Frigidaire FGQB4000F User manual

Product No. FGQB4000FS0
Series Frigidaire
Market Best Buy
Color white
Volts 120
Wiring Diagram 134509400
Owner's Guide 134674100
Installation Instructions 134528200
Operating Instructions 134420600
P16L0041.eps P16v0088.eps P16d0032.eps P16C0229.eps P16M0024.eps P16b0015.eps
134509400g.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995461778
06/02/23
(EN/SERVICE/WC)
361
GAS DRYER
Model No.
FGQB4000F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995461778 FGQB4000FS0
02/06 2
CABINET/DRUM
P16V0088
32
14
13
12
5
6
29
21
2
24 44
33
34
34
9
42
25
31
11
34
15
37
18
30
42
34
2
2
2
20
64
17

FGQB4000FS0 Publication No: 5995461778
# Functional Parts 3 02/06
* Non-Illustrated Parts
CABINET/DRUM
POS. NO PART NO. DESCRIPTION
2 131168200 Screw, pan head, 8-18B x 0.31
5 5303281019 Ball, grounding
6 5303281020 Clip, ball, steel, flat nut
9 131793200 Panel, service access, rear
11 131363200 Cover, terminal block
12 131825900 Bearing, drum support
13 131724300 Bracket, bearing support
14 131205400 Screw, bracket mtg., 10-16B x 1.375, cr/sq drive
15 # 131600500 Housing, gas heater assy, w/seal
17 3204254 Baffle, heater shield
18 131477000 Screw, 10-16AB x 0.375
20 134166500 Bracket, top panel mtg., rear
21 134122532 Drum, dryer, galvanized stl., service kit
24 131963900 Glide, drum
25 5303015671 Screw, hex washer head, 8-18 x 0 .375, cup point
29 131382300 Screw, quadrex head, 10-14 x 1.00, vane mtg., special
30 5303201200 Vane, straight
31 # 134501200 Power Cord, electric svce
32 131777700 Shaft, drum support, ballhitch
32* 5303307893 Lubricant, high temp
33 # 5308015399 Thermostat, safety
34 131243700 Screw, pan head, 8-18AB x 0.375
37 131952100 Duct, heat
42 134154100 Screw, hex washer head, 10-32 x 0.375, ground
44 134344900 Leveling Leg, screw
64 134360100 Bracket, svce panel mtg.
* 134467300 Stacking Kit, washer/dryer
* # 5303281153 Rear Bearing Kit, includes 5, 6, 12, 13, 14, 18, 32

Publication No: 5995461778 FGQB4000FS0
02/06 4
FRONT PANEL/LINT FILTER
49
25
27
39
58
50
50
8
20
21
9
9
42
26
42
25
22
6
1
44
47
46
42
42
48
41
41
42
42
17
17
18
28
P16D0032
2
2
2
16

FGQB4000FS0 Publication No: 5995461778
# Functional Parts 5 02/06
* Non-Illustrated Parts
FRONT PANEL/LINT FILTER
POS. NO PART NO. DESCRIPTION
1 134417000 Seal, air duct
2 131168200 Screw, pan head, 8-18B x 0.31
6 134382900 Duct, air
8 # 131845802 Cover, lint housing, w/moist sensor
9 131633200 Plug, white
16 134440100 Clip, U-nut
17 134408700 Clip, assembly
18 134321702 Panel, front service, white
20 134440200 Seal, felt, upper
20* 5308027429 •Adhesive, high temp
21 134134700 Seal, felt, lower
22 134397302 Panel, front, white, w/lamp hole
25 131658800 Door Catch
25 134548000 Latch, door, lower
26 # 131843101 Switch, door, with drum light
27 131450300 Trap, lint blade assy
28 134440000 Clip, guide
39 131205100 Screw, #8 pan head, 10-10B x 0.500, cr/sq drive
41 134412400 Hinge, door
42 134156200 Screw, flat head, 8-18AB x 0.44, quad drive
44 134413300 Gasket, door seal
46 134439300 Handle, door
47 134412204 Panel, inner door, white
48 134412003 Panel, outer door, white
49 134548100 Door Strike
50 131303300 Screw, pan head, 10-16AB x 0.500, locking
58 # 131843500 Lamp Assy, drum light, w/mtg bracket
58* 131862800 •Lamp

