Frigidaire AFFC2027DW User manual

Product No. AFFC2027DW1
Series 134A
Color white
Volts 115
Wiring Diagram 216804000
Owner's Guide 216960000
Market North America
Energy Guide 216794406
P08F0060.eps P08D0405.eps P08C0646.eps P08S0354.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995419214
04/10/20
(EN/SERVICE/MLR)
365
FREEZER CHEST
Model No.
AFFC2027DW
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995419214 AFFC2027DW1
10/04 2
DOOR
5
2
47
27
34
16
15
9
1
10
11
P08D0405
40
40
23
18
57
14

AFFC2027DW1 Publication No: 5995419214
# Functional Parts 3 10/04
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 216481401 Gasket, lid seal, white
2 5303925107 Lock Assy
* 5303313518 Washer, sealing
5 # 216702900 Key, lock
9 216829504 Panel-inner door, frzr
10 216923001 Plug button, 1/4", white
11 216130127 Lid, white
* 5303161215 Screw, ph truss head, 8-18AB x 0.500
14 216822900 Switch, light/lamp, ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket, light/lamp, 25 W
18 216897600 Handle, white
23 216212700 Light-signal, amber
27 5303212828 Clip, panel mtg
34 5303296969 Shield, lid lamp
40 216922700 Fastener, .330 dia stud, handle, (2)
47 # 216908000 Harness-lid
57 216899508 Overlay
* 5303917276 Insulation-door, fiberglass, (bulk)

Publication No: 5995419214 AFFC2027DW1
10/04 4
CABINET

AFFC2027DW1 Publication No: 5995419214
# Functional Parts 5 10/04
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
1 216909800 Catch-lock, white
1A 216818900 Support, lock catch clip
3 216502600 Plug, drain, interior
4 216073905 Plug-drain, exterior
6 216111200 Breaker, hinge side
7 216111800 Breaker, lock side
11 216110800 Breaker, chest end, (2)
18 216707200 Knob, temp control
21 # 216714600 Control-temperature
27 216629600 Screw, hex washer head, 10-16 x 0.500, tapping
28 216035300 Hinge
30 216110700 Breaker, corners
59 216916201 Basket, blue, upper, (3)
59A 216867401 Basket, blue, lower, (2)
62A 131420300 Screw, cr truss head, 8-18AB x 0.750
75 216034301 Panel, access, white
93 5303161215 Screw, ph truss head, 8-18AB x 0.500
100 216205101 Track, basket
* 216794406 Energy Guide
* 5303305324 Paint, touch-up, white

Publication No: 5995419214 AFFC2027DW1
10/04 6
SYSTEM

AFFC2027DW1 Publication No: 5995419214
# Functional Parts 7 10/04
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 5303280307 Condenser
4 # 216938600 Drier-filter
5 216806900 Harness-main
22 216056400 Clip, compressor mtg, SPRING
27 5308002681 Grommet, compressor
28 5303212615 Support, compressor
29 # 216967000 Compressor, w/o electricals
30 216649300 Controller-regulator LP
32 216649100 Clamp, elec cont mtg, compressor
42 216232700 Washer, flat, 1"OD x 0.531"ID
43A 5303212614 Clip, harness mount
47 216629600 Screw, hex washer head, 10-16 x 0.500, tapping
55 218909913 Capacitor-run, 220 VAC, 15 microfarad
86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
* 5303298960 Spacer-tube, 0.237" ID
