Frigidaire GLEH1642F User manual

Product No. GLEH1642FS0
Market North America
Color white
Volts 240
Wiring Diagram 134833100
Owner's Guide 134838500
Installation Instructions 134837700
Operating Instructions 134396400
Operating Instructions 134578800
Energy Guide 134815100
P17L0011.eps P17U0049.eps P17B0051.eps P17C0080.eps P17R0018.eps P17T0060.eps
134833100-1.eps 134833100-2.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995482162
07/01/11
(EN/SERVICE/WC)
361
FRONT-LOAD
LAUNDRY CENTER
WITH ELECTRIC
DRYER
Model No.
GLEH1642F
Copyright ©2007 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995482162 GLEH1642FS0
01/07 2
UPPER CABINET/DRUM HEATER
35 36
4
562
2
9
2
11
12
13
2
17
38
32
20
24
1
62
3
22
27
18
23
62
25
26
28
21
39
31
47
44
49
18
30
20
29
54 46
48
42
50
33
34
14
15
P17U0049
59
42 41

GLEH1642FS0 Publication No: 5995482162
# Functional Parts 3 01/07
* Non-Illustrated Parts
UPPER CABINET/DRUM HEATER
POS. NO PART NO. DESCRIPTION
1 131084710 Panel, white, left side
2 131168200 Screw, pan head, 8-18B x 0.31
3 131883301 Panel, top
4 134799902 Panel, rear, steel, galvanized
5 5303281019 Ball, grounding
6 5303281020 Clip, ball, steel, flat nut
9 3204249 Panel, motor access, rear
11 3204250 Cover, terminal block
12 131825900 Bearing, drum support
13 131724300 Bracket, bearing support
14 131205400 Screw, bracket mtg., 10-16B x 1.375, cr/sq drive
15 # 131475300 Heater Assy, w/housing
17 3204254 Baffle, heater shield
18 131477000 Screw, 10-16AB x 0.375
20 131963900 Glide, drum
21 134122552 Drum, dryer, stainless steel, service kit
22 131636280 Panel, front, white, w/lamp hole
23 134134700 Seal, felt, lower
24 134036400 Seal, felt, upper
25 131658800 Door Catch
26 # 131843101 Switch, door, with drum light
27 131359600 Lint Trap
28 134440000 Clip, guide
29 131382300 Screw, quadrex head, 10-14 x 1.00, vane mtg., special
30 5304405283 Vane, straight, gray
31 131202300 Screw, 10-16AB x 0.625
32 131777700 Shaft, drum support, ballhitch
33 # 3204267 Thermostat, safety
34 131243800 Screw, pan hd locking, 8-32CA x 0.375, cup point
35 131892100 Screw, 6-20B x 0.230
36 # 134120900 Thermal Limiter
38 131084810 Panel, white, right side
39 131084402 Panel, access, white, front
41 134222900 Hinge, dryer door
42 134156200 Screw, flat head, 8-18AB x 0.44, quad drive
44 131129900 Gasket, door seal
46 131789400 Handle, door, white
47 134406203 Panel, inner door, white
48 131789303 Panel, outer door, white
49 5303211430 Door Strike
50 134535300 Insulator, heat shield, outer door
54 # 134403200 Wiring Harness, door switch, with light
59 # 131843500 Lamp Assy, drum light, w/mtg bracket
62 131258400 Screw, 10-16AB x 0.500

Publication No: 5995482162 GLEH1642FS0
01/07 4
MOTOR/BLOWER/BELT
P17B0051
4
6
8
12
10A
2
9
10
27
28
15
13
16
250
48
42
38
43
2
33
2
19
18
2
2
23
25
22
2
2
2
16
7
57
1

GLEH1642FS0 Publication No: 5995482162
# Functional Parts 5 01/07
* Non-Illustrated Parts
MOTOR/BLOWER/BELT
POS. NO PART NO. DESCRIPTION
1 131295200 Seal, air duct
2 131168200 Screw, pan head, 8-18B x 0.31
4 131477000 Screw, 10-16AB x 0.375
6 134086300 Duct, air
7 3204490 Seal, housing, to air duct
8 3205245 Screw, pan head, 6-18AB x 0.60
9 5303304824 Clamp
10 134611700 Housing, blower, front, with seal
10A 134608200 Housing, blower, rear
12 131476300 Blower Wheel
13 134608400 Ground Strap, thermostat
15 # 134048800 Thermostat, control
16 131243700 Screw, pan head, 8-18AB x 0.375
18 131413600 Cradle, motor mount, with idler stud
19 134613501 Panel, motor cradle mt, upper
22 3205241 Spring, idler
23 131863100 Idler Arm Assy, with pulley
25 # 134503900 Belt, dryer drive
27 134242400 Clamp, motor mtg.
28 # 134196600 Motor, dryer drive, with pulley
33 131731400 Shield, access area, cover
38 3204320 Elbow, exhaust duct
39 131205100 Screw, #8 pan head, 10-10B x 0.500, cr/sq drive
42 134154100 Screw, hex washer head, 10-32 x 0.375, ground
42 5304439185 Bracket, marriage, interior
43 134305100 Screw, hex washer head, 1/4-20 x 1.000, special
48 131731310 Panel, dryer, bottom rear
50 3204329 Cover, safety, lower front
57 131729300 Cover, moisture sensor

