delivery of the appliance
required because of service.
WARRANTY
PERIOD
One year from original
purchase date.
Time period listed above.
FRIGIDAIRE, THROUGH ITS AUTHORIZED
SERVICERS, WILL:
Pay all costs for repairing or replacing any parts of this
appliance which prove to be defective in materials or
workmanship.
All of the provisions of the full warranty above and the
exclusions listed below apply.
FULL ONE-YEAR
WARRANTY
LIMITED WARRANTY
(Applicable to the
State of Alaska)
*IMPORTANT
RESPONSIBILITIES
OF THE CONSUMER
EXCLUSIONS
IF YOU NEED
SERVICE
This warranty applies only to products in ordinary household use, and the consumer is responsible for the
items listed below:
1. Proper use of the appliance in accordance with instructions provided with the product.
2. Proper installation by an authorized servicer in accordance with instructions provided with the appliance and in
accordance with all local plumbing, electrical and/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blown fuses, repair of loose
connections or defects in house wiring.
4. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which
are not a part of the appliance when it was shipped from the factory.
5. Damages to finish after installation.
6. Replacement of light bulbs and/or fluorescent tubes (on models with these features).
This warranty does not cover the following:
1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING
FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation
or exclusion may not apply to you.
2. Service calls which do not involve malfunction or defects in workmanship or material, or for appliances not in ordinary
household use. The consumer shall pay for such service calls.
3. Damages caused by services performed by servicers other than Frigidaire or its authorized servicers; use of parts other
than genuine Frigidaire Home Products parts; obtained from persons other than such servicers; or external causes
such as abuse, misuse, inadequate power supply or acts of God.
4. Products with original serial numbers that have been removed or altered and cannot be readily determined.
Keep your bill of sale, delivery slip, or some other appropriate payment record. The date on the bill establishes the warranty
period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. This
written warranty gives you specific legal rights. You may also have other rights that vary from state to state. Service under
this warranty must be obtained by contacting Frigidaire Home Products:
800 • 944 • 9044
Frigidaire Home Products
P.O. Box 212378
Augusta, GA 30917
Product features or specifications as described or illustrated are subject to change without notice. All warranties are made
by White Consolidated Industries, Inc. This warranty applies only in the 50 states of the U.S.A. and Puerto Rico.
Your appliance is warranted by Frigidaire Home Products, a division of White Consolidated Industries, Inc. We authorize no person to change
or add to any of our obligations under this warranty. Our obligations for service and parts under this warranty must be performed by Frigidaire
or an authorized Frigidaire servicer.
FRIGIDAIRE DRYER WARRANTY
Your Frigidaire product is protected by this warranty
