Frigidaire FEB30S5D User manual

FEB30S5D.eps CFEB30S5DSA.eps BFEB30S5DSA.eps DFEB30S5DSA.eps
318046227.eps
"
Clea n
Keep
warm
Broil
Bake Clock
Controls
Clea r
/Off
Bake
tim e
Start
t
i
me
Oven
ligh t
Timer
On/Off
Se lf-C lea n in g O v e n
DoorLocked
Oven
Preheat
Product No. FEB30S5DBA FEB30S5DSA
38254331E4061 38254331E4011
Series 30" single 30" single
Color black white
Market North America North America
Wiring Diagram 318046227 318046227
Owner's Guide 318200924 318200924
Installation Instructions 316201514 316201514
Service Data Sheet 316047413 316047413
Timer Guide 318200189 318200189
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995418166
04/10/07
(EN/SERVICE/ECL)
377
SINGLE ELECTRIC
WALL OVEN
Model No.
FEB30S5D
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995418166 FEB30S5D
10/04 2
CONTROL PANEL

FEB30S5D Publication No: 5995418166
# Functional Parts 3 10/04
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AFEB30S5D (FEB30S5DSA)
BFEB30S5D (FEB30S5DBA)
POS. NO PART NO. DESCRIPTION
2A 318257300 A B Shield, oven top
2B 318260100 A B Cover, box
19 318274600 A - Control Panel Assembly, glass, white, w/ touch pad
19 318274601 - B Control Panel Assembly, glass, black, w/ touch pad
20 # 316418522 A B Clock/Timer, electronic, ES350W1
* 316021107 A B Screw, hex head, 8-32, silver
* 5303211311 A B Screw, 8 x 0.500

Publication No: 5995418166 FEB30S5D
10/04 4
BODY

FEB30S5D Publication No: 5995418166
# Functional Parts 5 10/04
* Non-Illustrated Parts
BODY
Model Index: AFEB30S5D (FEB30S5DSA)
BFEB30S5D (FEB30S5DBA)
POS. NO PART NO. DESCRIPTION
1 318259200 A B Back, main
2 318258900 A B Shield, insulation, upper
6 318262502 A B Rack, oven
9 5303317977 A B Pan, broiler
10 5303317976 A B Insert, broiler pan
12 # 318089917 A B Switch, light
* 3015722 A B Clip, wire retainer
14 318224000 A B Receptacle, oven light
14* 318268099 A B Insulation, oven light
15 5303013071 A B Bulb/Lamp, oven light
16 3201911 A B Cover, oven light, glass
17 5304400195 A B Retainer, light cover
29 318147411 A B Bumper, door, (2)
37 # 316217002 A B Probe, oven temp
41 5303310526 A B Cover, hinge cutout
54 318222400 A B Housing, oven light
56 318259902 A - Trim, side filler, white, RH
56 318259904 - B Trim, side filler, black, RH
56A 318259903 A - Trim, side filler, white, LH
56A 318259905 - B Trim, side filler, black, LH
58A 318133791 A B Insulation, oven wrapper, back/bottom
58B 318133790 A B Insulation, oven wrapper, top/sides
58D 318133793 A B Insulation, 1/2" thick, 43 x 9.5
59 318072560 A B Duct, oven vent
59A 318261600 A B Bracket, vent tube
62 316056000 A B Terminal Block
62* 5303323144 A B Nut, 10-32
66 # 318255600 A B Element, broil, 2750W
67 # 318255401 A B Element, bake, 3400W
68 5304403015 A B Support, element hanger
70 318259100 A B Shield, insulation, sides, (2)
71 318260004 A B Panel, rear box
76 318056217 A B Front, oven
80 5303320846 A B Plate, oven mtg
81 318192400 A B Spring, oven
82 318258700 A B Shield, insulation, lower
83 318261403 A B Liner, oven assy
86 5303310524 A B Receptacle, hinge
87 318260602 A B Bracket, cable mtg.
89# 318261200 A B Motor, latch assy
90 318259700 A - Trim, oven front, white, bottom
90 318259701 - B Trim, oven front, black, bottom
99 318256200 A B Bracket, side, bottom, (2)
108# 318073018 A B Motor, blower
* 08016432 A B Screw, truss head, 8-18 x 0.375
108A 318251300 A B Bracket, fan support
112# 318112701 A B Relay
119# 318004900 A B Switch, thermal
127 5303310542 A B Adapter, vent tube, with converter

Publication No: 5995418166 FEB30S5D
10/04 6
BODY

FEB30S5D Publication No: 5995418166
# Functional Parts 7 10/04
* Non-Illustrated Parts
BODY
Model Index: AFEB30S5D (FEB30S5DSA)
BFEB30S5D (FEB30S5DBA)
POS. NO PART NO. DESCRIPTION
131 318272900 A B Box, vent
132 318003000 A B Plate, shield
142 318123910 A B Deflector
* 5303324184 A B Screw, 8-18 x 5/16, black, (4)
143 318172904 A B Support, wire/glass
163 318014111 A B Spacer
185 318014700 A B Spacer, oven shield, (4)
219# 318003606 A B Thermostat, safety
219A 318003613 A B Thermostat, safety
264 318257701 A B Trim, oven, black, front
310 5304440067 A B Cabinet Mounting Kit
311 318246010 A B Bracket, cabinet mtg, (2)
311* 5304438005 A B Screw, 6 x 1, black
312 318246702 A B Tool, cabinet bracket, RH
312 318246703 A B Tool, cabinet bracket, LH
* # 318078542 A B Box & wires assy
* 318231719 A B Harness, wiring, main
* 3201861 A B Screw, 6 x 0.375, (4)
* 5303211311 A B Screw, 8 x 0.500
* 5303323136 A B Screw ground
* 5303323139 A B Screw, 10-24 x 0.906
* 5303323277 A B Screw (8-18X13/32)
* 5304436875 A B Screw, 8-18 X 1/2, black

Publication No: 5995418166 FEB30S5D
10/04 8
DOOR

FEB30S5D Publication No: 5995418166
# Functional Parts 9 10/04
* Non-Illustrated Parts
DOOR
Model Index: AFEB30S5D (FEB30S5DSA)
BFEB30S5D (FEB30S5DBA)
POS. NO PART NO. DESCRIPTION
3 318260201 A B Trim, oven door, black, upper
3A 318260401 A B Trim, oven door, side, (2)
4 318261301 A - Glass Assy., oven door, white, outer, w/ trim
4 318261300 - B Glass Assy., oven door, black, outer, w/ trim
6 318260500 A B Baffle, door
7 318133792 A B Insulation, oven door
7A 318133797 A B Insulation, oven door, cavity
8 316117500 A B Glass, oven door, heat barrier
9 318259601 A B Liner, oven door
10 5304416408 A B Screw, 10-24 x 1.750, handle mtg
12 318053120 A B Seal, oven door
17 316402403 A B Spacer, door glass, (2)
23 5303310828 A B Hinge, oven door, (2)
29 318014402 A B Spacer, door
39 316203001 A - Handle, door, white
39 318231200 - B Handle, black
40 318242700 A B Bracket, glass holder, (2)
56 5304436875 A B Screw, 8-18 X 1/2, black
64 318165800 A B Spacer, (4)
* 08016432 A B Screw, truss head, 8-18 x 0.375
* 5303211311 A B Screw, 8 x 0.500
* 5303300265 A B Screw, 8-18 x 0.500, chrome, (3)
* 5303323277 A B Screw (8-18X13/32)

Publication No: 5995418166 FEB30S5D
10/04 10
WIRING DIAGRAM
