Signature Features
Store-More™ Capacity
Our large capacity freezer gives you
room to store more.
Lock with Pop-Out Key
Key is automatically ejected upon
locking for maximum security.
Store-More™
Removable Basket
Convenient lift-out storage for easy
access to most small frozen items or
items that are most frequently accessed.
SpaceWise®
Organization System
Heavy-duty dividers allow you to
organize food storage like never before.
System includes and accommodates pre-
printed storage labels.
Manual Defrost
25 Cu. Ft. Chest
Product Dimensions
Height (Including Lid) 35"
Width 73-1/4"
Depth 29-1/2"
More Easy-To-Use Features
Bright Lighting
Our bright lighting makes it easy to see
what’s inside
Power-On Indicator Light
Know at a glance that your freezer is
working.
Adjustable Temp Control
Defrost Water Drain
Lid Handle
ENERGY STAR®
Available in:
Freezer
FGCH25M8L W
White
(W)

Chest Freezers
Frigidaire Baseline
Specifications
subject to change.
Product Dimensions
A - Height (Including Lid)
B - Width
C - Depth
Height with Lid Open 90˚
35"
73-1/4"
29-1/2"
60-13/16"
NOTE: For planning purposes only. Always consult local and
national electric codes. Refer to Product Installation Guide for
detailed installation instructions on the web at frigidaire.com.
Accessories information available
on the web at frigidaire.com
1An electrical supply with grounded three-prong receptacle is required.
The power supply circuit must be installed in accordance with current
edition of National Electrical Code (NFPA 70) and local codes &
ordinances.
Features
Defrost
Adjustable Temperature Control
Interior Lighting
Store-More™ Removable Baskets
Food Organization System
Defrost Water Drain
Lid Handle
Lock with Pop-Out Key
Power-On Light
Certifications
ENERGY STAR®
CSA Rating
Specifications
Total Capacity (Cu. Ft.)
Annual Energy (kWH)
Annual Energy Cost (.1065/ kWH)
Power Supply Connection Location
Voltage Rating
Connected Load (kW rating) @ 115 Volts1
Amps @ 115 Volts
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
Manual
Yes
Bright
3
Yes
Yes
Yes
Yes
Yes
Yes
Household
24.6
508
$54
Bottom Rear
115V / 60Hz / 5A
.6
5
15
224 Lbs.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FGCH25M8L 01/12 © 2012 Electrolux Home Products, Inc.
Freezer
FGCH25M8L W 25 Cu. Ft. Chest

Chest Freezer Specifications
•Product Shipping Weight (approx.) – 224 Lbs.
•An electrical supply with grounded three-prong receptacle is
required. The power supply circuit must be installed in accordance
with current edition of National Electrical Code (NFPA 70) and
local codes & ordinances.
•Voltage Rating – 115V / 60 Hz / 5 Amps
•Connected Load (kW Rating) @ 115 Volts = 0.6 kW
•Amps @ 115 Volts = 5 Amps
•Always consult local and national electric codes.
•For adequate air circulation, allow 3" minimum clearance on all
sides with 1" at bottom.
•Locate where surrounding air temperature will not exceed 110° F,
to ensure optimum performance. (Temperatures 32° F and below
will NOT affect operation.)
•All bottom corners of unit MUST rest firmly on solid level surface
of hard material, same height as flooring. Surface must be strong
and stable enough to support unit when fully loaded.
•Equipped with adjustable leveling legs to ensure unit is level,
which is required in order to function properly.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
25 Cu. Ft. Chest Freezers
Frigidaire
Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FGCH25M8L 11/11 © 2011 Electrolux Home Products, Inc.
Freezer
FGCH25M8L W 25 Cu. Ft. Chest
