Frigidaire FEB27T6F User manual

FEB27T6FC.tif CPLEB30T9FCA.eps BUFEB27T6FCA.eps BLFEB27T6FCA.eps
DFEB30S5DCA.eps 318046121.eps
Product No. FEB27T6FCA
37054783E60S1
Series 27" double
Color stainless
Market North America
Wiring Diagram 318046121
Owner's Guide 318200943
Installation Instructions 318201514
Service Data Sheet 318047306
Timer Guide 318200137
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995471033
06/07/27
(EN/SERVICE/ECL)
377
DOUBLE ELECTRIC
WALL OVEN
Model No.
FEB27T6F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995471033 FEB27T6FCA
07/06 2
CONTROL PANEL

FEB27T6FCA Publication No: 5995471033
# Functional Parts 3 07/06
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
2A 318257301 Shield, oven top
2B 318260101 Cover, box
19 318271536 Control Panel Assembly, steel/glass, stainless/black, w/touch pad
20 # 316443801 Control, electronic, ES610W2, dual oven
77 316247900 Spacer, power board, (2)
77A 316114100 Spacer, (2)
97 316443902 Board, relay, dual oven
* 318231751 Harness, wiring, control-relay
* 5303211311 Screw, 8 x 0.500
* 5303311306 Screw, 8-18 x 0.375, (3)

Publication No: 5995471033 FEB27T6FCA
07/06 4
UPPER OVEN

FEB27T6FCA Publication No: 5995471033
# Functional Parts 5 07/06
* Non-Illustrated Parts
UPPER OVEN
POS. NO PART NO. DESCRIPTION
1 318259212 Back, main
2 318258910 Shield, insulation, upper
6 318262602 Rack, oven, (2)
9 5303317977 Pan, broiler
10 5303317976 Insert, broiler pan
12 # 318089917 Switch, light
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
54 318222400 Housing, oven light
58A 318285060 Insulation, rear & bottom, oven wrapper
58B 318285059 Insulation, top & sides, oven wrapper
58D 318285058 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
66 # 318255601 Element, broil, 3400W
67 # 318255103 Element, bake, 2300W
68 5304403015 Support, hanger, (2), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260001 Panel, rear box
71* 318340200 Bracket, insul. panel
76 318056222 Front, oven
80 5303320846 Plate, oven mtg
* 318249401 Tube, protector
81 318192400 Spring, oven
82 318258710 Shield, insulation, lower
83 318261503 Liner, oven assy
86 5303310524 Receptacle, hinge
89 # 318261211 Motor, latch assy
* # 318231750 Harness, wiring, main, latch
* # 318199744 Wiring Harness, latch, BAS
* # 318199746 Wiring Harness, latch, NO BAS
99 318252800 Support, side
* 5303300265 Screw, 8-18 X 1/2, (2)
107 318219401 Cover, fan
108# 318073018 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
109 316136400 Blade, fan
111 316136600 Nut, fan retainer
119# 318004900 Switch, thermal
125# 316415800 Motor, fan
125* 5303316994 Insulation, 3.81 x 3.13
126 318142100 Washer, motor, RH, convection
127 318317100 Adapter Assembly, vent tube, w/converter
131 318272900 Box, vent
132 318003000 Plate, shield
142 318123910 Deflector
143 318172904 Support, wire
163 318014111 Spacer
185 318014700 Spacer, oven shield, (4)
263 316136500 Washer, flat
264 318257711 Trim, oven, black, front
310 5304440067 Cabinet Mounting Kit
311 318246010 Bracket, cabinet mtg, (2)
311* 5304438005 Screw, 6 x 1, black
312 318246702 Tool, cabinet bracket, RH
312 318246703 Tool, cabinet bracket, LH
* 318165800 Spacer
* 5303211311 Screw, 8 x 0.500
* 5303323277 Screw, 8-18 X 13/32
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995471033 FEB27T6FCA
07/06 6
LOWER OVEN

FEB27T6FCA Publication No: 5995471033
# Functional Parts 7 07/06
* Non-Illustrated Parts
LOWER OVEN
POS. NO PART NO. DESCRIPTION
1 318259212 Back, main
2 318258910 Shield, insulation, upper
6 318345209 Rack, oven, (3)
12 # 318089917 Switch, light
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
54 318222400 Housing, oven light
56 318259914 Trim, side filler, black, RH
56A 318259915 Trim, side filler, black, LH
58A 318285060 Insulation, rear & bottom, oven wrapper
58B 318285059 Insulation, top & sides, oven wrapper
58D 318285058 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
62 316056000 Terminal Block
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
66 # 318255601 Element, broil, 3400W
67 # 318255103 Element, bake, 2300W
68 5304403015 Support, hanger, (2), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260001 Panel, rear box
71* 318340200 Bracket, insul. panel
76 318056222 Front, oven
80 5303320846 Plate, oven mtg
* 318249401 Tube, protector
81 318192400 Spring, oven
82 318258710 Shield, insulation, lower
83 318261503 Liner, oven assy
86 5303310524 Receptacle, hinge
87 318260601 Bracket, cable mtg.
89 # 318261211 Motor, latch assy
* # 318231750 Harness, wiring, main, latch
* # 318199744 Wiring Harness, latch, BAS
* # 318199746 Wiring Harness, latch, NO BAS
90 318259711 Trim, oven front, black, bottom
99 318256200 Bracket, side, bottom, (2)
107 318219401 Cover, fan
108# 318073018 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
109 316136400 Blade, fan
111 316136600 Nut, fan retainer
119# 318004900 Switch, thermal
125# 316415800 Motor, fan
125* 5303316994 Insulation, 3.81 x 3.13
126 318142100 Washer, motor, RH, convection
127 318317100 Adapter Assembly, vent tube, w/converter
142 318123910 Deflector
143 318172904 Support, wire
163 318014111 Spacer
185 318014700 Spacer, oven shield, (4)
263 316136500 Washer, flat
264 318257811 Trim, oven, black, front
* # 318078543 Box & wires assy
* 318231747 Harness, wiring, main
* 318165800 Spacer
* 5303211311 Screw, 8 x 0.500
* 5303323277 Screw, 8-18 X 13/32
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995471033 FEB27T6FCA
07/06 8
DOORS