Publication No: 5995482162 GLEH1642FS0
01/07 6
CONTROL PANEL
MAX
LIQUID
BLEACH
LIQUID
BLEACH
MAX
FABRIC
SOFTEN
FABRIC
SOFTEN
31
23
29
21
4
21A 25
21B
2
4
12
20 34
11
22
13
7
32
18
22
1
8
6
3
17 19
51
52
5
10
16A
14
16
37
45
33
38
36
43
39
26
46
26
2
27
48
34
59
54
55
56
60
58
P17C0080
2
33
33
24
35
15
9
44

GLEH1642FS0 Publication No: 5995482162
# Functional Parts 7 01/07
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
1 # 131960800 Timer, dryer, 4 off
2 131168200 Screw, pan head, 8-18B x 0.31
3 # 134136700 Wiring Harness, dryer control
4 131873401 Knob, rotary, white
5 # 134399900 Switch, dryer temp, LCD
6 # 134392000 Wiring Harness, washer control
7 131243800 Screw, pan hd locking, 8-32CA x 0.375, cup point
8 # 134803600 Timer, washer
9 # 134400000 Switch, rotary, 2 position
10 # 134399700 Switch, start, LCD
11 5303283289 Screw, cr pan head, 8-32 x 0.250, thread forming
12 # 134040800 Switch, on/off, white, round
13 131311700 Screw, pan head quad, 8-32 x 0.15
14 # 131724500 Buzzer
15 # 134437700 Switch, water temp, 4 position
16 # 131724700 Lamp, status light
16A 131724800 Lens, status light, clear
17 134263400 Bracket, control mount
18 134321500 Panel, trimplate, console front
19 # 5303286537 Buzzer
20 131288101 End Cap, white, LH
21 131873301 Knob, dryer timer, white
21A 131167601 Knob, washer timer, white
21B 5308015493 Spacer, washer, timer shaft
22 3161259 Screw, switch mtg, 6-32 x 0 .19, (2), sems
23 # 134605400 Wiring Harness, main
24 134156200 Screw, flat head, 8-18AB x 0.44, quad drive
25 131167701 Indicator, timer pointer, white/blue, washer
26 131823400 Screw, 8-18 x 2.00
27 131870600 Panel, disp drawer mt.
29 # 134571400 Wiring Harness, main, washer
29* 5303161300 Strap, plastic
31 131288211 End Cap, white, RH
32 3204357 Clip, grounding
33 131306216 Clamp
34 131243700 Screw, pan head, 8-18AB x 0.375
35 5308014350 Clip, end cap mtg, U-type
36 # 131974700 Valve, dispenser, w/seal
37 131271600 Hose, tub
38 # 131803710 Dispenser Assy
39 131863300 Siphon
39* 131307900 Clamp, siphon/bellows
43 131749200 Gasket, seal
44 131786000 Hose, dispenser
45 131786100 Hose, siphon/valve
46 134191412 Panel, control mtg., wing bend
48 # 134818201 Switch, pressure, single level
51 134426400 Bracket, pc board mount, (2)
52 # 134216300 Control Board, moisture sensor
54 131272100 Cover, bleach
55 131272000 Cover, softener
56 131271910 Drawer, dispenser
58 131729500 Handle, dispenser, with trim
59 131714900 Latch, drawer handle, white
60 131427500 Spring
* 131931201 Dampener, vibration, 3.5 x 2 x 2 in., foam

Publication No: 5995482162 GLEH1642FS0
01/07 8
LOWER CABINET/TOP
2
22
1
24
25
25
2
44
8
33
35
13
13
14
80
45
28
4
70
77
76
76
75
75
74
74
39
36
9
27
9
17
19 18
58A 58
30
39
7
15
29
16
10
11
12
P17R0018
21
2
20 22
37
39

