FREEZER
Model No.
FFU14M8H
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216576600
OWNER’S GUIDE - # 216768600
SERVICE DATA SHEET - #216576600
ELECTROLUX HOME PRODUCTS NORTH AMERICA.
P.O.Box 212378, Augusta, GA 30917
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFU14M8HW1 FFU14M8H 134A white 115
MARKET
North America
Publication No.
5995345260
001019
-EN/SERVICE /GS
365
10/00 2
Publication No. FFU14M8HW1
5995345260
DOOR
# = Fast-moving Parts 3 10/00
* = Non-Illustrated Parts
FFU14M8HW1 Publication No.
5995345260
DOOR
POS. NO PART NO DESCRIPTION
1 216522306 Gasket-door,white
2 5303925107 Lock Assy
5 # 216388700 Key,lock
6 5300158222 Screw-anchor,8-18
9 5303925466 Panel-outer door,white
11 216527613 Panel-inner door,frzr
12 316095402 Label-nameplate,Frigidaire ,white
12A 216373000 Frame-nameplate
13 08016354 Door Stop
14 5303313518 Washer,sealing
18 216446900 Handle,white
21A 08005520 Screw-door stop mtg,flat hd metric , 4.0 x 0.7-19.7
22 216443600 Bearing
22A 216503200 Bearing-hinge,btm
25 216022800 Screw,washer head ,8-18 X 1/2
26 216524300 Gasket,secondary
27 5303212828 Clip,panel
28 216523302 Rack-shelf
32 5309950074 Valve-breather
57 3017682 Insert-handle
64 216403700 Plug-button,base door
93 5303161215 Screw
10/00 4
Publication No. FFU14M8HW1
5995345260
CABINET
6
26
27 28
16
15
34
132
14
62
72
66
46
96
44
23
46
64
2
P08C0216
21
20
86
18
56
87
22
24
9
41
40
38
39
63
83
83
81
81
65
7
9
3
32
29
35
# = Fast-moving Parts 5 10/00
* = Non-Illustrated Parts
FFU14M8HW1 Publication No.
5995345260
CABINET
POS. NO PART NO DESCRIPTION
2 216269500 Adapter-drain
3 216502600 Plug-drain,interior
6 216604300 Breaker Kit w/corners
7 216603800 Breaker Kit w/corners,lock catch
9 216603400 Breaker Kit w/corners,28", top or bottom
14 216472300 Switch-light plunger
15 216608600 Bulb-light,40W ,130V
16 5300136117 Socket-light/lamp
18 216591802 Knob,temp control
20 5303288184 Cover-control housing
21 216620200 Control-temperature
22 08037931 Clamp,cap tube ,cold control
23 5308002706 Light-signal,amber
24 5300052943 Screw-clamp,truss hd cr ,control
26 216503300 Ramp,closer ,door
27 5303205738 Screw-hinge,cr ,1/4-20 x 1.000 ,btm
28 216247400 Hinge-bottom
29 216313502 Hose-drain
32 5308005500 Drain
34 216557500 Shield-light
35 216273000 Clip,drain hose
38 5303925086 Hinge-upper
39 5303294372 Nut-insert,hinge
40 5303212912 Cover-hinge
41 5303212937 Screw-top hinge
44 # 5303017178 Switch-rocker
46 08037851 Screw,PH type AB ,8-32x1/2 , wiring harness
56 09950853 Screw-control knob,phillips ,4-40 x 3/8
62 131420300 Screw,cr truss head ,8-18AB x 0.750
63 216396900 Foot-adjustable
64 08016369 Bracket
65 216447600 Drop front
66 # 216713700 Buzzer,alarm
72 216591212 Grille/Kickplate
81 216571000 Support-drop front,top
83 216571100 Support-drop front,btm
86 216036600 Screw,rwhd (gx-ca) ,8-32 x 1/2
87 08037849 Screw
96 08016772 Light-signal,red
132 5303283898 Screw,6-20AB x 3/8
* 09948773 Insulation,drain tube
* 216539100 Wiring Harness,alarm
10/00 6
Publication No. FFU14M8HW1
5995345260
SYSTEM
# = Fast-moving Parts 7 10/00
* = Non-Illustrated Parts
FFU14M8HW1 Publication No.
5995345260
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5300123788 Condenser
3 216605600 Trim-shelf,white ,evap
4 216634500 Drier-filter
5 216766300 Harness-main
6 3091418 Support-shelf,front LH
7 08037928 Support-shelf,front RH
11 216474600 Support-rear shelf
12 216225700 Grommet-spacer
13 216138900 Screw,hex sems ,8-18AB x 1.00 ,evap
15A 216404900 Heat Exchanger
26 216511900 Spacer tube,(3)
27 216498900 Grommet,compressor
29 216557000 Compressor,assy
30 216596700 Starter,factory instal
31 216100116 Overload Protector,factory instal
34 5306594529 Sleeve-compressor
35 5303272328 Screw,Ind hex sems ,1/4-28 unfx , compressor
36 # 216070100 Grid-top evaporator
37 # 216070200 Shelf-top evaporator
38 # 216070300 Shelf-middle evaporator
40 # 216070400 Shelf-bottom evaporator
43 09950610 Clip,cord
43A 216629700 Clip-harness
53 216347800 Cover terminal,cover-comp term
* 216502500 Sleeve-tube insert
* 216762300 Harness,int
