Frigidaire FEB386CEBH Instruction Manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FEB386CESH 38254391F6018 WHITE U.S.A.
FEB386CEBH 38254391F6068 BLACK U.S.A.
ELECTRIC WALL OVEN
Model No.
FEB386CE
©1999 White Consolidated Industries,
Inc.
FACTORY PARTS CATALOG
ELECTRIC WALL OVEN
WIRING DIAGRAM # - 318046208
OWNER’S GUIDE # - 318200914
TIMER INSTRUCTION GUIDE # - 318130806
INSTALLATION INSTR. # - 318201507
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA, L5T 1K6
TEL: [phone] Publication No.
5995334538
000302
-EN/SERVICE
377

Publication No. FEB386CE
5995334538
02/99 2
CONTROL PANEL
80
LA00CP82391-2
19
42
20
23

FEB386CE Publication No.
5995334538
# = Functional Part 302/99
* = Non-Illustrated Part
CONTROL PANEL
POS. NO PART NO DESCRIPTION
19 318030115 APanel-control white
19 318030114 BPanel-control black
20 # 318010700 A B Clock/Timer
23 318111602 AB Bracket-timer
42 318027401 ATrim-vent white
42 318027409 BTrim-vent black
80 318111500 A B Relay
*3201861 A B Screw, 6 X 3/8
A = FEB386CE (FEB386CESH)
B = FEB386CE (FEB386CEBH)

FEB386CE Publication No.
5995334538
02/99 4
CAVITY / ELEMENTS
81
82
124
59
103
62
71
1
LA00B82391-2
6
6B
67
66 68
83
58B
58A
2A
88
62
89
108
119
10
9
127
37 12
129
128
70
185
99 98A
70
185
98
99
14
54
56
130
130
130
130
15 1617
80
80
150A
150
41
56
107
56
56
86
86
76
41
2
131
132
132A
102
102
177
188
188
6A
264
222

FEB386CE Publication No.
5995334538
# = Functional Part 502/99
* = Non-Illustrated Part
CAVITY / ELEMENTS
POS. NO PART NO DESCRIPTION
1 318066402 A B Back-main
2 318102101 A B Shield-oven top
2A 318071703 A B Shield-oven top
6 5303310522 A B Rack-oven
6A 5303311206 A B Rack broiler pan
6B 318025400 A B Shelf-oven
9 5303317977 A B Pan-broiler
10 5303317976 A B Insert-broiler pan
12# 318089910 A B Switch-light
14 5308011085 A B Socket-light/lamp
15 3201908 A B Lamp-oven light
16 3201911 A B Glass-oven light lens
17 5304400195 A B Retainer-lens
37 # 316111203 A B Probe-oven temp
41 5303310526 A B Cover-hinge cutout
54 5303310514 A B Housing-oven light
56 318083501 ATrim-bodyside white
56 318083500 BTrim-bodyside black
58A 5303310539 A B Insulation
58B 318132600 A B Insulation oven back
59 318072504 A B Tube-oven vent
62 # 5303310518 A B Terminal Block
66 # 5303310513 A B Element-broil
67 # 5303310512 A B Element-bake
68 5304403015 A B Support element
70 5303300142 A B Shield-insulation
71 318071201 A B Shield-wire
76 318056202 A B Front-oven
80 5303301261 A B Spring-oven
81 5303320846 A B Plate-oven mtg
82 318072302 A B Shield
83 318089609 AB Liner-oven assy
86 5303310524 A B Channel-hinge
88 5303311222 A B Rod-latch
89 # 318095921 A B Motor-latch
89* 318120710 A B Switch-latch
98 318029201 A B Trim-side RH
98A 318029203 A B Trim-side LH
99 318055420 A B Support-adjustable
102 318090900 A B Support fixation
103 318028501 ATrim-base white
103 318028500 BTrim-base black
107 318119600 A B Cover-fan
108# 318073001 A B Motor-fan
109 5303311203 A B Fan blade
111 5303311205 A B Nut-fan retainr
119# 318004900 A B Switch-thermal
124 318076903 A B Box-vent
125# 5303311202 A B Motor-convection
127 5303310542 A B Adapter assy
128 5303311163 A B Bushing
129 5303311164 A B Spring
130 318070801 AEnd Cap-trim white
130 318070800 BEnd Cap-trim black
131 318102301 A B Cover-control housing
132 318101700 A B End-cover RH
132A 318101701 A B End-cover LH
150 318072205 A B Bracket-support RH
150A 318072204 A B Bracket-support LH
177 318053800 A B Gasket-vent
185 318014700 A B Spacer-oven shield
188 08007817 A B Spacer
222 318080000 A B Plate hole convection element
263 5303320346 A B Washer
264 318143813 BHidden wires
* 5303211311 A B Screw #8 X ½
*3015722 A B Clip-wire
*318078511 A B Bx & wires Ay
*5303302745 A B Screw, 10-16 X 1/8 (black)
A = FEB386CE (FEB386CESH)
B = FEB386CE (FEB386CEBH)

Publication No. FEB386CE
5995334538 CAVITY/ELEMENTS
02/99 6
POS.NO PART NO DESCRIPTION
* 5303300265 A B Screw 8-18 X ½
*5303308449 A B Fastener
*5303323136 A B Screw ground
*5303323139 A B Screw, 10-24 X 29/32
*5303323277 A B Screw, 8-18 X 13/32
*5303324184 A B Screw, 8 X 5/16
*5303323137 A B Screw, 10-32 X 17/32
*# 318078511 A B Box & wires assy
*5303302745 A B Screw, 10-16 X 1 1/8
*5304407813 A B Washer
*3131048 A B Screw, 8 X 5/8
A = FEB386CE (FEB386CESH)
B = FEB386CE (FEB386CEBH)

FEB386CE Publication No.
5995334538
0299 7
DOOR
23
17
23
9
6
4
7
29
29
18
12
3
20
20
39
10
LA00D82391-2
16
16
31 22
22 15
61
54

FEB386CE Publication No.
5995334538
# = Functional Part 802/99
* = Non-Illustrated Part
DOOR
POS. NO PART NO DESCRIPTION
3 318026125 ATrim-oven door white
3 318026710 BTrim-oven door black
4 318041304 AGlass-oven door white
4 318041303 B Glass-oven door black
6 318056811 A B Baffle-door
7 318106001 A B Insulation
9 318048606 A B Liner-oven door
10 5303311217 A B Screw-handle10-24X2 3/16
12 318053103 A B Seal-oven door
15 318091102 A B Bracket glass
16 318041603 A B Glass-oven door
17 318042102 A B Spacer-glass
18 318053001 A B Seal-window
20 318014301 ASpacer-handle white
20 318014300 BSpacer-handle black
23 5303310506 A B Hinge-oven door
29 5303210003 A B Spacer-handle mtg
31 318065102 A B Latch-door
39 316091111 AHandle-door white
39 316091113 BHandle-door black
54 5303308456 A B Screw 8-18 X 0.531 black
61 5303316982 A B Tape seal
*5303323277 A B Screw, 8-18 X 13/32
*5303211311 A B Screw, 8 X ½
*5303300265 A B Screw, 8-18 X ½
A = FEB386CE (FEB386CESH)
B = FEB386CE (FEB386CEBH)

Publication No. FEB386CE
5995334538
02/99 9
WIRING DIAGRAM
8
