Frigidaire FFC20K1CW User manual

CHEST FREEZER
Model number:
FFC20K1CW
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216804000
OWNER’S GUIDE - # 216802800 ENERGY GUIDE - # 216794400
SERVICE DATA SHEET - # 216804000
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC20K1CW0 FFC20K1CW 134A white 115
MARKET
North America
Publication No.
5995387825
030324
-EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

03/03 2
Publication No FFC20K1CW0
5995387825
DOOR

# = Fast-moving Parts 3 03/03
* = Non-Illustrated Parts
FFC20K1CW0 Publication No.
5995387825
DOOR
POS. NO PART NO DESCRIPTION
1 216481401 Gasket,lid seal ,white
9 216829506 Panel-inner lid,white
10 216141101 Plug button,white
11 216130121 Panel-outer door/lid,white
14 216822900 Switch,light/lamp ,ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket,light/lamp ,25 W
18 216140200 Handle,recessed ,white
27 5303212828 Clip,panel mtg
31 08009392 Gasket,white
34 5303296969 Shield,lid lamp
47 # 216898800 Harness-lid
* 5303925098 Insulation

03/03 4
Publication No FFC20K1CW0
5995387825
CABINET

# = Fast-moving Parts 5 03/03
* = Non-Illustrated Parts
FFC20K1CW0 Publication No.
5995387825
POS. NO PART NO DESCRIPTION
2 216269500 Adapter,drain hose
3 216502600 Plug,drain ,interior
4 216073900 Plug,drain ,exterior
6 216111200 Breaker,hinge side
11 216110800 Breaker,chest end ,(2)
12A 216892800 Nameplate
18 216707200 Knob,temp control
21 # 216714600 Control-temperature
27 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping
28 216035300 Hinge
30 216110700 Breaker,corners
59 216867300 Basket,upper ,(2)
62 131420300 Screw,cr truss head ,8-18AB x 0.750
75 216034301 Panel,access ,white
94 216140400 Lens,frost indicator ,blue
* 5303305324 Paint,touch-up ,white
* 216794400 Energy Guide
CABINET

03/03 6
Publication No FFC20K1CW0
5995387825
SYSTEM

# = Fast-moving Parts 7 03/03
* = Non-Illustrated Parts
FFC20K1CW0 Publication No.
5995387825
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5303280307 Condenser
4 216634500 Drier-filter
5 216806900 Harness-main
22 216056400 Clip,compressor mtg ,SPRING
27 5308002681 Grommet,compressor
28 5303212615 Support,compressor
29 216851800 Compressor,w/o electricals
30 216649318 Controller
32 216649100 Clamp,elec cont mtg ,compressor
42 216232700 Washer,flat ,1"OD x 0.531"ID
43A 5303212614 Clip,harness mount
47 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping
55 # 216787800 Capacitor,run ,50/60 Hz ,220 VAC ,12 microfarad
86 216036600 Screw,ph washer head ,8-32CA x 0.500 ,thread forming
* 5303298960 Spacer-tube,0.237" ID