FEB27T6FCA Publication No: 5995471033
# Functional Parts 9 07/06
* Non-Illustrated Parts
DOORS
POS. NO PART NO. DESCRIPTION
3A 318260401 Trim, oven door, side, (2)
3B 318262101 Cover, rear door, black, (2)
6 318260510 Baffle, door
7 318285057 Insulation, oven door
7A 318285061 Insulation, (2)
8 318212200 Glass, oven door, heat barrier
9 318259615 Liner, upper door
10 5303311174 Screw, 10-24 x 3/8
12 318053135 Seal, oven door
13 318272106 Door Assy, glass, stainless steel, upper door, w/tape & foil
17 318264700 Spacer, glass, (2)
23 318024722 Hinge, door, (2)
24 318260311 Trim, door, black, lower
39 318264500 Handle, oven door, black
40 318242700 Bracket, glass holder, (2)
56 5304436875 Screw, 8-18 X 1/2, black
64 318165800 Spacer
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303211311 Screw, 8 x 0.500
* 5303323277 Screw, 8-18 X 13/32

Publication No: 5995471033 FEB27T6FCA
07/06 10
WIRING DIAGRAM
COLOR CODE/CODIGOS DE COLOR/CODE
DE COULEUR
G.-GREEN/VERDE/VERT
W.-WHITE/BLANCO/BLANC
R.-RED/ROJO/ROUGE
O.-ORANGE/NARANJA/ORANGE
Y.-YELLOW/AMARILLO/JAUNE
BR.-BROWN/MORENO/BRUN
BL.-BLUE/AZUL/BLEU
BK.-BLACK/NEGRO/NOIR
318046121 REV:B
CAUTION: DISCONNECT POWER BEFORE SERVICING UNIT.
ATENCION:CORTAR EL CORIENTE ANTES DE REALIZAR ELMANTENIMIENTO DEL ELECTRODOMESTICO.
ATTENTION:COUPEZ L`ALIMENTATION AVANT D`EFFECTUER LA REPARATION.
TERMINAL BLOCK
BLOQUE DE CONEXION
BLOC DE CONNECTION
L2
N
L1
BK-7
OR/O/OU
(BK-8)*
W-5
J3
ELECTRONIC OVEN CONTROL/CONTROL
DE HORNO ELECTRONICO/
COMMANDE FOUR ELECTRONIQUE
ES 610/615
DLB IN
DLB OUT
CONV.
BAKE
BROIL
J5
1
BROIL ELEMENT/
ELEMENTO DE
ASADO/ELEMENT
GRIL
BL-6 OR/O/OU (BL-8)*
BAKE ELEMENT/ELEMENTO
DE HORNO/ELEMENT
CUISSON
Y-6
Y-6
t
V-14
V-14
LATCH MOTOR/MOTOR DE
CERROJO/MOTEUR VERROU
BK-5
BR-5
DOOR SWITCH/INTERRUPTOR DE
PUERTA/INTERRUPTEUR DE PORTE
SW.A
SEE LEGEND/
VER LEYENDA/
VOIR LEGENDE
THERMAL CIRCUIT BREAKER
INTERRUPTOR DE CIRCUITO
TERMICO
DISJONCTEUR THERMIQUE
TEMPERATURE PROBE/
SONDA DETEMPERATURA/
SONDE THERMIQUE
BK-14
NO
W-5
BK-14
R/W-7 OR/O/OU (R/W-8)*
OVEN CIRCUIT // CIRCUITO DE HORNO // CIRCUIT DU FOUR
BR-5
COOLING FAN/VENTILADOR DE ENFRIAMIENTO/
VENTILATEUR REFROIDISSEMENT
BK-5
BK-5
R-5
W-5
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
W-5
HIGH SPEED/ALTA VELOCIDAD/HAUTE VITESSE
R-6
OR/O/OU
(R-7)*
CODE GAUGE TEMP. C CSA UL
CODIGO MEDIDA
CODE CALIBRE
1 18 125 CL1251 3173
2 16 125 CL1251 3173
3 14 125 CL1251 3173
4 12 125 CL1251 3173
5 18 150 EXL-150 3321
6 16 150 EXL-150 3321
7 14 150 EXL-150 3321
8 12 150 EXL-150 3321
9 10 150 EXL-150 3321
