Frigidaire FFC05M0AW User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC05M0AW0 FFC05M0AW 134A white 115
MARKET
North America
Publication No.
5995354064
010529
-EN/SERVICE /GS
365
FREEZER
Model number
FFC05M0AW
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216787900
OWNER’S GUIDE - # 216802800
SERVICE DATA SHEET - # 216787900
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.BOX 212378, AUGUSTA, GA 30917

06/01 2
Publication No. FFC05M0AW
5995354064
DOOR

# = Fast-moving Parts 3 06/01
* = Non-Illustrated Parts
FFC05M0AW Publication No.
5995354064
DOOR
POS. NO PART NO DESCRIPTION
1 216480801 Gasket-door,white
9 216061502 Panel-inner lid,white
10 216141101 Plug button,white
11 216106014 Panel-outer lid,white
27 5303212828 Clip,panel

06/01 4
Publication No. FFC05M0AW
5995354064
CABINET

# = Fast-moving Parts 5 06/01
* = Non-Illustrated Parts
FFC05M0AW Publication No.
5995354064
POS. NO PART NO DESCRIPTION
6 216105700 Breaker-hinge\front,white
11 216105600 Breaker-ends,white
12A 240415201 Label-nameplate,white
18 216707200 Knob-control cold
21 # 216787700 Control-temperature
27 216337700 Screw,hex washer head ,10-24 x 0.500
28 216478800 Hinge Assy
30 216105500 Breaker-corners,white
71 5303302714 Screw,8-18x3/4 ,(2)
75 216329402 Panel-access,white
* 216802800 Owners guide
* 5303305324 Paint,touch-up ,white
CABINET

06/01 6
Publication No. FFC05M0AW
5995354064
SYSTEM

# = Fast-moving Parts 7 06/01
* = Non-Illustrated Parts
FFC05M0AW Publication No.
5995354064
POS. NO PART NO DESCRIPTION
1 5300120779 Condenser
4 216634500 Drier-filter
5 # 216696400 Harness-electrical
22 216056400 Clip-spring mtg
27 5308002681 Grommet,compressor
29 # 216784800 Compressor,w/o electricals
30 # 216649304 Controller
32 216694500 Clip,controller
55 # 216696700 Capacitor-run,180 VAC ,15 microfarad
85 216533100 Wire,ground
86 216036600 Screw,rwhd (gx-ca) ,8-32 x 1/2
SYSTEM
