Frigidaire FFC25C8CW User manual

Product No. FFC25C8CW1
Series 134A
Color white
Volts 115
Wiring Diagram 216901200
Owner's Guide 216960000
Market North America
Energy Guide 216794606
P08F0085.eps P08D0361.eps P08C0786.eps P08S0345.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995422655
04/11/22
(EN/SERVICE/)
365
FREEZER CHEST
Model No.
FFC25C8CW
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995422655 FFC25C8CW1
11/04 2
DOOR

FFC25C8CW1 Publication No: 5995422655
# Functional Parts 3 11/04
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 216469301 Gasket-door, white
2 5303925107 Lock Assy
5 # 216702900 Key, lock
9 216912900 Panel-lid, white
10 216923001 Plug button, 1/4", white
11 216032422 Lid, white
14 216822900 Switch, light/lamp, ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket, light/lamp, 25 W
18 216897600 Handle, white
27 5303212828 Clip, panel mtg
34 216578502 Shield, light
40 216922700 Fastener, .330 dia stud, handle, (2)
47 # 216889600 Harness-lid
57 216899500 Overlay, white
79 # 216898700 Control Board, electronic
* 216905300 Screw, control board, #3-24 x .25, (3)
* 5303917276 Insulation-door, fiberglass, (bulk)

Publication No: 5995422655 FFC25C8CW1
11/04 4
CABINET
6
30
11
7
1
11
28
27
62A
18
75
21
1A
59
59A
93
100
73
74
74
P08C0786
3
4

FFC25C8CW1 Publication No: 5995422655
# Functional Parts 5 11/04
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
1 216909800 Catch-lock, white
1A 216818900 Support, lock catch clip
3 216502600 Plug, drain, interior
4 216073905 Plug-drain, exterior
6 216111400 Breaker-hinge side, white
7 216112000 Breaker-lock side, white
11 216110800 Breaker, chest end, (2)
18 216707200 Knob, temp control
21 # 216844500 Control-temperature
27 216629600 Screw, hex washer head, 10-16 x 0.500, tapping
28 216035400 Hinge
30 216110700 Breaker, corners
59 216916200 Basket, upper
59A 216867400 Basket, lower
62A 131420300 Screw, cr truss head, 8-18AB x 0.750
73 216128200 Divider/drain pan
74 216486700 Support, divider, (4)
75 216034301 Panel, access, white
93 5303161215 Screw, ph truss head, 8-18AB x 0.500
100 216205100 Track, basket
* 216794606 Energy Guide
* 5303305324 Paint, touch-up, white

Publication No: 5995422655 FFC25C8CW1
11/04 6
SYSTEM

FFC25C8CW1 Publication No: 5995422655
# Functional Parts 7 11/04
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 5303925320 Condenser
4 # 216938600 Drier-filter
5 # 216890300 Harness-main
5 * 216890200 Harness, low voltage-, w/thermistor
22 216056400 Clip, compressor mtg, SPRING
27 5308002681 Grommet, compressor
28 5303212615 Support, compressor
29 # 216967000 Compressor, w/o electricals
30 216649300 Controller-regulator LP
32 216649100 Clamp, elec cont mtg, compressor
42 216232700 Washer, flat, 1"OD x 0.531"ID
43A 5303212614 Clip, harness mount
47 216629600 Screw, hex washer head, 10-16 x 0.500, tapping
55 218909913 Capacitor-run, 220 VAC, 15 microfarad
78 216893100 Assy-High Voltage
86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
* 5303298960 Spacer-tube, 0.237" ID