10 18 200 SEW-1 3122
11 16 200 SEW-1 3122
12 12 250 3252
13 16 250 3252
14 20 150 EXL-150 3321
15 8 150 EXL-150 3321
16 8 60
17 10 60
18 10 200 SEW-1 3122
19 20 125 CL1251 3173
20 20 200 SEW-1 3122
21 22 125 CL-1251 3173
22 22 150 EXL-150 3321
23 18 200 3573
12v 12v
120v
HALOGEN/HALOGENO/
HALOGENE
SW.A
SW.A
LATCH MOTOR
MOTOR DE CERROJO
MOTEUR VERROU
W-5
1
UPPER OVEN
J7
1J2
1
J6
1
1
J1
1
DLB IN
DLB OUT
CONV.
BAKE BROIL
L1L1
LOWER OVEN J4
P6
J3
1
1
J4
1
J5
1
P10
1
P8
1
J2
1
1
P1
1
P2
C
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
CONVECTION FAN/VENTILADOR DE CONVECCION/
CONVECTION VENTILATEUR
BK-5 BK-5
BK-14
BK-14
BK-14
t
V-14
TEMPERATURE PROBE/
SONDA DETEMPERATURA/
SONDE THERMIQUE
DOOR SWITCH/INTERRUPTOR DE
PUERTA/INTERRUPTEUR DE PORTE
SW.A
SEE LEGEND/
VER LEYENDA/
VOIR LEGENDE
BK-14
NO
BK-14
C
BK-14
BK-14
LATCH MOTOR/MOTOR DE
CERROJO/MOTEUR VERROU
BK-5
BR-5
BR-5
BK-5
BK-5
R-5
W-5
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
W-5
W-5
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
CONVECTION FAN/VENTILADOR DE CONVECCION/
CONVECTION VENTILATEUR
BK-5 BK-5
BROIL ELEMENT/
ELEMENTO DE
ASADO/ELEMENT
GRIL
BAKE ELEMENT/ELEMENTO
DE HORNO/ELEMENT
CUISSON
THERMAL CIRCUIT BREAKER/
INTERRUPTOR DE CIRCUITO
TERMICO/
DISJONCTEUR THERMIQUE
CONVECTION ELEMENT/
ELEMENTO DE CONVECCION/
ELEMENT CONVECTION
V-14
OPTION
OPCION
OPTION
OPTION
OPCION
OPTION
OPTION
OPCION
OPTION
UPPER OVEN/HORNO SUPERIOR/FOUR SUPERIEUR
LOWER OVEN /HORNO INFERIOR/FOUR INFERIEUR
EXAMPLE/EJEMPLO/EXAMPLE: (R-8)*
* WHEN USING 4000 W. BROIL ELEMENT
* CUANDO SE USA 4000 W. ELEMENTO DE ASADO
* QUAND UTILISE AVEC 4000 W. ELEMENT GRILLAGE
Y-6
BL-6 OR/O/OU (BL-8)*
BL-6
OR/O/OU
(BL-7)*
R-6
OR/O/OU
(R-7)*
LOW SPEED/BAJA VELOCIDAD/BASSE VITESSE
HIGH SPEED/ALTA VELOCIDAD/HAUTE VITESSE
LOW SPEED/BAJA VELOCIDAD/BASSE VITESSE
BK-14
R-7
OR/O/OU
(R-8)*
W-5
3
C
NO
BK-8
W-6
R-8
G-8
GND
BX
OUTSIDE
EXTERIOR
EXTERIEUR
INTSIDE
INTERIOR
INTERIEUR
AUX.
Y-6
BL-6
OR/O/OU
(BL-8)*
BK-5
OPTION
OPCION
OPTION
N
AUX.
RELAY
RELE
RELAIS
TMR
DLB OUT
REL
BD
THERMAL CIRCUIT BREAKER/
INTERRUPTOR DE CIRCUITO
TERMICO/
DISJONCTEUR THERMIQUE
LEGEND/LEYENDA/LEGENDE
CONVECTION ELEMENT/ELEMENTO DE
CONVECCION/ELEMENT CONVECTION
O-6 O-6
CONVECTION ELEMENT/
ELEMENTO DE CONVECCION/
ELEMENT CONVECTION
2500 W.
350 W.
O-6
O-6
SEE LEGEND
VER LEYENDA
VOIR LEGENDE
SEE LEGEND
VER LEYENDA
VOIR LEGENDE
REL BD
COOLING FAN/VENTILADOR DE ENFRIAMIENTO/
VENTILATEUR REFROIDISSEMENT
BK/W-5
BK-5 W-5
W-5
BK-5
LOW
OV
UPR
OV
L2
IN
R-6
OR/O/OU
(R-8)*
R-6
OR/O/OU
(R-8)*
R/W-5
BK-5