Publication No: 5995461778 FGQB4000FS0
02/06 6
CONTROLS/TOP PANEL
53
23
P16C0229
39
19
19
2
3
29
61
4
5
10
11 12
13
9
7
8

FGQB4000FS0 Publication No: 5995461778
# Functional Parts 7 02/06
* Non-Illustrated Parts
CONTROLS/TOP PANEL
POS. NO PART NO. DESCRIPTION
1 # 134484212 Control Board, pc, with housing
2 134432000 Knob, function
3 134431800 Knob, program
4 134347700 Pin, program knob
5 134347300 Pin, function knob
6 134447600 Light Pipe, array, 9 curved prgm
7 134429100 Light Pipe, array, 1 row of 5
8 134429200 Light Pipe, array, 2 row of 4
9 134429400 Light Pipe, array, 4 start group
10 134385100 Push Button, function
11 134385201 Push Button, start
12 134385301 Push Button, pause
13 134349400 Spring, push button
19 134402900 Screw, phillips, 6-19 x 0.650
23 # 134394400 Wiring Harness, controls
23*# 134491500 Wiring Harness, main
29 134442400 Panel, control console
39 134178901 Screw, 8-18AB x 0.455
53 134365000 Panel, work top, white

Publication No: 5995461778 FGQB4000FS0
02/06 8
MOTOR

FGQB4000FS0 Publication No: 5995461778
# Functional Parts 9 02/06
* Non-Illustrated Parts
MOTOR
POS. NO PART NO. DESCRIPTION
4 131435200 Lock, blower housing
7 131451600 Tube, exhaust, rear, w/mtg bracket
7* 131456800 Tube, exhaust, side/bottom, Optional Kit
10 # 131775600 Blower Assy, housing, w/cover & wheel
11 131749800 Spacer, idler
15 # 134587700 Thermistor, control
20 131017900 Screw, hex head, 1/4-20T x 1.25, spacer mtg., thread cutting
22 131601000 Spring, idler arm
23 # 131863007 Idler Arm Assy, w/pulley
25 # 134503600 Belt, dryer
27 134242400 Clamp, motor mtg.
28 # 131560100 Motor & Pulley Assy
34 131243700 Screw, pan head, 8-18AB x 0.375
46 134203400 Bracket, motor mtg
47 131633300 Seal, exhaust tube
48 131168200 Screw, pan head, 8-18B x 0.31
52 131202300 Screw, 10-16AB x 0.625

Publication No: 5995461778 FGQB4000FS0
02/06 10
BURNER

FGQB4000FS0 Publication No: 5995461778
# Functional Parts 11 02/06
* Non-Illustrated Parts
BURNER
POS. NO PART NO. DESCRIPTION
2 131168200 Screw, pan head, 8-18B x 0.31
34 131243700 Screw, pan head, 8-18AB x 0.375
55 # 134389600 Wiring Harness, gas valve
61 134122000 Bracket, burner mtg
64 134144900 Pipe, gas, right angle
65 08015112 Cap, pipe
66 134128700 Bushing, coupler
68 134185100 Tail Piece, coupling
69 # 5308015194 Union, hex nut
70 # 5303207409 Valve, gas
71 # 5303307291 Coil, secondary
72 # 5303307292 Coil, booster
73 # 5303207410 Orifice, natural gas, size 44
74 # 134192000 Igniter Assy
77 # 134197700 Burner, gas
79 # 5303281135 Sensor, radiant
80 # 134200801 Tube, burner, riveted
* # 134315100 LP Conversion Kit, natural to LP

Publication No: 5995461778 FGQB4000FS0
02/06 12
WIRING DIAGRAM
