Frigidaire FPEW3085KFA Control Instruction Manual

FPEW3085KF.tif CFPEW3085KFA.eps BFPEW3085KFA.eps DFPEW3085KFA.eps
318046266.eps
Product No. FPEW3085KFA
38257373C90S1
Series 30" single
Color stainless
Market North America
Wiring Diagram 318046266
Owner's Guide 318205305
Installation Instructions 318201532
Service Data Sheet 318047448
Timer Guide 318204125
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995539854
09/05/08
(EN/SERVICE/ECL)
377
30” SINGLE ELECTRIC
WALL OVEN
Model No.
FPEW3085KFA
Copyright ©2009 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995539854 FPEW3085KFA
05/09 2
CONTROL PANEL
2B 2A
19
CFPEW3085KFA
20

FPEW3085KFA Publication No: 5995539854
# Functional Parts 3 05/09
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
2A 318257300 Shield, oven top
2B 318260100 Cover, box
19 # 318575100 Panel Assembly, control, stainless, w/overlay-trim
20 # 316560148 Controller, electronic, ES530W3
20* 5303311306 Screw, 8-18 x 0.375, (6)
* 5304436875 Screw, 8-18 X 1/2, black
* 5304454881 Screw, #8-18 x 3/8

Publication No: 5995539854 FPEW3085KFA
05/09 4
BODY
119
81
81
1
80
80
143
272
272
67
57
58
7
7
6B
6
161 111
111
109
109
21
21
20
125
125
107
82
58B
10
9
264
131
132
58D
59
133
2
89
108
108A
70
185
71
163
163
87
62
142
58A
99
37
66
68
76
29
29
127
90
BFPEW3085KFA
99
185
70
12
83
56A
56
86
86
6A
6C
18
14
15
16
17
18
14
15
16
17

FPEW3085KFA Publication No: 5995539854
# Functional Parts 5 05/09
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 318259224 Back, main
2 318258957 Shield, insulation, upper
6 318922301 Rack, oven
6A 318926803 Rack, half, oven
6B 318919801 Rack, oven
6C 318929702 Insert, half rack
7 318368300 Pin, locking, (2)
9 5303317977 Pan, broilerOPTIONAL ACCESS0RY
10 5303317976 Insert, broiler panOPTIONAL ACCESS0RY
12 316445501 Switch, oven light, door frame
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
18 318222400 Housing, oven light
18* 318368500 Seal, housing, flat washer, lower oven
20 318389400 Plate, retainer
21 318389000 Seal, ring
29 316517600 Spacer, oven door
37 # 316217002 Probe, oven temp
56 318903704 Trim, side, black, RH
56A 318903705 Trim, side, black, LH
57 318361610 Panel, service
58 318330501 Insulation, service panel, 12.47 x 14.77
58A 318536600 Insulation, wrapper, top and sides
58B 318926906 Insulation, wrapper, back and bottom
58D 318372006 Insulation, 1/2" thick, 43 x 9.5
59 318072577 Duct, oven vent
62 316056000 Terminal Block
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
66 # 318255800 Element, broil, 4000W
67 # 318601601 Element, hidden bake, upper oven
* # 318231870 Wiring Harness, bake element
* 5303323130 Screw, 8 x 1/4, (5)
68 5304403015 Support, hanger, (4), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260007 Panel, rear box
76 318056292 Front, oven
80 5303320846 Plate, oven mtg
* 5304400794 Screw, handle mtg, 10-32 x 3/4
81 318192400 Spring, oven
* 5303323129 Screw, 8 X 0.750
82 318258730 Shield, insulation, lower
83 318261438 Liner, oven assy
86 318561100 Receptacle, hinge, (2)
86* 5304461333 Screw, 10-32 x 17/32
87 318260600 Bracket, cable mtg.
* 5303323136 Screw ground
89 # 318261215 Motor, latch assy

Publication No: 5995539854 FPEW3085KFA
05/09 6
BODY
119
81
81
1
80
80
143
272
272
67
57
58
7
7
6B
6
161 111
111
109
109
21
21
20
125
125
107
82
58B
10
9
264
131
132
58D
59
133
2
89
108
108A
70
185
71
163
163
87
62
142
58A
99
37
66
68
76
29
29
127
90
BFPEW3085KFA
99
185
70
12
83
56A
56
86
86
6A
6C
18
14
15
16
17
18
14
15
16
17

FPEW3085KFA Publication No: 5995539854
# Functional Parts 7 05/09
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
* # 318370303 Wiring Harness, latch
90 318259828 Trim, base, stainless
99 318256201 Bracket, side, bottom, (2)
107 318550200 Cover, fan, dual
108# 318073028 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
109 318398300 Fan Blade
111 318399800 Nut, fan retainer
119# 318004902 Switch, thermal
125# 318398200 Motor, fan
125* 318142100 Washer, motor, convection
127 318357001 Adapter Assembly, w/vent tube, and catalyst
131 318272901 Box, vent
132 318003000 Plate, shield
* 5304436875 Screw, 8-18 X 1/2, black
133 318347800 Chimney
142 318123910 Deflector
143 318172904 Support, wire
161# 318535300 Element, convection, duo
163 318531703 Spacer, (4)
185 318531800 Spacer, oven shield, (2)
264 318257723 Trim, oven, black, front
272 318249409 Tube, protector
* # 318394441 Box & wires assy
* # 318532183 Harness, wiring, main
* 318165800 Spacer
* 5303211311 Screw, 8 x 0.500
* 5303300265 Screw, 8-18 X 1/2, (4)
* 5303323277 Screw, 8-18 X 13/32
* 5303324184 Screw, 8-18 x 5/16, black, (4)
* 5304415832 Screw, 8-18 x 0.406
* 5304470882 Screw, anti-tip, 8 - 5/8, black, (2)

Publication No: 5995539854 FPEW3085KFA
05/09 8
DOOR
4142
56
56
56
56
3A
3A
13
6
3B
3B
7
7
7A
7A
9
64
12
17
17
23
23
40
40
64
8
8
16
DFPEW3085KFA
56
10
10
39

FPEW3085KFA Publication No: 5995539854
# Functional Parts 9 05/09
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
3A 318260401 Trim, oven door, side, (2)
3B 318262101 Cover, rear door, black, (2)
6 318260522 Baffle, door
7 318372000 Insulation, door, (2)
7A 318372002 Insulation, door, (2)
8 316117500 Glass, oven door, heat barrier
9 318360108 Liner, oven door, upper
10 5304472906 Screw, handle mtg, #10-24 x 1.5, (2)
12 318053121 Seal, oven door, upper
13 318927800 Door Assembly, outer, steel/glass, stainless/black, w/badge
16 318212210 Glass, oven door, heat barrier, lower door
17 318264710 Spacer, glass, lower, (2)
23 318567100 Hinge, upper, oven door, (2)
* 5304461333 Screw, 10-32 x 17/32
39 316551500 Handle, door, stainless
40 318242702 Bracket, glass holder, door, (2)
41 318370600 Bracket, glass retainer, (2)
42 318382301 Bracket, glass retainer, (4)
56 5304436875 Screw, 8-18 X 1/2, black
64 318165800 Spacer
* 5303300265 Screw, 8-18 X 1/2, (4)

Publication No: 5995539854 FPEW3085KFA
05/09 10
WIRING DIAGRAM