GLEH1642FS0 Publication No: 5995482162
# Functional Parts 9 01/07
* Non-Illustrated Parts
LOWER CABINET/TOP
POS. NO PART NO. DESCRIPTION
1 5303271009 Hose, inlet, 48 inch long
* 5303161296 Washer, inlet hose
2 131168200 Screw, pan head, 8-18B x 0.31
4 # 134733600 Controller Assy, speed, w/base & shield
7 131205300 Screw, 10-16 x 0.750
8 # 131763245 Door Lock/Switch Assy
9 131303300 Screw, pan head, 10-16AB x 0.500, locking
10 134224600 Frame, outer door
11 131278800 Panel, door glass
12 134195900 Frame, inner door
13 134227100 Screw, flat head, 10-16 x 0.600, quadrex
14 131763310 Striker, door/lock/sw
15 134202200 Hinge, door
16 131696300 Screw, quad pan head, 10-16 x 0.312
17 131346400 Pin, panel locator
18 131279300 Panel, service, white, front
19 131358400 Screw, hex washer hd, 8-18AB x 1.125
20 131460900 Bracket, top panel mtg., front
21 131243700 Screw, pan head, 8-18AB x 0.375
22 131279500 Retainer, spring steel
24 134086862 Panel, white, top
25 134381900 Trim, filler, white, LS-top panel
25 134381910 Trim, filler, white, RS-top panel
26 131311900 Screw, quadrex ph, 8-18AB x 0.500
27 134193300 Bracket, hinge support
28 131978500 Panel, back
29 131752040 Panel, cabinet front, white
30 131859600 Shield, overflow
33 # 134812800 Valve, water, 115 V
35 131732903 Bracket, reinforcement, top rear
36 131841600 Leveling Leg Assy, bolt, pad & nut
37 131304200 Roller Assy
39 134178901 Screw, 8-18AB x 0.455
44 131707800 Ring, drain hose
45 # 134592700 Hose, drain
58 131800410 Insulation, noise absorber
58A 131744202 Damper, vibration
70 134048600 Shield, drip protector
74 134301300 Spacer, dryer mtg, RS
74 134301310 Spacer, dryer mtg, LS
75 134301400 Brace, side, (2)
76 134390701 Panel, side, white, RS/LS, (2)
77 131458220 Base Plate
80 134547800 Screw, 10-16AB x 0.375

Publication No: 5995482162 GLEH1642FS0
01/07 10
MOTOR/TUB
7
49
8
3
36
14 16
13 19
20
21
17
18
12
11
10
15
35
33
41
48
48
43
42 32
31
33
30
31
45
44
26
27
28
29
25
3
23
22
P17T0060
40

GLEH1642FS0 Publication No: 5995482162
# Functional Parts 11 01/07
* Non-Illustrated Parts
MOTOR/TUB
POS. NO PART NO. DESCRIPTION
3 131793302 Bolt, carriage, 1/4-20 x 4.00
6 131975300 Counterweight, one piece
7 131277300 Spring, boot retainer
8 134177600 Bellows, door boot
10 131304700 Nut, hex, 1/4-20 UNC-2B, (2)
11 131276900 Washer, Bellville, spring steel
12 131793500 Plate, counterweight
13 131618600 Shell, outer tub, front
14 134144700 Spring Assy, suspension, w/sleeves
14* 131560000 Sleeve, protector, lwr spring hook
14* 131592200 Sleeve, protector, upr spring hook
15 131303900 Screw, hex washer head, 1/4-10A x 2.165
16 131618500 Drum Assy, spin basket
17 131274600 Vane
18 131302800 Screw, 10-16AB x 0.375
19 # 131770600 Motor
20 131303500 Screw, 12-14AB x 1.50, motor mtg.
21 134146100 O-ring, tub
22 131462800 Shell, outer tub, rear, with bearing
23 134125900 Counterweight, drum rear
25 134051000 Belt, drive, 6-rib
26 131883400 Pulley, drum drive, large, rear
27 131304400 Washer, 0.41 x 1.50, 0.12 thick
28 131304500 Washer, lock, 3/8
29 131303700 Screw, pulley mtg., m10 x 0.92, metric
30 131268200 Shock Absorber, air, stabilizer
31 131268300 Pin, shock mtg.
32 131268100 Bracket, shock mtg.
33 134532200 Screw, 10-16AB x 0.500
35 134051100 Pump, drain
40 134565200 Filter, pump
41 134044200 Hose, coin trap, tub-to-pump
42 134737300 Clamp, hose
43 131277500 Chamber, air
44 131789900 Tube Assy, air pressure, w/air chamber
45 131306202 Clamp, hose
48 131306234 Clamp, hose, wire
49 134266500 Clamp, bellows/boot, 0.059 OD wire, spring held
* 134815100 Energy Guide

Publication No: 5995482162 GLEH1642FS0
01/07 12
WIRING DIAGRAM

GLEH1642FS0 Publication No: 5995482162
# Functional Parts 13 01/07
* Non-Illustrated Parts
WIRING DIAGRAM
