Frigidaire FGB24S5AS - 24 Inch Single Gas Wall Oven User manual

frigidaire.com
Drop-In Cooktop
FPEC3085K S 30" Electric
Signature Features
24" Gas
Single Wall Ovens
FGB24S5A S / B
Large Capacity
Our large capacity oven gives you room
to cook more at once.
Ready-Select™ Controls
Easily select options or control
cooking temperature with our
easy-to-use controls.
Product Dimensions
Height 38-7/16"
Width 23-7/8"
Depth 25-3/8"
More Easy-To-Use Features
Vari-Broil™ Option
Allows you to choose between two
heat levels.
Large Window
Our large oven window lets you easily
see what’s inside.
Bright Oven Lighting
Our bright lighting makes it easy to see
what’s inside.
Delay Clean
Delay Bake
Oven Lock-Out
Timer Function
Timed Cook Option
Timer Lock-Out
Auto Shut-O
As an extra safety measure, the oven
will automatically shut off after 12 hours.
Sabbath Mode (Star-K® Certified)
Available in:
Self-Cleaning
Ovens clean themselves — so you don’t
have to.
Store-More™
Storage Drawer
Our convenient drawer gives you extra
storage space in your kitchen.
White
(S)
Black
(B)

Accessories information available
on the web at frigidaire.com
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FGB24S5A 11/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Specifications
subject to change.
Single Wall Ovens
FGB24S5A S / B 24" Gas
Cutout Dimensions
Height (Min.)
Height (Max.)
Width (Min.)
Depth (Min.)
37-1/2"
39"
22"
23-1/2"
Product Dimensions
A - Height
B - Width
C - Depth
D - Height (Wrapper)
E - Width (Wrapper)
Depth with Door Open 90˚
38-7/16"
23-7/8"
25-3/8"
37-3/8"
21-11/16"
43"
Single Gas Wall Ovens
Frigidaire Baseline
E
D
Spacer
B
C
A
NOTE: For planning purposes only. Always consult local and national electric and gas codes. Refer
to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
1For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded for
safe operation.
Features
Oven Control / Timing System
Window
Exterior Door Finish
Handle Design
Oven Cleaning System
Drawer Functionality
Oven Controls
Bake / Broil
Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
PowerPlus™ / Quick Preheat
My Favorite
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Bake
Self-Clean
Rapid / Quick Clean Option
Delay Clean
Kitchen Timer
Timed Cook Option
Control Lock
Auto Oven Shuto
Oven Lock-Out
Oven Features
Capacity (Cu. Ft.)
Convection System
Oven Light
Hidden Bake Element
Rack Configuration
Baking System
Broiling System
Bake / Broil Element (BTU)
Certifications
A.D.A. Compliant
Sabbath Mode (Star-K® Certified)
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Gas Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 120 Volts1
Amps @ 120 Volts
Minimum Circuit Required (Amps)
Approved for Under-Counter
Installation
Shipping Weight (Approx.)
Ready-Select™
Large
Color-Coordinated
Color-Coordinated
Self Clean
Storage Drawer
Yes /
Variable (Hi - Lo)
Yes
Yes
Yes
Yes
Yes
Yes
12 Hours
2.9
1
2 Racks
Regular
Vari-Broil™
14,000 / 12,000
Yes
16" x 17" x 18-1/2"
Right Bottom Rear
Right Bottom Rear
120V / 60Hz
.001 /.001
5.0 / 5.0
15
200 Lbs.
