Frigidaire FFC09C6CW User manual

CHEST FREEZER
Model number:
FFC09C6CW
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216929600
OWNER’S GUIDE - # 216802800 ENERGY GUIDE - # 216794008
SERVICE DATA SHEET - # 216929600
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC09C6CW1 FFC09C6CW 134a White 120
MARKET
North America
Publication No.
5995397907
031027
-EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

10/03 2
Publication No FFC09C6CW1
5995397907
DOOR

# = Fast-moving Parts 3 10/03
* = Non-Illustrated Parts
FFC09C6CW1 Publication No.
5995397907
DOOR
POS. NO PART NO DESCRIPTION
1 216481001 Gasket-door,white
2 5303925107 Lock Assy
5 # 216702900 Key,lock
9 216829800 Panel-lid
10 216923001 Plug button,1/4" ,white
11 216117934 Panel-outer lid,white
14 216822900 Switch,light/lamp ,ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket,light/lamp ,25 W
18 216897600 Handle,white
23 216212700 Light-signal,amber
27 5303212828 Clip,panel mtg
34 5303296969 Shield,lid lamp
35 216205400 Washer,signal light
40 216922700 Fastener,.330 dia stud ,handle ,(2)
47 # 216915800 Harness-lid
* 216707800 Screw,PH ,8-32 x 1/2 ,wiring harness
57 216899502 Overlay,white
* 5303917276 Insulation-door,fiberglass ,(bulk)
* 5309948955 Clip-panel

10/03 4
Publication No FFC09C6CW1
5995397907
CABINET

# = Fast-moving Parts 5 10/03
* = Non-Illustrated Parts
FFC09C6CW1 Publication No.
5995397907
POS. NO PART NO DESCRIPTION
1 216117700 Catch-lock
1A 216818900 Support,lock catch clip
3 216502600 Plug,drain ,interior
4 216073905 Plug-drain,exterior
6 216117500 Breaker-hinge side,white
7 216117600 Breaker-lock side
11 216105600 Breaker-ends,white
18 216707200 Knob,temp control
21 # 216787700 Control-temperature
27 216337700 Screw,hex washer head ,10-24 x 0.500
28 216478800 Hinge Assy
30 216105500 Breaker-corners,white
59 216848200 Basket,(2)
59A 216848300 Basket,lower ,(2)
62A 131168200 Screw,pan head ,8-18B x 0.31
75 216782000 Panel-access,white
93 5303161215 Screw,ph truss head ,8-18AB x 0.500
100 216081500 Track,basket
* 216794008 Energy Guide
* 5303305324 Paint,touch-up ,white
CABINET

10/03 6
Publication No FFC09C6CW1
5995397907
SYSTEM

# = Fast-moving Parts 7 10/03
* = Non-Illustrated Parts
FFC09C6CW1 Publication No.
5995397907
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5300120781 Condenser
4 216634500 Drier-filter
5 # 216927700 Harness-ext,main
22 216056400 Clip,compressor mtg ,SPRING
27 5308002681 Grommet,compressor
29 # 216888300 Compressor,w/o electricals
30 216888500 Starter,relay
31 216100113 Overload Protector
53 216347800 Cover terminal,cover-comp term
86 216707800 Screw,PH ,8-32 x 1/2 ,wiring harness
