Frigidaire FFU14FC4AW User manual

FREEZER
Model number
FFU14C4AW
FFU17C4AW
FFU20C4AW
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216803600 / 216803700
OWNER’S GUIDE - # 216802800
SERVICE DATA SHEET - #216803600 / 216803700
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFU14FC4AW0 FFU14FC4AW 134A white 115
FFU17FC4AW0 FFU17FC4AW 134A white 115
FFU20FC4AW0 FFU20FC4AW 134A white 115
MARKET
North America
Publication No.
5995357976
010822
-EN/SERVICE /GS
365
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O BOX 212378, AUGUSTA , GA 30917

09/01 2
Publication No FFU14/17/20C4AW
5995357976
DOOR

# = Fast-moving Parts 3 09/01
* = Non-Illustrated Parts
FFU14/17/20C4AW Publication No.
5995357976
DOOR
A = FFU14FC4A (FFU14FC4AW0)
B = FFU17FC4A (FFU17FC4AW0)
C = FFU20FC4A (FFU20FC4AW0)
POS. NO PART NO DESCRIPTION
1 216522306 A - - Gasket-door,white
1 216522309 - B - Gasket-door,white
1 216522312 - - C Gasket-door,white
2 # 5303925107 A B C Lock Assy
5 # 216702900 A B C Key,lock
6 5300158222 A B C Screw-anchor,8-18
9 216527609 A - - Panel-inner door,frzr
9 216527806 - B - Panel-inner door,white
9 216528108 - - C Panel-inner door
11 5303925466 A - - Panel-outer door,white
11 5303925474 - B - Panel-outer door,white
11 5303925476 - - C Panel-outer door,white
12 216816901 A B C Nameplate
12A 216817100 A B C Nameplate
13 08016354 A B C Door Stop
14 5303313518 A B C Washer,sealing
18 216446900 A B C Handle,white
21A 08005520 A B C Screw-dr stop mtg,flat hd metric , 4.0 x 0.7-19.7
22 216443600 A B C Bearing
22A 216503200 A B C Bearing-hinge,btm
26 216524300 A - - Gasket,secondary
26 216524200 - B C Gasket,secondary
27 5303212828 A B C Clip,panel
28 216523302 A - - Rack-shelf
28 216523102 - B C Rack-shelf,wide ,white
32 5309950074 A B C Valve-breather
57 3017682 A B C Insert-handle
64 216403700 A B C Plug-button,base door
93 5303161215 A B C Screw
* 5303925098 A B C Insulation

