Frigidaire FGB24S5A User manual

FGB24S5A.eps LA00CP74431-2.eps LA00BR74431-1.eps LA00B74431-1.eps
LA00D74431-2.eps 318046316-1.eps 318046316-2.eps
Product No. FGB24S5ABC FGB24S5ASC
37454432F1063 37454432F1013
Series 24" gas 24" gas
Color black white
Market North America North America
Wiring Diagram 318046316 318046316
Owner's Guide 318200957 318200957
Installation Instructions 318201554 318201554
Service Data Sheet 318047410 318047410
Timer Guide 318200191 318200191
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995491304
07/05/22
(EN/SERVICE/BJH)
377
SINGLE GAS WALL
OVEN
Model No.
FGB24S5A
Copyright ©2007 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995491304 FGB24S5A
05/07 2
CONTROL PANEL

FGB24S5A Publication No: 5995491304
# Functional Parts 3 05/07
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AFGB24S5A (FGB24S5ABC)
BFGB24S5A (FGB24S5ASC)
POS. NO PART NO. DESCRIPTION
18 5303280338 A - End Cap, black, RH
18 5303310391 - B End Cap, white, RH
18A 5303280339 A - End Cap, black, LH
18A 5303310389 - B End Cap, white, LH
19 318234108 A - Panel, control, black
19 318234107 - B Panel, control, white
20 # 318185431 A - Clock/Timer, electronic, black
20 # 318185430 - B Clock/Timer, electronic, white
20* 316220805 A - Overlay, clock, black, ES300
20* 316220804 - B Overlay, clock, white, ES300
21 5303308451 A - Trim, splasher, black
21 5303308462 - B Trim, splasher, satin
23 318015034 A B Bracket, clock/timer
24 # 316005602 A - Switch, rocker, black
24 # 316005607 - B Switch, rocker, white
42 318027101 A - Trim, center vent, black
42 5303271089 - B Trim, center vent, white
53 318056901 A - Deflector trim, black
53 318056902 - B Deflector trim, black
99 5303311528 A B Screw, oval hd sq dr, 6-20AB x 0.625, black
100 318112200 A B Plate, mounting, rocker switch
* 08002868 A B Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box
* 5303323130 A B Screw, 8 x 1/4, (4)

Publication No: 5995491304 FGB24S5A
05/07 4
BURNER

FGB24S5A Publication No: 5995491304
# Functional Parts 5 05/07
* Non-Illustrated Parts
BURNER
Model Index: AFGB24S5A (FGB24S5ABC)
BFGB24S5A (FGB24S5ASC)
POS. NO PART NO. DESCRIPTION
9 3201885 A B Nut, Keps, 10-24
14 # 5303210167 A B Regulator, pressure
17 # 5303210798 A B Valve, safety
18 # 5303210787 A B Burner, oven
19 # 318177710 A B Ignitor, oven burner
20 3203676 A B Baffle, oven burner
22 5303271092 A B Tubing, valve
23 # 5303283132 A B Burner, broiler
24 # 5303210786 A B Mixer Elbow, bake
24A# 5303210807 A B Mixer Elbow, broiler
25 5303326220 A B Baffle, broil burner
26 # 316119302 A B Ignitor, broiler
28 # 5303295305 A B Valve, shut off
30 5303305657 A B Elbow, fitting
36 318177801 A B Tubing, safety valve, upper
58 318123600 A B Shield, broiler
* 5303311549 A B Screw, burner mtg
* 3051070 A B Screw, hex washer head, 10-24 x 0.438, special
* 08002868 A B Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box
* 5303311306 A B Screw, 8-18 x 0.375, (8)

Publication No: 5995491304 FGB24S5A
05/07 6
BODY

FGB24S5A Publication No: 5995491304
# Functional Parts 7 05/07
* Non-Illustrated Parts
BODY
Model Index: AFGB24S5A (FGB24S5ABC)
BFGB24S5A (FGB24S5ASC)
POS. NO PART NO. DESCRIPTION
2 318145003 A B Wrapper, base
2A 318102402 A B Cover, mid top
4 318161500 A B Box, oven burner
6 318345204 A B Rack, oven, (2)
8 318121400 A B Panel, oven bottom
9 5303317977 A B Pan, broilerOPTIONAL ACCESS0RY
10 5303317976 A B Insert, broiler panOPTIONAL ACCESS0RY
12 # 318089913 A B Switch, light
12* 5303271097 A B Bracket, light switch
14 318224000 A B Receptacle, oven light
15 5303013071 A B Bulb/Lamp, light
16 08011086 A B Lens, oven light, glass
17 5304400195 A B Retainer, light cover
25 318179000 A B Shield, insulation, base
33 318187301 A B Shield, housing
36 3203725 A B Flue
37 # 316217002 A B Probe, oven temp
39 318144007 A B Cord, service
41 5303310526 A B Cover, hinge cutout
54 318222400 A B Housing, oven light
55 5303326219 A B Shield, flue
56 318145508 A - Trim, bodyside
56 5303308459 - B Trim, bodyside
57 318071130 A B Shield, rear wall
58 318285010 A B Insulation, oven bottom
58A 318285011 A B Insulation, oven back
58B 318285015 A B Insulation, top & sides, oven wrapper
58C 318285090 A B Insulation, flue
58D 318285033 A B Insulation, 3"x4"x17", (2)
58E 318285034 A B Insulation, 1"x1.75"x18"
58F 318285067 A B Insulation, deflector
58G 318285035 A B Insulation, flue
70A 5303210843 A B Shield, insulation
72 318327900 A B Wrapper, shield
76 318056139 A B Front, oven
80 318192400 A B Spring, oven
81 5303323710 A B Bracket, oven
83 318089411 A B Liner, oven assy
86 5303310524 A B Receptacle, hinge
87 5303308443 A B Bracket, safety valve
88 5303311222 A B Rod, latch
* 5303311528 A B Screw, oval hd sq dr, 6-20AB x 0.625, black
89 # 318095953 A B Motor, latch assy, w/brkt & switch
89* 318120711 A B Switch
97 318066804 A B Wrapper, back & sides
98 318029400 A B Trim, side, inner, RH
98A 318029401 A B Trim, side, inner, LH
99 318284201 A B Panel, adjustable, side, (2)
100 5303302715 A B Shield, flue, bottom