09/01 4
Publication No FFU14/17/20C4AW
5995357976
CABINET

# = Fast-moving Parts 5 09/01
* = Non-Illustrated Parts
FFU14/17/20C4AW Publication No.
5995357976
A = FFU14FC4A (FFU14FC4AW0)
B = FFU17FC4A (FFU17FC4AW0)
C = FFU20FC4A (FFU20FC4AW0)
POS. NO PART NO DESCRIPTION
3 216503100 A B C Screen-drain
5 # 216325600 A B C Fan Blade
6 216603400 A - - Breaker Kit w/corners,28", top or btom
6 216604200 - B - Breaker Kit w/corners
6 216604100 - - C Breaker Kit w/corners
7 216603800 A - - Breaker Kit w/corners,lock catch
7 216603700 - B - Breaker Kit w/corners,lock catch
7 216603600 - - C Breaker Kit w/corners,lock catch
9 216604300 A - - Breaker Kit w/corners
9 216603300 - B C Breaker Kit w/corners,32",top or btm
13 216787000 A B C Motor-fan
18 216707200 A B C Knob-control cold
19 216204900 A B - Gasket,evap cover
19 216204901 - - C Gasket-cover evap
20 216230300 A B C Cover,temp control
21 # 216788000 A - - Control-temperature
21 216715200 - B C Control-temperature
22 05878562 A B C Clamp,cap tube ,cold control
22A 5303916855 A B C Tube,sensor sleeve ,plastic ,clear
23 06594648 A B C Light-signal,amber
24 5300052943 A B C Screw-clamp,truss hd cr ,control
25 216737000 A - - Cover-evaporator
25 216737100 - B - Cover-evaporator
25 216737200 - - C Cover-evaporator
26 216503300 A B C Ramp,closer ,door
27 5303205738 A B C Screw-hinge,cr ,1/4-20 x 1.000 ,btm
28 216247400 A B C Hinge-bottom
32 5308005500 A B C Drain
33 216252001 A B C Bracket,signal light
34 216557500 A - - Shield-light
34 216557600 - B C Shield-light
38 5303925086 A B C Hinge-upper
39 5303294372 A B C Nut-insert,hinge
40 5303212912 A B C Cover-hinge
41 5303212937 A B C Screw-top hinge
42 216546100 A - - Shelf,16.69 X 23.88 WH,16.69x23.88 ,
42 216458400 - B C Shelf,14.50x27.88 ,WH
42A 216546200 A - - Shelf,14.50 X 23.88 WH,14.50x23.88 ,
42A 216458200 - B - Shelf,12.50x27.88 ,white
42A 216458500 - - C Shelf,wire ,16.69x26.88 ,white ,(3)
42B 216546000 - - C Shelf-fixed w/frame,white
47 216661600 A B C Baffle-plate
49 216278800 A - - Trivet
49 216278900 - B - Trivet
49 216279000 - - C Trivet
50 216394000 A B C Bracket-motor mtg fan
63 216396900 A B C Foot-adjustable
71A 216347500 A B C Screw,quadrex
72 216591215 A - - Grille/Kickplate
72 216591110 - B C Grille/Kickplate
80 06594601 A B C Bracket,control
93 5303161215 A B C Screw
93A 5303302760 A B C Screw
108 216388600 A B C Trap-drain
132 5303283898 A B C Screw,6-20AB x 3/8
* 09948773 A B C Insulation,drain tube
* 216159800 A B C Cover-indicator light
* 216502400 A B C Grommet-shelf mtg
* 216802800 A B C Owners guide
* 5303305324 A B C Paint,touch-up ,white
CABINET

09/01 6
Publication No FFU14/17/20C4AW
5995357976
SYSTEM

# = Fast-moving Parts 7 09/01
* = Non-Illustrated Parts
FFU14/17/20C4AW Publication No.
5995357976
SYSTEM
A = FFU14FC4A (FFU14FC4AW0)
B = FFU17FC4A (FFU17FC4AW0)
C = FFU20FC4A (FFU20FC4AW0)
POS. NO PART NO DESCRIPTION
1 # 5300123788 A - - Condenser
1 # 5300083897 - B C Condenser
2 5308000110 A B C Strap-evap/heater,aluminum ,(2)
4 216634500 A B C Drier-filter
5 # 216823900 A B C Harness-main
14 216740000 A - - Heater-defrost
14 216730700 - B C Heater-defrost
15 216737400 A - - Evaporator
15 # 216737300 - B C Evaporator
15A 216565700 A - - Heat Exchanger
15A 216783200 - B C Heat Exchanger
18 216727600 A B C Insulator-evap,styrofoam
19 216727700 A B C Insulator-evap,styrofoam
20 216731000 A B C Thermostat-defrost
23 # 216744500 A B C Timer-defrost
24 08016580 A B C Bracket
27 216498900 A B C Grommet,compressor
29 # 216784300 A - - Compressor,w/o electricals
29 # 216788400 - B - Compressor,w/o electricals
29 # 216788600 - - C Compressor,w/o electricals
30 216649313 A - - Controller
30 216649311 - B - Controller
30 # 216649303 - - C Controller
31A 216601800 A - - Pan-drain,production compr
31A 216517800 - B C Pan-drain
32 216649200 A - - Clip,controller
32 218740800 - B C Clamp,elec cont mtg ,compressor
34 5306594529 A B C Sleeve-compressor
35 5303272328 A B C Screw,Ind hex sems ,1/4-28 unfx , compressor
43A 216629700 A B C Clip-harness
55 # 216787800 A - - Capacitor-run
55 # 218909901 - B C Capacitor-run,220 VAC ,15 microfarad
86 216036600 A B C Screw,rwhd (gx-ca) ,8-32 x 1/2
87 08037849 A B C Screw
130 216730400 A B C Support-evaporator
* 216816500 A - - Pan-drain
* 216511900 - B C Spacer tube,(3)
* 216502500 A B C Sleeve-tube insert