Publication No: 5995491304 FGB24S5A
05/07 8
BODY

FGB24S5A Publication No: 5995491304
# Functional Parts 9 05/07
* Non-Illustrated Parts
BODY
Model Index: AFGB24S5A (FGB24S5ABC)
BFGB24S5A (FGB24S5ASC)
POS. NO PART NO. DESCRIPTION
102 3203688 A B Support, oven front
103 5303316735 A - Trim, base, black, lower
103 5303316734 - B Trim, base, white, lower
104 318170210 A B Flue
108# 318073025 A B Motor, blower
* 08016432 A B Screw, truss head, 8-18 x 0.375
117 5303302718 A B Bracket, thermo protect
119# 5303326252 A B Switch, thermal
121 318145005 A B Wrapper, base
122 5303210844 A B Shield, heat, lower
123 318071422 A B Shield, insulation, top & sides
128 5303311163 A B Bushing
129 5303311164 A B Spring
132 3201437 A B Strain relief
187 318013501 A B Tube, latch rod
227 5303323958 A B Retainer, oven bottom
234 5303210851 A B Shield, burner box
235 5303326207 A B Bracket
236 318108900 A B Shield, insulation, 1.25x1.0x12.9
239 5303326183 A B Angle, burner box
240 318119301 A B Shield, bodyside
* 318232523 A B Wiring Harness, main
* 318147411 A B Bumper, (2)
* # 318003606 A B Thermostat, safety, .945" mtg., 140/170
* # 318003613 A B Thermostat, safety, 1.375" mtg, 105/120
* 08002868 A B Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box
* 08011955 A B Screw, 10-24 x 0.375, square drive
* 5303211311 A B Screw, 8 x 0.500
* 5303300195 A B Screw, 10-32 x 0.375, terminal block, (2)
* 5303302745 A B Screw, 10-16x1-1/8, square drive
* 5303320422 A B Screw, 6-20 x 5/16, black, (6)
* 5303323130 A B Screw, 8 x 1/4, (4)
* 5303323277 A B Screw, 8-18 X 13/32

Publication No: 5995491304 FGB24S5A
05/07 10
DOOR/DRAWER
18
12
7
19
17
5
16
9
54
11
6
134
134
25
23
59
7
5
61
135
3
4
10
60
23
37A
37
LA00D74431-2
27
20
39
20
39
4
20
20

FGB24S5A Publication No: 5995491304
# Functional Parts 11 05/07
* Non-Illustrated Parts
DOOR/DRAWER
Model Index: AFGB24S5A (FGB24S5ABC)
BFGB24S5A (FGB24S5ASC)
POS. NO PART NO. DESCRIPTION
3 318026520 A B Trim, oven door, black
4 318051516 A - Glass, oven door, black, outer
4 318051515 - B Glass, oven door, white, outer
5 5303016336 A B Glass-oven door, heat barrier, lower oven
6 318073600 A B Shield, air wash
7 318285037 A B Insulation, oven door
9 318038600 A B Liner, oven door
10 5303311217 A B Screw, handle, door
11 318065102 A B Latch, door
12 318178801 A B Seal, oven door, upper oven
16 5303324250 A B Glass, door, 13 1/2 x 6 1/2
17 318139100 A B Spacer, glass, upper oven
18 318293510 A B Gasket, door glass seal
19 318139201 A B Collar, glass mtg
20 318014300 A - Spacer, handle, black, (2)
20 318014301 - B Spacer, handle, white, (2)
23 5303310506 A B Hinge, oven door, upper oven
23* 3201899 A B Washer, flat
25 318048309 A B Liner, oven door
27 318014403 A B Spacer, door
33 3203715 A - Glass-drawer, front
33 5303308464 - B Glass-drawer, front
34 318272801 A B Liner, drawer
35 5303326215 A B Drawer
36 318332200 A B Roller, nylon
37 3203722 A B Rail, drawer, RH
37A 3203723 A B Rail, drawer, LH
39 318362822 A - Handle Assembly, door, black, w/spacer
39 318362820 - B Handle Assembly, door, white, w/spacer
54 5304436875 A B Screw, 8-18 X 1/2, black
59 3202113 A B Plug, button
60 5303310510 A B Screw, 10-24 x 0.625
61 5303300414 A B Spacer, cork & rubber
134 318122101 A B Bracket, glass
135 3131903 A B Bumper, rubber
* 5303316982 A B Foam seal, (2)
* 3051070 A B Screw, hex washer head, 10-24 x 0.438, special
* 5303211311 A B Screw, 8 x 0.500
* 5303308458 A B Screw, 10-24, (4)
* 5303325981 A B Screw, 10-16 x 1 1/2

Publication No: 5995491304 FGB24S5A
05/07 12
WIRING DIAGRAM

FGB24S5A Publication No: 5995491304
# Functional Parts 13 05/07
* Non-Illustrated Parts
WIRING DIAGRAM
